CHAPTER 1: QUICK START
1.1 The Quickest Start Possible
Your miniPAR Logger has arrived completely ready to go. It is set to measure and record PAR,
temperature, time, battery voltage, and XYZ acceleration, once every 10 minutes and write one file
of measurements daily. Open the miniPAR Logger and move the Logger Control Switch to the
“Record” position. In this condition, the miniPAR Logger will record measurements for a year before
the internal batteries are expended. You must re-close the miniPAR Logger prior to deploying it. Be
sure to make sure the o-ring seal is free of debris before installing the outer case.
At the end of the deployment period, open the miniPAR Logger and connect it to a HOST computer
via the USB connection. The miniPAR Logger will appear as a ‘thumb drive’. Your temperature, XYZ
acceleration, and PAR measurements, together with a time stamp indicating the time the
measurements were made, are recorded in text files in the folder having the serial number of your
miniPAR Logger. These files can be copied onto any Windows or Mac HOST computer.
This Manual, and other software programs, are also recorded on the miniPAR Logger.
•MINIPARCONTROL PROGRAM:Allows you to see the state of the miniPAR Logger as well as
set the recording interval.
•MINIPAR PLOT PROGRAM:Allows you to see the plots of the recorded measurements.
•MINIPAR CONCATENATE PROGRAM:Gathers all the daily files into one CSV (comma-
separated values) CAT.txt file.
Your miniPAR Logger will return to recording measurements after you disconnect the USB
connection. If you wish to stop recording, then move the Logger Control Switch to the “Halt” position.
You may move the Logger Control Switch at any time.
Follow these steps to start the deployment, logging PAR, T, and XYZ acceleration once every
10 minutes:
1. Open the miniPAR Logger by unscrewing the white pressure housing from the black end
cap. It opens like a flashlight. Remove the white pressure housing completely. Inside you will
see the circuit pictured below:

WWW.PME.COM
TECHNICAL SUPPORT: INF[email protected] | [phone]
PG. 7
THIS DOCUMENT IS PROPRIETARY AND CONFIDENTIAL. © 2021 PRECISION MEASUREMENT ENGINEERING, INC. ALL RIGHTS RESERVED.
2. Move the Logger Control Switch to the “Record” position. The LED will flash green 5 times.
The miniPAR Logger will now record a measurement of time, battery voltage, temperature,
PAR, and 3 axis acceleration every 10 minutes (or at some other interval you may have set
using the miniPARControl program). The logger will start recording measurements at the
start of the next minute.
3. Inspect the o-ring seal for debris.
4. Close the miniPAR Logger by screwing the white pressure housing back onto the black end
cap.
5. Deploy the miniPAR Logger.

WWW.PME.COM
TECHNICAL SUPPORT: INF[email protected] | [phone]
PG. 8
THIS DOCUMENT IS PROPRIETARY AND CONFIDENTIAL. © 2021 PRECISION MEASUREMENT ENGINEERING, INC. ALL RIGHTS RESERVED.
Follow these steps to end the deployment:
1. Recover the miniPAR Logger
2. Clean and dry all accessible surfaces. Be careful of the white “dot” on the PAR sensor.
3. Open the miniPAR Logger by unscrewing the white pressure housing from the black end
cap. Remove the white pressure housing completely, taking care that water does not drip
onto interior surfaces of circuits or other items inside the miniPAR Logger.
4. Connect to a Windows HOST computer via the USB connection. The miniPAR Logger will
appear as a ‘thumb drive’.
5. Copy the folder having the same serial number as the miniPAR Logger (example 7530-1234)
to the HOST computer.
6. (Suggested, but optional) Delete the measurement folder, but NOT the miniPARControl
program or the other .jar programs.
7. (Optional) Run the miniPARControl program to see the state of the miniPAR Logger such as
battery voltage or to select a different recording interval. miniPARControl will also update the
time if the logger has drifted in time.
8. (Optional) Run the miniPARPlot program to see a plot of measurements.
9. (Optional) Run the miniPARConcatenate program to gather all the daily files of
measurements into one CAT.txt file.
10. If no more recording is desired, move the Logger Control Switch to “Halt”, otherwise leave it
set to “Record” to continue recording measurements.
11. Disconnect the miniPAR Logger from the USB connection.
12. Inspect the o-ring seal for debris.
13. Close the miniPAR Logger by screwing the white pressure housing back onto the black end
cap.
Remove the batteries if storing the miniPAR Logger for extended periods.
1.2 A Few Details
The previous section gave instructions for sampling at10-minute intervals. However, there are a few
additional details that will enhance use of the miniPARLogger.
RECORDING INTERVAL
The miniPAR Logger measures and records time, battery voltage, temperature, PAR, and 3-axis
acceleration at equal time intervals. The default time interval is 10 minutes. However, it is also
possible to instruct the miniPAR Logger to record at different intervals. This is accomplished by

WWW.PME.COM
TECHNICAL SUPPORT: INF[email protected] | [phone]
PG. 9
THIS DOCUMENT IS PROPRIETARY AND CONFIDENTIAL. © 2021 PRECISION MEASUREMENT ENGINEERING, INC. ALL RIGHTS RESERVED.
running the miniPARControl.jar program supplied with the miniPAR Logger. Recording intervals
must be 1 or more minutes and must be less than or equal to 60 minutes. Intervals outside this
range will be rejected by the miniPARControl program. Contact PME for other recording intervals.
Please refer to Chapter 2 for instructions on operating the miniPARControl program.
AVERAGE
Beginning with operating system Rev 1.05 miniPAR Loggers implement averaging of the sensed
PAR. This averaging is implemented to reduce the noise that light flicker nearby the surface can
generate in the recorded measurements. Each recorded PAR value results from the average of 30
readings of PAR, taken over a 5 second period. This averaging consumes additional battery energy.
However, the 10-minute sampling interval for a year is still possible. The amount of averaging can be
changed. miniPAR Loggers that have operating systems prior to Rev 1.05 can be upgraded. Contact
PME.
TIME
All miniPAR Logger times are UTC (formerly known as Greenwich meantime (GMT)). The miniPAR
Logger internal clock will drift in the <10 ppm range (< about 30 seconds/month) so you should plan
to connect it occasionally to a HOST computer having an Internet connection. The miniPARControl
program will automatically set time based on an Internet time server.
Please refer to Chapter 2 for instructions on operating the miniPARControl program.
FILE INFORMATION
The miniPAR Logger software creates 1 file daily on the miniPAR Logger’s internal SD card. The
number of measurements in each file will depend upon the sample interval. Files are named by the
time of the first measurement within the file based on the miniPAR Logger’s internal clock and
expressed in YYYY-MM-DD HHMMSSZ.txt format. For example, a file having the first measurement
on September 9, 2014 at 17:39:00 UTC will be named
2014-09-09 173900Z.txt.
Files can be uploaded from the miniPAR Logger by connecting it to a HOST computer. Use the
HOST computer’s copy/paste functions to move the files from the miniPAR Logger to the HOST
computer. Each measurement within the files has a time stamp. The time stamp format is Unix
Epoch 1970, the number of seconds that have passed since the first moment of 1970. This may be
inconvenient in some cases. If so, then the miniPARConcatenate program not only concatenates all
the measurement files, but also adds more readable statements of the time stamp.
Please refer to Chapter 2 for instructions on operating the miniPARConcatenate program.
The miniPAR Logger requires time and battery energy to work through the file directory on the SD
card to allocate new file space. A few hundred files on the SD card is not a problem, but as the

WWW.PME.COM
TECHNICAL SUPPORT: INF[email protected] | [phone]
PG. 10
THIS DOCUMENT IS PROPRIETARY AND CONFIDENTIAL. © 2021 PRECISION MEASUREMENT ENGINEERING, INC. ALL RIGHTS RESERVED.
number of files grows large into the thousands the miniPAR Logger may suffer decreased battery life
or other performance problems. Please, at the earliest convenient time, copy the recorded files to a
HOST computer and delete them from the miniPAR Logger’s SD card. Also, do not use the miniPAR
Logger to store files unrelated to the miniPAR Logger’s operation.
CLEANING THE SENSOR
Contact Li-Cor for instructions for cleaning the PAR sensor. The white pressure housing and black
end cap can be gently scrubbed.
AA ALKALINE BATTERY LIFE
Alkaline batteries will perform slightly worse than lithium, especially at low temperatures. Alkaline
batteries are superior to lithium in one way; you can determine how much battery life remains by
measuring the battery terminal voltage. For short deployments of a month or two, then alkaline
batteries will provide adequate performance. For longer deployments, or for deployments in cold
environments, then substitute lithium batteries.
AA LITHIUM BATTERY LIFE
The miniPAR Logger consumes battery power mostly from the measurement of PAR and
temperature, but also a small amount from simply keeping track of time, writing files, sleeping, and
other activities. The following table shows the approximate endurance of the miniPAR Logger when
powered by the Energizer L91 AA lithium / ferrous disulfide batteries:
Sample Interval (Minutes)
Main AA Battery life (Months)
Number of Samples
1
1
50K (approx.)
10
>12
50K (approx.)
60
>12
25K (approx.)
Keep a general record of the miniPAR Logger’s number of samples. It is not possible to accurately
tell the charge state of a lithium battery by measuring its terminal voltage. If you have a general idea
of the number of samples already obtained on a battery, then you can make an educated guess as
to how many more samples remain.
The numbers in the table above are, at the time of this writing, based upon extrapolations of testing
current demanded from batteries. The 1-month performance at 1 minute is very likely. Performance
at longer sample intervals will be much longer, but how long is difficult to predict. In any event, these
AA batteries are easily available and relatively inexpensive compared to the cost of the miniPAR
Logger. PME suggests you replace the batteries often, especially before any long (months)
measurement deployments.

WWW.PME.COM
TECHNICAL SUPPORT: INF[email protected] | [phone]
PG. 11
THIS DOCUMENT IS PROPRIETARY AND CONFIDENTIAL. © 2021 PRECISION MEASUREMENT ENGINEERING, INC. ALL RIGHTS RESERVED.
Monitor battery terminal voltage. You cannot tell from terminal voltage of a lithium battery how long
the battery will last, but you can tell if it will die soon. The Low Drain Performance plot below gives
an estimate of terminal voltage for both lithium and alkaline batteries. Your measured voltage will be
2X what is shown below since there are two batteries in series within the miniPAR Logger. You can
operate batteries down to about 2.4 Volts (for two in series, 1.2 Volts on the graph below). Your
batteries are dead if the measurement of each battery adds to less than 2.4 Volts.
You may also use alkaline AA batteries such as Duracell Coppertop. They will not last nearly as
long, especially at low temperatures, but will likely be adequate for several weeks at the 10- minute
interval. Alkaline batteries may leak if severely discharged.
When replacing batteries use only fresh batteries. Do not mix battery types. If one battery differs in
type or charge level from the other and the miniPAR Logger runs them to full discharge, then one
battery may leak.
Err on the side of caution when planning your deployment.
The recommended battery is the Energizer L91 lithium battery. For more information, including the
performance at low temperatures, click this link: http://data.energizer.com/PDFs/l91.pdf
The figure below gives a general idea
of terminal voltage vs. lifetime. Service
life in hours is incorrect since miniPAR
Logger draws far less than 50 mA
continuously, but the general shape of
the voltage vs. time gives an estimate
of life remaining. This plot is taken
from the manufacturer’s specification.
The plot is for a single battery. Double
the voltages shown to give the
terminal voltage as measured in the
picture above. The miniPAR Logger
halts operation at a total of 2.4 Volts.
COIN CELL BATTERY LIFE
The miniPAR Logger uses a coin cell battery for backing up the clock when the AA batteries are
removed. This coin cell battery will supply many years of clock operation. Should the coin cell battery
discharge, then it must be replaced by PME. Contact PME
RECALIBRATION
The miniPAR Logger will maintain its calibration without the necessity of adjustment by the user. The
miniPAR Logger should be returned to PME for recalibration. We suggest that this be done yearly.
We do not calibrate the miniPAR ourselves; we disassemble it and send the PAR sensor to Li-Cor
for re-calibration. Follow Li-Cor’s suggestion on how often their sensors need to be calibrated.

WWW.PME.COM
TECHNICAL SUPPORT: INF[email protected] | [phone]
PG. 12
THIS DOCUMENT IS PROPRIETARY AND CONFIDENTIAL. © 2021 PRECISION MEASUREMENT ENGINEERING, INC. ALL RIGHTS RESERVED.
O-RING AND SEAL
When the miniPAR Logger is opened after deployment, a small number of water drops are deposited
on the inner surface of the o-ring. When the white pressure housing is screwed back onto the black
end cap, these drops can become trapped inside the miniPAR Logger. Be sure to carefully dry the o-
ring and adjacent surfaces (especially underneath) prior to closing the miniPAR Logger. Re-lubricate
the o-ring at this time.
LED INDICATIONS
The miniPAR Logger indicates its operation with its LED. The table below presents LED indications:
LED
Reason
1 Green Flash
Normal. Presented immediately after new batteries are installed. Indicates
that the CPU has started its program.
1 Green Flash
Occurs at the time of sampling for sample intervals of 1 minute or less.
5 Green Flashes
Normal. Indicates that miniPAR Logger is beginning to record
measurements. This indication appears in response to switching the Logger
Control Switch to “Record.”
5 Red Flashes
Normal. Indicates the miniPAR Logger is ending recording of
measurements. This indication appears in response to switching the Logger
Control Switch to “Halt.”
Continuously Green
Normal. Indicates the miniPAR Logger is connected to a HOST computer via
the USB connection.
Continuously Flashing Red
SD card write error. Try removing/reinstalling batteries. Contact PME.
VERIFYING CALIBRATION
Compare miniPAR recordings to a light standard if available. The sensor can be covered with
aluminum foil to get a zero point.
CLOSING AND OPENING
Close and open the miniPAR Logger like you would a flashlight; open by unscrewing the white
pressure housing from the black end cap. Close by screwing the white pressuring housing on to the
black end cap. When closing, do not tighten the white pressure housing. Just screw it on until it
makes contact with the black end cap. See Chapter 3 for more instructions.

WWW.PME.COM
TECHNICAL SUPPORT: INF[email protected] | [phone]
PG. 13
THIS DOCUMENT IS PROPRIETARY AND CONFIDENTIAL. © 2021 PRECISION MEASUREMENT ENGINEERING, INC. ALL RIGHTS RESERVED.
STORAGE WHEN NOT IN USE
Remove the batteries. Keep the black end covered with the cap supplied by PME. If the cap is lost,
then cover the black end cap with aluminum foil. There may be a calibration effect of ambient lighting
so attempt to keep ambient light from reaching the sensing foil as much as possible.
JAVA
miniPAR programs depend on Java and require Java 1.7 or higher. Update Java at
https://java.com/en/download/index.jsp
CHAPTER 2: SOFTWARE
2.1 Overview and Software Installation
The miniPAR Logger arrives with these files on the SD card:
•miniPARControl.jar program allows you to see the state of the miniPAR Logger as well as
set the recording interval.
•miniPARPlot.jar program allows you to see the plots of the recorded measurements.
•miniPARConcatenate.jar program gathers all the daily files into one CAT.txt file.
•Manual.pdf is the manual.
These files are located on the root directory of the miniPAR Logger.
PME suggests you leave these programs where they are on the miniPAR Logger, but you may copy
them to any folder on your HOST computer’s hard drive.
miniPARControl, miniPARPlot, and miniPARConcatenate programs are Java language programs
that require the HOST computer to have the Java Runtime Engine V1.7 (JRE) or later versions
installed. This engine is commonly required for Internet applications and will likely already be
installed on the HOST computer. You can test this by running the miniPARPlot program. If this
program displays its graphical user interface, then the JRE is installed. If not, then the JRE can be
downloaded via the Internet from http://www.java.com/en/download/windows_xpi.jsp
At this time, the miniPAR Logger is supported on the Windows operating systems but may also
operate on Macintosh and perhaps Linux.
2.2 miniPARControl
Begin program operation by clicking “miniPARControl.jar”. The program presents the screen shown
below:

WWW.PME.COM
TECHNICAL SUPPORT: INF[email protected] | [phone]
PG. 14
THIS DOCUMENT IS PROPRIETARY AND CONFIDENTIAL. © 2021 PRECISION MEASUREMENT ENGINEERING, INC. ALL RIGHTS RESERVED.
The miniPAR Logger must be connected to the HOST
computer via the USB connection. When correctly
connected, the miniPAR Logger’s LED will display a
constant green light.
Click the “Connect” button. The program will contact the
miniPAR Logger. If the connection is successful, then the
button will turn green and display “Connected”. The Serial
Number and other parameters will be filled in from the
information taken from the miniPAR Logger.
If the HOST computer is connected to the Internet, then
the current difference between an Internet server’s time
and the miniPAR Logger’s internal clock will be displayed.
If more than a week has passed since time was last set,
then the miniPAR Logger’s clock will be set and the
checkmark icon will appear. If the HOST computer is not connected to the Internet, then no time
services will occur.
The current miniPAR Logger’s sample interval will be displayed next to the “Set Sample Interval”
button.
To set the interval, enter an interval not less than 1 minute and not greater than 60 minutes. Click
the “Set Sample Interval” button. Shorter and faster intervals are available. Contact PME.
If this interval is acceptable, then the interval need not be set.
End the miniPARControl program by closing the window. Disconnect the miniPAR Logger’s USB
cable.
Upon disconnection of the USB cable, the miniPAR Logger will begin logging or remain halted as
indicated by the position of the Logger Control Switch.
2.3 miniPARPlot
Begin the program operation by clicking “miniPARPlot.jar”. The program presents the screen shown
below.
The miniPARPlot program plots the files recorded by the
miniPAR Logger. The program reads all the miniPAR
Logger files in a folder, except the CAT.txt file. Select the
folder that contains the files recorded by the miniPAR
Logger. If the miniPARPlot program is run directly from
the miniPAR Logger, then the program will suggest the
folder that is located on the miniPAR Logger’s SD card.
You may accept this by clicking “Plot”, or you may click “Select DATA Folder” to browse to your
HOST computer’s hard drive. If the number of measurements recorded is small, for example a few
thousand, these can conveniently be plotted directly from the miniPAR Logger’s storage. However, it

WWW.PME.COM
TECHNICAL SUPPORT: INF[email protected] | [phone]
PG. 15
THIS DOCUMENT IS PROPRIETARY AND CONFIDENTIAL. © 2021 PRECISION MEASUREMENT ENGINEERING, INC. ALL RIGHTS RESERVED.
is best to copy large measurement sets to the HOST computer and select them there. The file
access to the miniPAR Logger is slow. The miniPAR Logger’s measurement folders must NOT
contain any files besides those the miniPAR Logger recorded and the CAT.txt file.
Click “Plot” to begin plotting.
The program reads all the miniPAR Logger’s data files in the selected folder. It concatenates these
and presents the plot shown below.
You may zoom this plot by drawing a square from upper left to lower right (click and hold left mouse
button) that defines the zoom region. To zoom completely out, attempt to draw a square from lower
right to upper left. Right click on the plot for options such as copy and print. The plot can be scrolled
with the mouse while the Control key is held depressed. Copies of the plot can be obtained by right
clicking on the plot and selecting Copy from the pop-up menu.
Different DATA Folders can be selected during one session of the program. In this case, the
software produces multiple plots. Unfortunately, the plots are presented exactly on top of one other
so when a new plot appears it is not obvious that the old plot is still there. It is. Just move the new
plot to see previous plots.
The program can be re-run at any time. If an already processed DATA Folder is selected, then the
program simply reads the miniPAR Logger’s measurement files again.
End the miniPARPlot program by closing the window.
Special note: plotting of sample sets of more than 200K samples may consume all the memory
available to the JRE. The miniPARPlot program will present a partial plot and freeze in this case. A
simple solution is to separate the files into multiple folders and plot each folder individually. A special
miniPARPlot that sub-samples can be provided by PME. Please contact PME in this case.

WWW.PME.COM
TECHNICAL SUPPORT: INF[email protected] | [phone]
PG. 16
THIS DOCUMENT IS PROPRIETARY AND CONFIDENTIAL. © 2021 PRECISION MEASUREMENT ENGINEERING, INC. ALL RIGHTS RESERVED.
2.4 miniPARConcatenate
Begin the program operation by clicking “miniPARConcatenate.jar”. The program presents the
screen shown below.
The miniPARConcatenate program reads and
concatenates the files recorded by the miniPAR Logger.
This program produces a CAT.txt file in the same folder as
selected for the data. The CAT.txt file contains all the
original measurements and contains two additional
statements of time. CAT.txt is CSV (comma-separated
values) file and can easily be imported into Excel and other
database files.
Select the folder that contains the files recorded by the miniPAR Logger. If the miniPARPlot program
is run directly from the miniPAR Logger, the program will suggest the folder located on the miniPAR
Logger. You may accept this by clicking “Concatenate”, or you may click “Select DATA Folder” to
browse your HOST computer’s hard drive. If the number of measurements recorded is small, for
example a few thousand, then these can conveniently be plotted directly from the miniPAR Logger’s
storage. However, it is best to copy large measurement sets to the HOST computer and select them
there. The file access to the miniPAR Logger is slow.
The miniPAR Logger measurement folders must NOT contain any files besides those the miniPAR
Logger recorded and the CAT.txt file.
Click “Concatenate” to begin concatenating files and create the CAT.txt file.
The CAT.txt file will resemble the following:
End the miniPARConcatenate program by closing the window.

WWW.PME.COM
TECHNICAL SUPPORT: INF[email protected] | [phone]
PG. 17
THIS DOCUMENT IS PROPRIETARY AND CONFIDENTIAL. © 2021 PRECISION MEASUREMENT ENGINEERING, INC. ALL RIGHTS RESERVED.
CHAPTER 3: MINIPAR LOGGER
3.1 Overview
All miniPAR Logger measurements are saved in files on the SD card inside the miniPAR Logger.
The files are transferred to a HOST computer via a USB connection where the miniPAR Logger
appears as a “thumb drive”. Measurements may be plotted by the miniPARPlot program and files
concatenated by the miniPARConcatenate program. The miniPAR Logger itself is controlled by the
miniPARControl program. Customers are required to open the logger each time measurements are
transferred to the HOST computer. This chapter describes the miniPAR Logger’s internal features.
3.2 Opening and Closing the miniPAR Logger
The miniPAR Logger’s circuitry is contained in a waterproof housing that must be opened.
Unscrewing the white pressure housing from the black end cap opens the miniPAR Logger. This is
similar to opening a flashlight. Turn the white pressure housing counterclockwise relative to the black
end cap. Close the miniPAR Logger by reversing this procedure after being sure that the o-ring is
free from debris. If debris is found, then wipe it off with a clean, lint-free cloth. PME recommends
Kimtech Kimwipes for this application. Lubricate the o-ring occasionally with silicone oil intended for
buna-N o-ring material.
When closing the miniPAR Logger, inspect the o-ring and the interior of the white pressure housing
for debris. Lubricate the o-ring, and screw the white pressure housing onto the black end cap until
the white pressure housing just touches the black end cap. Do not tighten! The miniPAR Logger
tends to get a little tighter during deployment.
If you cannot open the miniPAR Logger by yourself, then find another person with strong hands. This
person should grip the black end cap while the other person turns the white pressure housing.
3.3 Electrical Connections and Controls
Removal of the cover reveals the miniPAR Logger’s
connections and controls, shown here.
The LED Light is a LED that can display either red or
green light. This is used to indicate the different features
described in Chapter 1 of this manual.
The Logger Control Switch controls the miniPAR
Logger’s mode:
•RECORD:When the switch is in this position the
miniPAR Logger is recording measurements.
•HALT:When the switch is in this position the miniPAR
Logger is not recording and is sleeping at low power.

WWW.PME.COM
TECHNICAL SUPPORT: INF[email protected] | [phone]
PG. 18
THIS DOCUMENT IS PROPRIETARY AND CONFIDENTIAL. © 2021 PRECISION MEASUREMENT ENGINEERING, INC. ALL RIGHTS RESERVED.
The USB Connection allows communication between the miniPAR Logger and an external HOST
computer. When connected, the miniPAR Logger is in HALT mode regardless of the Logger Control
Switch position. When disconnected, the miniPAR Logger’s mode is controlled by the Logger Control
Switch position. The switch position may be changed while the USB is connected.
The Main Batteries (2 X AA on side opposite to pictured side above) provide main power to the
miniPAR Logger. Note the positive (+) terminal. Batteries are described in Chapter 1 of this manual.
3.4 Battery Replacement
Be sure that the replacement batteries are compatible with the miniPAR Logger. PME recommends
Energizer L91 AA size lithium batteries or Duracell AA size alkaline batteries.
http://data.energizer.com/PDFs/l91.pdf
http://ww2.duracell.com/media/en-
US/pdf/gtcl/Product_Data_Sheet/NA_DATASHEETS/MN1500_US_CT.pdf
Caution: Improper replacement of the batteries will damage the miniPAR Logger.
Follow these steps:
1. Move the miniPAR Logger’s Control Switch to the “Halt” position.
2. Remove the depleted batteries noting the position of the (+) terminal.
3. Switch minPAR to RECORD, then back to HALT. Wait 1 minute.
4. Use only new, fully charged batteries, both of the same type.
5. Install fresh batteries with the (+) position the same as the removed batteries. The (+)
position is also marked on the inside of the battery holder.
6. The miniPAR Logger’s LED Light should flash to indicate that the software is beginning
operation within a second or two after you complete the battery installation. At this time the
logger will enter the mode selected by the Logger Control Switch (which should initially be
“Halt” from Step 1).
Please be aware that the warranty will become void if the batteries are installed backwards.
Enjoy your new miniPAR!
