PMI SWH3000 User manual

WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING.
SWH3000 12152014 Page 1
SLIM WALL
OWNER’S GUIDE
USE AND CARE MANUAL
MODEL SWH3000
For Customer Assistance
CALL 1-800-325-6952
• Read all instructions carefully before installation
• This cooler must be connected to 120Volt AC, 60 Hz (cycle)
power only. NOTE: Improper voltage will void the pump
and/or motor warranties and may cause serious personal
injury or property damage.
• This cooler must be plugged into a GFCI protected
receptacle, which has been properly installed in accordance
with all local and national codes. If you are not sure that
the receptacle is GFCI protected, consult with a qualied
electrician.
• This cooler is equipped with a power cord having an
equipment grounding conductor and grounding plug. Do
NOT attempt to defeat this safety device by removing the
grounding pin.
• Do NOT step on or roll over power cord with heavy or sharp
objects. Do NOT operate if plug or cord is damaged in
any way. If the unit is damaged or malfunctions, do NOT
continue to operate.
• Remove the plug from the electrical receptacle by pulling on
the plug and not the cord.
• Always disconnect electrical power to unit before
attempting to work on or service your cooler.
• Do NOT operate near open containers of ammable liquid
or gases.
• Do NOT operate with evaporative pad(s) removed.
• Use of extension cords is NOT recommended.
Congratulations: You have purchased a product of superior
performance and design, which will give the best service
when properly operated and maintained.
This guide was designed to provide you with the
information needed to install, operate, inspect, maintain and
troubleshoot your Slim Wall evaporative cooler.
The rst section, Installation and Start-Up, gives details for
installation. The second section, Maintenance, contains
operational and maintenance instructions to aid in keeping
your unit in good working order, while Troubleshooting
includes information to help diagnose and repair commonly
encountered problems.
• Do NOT operate this cooler (fan motor) with any solid-state
speed control device.
• Do NOT operate with back panel or outlet grille removed.
Do NOT place ngers or any other objects inside the blower
section. Serious risk of personal injury or property damage
can occur.
• NEVER wash your cooler cabinet with a garden hose. Water
may harm motor and pump.
• Do NOT locate or operate cooler near exhaust or vent pipes
as odor or fumes may be drawn into unit.
• Your warranty does NOT cover shipping damage. Report all
shipping damage at once to store making delivery.
• For future reference, record the serial number and purchase
date of your evaporative cooler here:
Serial #
Purchase Date:
Place of Purchase:
IMPORTANT: Read the complete installation instructions
before proceeding with installation.
WARNING: THE USE OF ANODE DEVICES,
CHEMICAL ADDITIVES, OR COOLER CLEANER
TREATMENTS IN THIS COOLER WILL VOID
WARRANTY.
1-999-2490

Page 2
INTRODUCTION
Your Slim Wall evaporative air cooler was thoroughly tested
and inspected before leaving the factory. This manual is
your guide to proper installation procedures along with
information about reasonable care and maintenance that will
ensure safe, economical and trouble free cooling. Failure to
follow these instructions may damage your cooler, impair
its operation, create the potential for serious personal injury
and/or void the warranty.
Read it carefully.
A Note About Air Exhausting/Maximum Cooling
Since coolers function best when there are plenty of
openings for the air to exhaust, you can leave doors or
windows open so your house can breathe. To get the
maximum capacity of your cooler, and to help keep insects,
dust, dirt, etc. out of the cooled space, the house should
maintain a slightly positive air pressure (there should be
slightly more air going into the house than is leaving). This is
controlled by how much the windows or doors are opened.
How much should you open your windows or doors? You
should adjust your openings until the air pressure inside
the house is nearly balanced with the air outside. A good
method to determine when the air is reasonably balanced is
to place a tissue paper against the screen in the window or
door farthest from the cooler and adjust the other openings
in the house until the tissue paper stays lightly on the
screen. You can adjust different windows in the house to
direct the most airow to the areas that are occupied during
different parts of the day or night (example: living room
windows during the day and bedroom windows at night.)
Carefully read the contents of the manual and review the
drawings of the cooler to familiarize yourself with the
various parts before beginning the installation process.
Do NOT attempt to perform any part of the installation
described in this owner's manual unless you are fully
qualied to do so.
CAUTION: Disconnect all electrical power to the
cooler before attempting to install, open or service your
cooler.
Even while routinely inspecting or servicing the inside, the
cooler can be accidentally started. Keep people and pets
away from the cooler and electrical supply when you are
working on it. Before opening, servicing or cleaning the unit,
unplug the unit from the wall receptacle and take steps to
ensure that the cord cannot be plugged back in and the
cooler turned on accidentally. Do not plug power cable into
receptacle until installation or service work is complete.
Before attempting to install the cooler, conrm that the
following preparations have been made:
• This cooler must be plugged into a 120 volt GFCI (Ground
Fault Circuit Interrupter) protected receptacle. If you are
not sure that the receptacle is GFCI protected, consult
INSTALLATION
• Install cooler where only fresh outside air can enter.
Avoid installing the cooler in an area where the free
air movement around and into the cooler is restricted
or locations where obnoxious odors or fumes may be
drawn into cooler from vent pipes, kitchen exhausts, etc.
• Proper installation requires a wall with a thickness
between 6" and 8-½". If the wall is thinner than this a
spacer can be installed on the outside of the wall to
properly space the unit.
• It is extremely important to create a watertight seal
between the outside wall and the duct passing through
the wall.
INSTALLATION
THROUGH THE WALL
REQUIRED TOOLS:
• Drill
• Stud nder
• ¼" nut driver
• 1/2"& 7/16" inch socket
• Ratchet
• Level & measuring tape
• Drywall saw
• Stucco/Siding Cutting blade and saw
Fig. 1 - Inside of Cooler
(back panel removed)
located within 5 feet of planned installation location (cooler
power cord is 6 ft long, use of extension cords is not
recommended).
CAUTION: When cutting or drilling into the wall,
do NOT damage electrical wiring or other hidden
utilities (water or gas lines, sewer lines, etc.).
Installation work and electrical wiring must be done
in accordance with all applicable building codes and
standards, including re rated construction.

Page 3
INSTALLATION
1. Remove the outlet grill, spacing control plate
and back panel
A. Remove the six screws on the sides of the
screen (Fig. 2).
B. Remove the four screws attaching the spacing
control plates (Fig. 3).
C. Keep all screws as they will be reused during
installation.
D. Remove back panel (Fig. 4).
Fig. 2 - Output Grille Removal
Fig. 3 - Spacing Control Plate Removal
A
B
Fig. 4 - Back Panel Removal
C
1st - Lift
panel up
2. Locate wall studs
NOTE: This cooler is intended to be installed between
studs that are either 16" on center or 24" on center.
The unit cannot be installed between studs that are
less than 16" on center. If studs are less than 16" on
center a different installation location must be chosen
or structural changes must be made. Consult a qualied
professional before making structural changes to the
wall.
CAUTION: When cutting or drilling into the wall,
do NOT damage electrical wiring or other hidden
utilities (water or gas lines, sewer lines, etc.).
3. Once you have selected the studs you intend to use,
mark the lines for the duct cutout.
Use a level and mark a horizontal line a minimum of
24" off the ground. Add a second horizontal line 14-¾"
above the rst line. Mark two vertical lines 13-½" apart
to form a rectangle that is centered between the studs
that were selected for installation.
4. Ensure that the lines are in the correct places and
then cut through the entire wall including the drywall.
5. Measure the thickness of the wall.
If the thickness is less than 6", a spacer will be required
as specied in step 6. If the thickness is greater than
6", skip step 6 and proceed to step 7.
1st - Lift
panel up
2nd - Pull
panel outward

Page 3
6. If a spacer is required, make one from wood that is a
minimum of 1-½" wide similar to what is shown (Fig.5).
Ensure the thickness of spacer combined with the wall
thickness will be between 6" and 8-½". Cut boards to
t around the duct cutout. Cut two 26" long boards to
make spacers for the mounting brackets. Space the
lower spacer so the center of the board is 17-¼" below
the bottom of the cutout. Ensure that the spacer is level
and that the fasteners used will not interfere with the
fasteners that will be used to connect the bracket to the
spacer. Place the top spacer so the center of the spacer
is 35" from the center of the lower board.
7. Attach the angle brackets to the studs. Place the lower
bracket ange up so that the top of the ange is 16-1/8"
below the bottom of the duct cutout. Ensure the bracket
is installed level and is centered in relation to the duct
cutout. Pre drill the holes and attach the brackets using
the included lag screws. Attach the top bracket with the
ange facing down at a vertical distance of 33" from the
ange of the bottom bracket. Ensure the bracket is level
and centered in relation to the duct cutout.
Fig. 5 - Spacer
Fig. 6 - Wall Mounting Brackets
8. Install unit
A. Ensure all cords are contained within the duct
extension so they do not get caught when the unit is
being installed.
B. Slide the cooler into place until the wall side of the
cooler is ush with the exterior wall or the spacer.
C. Use sealant around the unit to prevent rain, blowing
dust, insects etc. from entering the indoor space.
D. Bolt the cooler to the top mounting ange using the
supplied bolts, washers and nuts (Fig 7).
Bolts
Washers
Nuts
Fig. 7 - Mounting Bolts
35"
17-1/4"
14-3/4"
16-1/8"
13-1/2"
33"

Page 4
9. Adjust duct extension (Fig. 8)
A. Using a 7/16" socket and ratchet loosen, the four
screws until the ange that mates to the spacer
control plate extend beyond the interior wall.
B. Reinstall spacing control plates (Step 1B , Fig.3)
C. Using the 7/16" socket and ratchet tighten the four
screws until the spacing control plates are ush with
the interior wall
10. Gently pull the cords going into the cabinet to remove
any slack. Using the zip ties included in the parts bag,
secure the cords at the locations shown to make sure
all slack is out of the cabinet and the sections of the
cords in the duct will not interfere with the operation of
the blower wheel or the outlet louvers.
11. Use sealant around the duct extension to prevent rain,
blowing dust, insects, etc. from entering the indoor
space.
12. Reinstall the outlet grille using the six screws that
were removed in step 1. Ensure the power cord goes
through the cutout in the bottom of the outlet grille
(Fig. 9).
Fig. 9 - Power Cord Routing
Install overow drain bushings in bottom of cooler.
Slide rubber washer over drain bushing, push drain
bushing through bottom of cooler and tighten nut.
Screw plastic overow standpipe into the drain
bushing and tighten (hand-tight) to prevent leakage.
Where conditions allow for drainage, connect a drain
line (garden hose) to the right drain bushing and drain
in accordance with local codes.
DRAIN BUSHINGS
CAUTION: All plumbing installations must comply
with local building codes.
NOTE: coolers should not be connected to “soft” water
systems. Soft water will accelerate corrosion and
decrease the effective life of pads and cooler cabinet.
a. A water supply valve should be installed at a convenient
location to allow the water supply to be turned on and
off for servicing or winterizing. Minimum 1/4" diameter
tubing should be used to provide water to the cooler,
larger tubing should be used if the length is greater than
100 feet and reduced to 1/4" at the unit.
b. Install oat valve in location and orientation as shown.
c. Route water line up the left stand pipe as shown in
gure 10
d. Place compression nut and ferrule over end of tubing.
e. Connect 1/4" tubing from water supply to oat valve
f. Insert tube into oat valve and tighten to secure.
g. Adjust oat for a water level of 2 1/2".
WATER SUPPLY
Fig. 8
Cord securing locations
Fig. 10

To minimize scale build-up, use the
included bleed-off assembly. Remove
the cap from the bleed-off tee, insert
the black tubing and route it through
the right standpipe opening. To prevent
siphoning of the water, make sure that
the bleed-off tee is above the water
level.
BLEED-OFF
CAUTION:
• This cooler is designed for connection to 120 volt AC,
60 Hz (cycle) power only. NOTE: Improper voltage will
void the pump and/or motor warranties and may cause
serious personal injury or property damage.
• This cooler must be plugged into a GFCI protected
receptacle, which has been properly installed in
accordance with all local and national codes. If you are
not sure that the receptacle is GFCI protected, consult
with a qualied electrician.
• This cooler is equipped with a power cord having an
equipment grounding conductor and grounding plug.
Do NOT attempt to defeat this safety device by
removing the grounding pin.
Cooler checkout and rst time start-up
Congratulations once you install the outlet grille and back
panel your cooler is complete and ready for use. Please
proceed to Pre-startup inspection checklist before starting
unit for the rst time.
ELECTRIC POWER
Pre-start-up Inspection Checklist
• Cooler mounting is level
• Power supply cord is plugged into a GFCI protected
receptacle; cord is secure from accidental damage.
• Bleed-off is correctly installed and fully functional
• Water hose connected securely without leaks. Water
faucet or supply is turned on
• Float valve is correctly installed, adjusted for proper
water level and fully operational.
• Outlet grille and back panel correctly installed.
• Pump impeller turns freely. Remove impeller cover
(see “Cleaning Pump”) and check rotation.
• Blower wheel turns freely
GENERAL INSPECTION
Start-up Inspection Checklist
CAUTION: Never operate unit with outlet grille or
back panel removed. This will result in an overloaded
condition and may damage the fan motor. The motor
and pump have an internal automatic thermal overload
switch that will shut the motor and/or the pump off
if it overheats! The motor and/or pump can restart
automatically when they cool down.
Page 5
To verify and check out the cooler installation on initial
or annual start-up, the following procedure should be
followed.
• Open building exhaust/ relief vents (windows, doors,
etc.)
• Plug supply cord into receptacle.
• Push “COOL” switch to ON position (pump on).
• Verify that pump starts and pads are evenly wet.
• Switch “FAN” to “HIGH”, observe that the motor starts
and runs.
• Switch to “LOW”, observe that the motor changes to low
speed.
In case of trouble in any of these stages, refer to the
Troubleshooting chart on page 8.
After initial start-up and during periodic inspections,
check for and/or observe the following: Refer to the
Troubleshooting Chart on page 8 if necessary.
• Leaks from cabinet.
• Observe cooler media for uneven wetting
• Conrm water level setting is correct.
• Verify full, even ow in water distribution system.
• Blower wheel rotates freely, no unusual noises.
• Check motor mounting, cabinet hardware and setscrews
on blower wheel are tight.
CABINET INSPECTION
CHECKLIST
Controls
Rocker-type control switches are used to select the
operating mode of the cooler. These switches control fan
speed (FAN-HIGH/OFF/LOW) and the pump operation
(COOL-ON/OFF). To eliminate a rush of warm air when
starting the cooler, be sure to turn the pump (COOL) on for
a few minutes before turning on the blower motor (FAN) in
low or high speed.
OPERATING INSTRUCTIONS
Regular maintenance and periodic inspection is a key to
long and successful service of your Slim Wall Cooler. The
cooler should be serviced at least once a year or more
often if required (dusty environment, constant use, poor
water quality, etc.). For maximum efciency, longer life
and appearance, every two months during operation, the
cooler should be inspected and cleaned.
Note: Do NOT undercoat the water reservoir
Your cooler's water reservoir is nished with our Peblar
XT® appliance-type nish. It is so hard that asphalt-type
cooler undercoating will not stick to it. Undercoating will
break free, clogging the pump and water distributor.
MAINTENANCE SCHEDULE

Page 6
NOTE: Do NOT use cooler cleaners, cooler treatments or
other chemical additives in this evaporative cooler. Use of
any additives or water treatment will void your warranty
and impair the life of the cooler.
Before starting any maintenance operation, read
thoroughly all operating and maintenance instructions and
observe all CAUTIONS and WARNINGS.
CAUTION: Never wash your cooler cabinet with
a garden hose; water may harm motor and pump.
Motors damaged by water are NOT covered under
warranty.
All foreign materials, scale, salt deposits, lime, etc. can
and should be removed from bottom pan and other
components. Your cooler's long lasting nish can be
brought to like-new condition by using warm water and a
soft cloth.
NOTE: Avoid using scouring pads, steel wool or wire
brushes, as these will damage the nish and encourage
CLEANING
CAUTION: Disconnect all electrical power to the
cooler by removing the plug from the receptacle before
attempting to install, open, or service your cooler.
IMPORTANT: Before operating cooler at beginning
of each cooling season, turn cooler motor and pump
motor shafts by hand to make sure they turn freely.
Failure to do so may result in burning out motor.
Periodic inspection of your cooler will enhance the chance
for long, trouble-free service life. For maximum efciency,
every two months during operation, or any time the
cooler is opened, the cooler should be inspected. Some
suggested items:
• Check for leaks
• Are there any dry spots on the media when cooler is in
operation?
• Are bolts, nuts and set screws snug?
• Are the bearings, etc. making unusual noises?
• Does the blower wheel turn freely?
• Is oat level set correctly?
• Is water in the bottom pan clean?
MAINTENANCE & INSPECTION
CAUTION: Do not allow pump to fall over and
become submerged; water will damage pump motor.
Clean water pump and hose assembly as follows:
1. Unplug power supply cord from wall receptacle, remove
pump mounting bracket screw and gently lift pump
from cooler. Shake gently to remove water.
2. To prevent breakage, carefully release the snap-out
impeller cover plate and remove cover plate from the
pump body.
3. Using a mild detergent solution and a soft cloth, clean
deposits from screen and around impeller to dislodge
any remaining foreign material.
4. Remove any foreign material in the hose adapter
(between the pump and hose), or between the hose and
water distributor assembly.
5. Rinse and reinstall impeller cover plate.
6. Reinstall pump and reconnect power cord.
CLEANING WATER PUMP
& HOSE
The hardness, adhesion and smoothness of the internal
and external nish on your cooler makes it extremely
unlikely that scratches or chipping will occur. In the event
that nish damage does occur, it
should be promptly repaired by the following procedures:
1. Sand the area around bare metal spots.
2. Prime and paint with a quality paint.
Do NOT use asphalt type cooler undercoat material in
water reservoir. Undercoat will break free, clogging the
pump and water distributor.
TOUCH-UP
Blower Motor and Pump Motor Bearings
The blower and pump motor bearings do not require
lubrication.
Cleaning or Replacing Media Pads
CAUTION: Disconnect all electrical power to the
cooler before attempting to install, open, or service
your cooler.
The condition of your cooler pads should be checked
at least once a year; at the beginning of the season is
best. However, your pads may need to be checked more
frequently, depending on local air and water conditions.
For instance, in areas where mineral content of the water
is high or the air is dusty, deposits may build up in the
cooler pads, restricting airow.
LUBRICATION

Page 7
Clean or replace pads as follows:
1. Disconnect power from unit.
2. Remove pads from cabinet as follows:
a. Remove back panel from cabinet.
b. Remove pads by sliding the pad straight backwards.
3. If passages are clogged or pad is dirty, hose off inlet
face of pad. Light, gentle brushing of the inlet edges
of the pad with a stiff bristle brush (do not use a wire
brush) will not harm the pad and will remove more
stubborn scaling.
4. If necessary, replace with new rigid media pads,
available only from your rigid media dealer. Aspen,
expanded paper or other types of evaporative cooling
pads will not work and will void your warranty.
5. Using a mild detergent, wash dirt and scale from the
inside of the wet section cabinet. Wire brushing is not
recommended. If nish is damaged or rusting is noted,
repair as noted in the “Touch-Up” section. Rinse with
fresh water.
6. Reinstall pads, making sure they are positioned
correctly
7. Reinstall back panel
Media Replacement
Wiring Diagram

TROUBLESHOOTING
The following guide is intended to help you diagnose and x some of the most commonly encountered problems; by no
means does this guide cover all of the possible problems you may encounter. If you cannot diagnose and correct the
problem, or if it persists, contact qualied service personnel. All electrical work should be done by, or with the help of, a
qualied electrician.
PROBLEM/SYMPTON POSSIBLE CAUSE CORRECTIVE ACTION
Water draining from unit 1. Float valve out of adjustment
2. Float movement obstructed
3. Float valve non-functional
1. Adjust oat to 2 1/2" water depth
2. Free oat from obstruction
3. Replace oat assembly
Dry media pads 1. Pads clogged (mineral accumulation)
2. Dry spots or streaks on media pad
3. Clogged water line
4. Pad trough clogged
5. Pump not working
6. Loose connections in water system
7. Water turned off to cooler
8. Pump basket/screen clogged
1. Clean or replace media pads
2. Check water distributor system
3. Locate and free obstruction
4. Clear debris from trough
5. Clean or replace pump
6. Check for leaks and correct
7. Turn on water supply
8. Clean basket / screen
Motor does not start or no
air delivery
1. Electrical power disconnected
2. Non-functional motor
3. Non-functional switch
1. Check power receptacle and cord
2. Replace motor
3. Replace switch
Inadequate air delivery 1. Insufcient air exhaust
2. Pads plugged
1. Open windows to increase air ow
2. Clean/Replace media pads
Motor cycles on & off 1. Low Voltage
2. Non-functional motor
1. Check voltage
2. Replace motor
Noisy operation 1. Blower rubbing on housing
2. Blower set screw loose
1. Reposition wheel
2. Tighten set screw
Excessive humidity inside Inadequate exhaust from building Open relief vents to increase exhaust
REPLACEMENT PARTS
When ordering replacement parts, always refer to the serial and model number of your cooler. Use the part numbers listed in
the accompanying parts list, as illustrated in the diagrams for your model.
Page 8
