PMI SVM-10 User manual

SVM-10 Manual
Stray Voltage Monitor Scanner
User’s Manual
Power Monitors Inc. 1-800-296-4120
1661 Virginia Avenue 540-434-4120
Harrisonburg, VA 22802 USA Fax: [phone]
http://www.powermonitors.com

SVM-10 Manual
©2002 Power Monitors Inc.
All Rights Reserved
Contents subject to change without notice.
This version: April 2002
Corrections or ideas for this manual please e-mail: [e-mail]

SVM-10 Manual
Foreword
We founded Power Monitors Inc. (PMI) to provide state-of-the art, easy-to-use, and
affordable electronic test equipment to the power industry. Our products have been
developed by working directly with electric utilities to determine their specific needs.
These products are designed for only one purpose: to collect and assist in the analysis of
field-recordable data for electric utilities.
The SVM-10™ was developed with your needs in mind. We created them to meet the
needs of a large utility, and based their unique capabilities on our years of experience
building versatile voltage recording and analysis equipment. Inside lightweight,
weatherproof, rugged enclosures, state-of-the-art electronics measure and record true
RMS voltage on four channel connections. The units require so little power; they operate
on the voltage from one line cord. There are no batteries to recharge prior to use. Each
unit has been individually calibrated to ensure high accuracy and stability over a wide
range of temperatures.
PMI scanners remain the only products on the market that will allow both electronic
“stripchart” recording and a number of specialized recording modes tailored to the
power industry. The specialized reports are merged with unique data collection
techniques to provide accurate information that is easy to understand. Features such as
min/max/Avg recording of voltage make PMI scanners the ideal products for
distribution monitoring.
The Scanner features:
True RMS voltage measurement on each of four channels
Programmable abnormal voltage recording
On-site, real-time display of voltage
Single-cycle response (16 msec)
More than 122,000 samples per second
0-10 volt RMS operating range
Up to 2,048K FLASH EPROM memory
Memory capacity for more than one year of summary data, 500 event
records, 500 records of significant change
Rugged, weatherproof enclosure NEMA 4X
All channels captured simultaneously in one cabinet

SVM-10 Manual
Scanner/WinScan™ graphs and reports include:
Stripchart and histogram analysis for RMS voltage report
Daily Profile
Significant change report
Waveforms (optional)
Because of these capabilities, the SVM-10™ Scanner is the perfect instruments for
analyzing and solving power quality and quantity problems. After looking through this
manual and using your Scanner, please contact us with any questions about its
operation, or with ideas for new features or products. We want you to be happy with this
product, and we always appreciate any input that helps us develop products to meet your
future needs.
Thank you,
Walter M. Curt
Owner, Power Monitors Inc.

SVM-10 Manual

SVM-10 Manual
Table of Contents
FOREWORD.............................................................................................3
SAFETY ISSUES......................................................................................9
GENERAL DESCRIPTION CHAPTER 1..............................................12
1.1 GENERAL......................................................................................12
1.1.1 Purpose.....................................................................................12
1.1.2 Manual Layout .........................................................................12
A. Chapters ....................................................................................12
B. Paragraphs.................................................................................13
1.2 SCANNER DESCRIPTION ..........................................................13
1.2.1 General .....................................................................................13
1.2.2 Inputs........................................................................................14
1.2.3 Instrument Size.........................................................................14
1.2.4 System Description...................................................................14
A. Screens and Displays .......................................................................14
B. Day-To-Day Use..............................................................................14
C. Configuration ............................................................................14
D. Applications......................................................................................15
E. System Technology ...................................................................15
1.2.5 Memory....................................................................................15
1.2.6 Clock ........................................................................................15
1.2.7 Scanner Construction ...............................................................15
1.2.8 Communications.......................................................................15
1.3 SUPPLIED EQUIPMENT .............................................................16
1.3.1 Equipment Listing ....................................................................16
1.4 ACCESSORIES .............................................................................16
1.4.1 General .....................................................................................16
1.4.4 Adapters ...................................................................................16
1.4.5 Cases.........................................................................................16
1.4.6 Spare Parts List ........................................................................16

SVM-10 Manual
1.5 SPECIFICATIONS ........................................................................17
1.5.1 General .....................................................................................17
Table 1-1 SVM-10™ Specifications........................................17
CONNECTION INFORMATION CHAPTER 2 ....................................20
2.1 INTRODUCTION..........................................................................20
2.1.1 General .....................................................................................20
2.1.2 Manual Updates........................................................................20
2.2 EQUIPMENT HANDLING...........................................................20
2.2.1 Initial Inspection.......................................................................20
2.2.2 Unpacking Procedure...............................................................20
A. Detected Damage......................................................................21
2.2.3 Equipment Return.....................................................................21
A. Return Authorization and Required Information......................21
2.2.4 Storage......................................................................................21
Table 2-1: Environmental Precautions.................................21
2.3 WIRING SPECIFICATIONS AND...............................................22
PROCEDURES....................................................................................22
2.3.1 Power Requirements ................................................................22
A. Scanner Operating Power Connection......................................22
B. Batteries and power...................................................................22
2.3.2 Installing the Scanner...............................................................22
A. The Line cord............................................................................23
C. The voltage leads.......................................................................23
Table 2-2: Voltage jack color coding...................................23
2.3.3 Communications Port Connections..........................................25
A. General..............................................................................................25
B. RS232 Serial Cable ...................................................................26
OPERATION CHAPTER 3.....................................................................27
3.1 INTRODUCTION..........................................................................27
3.1.1 General .....................................................................................27
3.2 CONTROL AND PRESENTATION.............................................27
3.2.1 General .....................................................................................27
3.2.2 Operator Controls.....................................................................27

SVM-10 Manual
A. LCD menus and keypad..................................................................27
1. Reading real-time data onthe LCD..............................28
2. Changing settings using the keypad..............................29
AN OUTLINE OF WINSCAN™ CHAPTER 4......................................31
4.1 RETRIEVING DATA FROM THE SCANNER ...........................31
APPENDIX 1: PC AND SCANNER CONFIGURATION FACTORY
SETTINGS...............................................................................................32
APPENDIX 2: WARRANTY CLAUSE .................................................34
APPENDIX 3: TROUBLESHOOTING..................................................35
APPENDIX 4: FORMULAS (NOT ALL ARE USED IN SVM-10)......36
INDEX.....................................................................................................41

SVM-10 Manual
This page Left Blank Intentionally

SVM-10 Manual
SAFETY ISSUES
Please read carefully before installing or using the Scanner.
 The Scanner contains dangerous voltage levels during operation. Do not disassemble
the Scanner. THE ONLY USER-SERVICEABLE PARTS INSIDE ARE THE
BATTERIES! Insure power is completely removed from the unit prior to changing
the batteries.
This device is manufactured for use by trained and qualified personnel only.
Do not install or operate while in contact with standing water or wet ground.
 Wear protective gloves and safety glasses at all times during the installation,
operation and removal of the Scanner.
 During installation, disconnect power from any lines to which the Scanner will be
attached.
 Although the Scanner has been designed and built to be as safe as possible, great
care should be exercised at all times during operation and installation.

SVM-10 Manual

SVM-10 Manual
General Description Chapter 1
1.1 GENERAL
1.1.1 Purpose
This manual is a user reference guide for the Series SVM-10™ Scanners (Figure 1-1).
The manual provides detailed instructions for connection, operation, programming, and
communications interface.
1.1.2 Manual Layout
The layout of this Manual is by Chapters and numbered Paragraphs.
A. Chapters
Chapters within this manual are arranged in the following order:
Chapter 1 - General Description
Chapter 2 - Connection Information
Chapter 3 - Operation
Chapter 4 - Configuration
Chapter 5 - Communications Interface Figure 1-1: SVM-10™ Scanner

SVM-10 Manual
B. Paragraphs
Paragraphs are numbered sequentially with the first number corresponding to the
Chapter number, the second number corresponding to the topic, and the third indicating
number paragraph within that topic. Alpha characters indicate subparagraphs of the
main paragraph.
1.2 SCANNER DESCRIPTION
1.2.1 General
The SVM-10 Scanner is easy-to-use, true RMS, micro-computer-based voltage
recording device that produce accurate readings and professional reports. These
scanners can help you resolve customer stray voltage complaints, conduct long-term
voltage surveys, and detect voltage variations as brief as one cycle. The Scanner will not
disrupt normal power supply; rather, it uses a minimal amount of voltage from one 120
vac outlet.
Each Scanner gathers and stores stripchart data, recording the average, minimum and
maximum readings for a selected interval with one-cycle resolution. Even events lasting
less than one cycle are revealed in WinScan™ reports if the Scanner is configured to
capture the information.
Installing the Scanner is relatively simple, although using the unit requires the same
attention to safety as working with any other high-voltage device. Once the unit has
been installed and the data you need have been recorded, the data can be downloaded
using either a modem (if your Scanner is so equipped) or serial cable. Real-time data can
be checked using the keypad and liquid crystal display (LCD) on the unit’s front. An
optional Palm®interface is also available for viewing real time data from the unit.
Please refer to the PalmView manual for further information.
You can then view and analyze the data using the WinScan™ software. With the
software you can create an array of graphs and reports, each of which provides you with
useful, clearly presented power data.

SVM-10 Manual
1.2.2 Inputs
Direct hookups are fed into 4 voltage, 0-10vac inputs. Four direct inputs are available to
be recorded and used with reports and strip charts. To record an input, the input must be
selected as a strip chart in WinScan™.
1.2.3 Instrument Size
The Scanner is contained in a standard 6.5 inch (165.1mm) wide x 6.5 inch (165.1mm)
high x 4.25 inch (107.95mm) deep NEMA 4x lockable case.
1.2.4 System Description
The Scanner is a system designed to measure and record AC Voltage parameters using
state of the art digital technology. Signal inputs from AC power connections are
monitored by the system. No pen, ink or paper are required; a graphics display shows
the information. The unit can also be used with PalmView software running on a
Palm® Personal Digital Assistant (PDA) for real time viewing of waveforms, harmonic
bar graphs, vectors, as well as numeric values.
A. Screens and Displays
Screen display styles are available to present data in a familiar format. User instruction
and data entry screens feature easy to use menus, with easy to understand terms.
Operating display screens show information in a logical and easy-to-read format.
B. Day-To-Day Use
Day-to-day operating measurements are stored and recalled instantly. Up to two MB of
standard internal memory allows data to be efficiently and economically stored and
retrieved.
C. Configuration
WinScan™ software allows the user to program the unit quickly and efficiently using an
IBM Windows based compatible PC.
Programming can also be done using PalmScan Software running on a Palm® PDA.
It’s graphical touch screen interface provides straight forward,
user friendly configuration. Strip charts, and Event parameters can be easily
programmed. Other parameters such as Scales, and engineering units are also easy to
program.

SVM-10 Manual
D. Applications
A Scanner may be configured by you to record and monitor almost any voltage
configuration. Typical measurement applications include, but are not limited to:
Voltage Levels
Harmonics to the 51st
E. System Technology
This Power Scanner is a state of the art system, designed around a microprocessor, with
an executable program stored in memory. The memory is used for data and setup
storage.
1.2.5 Memory
Electrically Erasable Programmable Read Only Memory (EEPROM) eliminates the need
for a battery back-up. Programming is stored in EEPROM. In the event of a power loss
or system reset, the programming will be protected.
1.2.6 Clock
The Time-of-Day clock will be maintained indefinitely after loss of line power by an
internal Lithium battery.
1.2.7 Scanner Construction
The Power Scanner features modular construction. All printed circuits boards are
conveniently accessible for fast and simple troubleshooting and/or removal via a lift-out
chassis. The lift-out chassis also facilitates easily changing the LCD. All viewing
controls and indicators are located on the front panel. Servicing should only be done by
an authorized service center of PMI. The PC boards are conformal coated and high
voltage is present, servicing by unauthorized personnel can result in product or bodily
damage.
1.2.8 Communications
The standard RS232 port allows you to
plug the Scanner into your computer
and download the data from memory.
An AC Adapter is also supplied that you can plug
into the 9 pin D shell that will power
the unit for programming or downloads.
This eliminates the need to have AC voltage
Figure 1-3: Serial Cable

SVM-10 Manual
supplied directly to the
voltage leads.
1.3 SUPPLIED EQUIPMENT
1.3.1 Equipment Listing
The following items are supplied with your Scanner:
the SVM-10™ Scanner,
CD Containing
WinScan™ Software
This manual
a WinScan™ Manual
Sample files
a serial communications cable
a 12-volt power adapter wall transformer and cord.
If any of these items are missing, call PMI immediately.
The package may include these optional items:
a modem cable (if your unit is equipped with a modem).
1.4 ACCESSORIES
1.4.1 General
Additional functions and capabilities can be added to the Scanner as accessories. These
options are briefly described in the following paragraphs.
1.4.4 Adapters
If you have an older PMI unit we have a wide range of adapters available so you can
use your existing serial cables with your new unit(s).
1.4.5 Cases
PMI carries a wide selection of cases to carry your new or old unit, cables, and manuals
all in the same container. See figure 1-6.
1.4.6 Spare Parts List

SVM-10 Manual
SVM-10™ Series
(*R-models only)
SVM-10™ Manual PMI#XXXXXXX
Serial Adapter PMI#30550106
Wall Transformer PMI#31100008
*Modem Cable PMI#20506001
SVM-10™ Comm. Cable PMI#20506002
Figure 1-6: Cases
1.5 SPECIFICATIONS
1.5.1 General
The SVM-10™ Scanner specifications is shown in Table 1-1.
Table 1-1 SVM-10™ Specifications
SVM-10™ Scanner Specifications
Input
ACVoltage 0 to 10 VAC
Sample rate: samples per second
61,440 all channels
15,360 per channel (256/cycle)
Channels
4voltage
Measured Qualities
RMS Voltage (Volts)
Note: All quantities are measured for each cycle.
Accuracy/Resolution
(-20°F to 135°F)
Accuracy Percent of full scale
Voltage 0.33 %
Resolution: Displayed/Internal
Voltage 0.01 V / 0.001 Vinternal
Input Impedance
Channels1,2,3 12kOhms
Channel 4 500 Ohms
Information Storage
Memory
RAM 128K (battery-backed)
FLASH EPROM 512K to 2,048K
DSP Waveform RAM up to 256K
TOTAL MEMORY 1.1millionreadings
Capacity
Summary data Over 1 year
Event data 500 records
Significant change data 500 records
Stripcharts 4 hours to over 1 yr.
Voltage
Retentiontime > 5 years
Communications
Local
Type Serial Cable
Standards RS232 Compatible
Data rate 1,200 to 38,400 baud
Modem (optional): 14.4 kbps
Local Output

SVM-10 Manual
Implementation of new developments and product improvements may result in specification changes in this
document
Environmental
Operating temperature -20°F to 135°F
Shock 60Hz to2KHz,
acceleration25G
Vibration 10Hz to 60Hz,
amplitude1.8mm
Physical Dimensions
Size 6.5” x 6.5” x 4.25”
Weight 5.0 lbs.
Case NEMA 4X
Power Fail Operation
The device operates with no input voltage for more
than 30 minutes. This allows it to measure down to 0
volts on all channels during power outage periods.
Harmonics(optional)
Voltage
Measures:
Magnitude
Phase
THD
Waveform capture:
Measuresto the 51st
Triggered
Type
Size
Interface
Wide-temperatureLCD
4 lines by 20 characters
Menu-driven
SVM-10™ Specifications Continued..
Controls
Stripchartsettings 1 second to 4 hours
Significantchange 1V to 8 V, in 1V steps
Battery voltage check Automatic
Keypad 4-key membrane
Power Requirements
Recordingload < 1.5 Watts

SVM-10™ Manual
19

SVM-10™ Manual
20
Connection Information Chapter 2
2.1 INTRODUCTION
2.1.1 General
This chapter provides information and procedures for connection of the Scanner.
Included are handling procedures, installation and wiring specifications, and
instructions for both standard and optional equipment.
2.1.2 Manual Updates
This manual may periodically be up-dated with addendums that could affect the
connection information contained in this section. Review each addendum, if any, in the
front of this manual and note changes that pertain to this section.
2.2 EQUIPMENT HANDLING
2.2.1 Initial Inspection
Exercise care when unpacking instruments from the shipping cartons. The instruments
are packed in a shock-resistant foam retainer to prevent damage during normal transit.
If damage to the shipping carton is evident, ask the carrier's representative to be present
when the instrument is unpacked and refer to Limited Warranty Statement, Appendix A.
2.2.2 Unpacking Procedure
Perform the following steps to unpack your Recorder.
1. Remove the foam retainer and instrument from the shipping carton.
2. Carefully remove the instrument from the foam retainer.
