PNI ESCORT HP 7120 User manual

PNI ESCORT HP 7120 +
PNI EXTRA 48
CB radio and CB antenna / CB радио и CB антена /
CB-Radio und CB-Antenne / Emisoras CB y antena CB / Poste CB et antenne CB /
CB rádió és CB antenna / Radio CB e antenna CB / CB-radio en CB-antenne / CB
radio i antena CB / Statie radio CB si antena CB
EN User manual ............................................. 3
BG Ръководство за потребителя ................ 10
DE Benutzerhandbuch ................................... 17
ES Manual de usuario .................................... 24
FR Manuel utilisateur ..................................... 31
HU Használati utasítás ................................... 38
IT Manuale utente ........................................ 45
NL Handleiding .................................................... 52
PL Instrukcja obsługi ..................................... 59
RO Manual de utilizare ................................... 66

EN
3
WARNINGS
Please read the ollowing precautions to prevent re, personal injury or the radio destruction.
Do not attempt to adjust the radio while driving; is dangerous.
This radio is designed for power supply at 13.8V DC. Do not use a 24V battery to power the
radio.
Do not place the station on an excessively dusty, damp or unstable surace.
Do not connect the antenna during transmission, risk oburning or electric shock.
Please keep distance rom devices that cause intererence (such as TV, generator, etc.)
People who use pacemakers are advised to keep distance from the antenna during transmission
and especially not to touch it.
Do not connect metal objects to the internal electrical side; danger of electric shock.
Avoid exposing the radio to temperatures below -26°C and above +80°C, the temperature on
a vehicle may sometimes exceed 80°C, which can cause irreparable damage to electric devices.
Do not expose the radio to sunlight.
Do not place anything on the radio, it will prevent it rom cooling down.
Check to see if you have enough charged battery to avoid rapid discharge.
It is important to stop the radio beore starting the engine, to avoid damage caused by high
starting voltage.
You must use a 2A 250V fuse type F. Under no circumstances use a higher value.
Ian abnormal odor or smoke is detected as coming rom the radio, switch othe appliance
immediately.
Do not transmit or a long time, the radio may warm up.
Keep the station away from children.
OTHER WARNING:
Beore connecting or using this product, please read these operating instructions careully. Keep
this manual for future reference.
Beore using the radio, please connect the antenna, then check the SWR beore transmitting. A
too high SWR can cause demage to the CB nal output transistors, which is not covered by the
warranty.
The radio does not includes components that can be repaired by the user. Please contact an
authorized service center.
To prevent the risk o re, use only a suitable power supply.

4
PNI Escort HP 7120 can be operated as a mobile station in a car or with a suitable DC power
supply as a base station. This device complies with the latest European CB stan-dards. Due to its
selectable CB standards it can be used throughout Europe. Please select only a CB standard that
is allowed in the country of use.
FEATURES
• Multi-standard device
• Up/Down keys on the microphone
• Channel Scan
• LCD display
•Digital Automatic Squelch, adjustable
• RF Gain
• Emergency channel 9/19
• Socket for external loudspeaker
DESCRIPTIONS AND COMMANDS
1 2 3 4 6
7
5
Nr. Key Shortly press Long press
1Microphone jack - -
2SQ/ASQ Activating and controlling squelch
manually Activate/deactivate ASQ
3RF Gain Activate/deactivate RF Gain -
4EMG Switch continually amongst ch9/
ch19/channel in use
Activate/deactivate key lock
function
5Up/down keys Channel change, squelch level
change -
6On/okey
Volume control - -
7A/F AM/FM selection Enable SCAN function

EN
5
DISPLAY
TX
RX
AQ
1 3 5 7 9 +30
FM AM
M H
SC R
17
3
4
5
6
2
1 - Selected channel
2-AM/FM mode
3-RX/TX: reception (RX) and trasmission (TX) indicator
4-SC: SCAN function activated
5-AQ: automatic squelch activated
6-R: RF GAIN activated
7 - Received signal strenght indicator and trasmission power signal
BACK PANEL
ANT
EXT SP
1
23
1 - Power supply cable
2 - External speaker
3 - Antenna connector
INSTALLATION
Check the radio and all accessories before installing.
Power the radio with the cigarette lighter plug included in the package. The radio must be powered
at a voltage between 12 - 13.8V. The fuse mounted on the power cord protects the radio against
damage caused by technical deects or wrong polarity. Ithe use is blown, rst eliminate the cause
and then replace it using the F3A 250V type.
Check the connections correctly before starting the radio. Make sure there is no risk of shortcircuit.
Operation with AC Adapter
Operate your radio only at a stabilized radio power supply, which is capable to provi-de at least 2A
at 12 -13.8V DC. Unregulated power supplies or battery chargers are unsuitable and can cause
damage. Connect the red lead to the positive (+) terminal othe power supply, the black wire to the
negative (-) terminal othe power supply.

6
ANTENNA CONNECTION
Connect the CB antenna to the ANT socket on the back of your radio. The antenna must be tuned
to the CB radio band. For this use a SWR meter. For a good radio range, the SWR should not
exceed a value o2. A high SWR also points to deects in antenna, cable, or a short circuit in the
antenna line. Never transmit without connected antenna!.
Note: The radio antenna is to be mounted from other antennas and interference sources as much as
possible. CB antennas must be mounted usually in the vehicule highest part on a metal surfaces.
A sufciently large metal surace is essential or the unction othe antenna. For installation on a
berglass cabs or plastic wind deectors, special ground less antennas can be used.
OPERATION
•Power On/Of the radio: Turn the radio on by turning the knob [6] clockwise. The current
standard, then the selected channel, will appear on the screen or one second. Turn knob [6]
anti-clockwise to stop the radio.
Note: The radio is preset rom the actory on Channel 22, the CE standard.
•Volume control: Continue to turn the knob [6] clockwise to adjust the volume to the desired
level.
•Channel selection: Press the keys [5] on the radio or the up/down keys on the microphone
to change the channel number.
•Squelch level control: Press the [2] key briey. The current squelch level will appear on the
screen. Use the up/down keys to select the desired SQ level (rom 0.1 to 2.8) or OF to disable
the function.
0.F = Squelch o
0.1 = Lowest Squelch level
2.8 = Highest Squelch level
Note: Higher SQ level require a stronger signal to open the speaker and hear the spo-kesman.
•ASQ control: Long press the [2] key to activate the ASQ function. The “AQ” icon and the
current ASQ level will appear on the screen. Use the up/down keys to select the desired ASQ
level (rom A.1 to A.9). Press the [2] key long to deactivate the ASQ unction.
A.1 = lowest level
A.9 = highest level
Notes:
Higher DS level require a stronger signal to open the speaker and hear the spokesman.
For automated Squelch, we recommend level A.2 (or A.3 or louder areas).
•Modulation type: Briey press the [7] key to change between AM and FM. The selected
modulation will appear on the screen.
Note: Beore modiying the modulation, check the selected standard.
•RF Gain control: Press the [3] key briey. The “R” icon will appear on the screen and the
current RF gain level will blink. Use the up/down keys to change the level (06, 12, 18, 24, 30,
36, 42, 48, 54).
Note: We recommend RFG unction disabled (or level 06 or louder areas).
•Emergency channel: Press the [4] key briey. The channel number 09 blinks on the screen.
Press again, the channel number will blink 19 on the screen. Press the third time to return to
the normal channel.
•Key Lock: Press long the [4] key. The “LC” icon will appear on the screen. Key lock function
is active. Press the [4] key again, OF will appear on the screen. The key lock unction is
disabled.
•Scan function: Press long the [7] key to start channel scanning. The “SC” icon appears on

EN
7
the screen. Use the up/down keys to change the direction of the scan. Press the [7] key or the
PTT key on the microphone again to deactivate the scan function.
CHANGING THE CB-STANDARD
To change the standard you are using the CB radio in, do the ollowing:
• Press and hold the [7] - A/F key while turning on the radio
• Press the up/down keys to select the desired standard
•Close and restart the radio. Immediately ater turning on, the current standard will be displayed
for a second.
FREQUENCY BAND CHART:
Norm Frequency
(MHZ) Channels Country EMG (9/19)
EU 26.965-27.405 40CH (4W) AM/
FM
AT, BE, BG, CH,
CY, DK, EE, ES,
FI, FR, GR, HR,
HU, IE, IS, IT,
LT, LU, LV, NL,
NO, PT, RO,
SE, SI
CH09: 27.065MHz AM/FM
CH19: 27.185 AM/FM
CE 26.965-27.405 40CH (4W) FM
only RO, MT CH09: 27.065MHz FM CH19: 27.185MHz FM
UK 27.60125-
27.99125
40CH (4W) FM
only UK CH09: 27.68125MHz FM CH19: 27.78125MHz FM
PL 26.960-27.400
-5KHZ
40CH (4W) AM/
FM
PL CH09: 27.060MHz AM/FM
CH19: 27.180MHz AM/FM
I26.965-27.405 40CH (4W) AM/
FM IT CH09: 27.065MHz AM/FM CH19: 27.185MHz AM/FM
I2 26.965-26.955 34CH (4W) AM/
FM IT CH09: 27.065MHz AM/FM CH19: 27.185MHz AM/FM
dE
26.965-27.405 01CH-40CH
(4W) AM/FM DE CH09: 27.065MHz AM/FM
CH19: 27.185 AM/FM
26.565-26.955 41CH-80CH
(4W) FM only
In 26.965-27.275 27CH (4W) AM/
FM IN CH09: 27.065MHz AM/FM CH19: 27.185MHz AM/FM
EXTERNAL SPEAKER
An external speaker (8 Ohm) can be connected to the 3.5mm mono socket on the back othe
radio. The built-in speaker automatically turns owhen a plug is inserted into this jack.

8
RESTORE FACTORY DEFAULT
• Press the [2] - SQ key while turning on the radio.
• The “rt” icon will appear on the screen
• All settings and functions will be reset
SPECIFICATION
Frequency 26.965-27.405 MHz
Dimensions 110 X 120 X 28 mm
Weight 385 g
Power supply 13.8V
Current consumption 2 A max
Operating temperature -26°C ~ +80°C
Frequency error ±300HZ
TX power 4 Watt
Spurious transmissions < 4 nW (-54 dBm)
Adjacent channel power < 20 µW
FM deviation 1.7KHZ-2.0KHZ
AM modulation index 80%-90%
RX Sensitivity better than 0.25uv@12db
Image rejection 70 dB
Adjacent channel rejection 60 dB
Audio output 1 Watt 8 Ohm
Frequency response 300-2600 Hz

EN
9
PNI EXTRA 48 CB ANTENNA
PNI EXTRA 48 is a small CB radio antenna suitable or both cars and trucks, compatible with all
CB radio on the market. It is very easy to install with the help of the magnetic base in the package.
INSTALLATION INSTRUCTIONS
Fix the antenna on the magnetic base and position it in the middle of the car dome.
Connect the antenna to a CB radio.
Note: The antenna is tuned from the factory.
TECHNICAL SPECIFICATIONS
Frequency 26 - 28Mhz Whip length 440 mm
Gain >5dbi Cable RG174, L=4000 mm
S.W.R. <1.2:1 Polarization Vertical
Power Max. 150W Material Fiber glass
Impedance 50 Ohm Magnetic support 103 x 66 x 40 mm

BG
10
СПЕЦИАЛНИ ПРЕДУПРЕЖДЕНИЯ
Моля,прочетете следните предпазни мерки,за да предотвратите пожар,телесна
повреда или унищожаване на станцията.
Не се опитвайте да регулирате станцията,докато шофирате,това е опасно.
Тази станция е предназначена за захранване при 13.8V DC. Не използвайте 24V батерия
за захранване на станцията.
Не поставяйте станцията върху прекалено напрашена,влажна или нестабилна
повърхност.
Не свързвайте антената по време на предаване,опасност от изгаряне или токов удар.
Моля,пазете дистанцията от устройства,които причиняват смущения (като телевизор,
генератор и др.)
На тези,които използват пейсмейкъри,се препоръчва да стоят на разстояние от антената
по време на предаване и най-вече да не я докосват.
Не доближавайте метални предмети към вътрешната електрическа страна;опасност от
токов удар.
Избягвайте излагането на станцията на температури под -26 °C и над +80° C, а
температурата на превозното средство понякога може да надвишава 80 °C, което може да
причини непоправими щети при продължително излагане.Не излагайте продължително
станцията на слънчева светлина.
Не поставяйте нищо върху уреда,това ще предотврати охлаждането му.
Уверете се,че имате достатъчно заредена батерия,за да избегнете бързото разреждане.
Важно е да спрете станцията преди да стартирате двигателя,за да избегнете повреди,
причинени от високото стартово напрежение.
Когато сменяте предпазителя,трябва да използвате предпазител тип 2A 250V F. При
никакви обстоятелства не използвайте по-висока стойност.
Ако се открие необичайна миризма или дим от станцията,спрете уреда веднага
Не предавайте с голяма сила дълго време,станцията може да загрее.
Пазете станцията от деца.
ДРУГИ ПРЕДУПРЕЖДЕНИЯ:
Преди да свържете или използвате този продукт,прочетете внимателно това ръководство за
експлоатация.Съхранявайте това ръководство за бъдещи справки.
Преди да използвате радиото,свържете антената,след това проверете SWR преди
предаването.Прекалено високият КСВ може да причини повреда на транзисторите на
крайния изход CB, което не се покрива от гаранцията.
Радиото не включва компоненти,които могат да бъдат поправени от потребителя.Моля,
свържете се с оторизиран сервизен център.
За да предотвратите риска от пожар,използвайте само подходящо захранване.

BG
11
PNI Escort HP6500 може да се използва като мобилна станция в автомобили или като базова
станция,ако й осигурите подходящо захранване.Устройството отговаря на най-новите
европейски стандарти.Благодарение на избираемите правила, HP 7120 Escort PNI може да
се използва в цяла Европа.
Моля,изберете нормата,разрешена в държавата,в която се намирате.
ОСНОВНИ ХАРАКТЕРИСТИКИ
•Мулти-стандартно устройство
•Клавиши за промяна на канала нагоре/надолу върху микрофона
•Сканиране на канали
•LCD екран
•Автоматично и регулируемо шумоподтискане
•RF усилване
•Аварийни канали 9/19
•Връзка с външен високоговорител
ОПИСАНИЕ НА КЛАВИШИ И ФУНКЦИИ
1 2 3 4 6
7
5
№ Клавиш Функция,чрез кратко натискане Функция,чрез дълго
натискане
1Муфа
микрофон - -
2SQ/ASQ Активиране и ръчно управление
на шумоподтискането
Активиране/деактивиране
ASQ
3RF Gain Активиране/деактивиране RF
Gain -
4EMG Спешен избор на канали 9/19 Активиране/деактивиране
функция блокиране на клавиш
5Клавиши
нагоре/надолу
Смяна на канали,смяна нивото
на шумоподтискане -
6Бутон on/o
Звук - -
7A/F Смяна на AM/FM режим Активиране функция
сканиране
