Polar Electro CD229-A User manual

Model:
CD229-A / CD230-A
Refrigerated
Merchandiser
Instruction manual
CD229-A_CD230-A_A5_v2_20200903.indb 1CD229-A_CD230-A_A5_v2_20200903.indb 1 2020/9/3 09:402020/9/3 09:40

2
AU Telephone Helpline: 1300225960
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components or service panels on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• DO NOT use jet/pressure washers to clean the appliance.
• DO NOT use the appliance outside.
• DO NOT use this appliance to store medical supplies.
• DO NOT allow oil or fat to come into contact with the plastic
components or door seal. Clean immediately if contact occurs.
• DO NOT store products on top of the appliance.
• Bottles that contain a high percentage of alcohol must be
sealed and placed vertically in the refrigerator.
• Always carry, store and handle the appliance in a vertical
position and move by holding the base of the appliance.
• Always switch off and disconnect the power supply to the unit
before cleaning.
• Keep all packaging away from children. Dispose of the
packaging in accordance with the regulations of local
authorities.
• If the power cord is damaged, it must be replaced by a POLAR
agent or a recommended qualified technician in order to avoid
a hazard.
• Children should be supervised to ensure that they do not play
with the appliance.
CD229-A_CD230-A_A5_v2_20200903.indb 2CD229-A_CD230-A_A5_v2_20200903.indb 2 2020/9/3 09:402020/9/3 09:40

3
AU
Telephone Helpline: 1300225960
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• Polar recommends that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
Caution Risk of Fire
• Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of
obstruction. Unit should not be boxed in without
adequate ventilation.
• Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning: Do not damage the refrigerant circuit.
• Warning: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are the
type recommended by the manufacturer.
Product Description
CD229-A - POLAR Refrigerated Display Merchandiser 120 litre
CD230-A - POLAR Refrigerated Display Merchandiser 160 litre
Pack Contents
• POLAR Counter-Top Refrigerated Merchandiser
• Shelves x 2
• Instruction manual
POLAR prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your POLAR dealer immediately.
CD229-A_CD230-A_A5_v2_20200903.indb 3CD229-A_CD230-A_A5_v2_20200903.indb 3 2020/9/3 09:402020/9/3 09:40

4
AU Telephone Helpline: 1300225960
Installation
Note: If the unit has not been
stored or moved in an upright
position, let it stand upright for
approximately 12 hours before
operation. If in doubt allow to
stand.
1. Remove the appliance from the packaging.
Make sure that all protective plastic film and
coatings are thoroughly removed from all
surfaces.
2. Maintain a distance of 20cm (7 inches)
between the unit and walls or other objects for
ventilation. NEVER LOCATE NEXT TO OR
NEAR A HEAT SOURCE.
Note: Before using the appliance
for the first time, clean the
shelves and interior with soapy
water.
Operation
Control Panel
The control panel is located below the doors on the
rear of the appliance.
Turn On
1. Close the doors of the appliance
2. Connect the appliance to a mains power supply
3. Press the button to turn the light On or Off
as required.
Setting the Operating Temperature
1. Press the SET button. The display will flash
2. Press the or buttons to display the
required temperature.
3. Press the SET button to store the temperature
Table of Controller Parameters
The operating parameters of this appliance have been preset for optimum performance and to maximise
the life of the appliance.
Note: The range refers to controller not machine capability, e.g. these units will function
between 0°C and 12°C only so parameters E1 and E2 should be set between 0°C and 12°C .
Display Parameter Preset Value Range
E1 Lower set temperature 0°C -20°C to 2°C
E2 Upper set temperature 12°C 2°C to 45°C
E3 Temperature buffer 4°C 1°C to 10°C
E4 Temperature buffer time delay 3 minutes 0 to 10 minutes
E5 Fixed parameter 0 DO NOT CHANGE
E6 Fixed parameter 00 DO NOT CHANGE
F1 Defrost period 25 minutes 1 to 60 minutes
F2 Defrost interval 6 hours 1 to 24 hours
F3 Defrost temperature 20°C 0°C to 22°C
F4 Centigrade/Fahrenheit 0°C °C/°F
CD229-A_CD230-A_A5_v2_20200903.indb 4CD229-A_CD230-A_A5_v2_20200903.indb 4 2020/9/3 09:402020/9/3 09:40

5
AU
Telephone Helpline: 1300225960
Should the parameter need adjusting:
1. Press and hold the SET button for six seconds. The “E1” parameter is displayed
2. Press the or buttons until the required value is displayed
3. Press the SET button to store the new value and cycle to the next parameter
NOTE: The controller times out after 10 seconds if no buttons are pressed
Manual Defrost:
Press and hold the button for 6 seconds to begin automatic defrost. The defrost light illuminates
Cleaning, Care & Maintenance
1. Switch off and disconnect from the power supply before cleaning.
2. The doors can be removed for ease of cleaning
3. Clean the interior of the appliance as often as possible
4. Do not use abrasive cleaning agents. These can leave harmful residues
5. Clean the door seal with warm soapy water
6. Always wipe dry after cleaning
Replacing the Interior Lamp
Call your POLAR dealer or a qualified electrician, the Lamp Assembly is available to purchase as a spare
part.
Cleaning the Condenser
Periodically cleaning the condenser can extend the life of the appliance. POLAR recommend that a POLAR
agent or qualified technician clean the condenser.
Troubleshooting
If your POLAR appliance develops a fault, please check the following table before making a call to the
Helpline or your POLAR dealer.
Fault Probable Cause Solution
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug and lead are damaged Call POLAR agent or qualified Technician
Fuse in the plug has blown Replace the fuse
Power supply Check power supply
Internal wiring fault Call POLAR agent or qualified Technician
CD229-A_CD230-A_A5_v2_20200903.indb 5CD229-A_CD230-A_A5_v2_20200903.indb 5 2020/9/3 09:402020/9/3 09:40

6
AU Telephone Helpline: 1300225960
Fault Probable Cause Solution
The appliance
turns on, but the
temperature is too
high/ low
Too much ice on the condenser Defrost the appliance
Condenser blocked with dust Call POLAR or qualified technician
Doors are not shut properly Check doors are shut and seals are not
damaged
Appliance is located near a heat
source, in the direct sunlight or
air flow to the condenser is being
interrupted
Move the refrigerator to a more suitable
location
Ambient temperature is too high Increase ventilation or move appliance to a
cooler position
Unsuitable foodstuffs are being
stored in the appliance
Remove any excessive hot foodstuffs or
blockages to fan
Appliance is overloaded Reduce the amount of food stored in the
appliance
Factory default parameters adjusted Call POLAR or qualified technician
The appliance is
leaking water
The appliance is not properly
levelled
Adjust the screw feet to level the appliance
(if applicable)
The appliance is
unusually loud
Loose screw/nut Check and tighten all nuts and screws
The appliance has not been installed
in a level or stable position
Check installation position and change if
necessary
The display lamp
does not illuminate
Lamp needs replacing Call POLAR or qualified technician
Light not turned on Ensure Light button has been pressed
properly
Door does not shut Dirt/obstacle in runners Clean runners
Technical Specifications
Model Voltage Power
(W)
Current
(A)
Temperature
Range
Capacity
(Litres) Refrigerant Dimensions H x W x D mm
Weight
(kg)
CD229-A 220-240V~
50Hz
160 1.4A 0°C to 12°C 120 R600a (50g) 686 x 696 x
568
57
CD230-A 220-240V~
50Hz
200 1.4A 0°C to 12°C 160 R600a (65g) 686 x 874 x
568
66
CD229-A_CD230-A_A5_v2_20200903.indb 6CD229-A_CD230-A_A5_v2_20200903.indb 6 2020/9/3 09:402020/9/3 09:40

7
AU
Telephone Helpline: 1300225960
Electrical Wiring
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
CD229-A_CD230-A_A5_v2_20200903.indb 7CD229-A_CD230-A_A5_v2_20200903.indb 7 2020/9/3 09:402020/9/3 09:40

DECLARATION OF CONFORMITY
•Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad • Declaração de conformidade
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento
Model • Modèle • Modell • Modello
• Modelo • Malli
Refrigerated Display Merchandiser - 120Ltr
Refrigerated Display Merchandiser - 160Ltr
CD229 (& -E -A)
CD230 (& -E -A)
Application of Territory Legislation &
Council Directives(s)
Toepassing van Europese Richtlijn(en)
• Application de la/des directive(s) du
Conseil • Anwendbare EU-Richtlinie(n)
• Applicazione delle Direttive
• Aplicación de la(s) directiva(s) del
consejo • Aplicação de directiva(s) do
Conselho
Low Voltage Directive (LVD) - 2014/35/EU
EN 60335-1:2012 +A11:2014 +A13:2017
EN 60335-2-89:2010 +A1:2016 +A2:2017
EN 62233:2008
Electro-Magnetic Compatibility (EMC)
Directive 2014/30/EU - recast of
2004/108/EC
EN 61000-6-1: 2007
EN 61000-6-1: 2007+A1:2011
Restriction of Hazardous Substances
Directive (RoHS) 2015/863 amending Annex
II to Directive 2011/65/EU
Electrical Safety
EN 60335-1:2012 +A11:2014 +A13:2017
EN 60335-2-89:2010 +A1:2016 +A2:2017
EN 62233:2008
Electromagnetic Compatibility
EN 61000-6-1: 2007
EN 61000-6-1: 2007+A1:2011
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante • Nome do fabricante
Polar
Producer Address • Adres fabrikant •
Adresse du producteur • Anschrift des
Herstellers • Indirizzo del produttore •
Dirección del fabricante • Morada do
fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
42 North Point
Business Park
New Mallow Road
Cork
Ireland
15 Bagdally Road,
Campbelltown
NSW 2560
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation,
Directive(s) and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und Norm(en)
entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y estándar(es)
arriba mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es)
Directiva(s) e Norma(s)
Date • Data • Date • Datum • Data • Fecha • Data
24th August 2020
Signature • Handtekening • Signature • Unterschrift
Firma • Firma • Assinatura
Full Name • Volledige naam • Nom et prénom •
Vollständiger Name • Nome completo
•Nombre completo • Nome por extenso
Ashley Hooper
Josie Holt
Position • Functie • Fonction • Position • Qualifica
•Posición • Função
Technical & Quality Manager
Commercial Manager/
Responsible Supplier
CD229-A_CD230-A_A5_v2_20200903.indb 8CD229-A_CD230-A_A5_v2_20200903.indb 8 2020/9/3 09:402020/9/3 09:40

CD229-A_CD230-A_A5_v2_20200903.indb 9CD229-A_CD230-A_A5_v2_20200903.indb 9 2020/9/3 09:402020/9/3 09:40

CD229-A_CD230-A_A5_v2_20200903.indb 10CD229-A_CD230-A_A5_v2_20200903.indb 10 2020/9/3 09:402020/9/3 09:40

CD229-A_CD230-A_A5_v2_20200903.indb 11CD229-A_CD230-A_A5_v2_20200903.indb 11 2020/9/3 09:402020/9/3 09:40

CD229-A_CD230-A_A5_v2_20200903
http://www.polar-refrigerator.com/
CD229-A_CD230-A_A5_v2_20200903.indb 12CD229-A_CD230-A_A5_v2_20200903.indb 12 2020/9/3 09:402020/9/3 09:40
