USE OF THE POLARIS CLEANER IN A VINYL LINER POOL
Certain vinyl liner patterns are particularly susceptible to rapid surface wear or pattern removal caused by objects coming
into contact with the vinyl surface, including pool brushes, pool toys, floats, fountains, chlorine dispensers, and automatic
pool cleaners. Some vinyl liner patterns can be seriously scratched or abraded simply by rubbing the surface with a pool
brush. Ink from the pattern can also rub off during the installation process or when it comes into contact with objects in the
pool. Zodiac Pool Systems, Inc. is not responsible for, and the Limited Warranty does not cover, pattern removal, abrasion
or markings on vinyl liners.
To avoid risk of potentially serious injury:
• Do not handle the Polaris cleaner while it is operating, except when checking the wheel RPM.
• Always remove the Polaris cleaner before swimmers enter the pool.
For customer service or support:
• Please mail warranty card immediately.
• For on-line support: www.polarispool.com
• To contact Polaris: US and Canada
Customer Service
2620 Commerce Way
Vista, CA 92081-8438
1-800-822-7933
CAUTION
Before You Start: Important Information
• Before installing the Polaris®cleaner, make sure the pool filter is clean.
• New plumbing lines should be flushed out before installing the Polaris cleaner.
• The Polaris cleaner should not be used to remove plaster dust in new pools.
• Always disconnect the cleaner before cleaning or backwashing the pool filter.
• After cleaning or backwashing, let the filtration system run for at least five (5) minutes before
reconnecting the cleaner.
• Always remove the cleaner from the pool before chemical shock treatements, such as super oxidation or
chlorination.
• Solar heating systems, ozone generators, and other air inducing equipment may cause air flow through the
cleaner, adversely affecting cleaner balance and performance. Plumb the dedicated cleaner line upstream
of these components.
• Highly chlorinated water can cause maintenance problems. Avoid running the Polaris cleaner while
chlorinating.
WARNING

English
3
• Scissors or garden shears
• Pliers
• Tape measure
Included in the Box
Tools Needed for Installation
• Piece of tape
• UWF tool (optional part # 10-102-00)
a. Cleaner Body
b. All-Purpose Zipper Bag
c. Head Float
d. Sweep Hose
e. Tail Sweep PRO®
(with Sweep Hose Scrubber)
f. Feed Hose
g. Hose Float(s)
h. Back-up Valve
i. Quick Disconnect and
Pressure Relief Valve
j. Universal Wall Fitting (UWF®)
k. Filter Screen, UWF/QD
l. Bag Collar
m. Pressure Tester
n. Bonus All-Purpose Zipper Bag
d
e
a
h
g
f
k
j
i
c
l
b
7
m
n

English
4
Installing the Cleaner
Read the complete owner’s
manual before you begin installation.
1 Prepare the Pool
1. Turn on the filtration pump for 2-3 minutes to flush out the plumbing lines.
2. Turn off the filtration pump.
3. Lay hose (f) out on the pool deck in sunlight to relax coils. This will reduce
the risk of tangling during cleaning.
2 Install the Universal Wall Fitting
Purpose of installing the UWF®:Once the UWF is properly installed, the Quick
Disconnect can be removed each time without removing the UWF.
1. Remove the Universal Wall Fitting (UWF) (j) from the end of the hose (f) and
thread (by hand) into the dedicated return line opening in the pool.
2. Make sure the filter screen (k) is firmly seated in the Quick Disconnect (i).
3. Install Quick Disconnect into the UWF by turning clockwise (do not over-tighten),
then pull to secure in place.
k
i
j

English
5
If your pool has two or three return lines, use the Eyeball
Fitting Connection Kit (part #9-100-8001). This kit
provides a Universal Wall Fitting (UWF®) and pressure
relief valve to be installed into the 2nd return line. Also
included is an eyeball regulator, which will replace the
existing eyeball if a 3rd return line is present.
Use the UWF Eyeball Fitting Kit (part
#6-511-00) to restore proper water
circulation when the cleaner is removed
from the pool.
If the pool does not have a dedicated return line, the Polaris TR36P cleaner connects to most common
return lines using special adapter kits available for purchase at a participating Polaris dealer.
For pools with plastic-pipe return lines (without pipe threads) that are cut off flush with the pool wall:
1" Stub Pipe Connection Kit
(part #9-100-8002)
1" Return Line
1" Expansion
Connector
If pipe is 1″ in
diameter, use 1″ Stub
Pipe Connection Kit
(part #9-100-8002)
1-1/2" Stub Pipe Connection Kit
(part #9-100-8003)
1-1/2"
Expansion
Connector
1-1/2" Return Line
If pipe is 1-1/2″ in
diameter, use 1-1/2″
Stub Pipe Connection
Kit (part #9-100-8003)

Does current fitting
look like this?
Connector
Head
Retainer
Ring

Wall Fitting 
Adapter

Eyeball Adapter Connection Kit
(part #9-100-8005)
For directional eyeball
fittings that do not
have a 1-1/2” threaded
socket, request the
Eyeball Adapter
Connection Kit (part
#9-100-8005)
Pool/Spa Connections Requiring Special Fittings
If a spa is connected to the pool filtration equipment, obtain expansion regulators in addition to one of the
kits listed above. Contact your dealer or Customer Service to determine which parts may be necessary.
Installing Other Pool Connections
Eyeball Regulator
Pressure
Relief Valve
Universal Wall Fitting
(UWF) O-Ring
Eyeball Connector
Eyeball Regulator
Retainer Ring
If the UWF and Eyeball
Regulators still cannot be
installed on the pool, contact
your dealer or Customer Service
to determine which parts may be
necessary.
Multiple Return Lines? Polaris®Cleaner Removed from Pool?

English
6
3 Test Water Pressure
4 Adjust Hose Length
1. Turn on the filtration pump.
2. With the hose connected to the UWF®, hold
the pressure tester (o) under water. Cover the
large hole with your thumb and confirm water is
releasing from the pressure
relief valve (i).
NOTE: There are two holes in the end of the pressure
tester. It is important to block the larger hole to verify
pressure.
1. Turn the pump on. Hold hose
under water until the pressure
relief valve releases pressure.
2. Extend the hose to the
farthest point of the pool.
The hose end must be within
6 inches (15 cm), longer or
shorter.
3. Measure the hose with the
pressure on and cut excess
length from the first hose
section (p). (This is the
section connected to the
Quick Disconnect (i).)
4. Reconnect hose sections.
5. After adjusting the hose
length, position the three
hose floats as shown.
o
i
No water flow from pressure relief valve?
• If your Polaris®cleaner is connected to a dedicated cleaner line, adjust the diverter valve to
increase the water flow to the cleaner.
• Make sure filter screen (k) is correctly positioned in Quick Disconnect.
• Check skimmer, pump basket, and main filter for debris restricting flow.
• If the Polaris cleaner is connected to one of multiple return lines, verify you have the correct
Polaris return line connection kits installed (see page 5 of this manual).
Hose too short?
• Contact your local Polaris dealer. Buy a new hose section. Add to
the first hose section (p) and cut until within 6 inches (15 cm).
6 in (15cm)
Recommended
Recommandé
Recomendado
f
h
g
i
p
Float (g)
Flotteur (g)
Flotador (g)
7ft (2.13m)
4ft (1.2m)

English
7
5 Assemble the Cleaner
1. Remove the pressure tester (o) by unscrewing the hose nut (q).
NOTE: The hose nut has reversed threads.
2. Use the same hose nut (q) and secure the hose to the cleaner body at the
feed pipe.
3. Pull the bag up and attach to the hose using the bag clip (n) .
4. Push the head float (c) all the way forward, up against the
cleaner body.
c
q
n

English
8
Before operating the Polaris cleaner®, check for proper wheel revolutions per minute
(RPM). For maximum efficiency, the Polaris should operate between 28 and 32
RPM.
1. Mark the single side wheel using using a piece of tape (or a small leaf tucked
into the tire).
2. Turn the pump on, hold the cleaner below the water level and count wheel
revolutions for one minute.
3. Optimum wheel speed should be between 28 and 32 RPM.
Operating the Cleaner
1. Connect hose in the pool at the UWF®.
2. Submerge the cleaner in the pool, allowing it to sink to the bottom.
3. Turn on the filtration pump and allow it to prime. Cleaner will begin to move.
1 Start the Cleaner
2 Check for Proper Wheel RPM
WARNING
To avoid risk of potentially serious injury, do not swim or use the pool
when the cleaner is submerged or operating.
mark the single
side wheel
(leaf, tape, or
marker)
Single-wheel Side
Sweep Hose
1 min
C
28 - 32 RPM
IMPORTANT
Keep cleaner
submerged for
accurate wheel
speed count.
mark the single side
wheel (tape or small leaf)

English
9
3 Adjust the Wheel Speed
• Check the filter screen in the Quick Disconnect for debris.
• Clean the skimmer, filter and pump basket.
• Check the hoses, connections, and swivel for leaks.
• If the cleaner is connected to a dedicated return line, adjust the diverter
valve to increase water flow.
Wheel Speed less than 28 RPM?
Wheel Speed more than 32 RPM?
• If the cleaner is connected to a dedicated cleaner line, adjust the diverter
valve to reduce the water flow to the cleaner.
• Unscrew the pressure relief valve until proper RPM is reached.
NOTE: For easier removal, use the Polaris®UWF®removal tool (Contact
your local Polaris dealer, Part # 10-102-00).

English
10
When operating correctly, the Polaris®cleaner vacuums, sweeps and scrubs all surfaces
randomly throughout the pool. The climbing ability depends on the pool’s shape and water
pressure or flow. The Polaris cleaner climbs best in pools without sharp angles or curves
in the transition from the pool floor to the pool wall. Approximately every 3-1/2 minutes the
Polaris cleaner goes into back-up mode. This action pulls the Polaris cleaner away from pool
obstacles.
The sweep hose should move in a gentle sweeping motion. To increase or
decrease sweeping motion:
1. Turn the filtration pump OFF.
2. Turn the adjustment screw on the feed pipe (r) counterclockwise to
increase sweep hose motion. Turn the adjustment screw clockwise to
decrease motion.
Decrease
motion Increase
motion
If the cleaner is veering left or right instead of tracking straight, adjust the
thrust jet (on the back of the cleaner body) for climbing walls or turning.
Fine Tuning the Cleaner
1 Adjust the Sweep Hose
2 Adjust the Thrust Jet
Fine tune your cleaner by adjusting the sweep hose or the
thrust jet as necessary, for optimal operation.
P
u
s
h
e
s
U
n
i
t
L
e
f
t
P
u
s
h
e
s
U
n
i
t
R
i
g
h
t
12
6
39
I
n
c
r
e
a
s
e
s
C
l
i
m
b
i
n
g
D
e
c
r
e
a
s
e
s
C
l
i
m
b
i
n
g
11
11
NOTE: Factory default setting is
eleven o’clock. Only adjust thrust
jet to accomodate unique pools
shapes.

English
11
Routine Maintenance
1 Empty the Bag
2 Backwash the Pool Filter
3 Storage and Winterizing
Perform routine maintenance to prolong the life of your cleaner.
1. Detatch the bag by releasing the prongs.
2. Remove the bag tie collar from the feed hose.
3. Open the closure and dump out the debris.
Empty the bag when it is half full, especially if the dirt load is mostly sand.
NOTE: It is easier to empty a dry bag. Remove the bag and let dry before emptying.
Alternate between two bags while drying, so the cleaning cycle is not interrupted.
Backwash your pool filter periodically. Always disconnect the Polaris®cleaner
from the pool wall before cleaning or backwashing the pool filter. After cleaning or
backwashing, let the filtration system run for at least five minutes to flush out the
return lines before re-connecting the Polaris cleaner.
NOTE: Never store the cleaner in direct sunlight.
To store the cleaner for the winter:
1. Remove cleaner from the pool and drain all water to avoid freezing water damage
(freeze damage is not covered under the warranty).
2. Remove the UWF®from the pool wall using the Quick Disconnect. Use a pulling
pressure as you unscrew.
If necessary, use the UWF Removal Tool (part #10-102-00) available from your local
Polaris dealer.

English
12
Troubleshooting
Problem Solution
Hangs up on steps or other
obstacles for longer than
3 1/2 minutes.
1. Check the wheel RPM.
2. Verify the back-up valve is cycling.
3. Adjust the thrust jet.
4. Remove unnecessary pool hardware or install a Ladder
Guard Kit (Part # G21) from a Polaris®dealer.
5. Check the bag and empty if needed.
Cleaner is sluggish, running with less
power than normal.
1. Check the filter screen in the Quick Disconnect and
clean, if necessary.
2. Clean the skimmer basket, pump basket, and pool
filter.
3. Check hoses, connections, and swivels for leaks that
could cause loss of water pressure.
4. Check the wheel RPM (between 28 - 32).
Cleaner flies around the pool and/or
does not make contact with
the bottom.
1. Check the wheel RPM.
- If cleaner is connected to a dedicated return line with
a diverter valve, adjust the valve to decrease water flow
to cleaner.
- If more than 32 RPM, unscrew the pressure relief
valve to decrease water flow to
the cleaner.
2. Verify the back-up valve is cycling. Hold the valve out
of the water and watch the jet. It should come on and
go off every 3 1/2 minutes.
Cleaner does not back up. 1. Verify the back-up valve is cycling every 3 1/2 minutes.
2. Check the wheel RPM (between 28 - 32).
3. If the bag is full, empty it.
4. If the head float has water in it, replace it.
5. Make sure feed hose is floating.
Cleaner only turns in one direction. 1. Adjust the thrust jet.
2. Verify the feed hose assembly is floating properly.
Waterlogged hose floats can cause the feed hose
to sink. Older hoses may lose buoyancy, replace if
needed.
3. If the end of the hose connecting to the cleaner has a
curve, align it with the curve in the feed pipe.
4. Make sure that the swivel on the feed pipe turns freely.

English
13
Problem Solution
Feed hose becomes tangled. 1. Remeasure the hose to verify that it is adjusted to the
proper length for the pool shape.
2. With the Polaris cleaner operating, check that the
swivels in the hose and the hose connections turn
freely.
3. Make sure feed hose is floating.
4. With the Polaris®cleaner turned off, spin each of the
wheels.
All wheels should turn together.
Sweep hose is sucked into
the vacuum tube.
1. Make sure the orifice at the end of the sweep hose is
not blocked by the sweep hose scrubber.
2. Adjust the sweep hose to a gentle sweeping motion.
Sweep hose sprays too much water
out of the pool.
1. Verify the Tail Sweep Pro®is installed correctly.
2. Adjust the speed of the sweep hose by tightening the
adjustment screw.
The cleaner does not clean the
entire pool.
1. Check the hose length reaches within 6″ of the farthest
point of the pool. If not, order a new hose section from
your Polaris dealer.
2. Check thrust jet for 11 o’ clock position that optimizes
random turning.
3. With the pump running, turn the cleaner head upside
down. Verify the three vacuum jets have consistent
unobstructed flow. If not, contact Customer Service or
a Polaris authorized Service Center for assistance.
The cleaner is running in circles on
its side.
1. Check filter bag, if full it can weigh the cleaner down on
one side.
2. Remove the head float and shake it. If there is water in
the float, order a new one.
3. The feed hose float should float evenly on the surface
of the pool.

English
14
Problem Solution
Cleaner does not climb walls. 1. Verify the wheel speed is 28 - 32 RPM.
2. Verify the thrust jet is in the 11 o’clock position.
3. Verify the head float is positioned all the way forward.
4. Verify the hoses have been cut correctly, following the
instructions.
5. With the pump running, turn the cleaner head upside
down. Verify the three vacuum jets have consistent
unobstructed flow. If not, contact customer service or a
Polaris®authorized service center for assistance.
Cleaner tires are slipping on tile or
fiberglass pool surface.
1. Verify your cleaner has Polaris PosiTrax®tires installed
on all three wheels. Polaris PosiTrax tires are only for
use on tile and fiberglass pool surfaces.
2. Verify the wheel speed is 28 - 32 RPM.
Wheels rotate less than 28 times
per minute
1. Verify the filter screen, pump baskets, and main filter
are clean.
2. Verify there are no leaks in the cleaner hoses, swivels,
or connectors.
3. If cleaner is installed on a dedicated cleaner line, adjust
the diverter valve to increase flow to the cleaner.
Wheels rotate more than 32 times
per minute
1. If cleaner is connected to a dedicated cleaner line,
adjust the diverter valve to reduce the water flow to the
cleaner.
2. Unscrew the pressure relief valve on the UWF®
connector assembly until RPM is between 28 and 32.

English
15
1.800.822.7933
www.polarispool.com


®
For replacement parts or additional troubleshooting
questions, call or go online.
Questions?

Zodiac Pool Systems, Inc.
2620 Commerce Way, Vista, CA 92081
1.800.822.7933 | www.polarispool.com
Polaris®and the 3-wheeled cleaner design are registered trademarks of Zodiac Pool Systems, Inc.
All other trademarks referenced herein are the property of their respective owners.
©2016 Zodiac Pool Systems, Inc. H0570700_REVC

MANUEL DU PROPRIÉTAIRE
H0570700_REVC
TR36P

Français
18
UTILISATION DU NETTOYEUR POLARIS DANS UNE PISCINE À TOILE EN VINYLE
La surface de certaines toiles en vinyle à motifs peut s’user rapidement et les motifs peuvent disparaître au contact
d’objets tels que les brosses de nettoyage, jouets, bouées, fontaines, distributeurs de chlore et nettoyeurs de piscine
automatiques. Les motifs de certaines toiles en vinyle peuvent être sérieusement égratignés ou usés par le simple
frottement d’une brosse de piscine. La couleur de certains motifs peut également s’effacer pendant l’installation ou en cas
de contact avec des objets présents dans la piscine. Les motifs effacés, l’usure ou les traces de frottement sur les toiles en
vinyle ne relèvent pas de la responsabilité de Zodiac Pool Systems, Inc. et ne sont pas couverts par la garantie limitée.
Pour réduire les risques de blessures potentiellement graves :
• Ne manipulez pas le nettoyeur Polaris pendant qu’il fonctionne, sauf pour vérifier la vitesse
tr/min de la roue.
• Retirez toujours le nettoyeur Polaris avant que des nageurs entrent dans la piscine.
Pour le service à la clientèle ou l’assistance :
• Veuillez retourner la carte de garantie immédiatement.
• Pour l’assistance en ligne : www.polarispool.com
• Pour contacter Polaris : États-Unis et Canada
Customer Service
2620 Commerce Way
Vista, CA 92081-8438
1-800-822-7933
ATTENTION
Avant de commencer: Informations importantes
• Avant d’installer le nettoyeur Polaris®, assurez-vous que le filtre de piscine est propre.
• Rincez les nouvelles conduites de plomberie avant l’installation du nettoyeur Polaris.
• N’utilisez pas le nettoyeur Polaris pour enlever la poussière de plâtre dans les nouvelles piscines.
• Déconnectez toujours le nettoyeur avant de procéder au nettoyage ou au lavage à contre-courant du filtre.
• Après le nettoyage ou le lavage à contre-courant, laissez le système de filtration en marche pendant au
moins cinq (5) minutes avant de reconnecter le nettoyeur.
• Retirez toujours le nettoyeur de la piscine avant de procéder à un traitement chimique de choc, notamment
de super oxydation ou chloration.
• Les systèmes de chauffage solaire, les générateurs d’ozone et les autres appareils à admission d’air
peuvent générer un écoulement d’air au travers du nettoyeur et exercer une influence négative sur son
équilibre et ses performances. Raccordez la tuyauterie de nettoyeur dédiée en amont de ces composants.
• L’eau fortement chlorée peut causer des problèmes d’entretien. Évitez d’utiliser le nettoyeur Polaris pendant
la chloration.
AVERTISSEMENT

Français
19
• Ciseaux ou cisailles de jardinier
• Pinces
• Ruban à mesurer
Contenu de la boîte
Outils requis pour l’installation
• Morceau de ruban adhésif
• Outil UWF (pièce en option n° 10-102-00)
a. Corps du nettoyeur
b. Sac tout usage à glissière
c. Flotteur de tête
d. Tuyau de balayage
e. Tail Sweep PRO®
(avec brosse de tuyau de balayage)
f. Tuyau d’arrivée
g. Flotteur(s) de tuyau
h. Soupape de recul
i. Raccord de déconnexion rapide et
soupape de surpression
j. Raccord mural universel (UWF®)
k. Crépine, UWF/déconnexion rapide
l. Collier de serrage du sac
m. Testeur de pression
n. Sac tout usage à glissière supplé
mentaire
d
e
a
h
g
f
k
j
i
c
l
b
7
m
n

Français
20
Installation du nettoyeur
Lisez la totalité du manuel du propriétaire
avant de commencer l’installation.
1 Préparez la piscine
1. Mettez la pompe de filtration en marche pendant 2 à 3 minutes pour rincer
les conduites.
2. Arrêtez la pompe de filtration.
3. Disposez le tuyau (f) sur la terrasse de la piscine afin de l’exposer au soleil
pour assouplir les rouleaux. Cela réduira les risques d’emmêlement pendant
le nettoyage.
2 Installez le raccord mural universel
Raison d’installer le raccord UWF®: Lorsque le raccord UWF est correctement installé,
vous pouvez retirer le raccord à déconnexion rapide sans avoir à retirer le raccord UWF.
1. Retirez le raccord mural universel (UWF) (j) de l’extrémité du tuyau (f) et vissez-le (à la
main) dans l’ouverture de la tuyauterie de retour dédiée dans la piscine.
2. Assurez-vous que la crépine (k) repose fermement dans le raccord à déconnexion
rapide (i).
3. Installez le raccord à déconnexion rapide dans le raccord UWF en tournant dans le
sens horaire (sans le serrer excessivement), puis tirez pour le verrouiller en place.
k
i
j
