Polaris PG10/GHX User manual

1
Instruction Manual
PRINTED 0517 100286999_2000536191_Rev C
KEEP THIS MANUAL IN THE POCKET ON HEATER FOR FUTURE REFERENCE
WHENEVER MAINTENANCE ADJUSTMENT OR SERVICE IS REQUIRED.
POWER DIRECT VENT GAS MODELS
WITH DIRECT SPARK IGNITION
MODELS
PG10/GHX/GSP/GTP
Series 200, 201
NATURAL GAS & PROPANE
ALL TECHNICAL AND WARRANTY QUESTIONS: SHOULD BE DIRECTED TO THE LOCAL DEALER FROM WHOM THE WATER HEATER WAS
PURCHASED. IF YOU ARE UNSUCCESSFUL, CALL THE TECHNICAL SUPPORT PHONE NUMBER SHOWN ON THE WATER HEATER LABELING.
RESIDENTIAL GAS WATER HEATERS
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or death.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
If you cannot reach your gas supplier,
call the fire department.
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
•
•
•
•
• For Your Safety •
AN ODORANT IS ADDED TO THE GAS USED
BY THIS WATER HEATER.
Thank you for buying this energy efcient water heater.
We appreciate your condence in our products.
LOW LEAD
CONTENT

2
TABLE OF CONTENTS
SAFE INSTALLATION, USE AND SERVICE.................................3
APPROVALS .................................................................................3
GENERAL SAFETY INFORMATION.............................................4
Precautions ..............................................................................4
Grounding Instructions .............................................................4
INSTALLATION REQUIREMENTS FOR THE COMMONWEALTH
OF MASSACHUSETTS.................................................................7
INTRODUCTION...........................................................................8
Abbreviations Used ..................................................................8
Qualications............................................................................8
Preparing For The Installation ..................................................8
MODEL CHARACTERISTICS.......................................................9
FEATURES AND COMPONENTS ..............................................10
Controls And Switches ...........................................................13
INSTALLATION CONSIDERATIONS ..........................................14
Locating The Water Heater ....................................................14
Insulation Blankets .................................................................15
Combustion Air And Ventilation ..............................................15
Corrosion and Water Quality ..................................................15
INSTALLATION REQUIREMENTS .............................................16
Gas Supply Systems ..............................................................16
Supply Gas Regulator ............................................................16
Power Supply .........................................................................16
Mixing Valves..........................................................................17
Circulation Pumps ..................................................................17
Space Heating And Potable Water System............................18
Storage Tank Installation ........................................................18
Solar Installation.....................................................................18
Closed Water Systems ...........................................................18
Thermal Expansion ................................................................18
Temperature-Pressure Relief Valve........................................19
Condensate DRAIN................................................................20
VENTING INSTALLATION ..........................................................21
Vent Installation Considerations .............................................21
General Venting Instructions ..................................................21
Approved Vent/Intake Material ...............................................21
Polypropylene Installations.....................................................22
Vent Pipe Termination.............................................................22
Planning The Vent System .....................................................22
Integrated Filter Installation ....................................................23
Direct Vent Air Intake Moisture Protection..............................24
Horizontal Vent Terminal Installation ......................................24
Vertical Vent Terminal Installation...........................................25
Termination Clearances Sidewall Direct Vent.........................26
Direct Vent Installation Diagrams ...........................................27
Concentric Vent Installation....................................................28
Venting Multiple Units.............................................................29
WATER HEATER INSTALLATION ..............................................30
CONDENSATE DRAIN INSTALLATION ................................30
Supply Gas Line Installation...................................................30
Gas Line Leak Testing............................................................31
Purging ...................................................................................31
Electrical Wiring......................................................................32
Water Line Connections .........................................................32
TEMPERATURE REGULATION .................................................34
HIGH TEMPERATURE LIMIT CONTROL (ECO)...................34
Thermostat Control.................................................................34
CONTROL SYSTEM OPERATION .............................................35
Overview ................................................................................35
Control System Navigation.....................................................35
User Settings & Control System Menus .................................38
START UP ...................................................................................43
Start Up Conditions ................................................................43
Prior To Start up......................................................................43
Filling The Water Heater.........................................................43
Initial Start Up.........................................................................44
Lighting & Operation Labels ...................................................45
Checking The Firing Rate.......................................................46
Gas Input Rate .......................................................................46
High Altitude Installations .......................................................46
TROUBLESHOOTING ................................................................47
Installation Checklist...............................................................47
Sequence Of Operation..........................................................47
Sequence Of Operation Flow Chart .......................................48
Operational Problems.............................................................49
Fault And Alert Conditions ......................................................50
LEAKAGE CHECKPOINTS.........................................................52
PERIODIC MAINTENANCE........................................................53
Venting System Inspection .....................................................53
Integrated Filter Preventative Maintenance ............................53
Temperature-Pressure Relief Valve Test ................................53
Draining and Flushing ............................................................54
Service ...................................................................................54
DIAGRAMS .................................................................................55
CCB - Central Control Board Layout ......................................55
Wiring Diagram.......................................................................56
Piping Diagrams .....................................................................58
NOTES ........................................................................................60
NOTES ........................................................................................61
