Polk Audio LCi Series User manual

PLACEMENT OPTIONS
Polk Audio LCj Series In-Wall Loudspeakers
give you nearly endless placement options.
But remember that placement choice for your
in-wall speakers bears careful consideration,
as installation requires that you cut a hole in
your wall or ceiling!
Fill a room with sound by installing in-wall
speakers in nearly any wall or ceiling
location [figure 1]. Polk LCj Series In-Wall
Loudspeakers have a wide dispersion pattern
and aimable tweeters that allow you to focus
their sound.
o
1 +----- OPTION 1 -----+1
OPTION 2 ~
6.1 Sutound !
ADJUSTING THE TWEETER
Aiming the tweeter toward your listening
position improves imaging and detail. When
using LCj Series In-Wall Loudspeakers as
front/main home theater speakers [figure 2],
aim the tweeter toward your listening posi-
tion. For rear/surround speakers installed in
walls or ceilings [figure 3], aim the tweeter
toward the nearest reflecting surface (an
adjacent wall or ceiling) for a more diffuse
sound field (if you so desire; for more
direct sound, aim the tweeters at your
listening position).
o o
,-, f- 7.1 Surround ~ , ,
'-... Option '- ...
o/, 0
6.1 SJrroundOption
FIGURE 1
Lei Series audio and A/V placement
options, in wall or ceiling.
Opciones de ubicacion al ras de la pared 0 del cielorraso para
equipo audiovisual y de audio de la Serie RC.
Recommended measurements for HT front stage placement.
PlafzierungsmOglichkeiten fur RC·Systeme in
Wand oder
Zimmerdecke (Audio und kombiniertes AudiolVideo)
10001
~D~
[T
TJ
1-2 ft. 1·2ft.
132-60cml 13HOcm)
recommended height
3'·6'
1-2m
FIGURE 2
Recommended meosurements
for HT front stage placement.
M.edidas
recomendadas para la ubicacion
en el escenario del cine en casa.
Mesures
recommandees pour I'installation
des haut'parleurs avant.
Empfahlene Abmessungen fUr die Plafzierung
in Heimtheatern (Frontbeschallung).
For Customer Service, call 800-377-7655. 2

PERFORMANCE ENCLOSURES
Are available for all models. These are engi-
neered enclosures that mount in the wall or
ceiling to maximize the bass and midrange
performance of your LCj Speakers. They are
typically installed prior to drywalling in new
construction, but can be retrofitted if desired.
Note: LCj Series In-Wall Loudspeakers are
not magnetically shielded and should not
be placed closer than l' (30cm) from a
direct view television or video monitor.
If you experience discoloration or distortion,
immediately move the speakers away from
your TV.
FIGURE 3
Examples of in-wall and in·ceiling placement. When used as
rear/surrounds~ aim tweeter toward the nearest reflecting surface
(an adjacent wall or ceiling) for a more diffuse sound field.
Ejemp/os
de ubicacion al ras de la pared 0 del cie/orraso. Cuando
se use como altavoz posterior 0 surround, oriente el tweeter
hacio 10 superficie reflectora milS cercana (pored 0 cielorraso
adyacente) pora producir un campo de sonido mas difuso.
Exemples d'installations au mur et au plafond. Pour usage
arriere-ambiophonique, dirigez les tweeters vers la surfoce
reflechissante la plus proche (mur ou plafond) si vous
desirez une image sonore plus diffuse.
Beispie/e zur Platzierung in Wand und Zimmerdecke. Bei
Verwendung als Hintergrund-/Surround·System sollten die
Hochtonlautsprecher zur besseren Zerstreuung des Schallfelds
in Richtung der nachstliegenden reflektierenden Flachen
positioniert werden (Wand oder Zimmerdecke).
DIRECTING THE DRIVER (LCi60 & LCi 80)
The fixed 15° angled driver in the ceiling
speaker allows you to direct the midrange
towards your listening area when used for
front stage (l~ft-center-right). When used as
rear surrounds or 6.1 or 7.1 back speakers,
direct the driver towards the listening area
for a more direct sound field or toward a
wall for a more diffuse soundfield.
FIGURE 4
To aim the LCi Ring Radiator Tweeter, use your fingers to gently
manipulate the outer ring of the tweeter cup, pushing lightly one
way or the other to tilt the tweeter, until it is aimed in the direc·
tion
of your listening position. DO NOT GRAB OR TURN THE PRO·
TRUDING
TWEETER PHASE PLUG IN THE CENTER OF THE TWEETER.
This phase plug is fragile.
Para apuntor eI Tweeter Radiador Anular LCi, manipu/e cuida·
dosamente con los dedos el anillo exterior del tweeter empujan'
do· ligeramente hacia uno yofro lado haste que el tweeter
apunte hacia la posiciOn del oyente. NO AGARRE NI GIRE EL
ENCHUFE DE FASE QUE SOBRESALE DEL CENTRO DEL TWEETER. Este
enchufe de fase es muy fritgi/.
Pour orienter Ie haut-porleur d'aigus a radiateur annulaire LCi,
manipu/er doucement avec les doigts I'anneau externe du haut·
parleur d'aigus en poussant legerement dans un sens ou dans
I'aulre pour incliner Ie haut-parleur, jusqu'a ce qu'il soit oriente
vers/a position d'ecoule. NE PAS. SAISIR NI TOURNER LA FICHE DE
PHASE DU HAUT·PARLEUR QUI DEPASSE AU CENTRE DE CELUI-ci.
Cetle fiche est fragile.
Um den LCi Ring Radiator-Tweeter auszurichten, manipulieren Sie
den auBeren Ring des Tweeters vorsichtig mit Ihren Fingern.
Driicken Sie
zur 5chriigstellung des Tweeters leicht auf die eine
oder andere Seite, bis er auf Ihre HOrposition ausgerichtet ist.
GREIFEN BZW; DREHEN SIE NICHT DEN IN DER MITTE DES TWEET·
ERS HERVORSTEHENDEN TWEETER·PHASE-PLUG. Dieser Phase'
Plug ist zerbrechlich.
3 Get more information and exclusive accessories, visit www.polkaudio.com

MAKING ADJUSTMENTS
The LCi Series features technology that can
tailor the sound for performance in difficult
or unusual placement situtations.
LC265i, LC65i, LC80i & LC60i MODEL
ADJUSTMENTS:
Wall Distance Toggle -In-wall loud-
speakers excel when placed'more than 2'
(60cm) from side walls. If position limitations
demand that in-wall loudspeakers be installed
closer than 2'(60cm) from side walls, the
proximity of the surface can result in a
response "bump" between 50 and 200Hz.
This can cause in-wall speakers to sound
"boomy." The Distance Toggle Switch flattens
response and tunes out "boominess" without
sacrificing
deep bass response, for more life-
like sound.
Recommended speaker
distance
from side walls
is 2 feet (60cm).
v
FIGURE 5
"placementis closer than 2' to awall, engage the Wall Distance
Toggle ("Wall Dist.")
to match the <2' setting.
En cas de posilionnement amoins de 5cm (2 pouces) du mur,
meffre
Ie commutateur de distance par rapport au mur ("Wall
Dist. ") dans la position < 2'.
Si el a/tavoz queda a menos de 61 cm (2 pies) de la pored, lije el
interruptor &ascu/ante
de distancia ala pared ("Wall Dist.") en la
posicion <2'.
Wenn
der Wanda&stond weniger als 60 cm (2 FuB) &etriigt,
scha/ten Sie
den Wanda&standsscha/ter ("Wall Dist.") ein, um mit
der Einstellung <2'. ii&ereinzuslimmen.
-3dB 1\veeter Attenuation -If your lis-
tening room is very reflective, with smooth
sheetrock walls, hardwood floors, and
non-cushioned furniture, the sound will be
overly "bright" and unnatural.
Engaging the LCi Tweeter Attenuation feature
(by selecting the "Cut" setting) compensates
for the effect of reflectivity in a hard room.
Tweeter Attenuation flattens room response
without hindering higher frequency response,
for warmer, more
realistic sound and more accurate imaging.
For Customer Service, call 800-377-7655. 4

LC801 & LC601 MODEL ADJUSTMENTS:
Area Targeting - Round LCi models fea-
ture a swiveling Ring Radiator 'I\veeter speak-
er for better directionality. The "sweet spot"
is within a 30° cone of sound coming from
the aimed speaker. The round model LCi
Loudspeakers feature an innovative Area
Targeting Switch. Engaging this function
"expands" the area of high frequency
response, improving off-axis imaging
and filling the room with well-balanced,
high performance sound.
FIGURE 6
When the listening position is outside of the "Normal"
30· cone of sound coming from the aimed tweeter,
engage the Area Targeting feature by switching this
button 10 the "Expand" position.
Dans
Ie cas aU la position d'ecoute 58 Irouve en dehors
du cOne acoustique "Normal" de 30' provenant du
haut-parleurd'aigus oriente, mettre ce boulon en posi-
tion "Expand" pour activer 10 Ionction de ciblage de
zone.
Cuando 10 posicion del oyente quede fuero del cono de
sonido "Normal" de 30' emitido por eI tweeter dirigi-
do, active 10 funcii>n de cobertura de area fijando este
batOn en 10 posiciOn "Expand".
Wenn die HOrposition au8erhalb des "norma/en" 30"-
Konus
des Sounds aus dem ausgerichteten Tweeter
liegt, aktivieren Sie die Funktion "Area Targeting"
.(Bereichsabstimmung), indem Sie diese Taste auf die
Position
"Expand" (Erweitern) stellen.
S Get more information and exclusive accessories, visit www.polkaudio.com

PAINTING YOUR Lei SERIES IN-WALL
LOUDSPEAKERS
You will need:
• Paint of your choice (to make the job easi-
er, we recommend spray painting the grille)
• A
paperclip or corkscrew (for removing the
paintable grille, corkscrew can also be used
to open the wine when you relax with your
newly painted Lei speakers, see page 10).
• Masking tape
• Paint mask (to cover unpaintable
parts, suppJied.0
:::::::::::::'~.'.~~~
.... ... ..... ... .~-.;:.....,
·............ .. . ..
·.
·.
·.
·.
·.
·.
·.
·.
·.
·.
·.
·.
·.
·.
·.
·.
·.
·.
·.
· .
·.
·.
FIGURE 7
Use apaperclip 10 remove grille.
Use
un sujetapapeles para quitar la rejilla.
Utilisez
un trombone pour retirer la grille.
Entfernen 5ie
den Gitteraufsatz mit einer Biiraklammer.
PREPARING TO PAINT:
1. Separate the parts of the speaker. If the
speaker is not yet installed, the grille can
be removed simply by pushing the clamp
screws forward to push the grille off the
speaker from the inside. If the speaker is
already in the wall, carefully hook the
grille with a bent paper clip and pull it
gently away from the frame [figure 7].
2. Remove the cloth scrim from the inside of
the grille. Replace after paint dries.
3. When painting the frame of the speaker,
use the supplied paint masks to carefully
mask off the front of the speakers to pro-
tect the drivers and baffles while painting.
You can do this while the speaker is
already installed in the wall (if, for
instance, you're repainting the room). If
you do not have the paint masl<s, carefully
mask the speaker components using paper
and masking tape.
FIGURE 8
Mask the drivers and baHles, then spray paint in thin coats.
Enmascare los
excitadores ylos bafles, luego
aplique manos delgadas de pintura aerosol.
Masquez les haut'parleurs et les ecrans acoustiques
puis
vaporisez la peinture en couches minces
Decken 5ie die Treiber
und Resonanzwande abo
5pritzen 5ie dann den Lack in diinnen 5chichten auf.
For Customer Service, call 800-377-7655. 6

PAINTING THE FRAME:
1. Apply paint to exposed (unmasked parts).
Use two or more thin coats. Spray painting
is recommended [figure 8].
2. When the paint is completely dry, remove
the masking material.
PAINTING THE GRILLE:
1. The grille of the LCj Series speaker fea-
tures an even, protective paint. This paint
is an ideal primer.
2. Grilles must be spray painted. Do not use
abrush and paint. Thick, brushed paint
may clog the grille holes.
3. After removing the grille by carefully hook-
ing it with a bent paper clip and pulling it
gently away from the frame, spray on two
thin coats of finish color. If you're using a
compressor
and spray gun, use the finest,
most diffuse setting. Be careful not to fill
the holes in the grille with paint [figure 9].
4. When the paint is completely dry, carefully
reinstall the grille by fitting it into its
recess so that it is just resting on the
frame. Starting with one corner, go around
the speaker and push the grille into the
grille notch alittle bit at a time. Be gentle;
the grille may be easily bent out of shape
by rough handling. You will feel a positive
"snap" when it is fully in place.
1\ \W"'\\\1 \\\\\\:\
: :: :. : ~ ~ ~ ;: : ~ :;:: ...
. :::,:::~~.~:::~\~'::',' ..
·;,L""ill \\ \
FIGURE 9
Paint the grille. Use thin coats of spray paint.
Do not block grille holes with paint.
Pinte
10 rejilla. Aplique monos delgadas de pintura aerosol.
No bloquee con pintura 105 agujeros de 10 rejilla.
Peinturez
10 grille. Appliquez des couches minces de peinture
aerosol. N'obstruez pas les trous de 10 grille de peinture.
Streichen Sie
den Gitteraufsatz. Verwenden Sie dazu dOnne
Spritzlackschichten. Die
OHnungen des Gitteraufsatzes dOrfen
nicht
mit Farbe bzw. Lack blockiert werden.
7 Get more information and exclusive accessories, visit www.polkaudio.com

INSTALLATION
Out of the box and into the wall, that's how
easy it is to install Polk Lei Series In-Wall
Loudspeakers.
If you intend to do the installation yourself
we recommend that you possess some skill
in the proper use of hand and power tools.
You should have a thorough understanding of
local building and fire codes and afamiliarity
with
the area behind the wall or ceiling into
which you plan to install your speakers.
Install speaker wires before installing speak-
ers. Wire meeting appropriate building and
fire codes must be used. Use at least 18
gauge wire or heavier for the utmost in sound
quality. Wiring is best performed by an expe-
rienced professional. If you are in doubt that
you possess the necessary skills or tools,
consult your Polk Audio dealer, or a profes-
sional installer.
TEMPLATE
FIGURE lOa
Rouncl Templare: Trace within the pop-out areo.
Planri/la recloncla: Marque clentro clel area que
se va aclesechar.
Gabarit roncl: Tracez
ci I'inrerieur clu gabarit.
Runcle Vorlage: Umranclen Sie clen
inneren,
gestanzten Teil cler Vorlage.
YOU WILL NEED:
• Pencil for marking the location
of installation
•
Keyhole saw, utility knife or material-
appropriate incising
implement for
cutting drywall or other wall material
•
Level
• Screwdriver, preferably powered,
with Phillips head bit
•
Power drill with appropriate bit
(optional, for starting wall cut)
TEMPLATE
FIGURE lOb
Rectangular Template: Trace arouncl the template.
Planri/la rectangular: Marque alrecleclor
cle 10 planri/la.
Gabarit rectangulaire: Tracez autour
clu gabarit.
Rechteckige Vorlage: Umranclen Sie clen QuBeren
Rancl cler Vorlage
mit einem
FIGURE l'
Cut the hole with the appropriate tool.
Haga
el corte con 10 herramienta apropiacla.
Taillez I'ouverture
avec I'outil approprie
Schneiclen Sie clie OHnung mit clem
entsprechenclen
Werkzeug aus.
For Customer Service, coil 800-377-7655. 8

FOLLOW THESE EASY STEPS:
• Make sure the material into which you plan
to mount the speakers (plaster, drywall,
paneling, stone, etc.) can support the
weight of the speakers (see specification
page for the weight of your model).
• Make sure the locations you select do not
conceal studs, electrical wiring or plumb-
ing. Prior to installation, hold the speaker
in your chosen location to make sure it
safely clears obstacles such as studs, cor-
ners, beams, lighting fixtures and door/win-
dow frames. Your cutout must be at least
1" (25mm) from adjoining walls or ceiling,
internal studs or plumbing.
• Using the template, trace the installation
location with a pencil. You can do this by
holding the template in your preferred
location and tracing around it. Use a level
to make certain the template is straight and
plumb. This is the exact cutout size.
[figures lOa &lOb]
•
Carefully cut the hole with the appropriate
cutting tool for your wall or ceiling material.
Start
the hole by drilling a hole on the inside
of the tracing (with the drill bit touching the
line). Use this hole to insert the saw or knife
and begin cu tting [figure 11].
•
Once you have cut the hole, fish your previ-
ously positioned wiring out of the hole and
connect the speaker. Follow the hookup
directions included with your receiver. Strip
Ih inch (12 mm) of insulation from each of
the two conductors of the wire to expose
the bare metal and twist each of the con-
ductors into a single unfrayed strand (so
you have two unfrayed strands). Note that
one of the terminals on the rear of each
speaker is red (+) and the other is black
(-). Make certain that you connect the wire
from the red terminal (+) of your amplifier
or receiver to the red terminal (+) on your
speaker and the wire from the black termi-
nal (-) of your amplifier or receiver to the
black terminal (-) on your speaker. Most
wire has some indicator (such as color-
coding, ribbing or writing) on one of the
two conductors to help you maintain
consistency [figure 12].
FIGURE 12
Hook up the speaker wires.
Conecte los cables de los altavoces.
Branchez les fils
de haut-parleur.
Schlie8en
Sie die lautsprecherkabel an.
9 Get more information and exclusive accessories, visit www.polkaudio.com

• To install the speaker, first carefully remove
the grille using astraightened paperclip or
other pointed metal tool. Insert the point
into one of the grille perforations near a
corner
and lift the grille free. Never use
a knife or screwdriver to pry between the
grille and the speaker frame. This will
damage your speaker.
• Loosen the rotating wall clamps by
unscrewing them. Make sure that the
rotating wall clamps are flipped inwards
so that your speaker fits into your cutout
without nicking your wall. Then place the
speaker carefully into the cutout [figure
13]. If you have a level, use it to help you
correctly align the speaker. Tighten the
wall clamp screws with a screwdriver. This
will rotate the wall clamps and secure the
speaker to the wall. Hint-on the LC265j
and LC65i models, tighten the center
screws before tightening the corners for
the most flush fit to your wall. Do not over-
tighten the wall clamp screws [figure 14].
FIGURE 13
Place the speaker carefully into the cutout.
Co/oque cuidadosamente el altavoz en el agujero.
Placez
delicatement Ie haut-par/eur dans I'ouverture.
Platzieren Sie die Lautsprecher vorsichtig
in der
ausgeschnittenen OHnung.
• Carefully reinstall the grille by fitting it into
its recess so that it is just resting on the
frame. Starting with one corner, go around
the speaker and push the grille into the
grille notch alittle bit at a time. Be gentle;
the grille may be easily bent out of shape
by rough handling. You will feel a positive
"snap" when it is fully in place. (Where's
the corkscrew?)
U'
FIGURE 14
Tighten reloining wall clamps to engage wall. Use a
#2 Phillips head screwdriver or a pawered screwdriver.
Apriete las prensas de retencion de la pared para
enganchar el allovoz ala pared. Use un destornillador
Phillips No. 20
un destornillador electrico.
Reserrez les attaches murales pour fixer solidement I'unite au
mur. Utilisez un tournevis ou une perceuse a tete Phillips no 2.
Iiehen Sie die Wandklemmen fest, um das System an der
Wand zu befestigen. Verwenden Sie dazu einen
Kreuzschlitzschraubendreher (Nr. 2) oder einen
Schraubendreher mit Motorantrieb.
For Customer Service, call 800-377-7655. 10
