Poly-Tex FB3020 User manual

ASSEMBLY INSTRUCTIO NS
IMPO RTA NT
Please read these instructions carefully before you start to
assemble this display. Save these instructions for future reference.
FB3020 v1.0.1

FB2810
BENCH END
(2)
FB2533
STABILIZER
(1)
RF2554
1'-6" x 6' BENCH TOP
(3)
RF2555
23" x 6' BENCH TOP
(1)
FT3600
NORSTAD CLIP
(8)
NB1924
THUMB SCREW
(8)
NB1901
3/8" WING NUT
(4)
NB1923
3/8" NYLON WASHER
(4)
No tools are required to assemble this product.

1. ATTACH STABILIZER TO BOTH
BENCH ENDS USING NYLON
WASHERS AND WING NUTS.
STABILIZER
BENCH END
BENCH END
2. SET BENCH TOPS ON ASSEMBLED
FRAME.
3. SECURE BENCH TOPS TO BENCH
ENDS USING NORSTAD CLIPS AND
THUMB SCREWS. SEE FIGURE 1
BENCH TOP
NORSTAD CLIP
BENCH END TUBE
FIGURE 1
USE CAUTION
DURING ASSEMBLY
PINCH HAZARD

GM4000
6'-1 1/2" BASKET PURLIN
(1)
FB2007
BASKET PURLIN
SUPPORT
(2)
NB1830
5/16" x 2 1/4"
CARRIAGE BOLT
(6)
ASSEMBLED FB3020
TRI-STEP DISPLAY
BASKET
PURLIN
SUPPORT
BASKET PURLIN
INSTRUCTIONS:
1. INSERT BASKET PURLIN
SUPPORTS INTO BENCH
ENDS.
2. ATTACH BASKET PURLIN
TO BASKET PURLIN
SUPPORTS USING 5/16"
x1"LONGCARRIAGE
BOLTS, LOCK WASHERS,
AND WING NUTS.
NB1901 - 6
NB1923 - 6

FB2004
CASTER ASSEMBLY
(2)
NB1924
THUMB SCREW
(4)
ONCE DISPLAY IS IN PLACE, ALL CASTERS
MUST BE LOCKED TO PREVENT MOVEMENT.
THE BRAKE IS ACTIVATED BY ROTATING THE
LEVER FROM THE "OFF" POSITION TO THE
"ON" POSITION.
INSTRUCTIONS:
1. ATTACH ADJOINING UNIT'S
STABILIZER AND BENCH END
TO THE EXISTING UNIT'S
BENCH END.
2. SET BENCH TOPS OVER-
LAPPING EXISTING BENCH
TOPS AS SHOWN BELOW.
3. SECURE CLIPS ONLY ON
END UNITS OF MULTIPLE
UNITS JOINED TOGETHER ( ).
BENCH TOP BENCH
TOP
BENCH END
BENCH SUPPORT
EXISTING UNIT
ADJOINING UNIT
STABILIZER
ADJOINING UNIT
BENCH END
EXISTING UNIT
BENCH END
END FRAME LEG
THUMB SCREW
CASTER RAIL
INSTRUCTIONS:
1. SLIDE CASTER RAILS INTO BOTTOM OF END FRAMES.
2. TIGHTEN THUMB SCREWS SECURELYTOLOCKINTOPLACE.

FB2811
BENCH END
(2)
FB2531
CANOPY PURLIN
(3)
FB1999
65 1/2" BASKET POST
(2)
FB2003C
19" BASKET POST
(2)
FB2002
U-BRACE
(2)
NB1830 - 6
NB1901 - 6
NB1923 - 6

ASSEMBLED FB3020
WITH FB2811 ENDS
19" BASKET POST
65 1/2" BASKET POST
CANOPY PURLIN
U-BRACE
INSTRUCTIONS:
1. INSERT 19" BASKET POSTS INTO REAR POCKETS OF BENCH ENDS.
2. INSERT 65 1/2" BASKET POSTS INTO FRONT POCKETS OF BENCH ENDS.
3. SLIDE U-BRACES ONTO BASKET POSTS.
4. ATTACH CANOPY PURLINS TO U-BRACES AND BASKET POSTS USING
5/16" x 2" LONG CARRIAGE BOLTS, LOCK WASHERS, AND WING NUTS.

FB2531
6'-1 1/2" CANOPY PURLIN
(3)
CANOPY
(1)
NB1830 - 6
NB1901 - 6
NB1923 - 6

INSTRUCTIONS:
1. ASSEMBLE TOWER FIRST (PAGE 7).
2. ATTACH CANOPY PURLINS TO U-BRACES AND BASKET POSTS USING
5/16" x 2" LONG CARRIAGE BOLTS, LOCK WASHERS, AND WING NUTS.
3. PLACE CANOPY OVER TOWER AND SECURE WITH VELCRO STRAPS.
U-BRACE
CANOPY PURLIN
65 1/2" BASKET POST
19" BASKET POST
ASSEMBLED FB3020
TRI-STEP DISPLAY
WITH FB2811 ENDS
CANOPY

FB2531
6'-1 1/2" CANOPY PURLIN
(3)
FB2812
BENCH END (1.66)
(2) FB2530
CANOPY BRACE
(2)
CANOPY "A"
(1)
NB1830 - 6
NB1901 - 6
NB1923 - 6

INSTRUCTIONS:
1. PLACE CANOPY BRACES INTO BENCH ENDS.
2. ATTACH CANOPY PURLINS TO CANOPY BRACES WITH 5/16" x 2 1/4" LONG CARRIAGE
BOLTS, LOCK WASHERS, AND WING NUTS.
3. PLACE CANOPY "A" OVER TOWER AND SECURE WITH VELCRO STRAPS.
CANOPY BRACE
CANOPY PURLIN
ASSEMBLED FB3020 WITH
FB2812 BENCH ENDS
CANOPY

Limited Warranty
Poly-Tex, Inc. warrants its products to be free from defects in material and workmanship for a
period of (1) year from date of invoice. This warranty is provided to the original purchaser of the
product and is not transferable. Poly-Tex does not warrant parts not manufactured by Poly-Tex,
but does assign any transferable manufacturer or supplier warranties. Should any defect be
found, full repair or replacement will be rendered to the customer at no cost following inspection
by a Poly-Tex representative and the return of the defective product to our Castle Rock, MN
factory. Expenses for removal or reinstallation of defective products will not be covered by the
warranty.
POLY-TEX SHALL NOT BE HELD RESPONSIBLE FOR ANY SPECIAL OR
CONSEQUENTIAL DAMAGES, OR FOR ANY DELAY IN PERFORMANCE OF THIS
WARRANTY BEYOND OUR CONTROL. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF
ALL OTHER WARRANTIES WHETHER IMPLIED,WRITTENORORALINCLUDINGTHE
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
This warranty does not cover damage from customer abuse, misuse, improper installation,
customer modifications, customer negligence in performing normal maintenance, damage
resulting from acts of nature.
Contact information
Poly-Tex, Inc. PO Box 458
27725 Danville Ave Castle Rock, MN 55010
Toll free [phone] Fax [phone]
www.poly-tex.com
Do not climb, sit on, or use this product as a ladder. Injuries may occur.
Do not place or install electrical items on this product. Wet conditions are typical and
electrical shock may occur.
Do not place this product on a slope that exceeds 3 degrees.
Do not move this display after product is in place. Damage to display and injuries may occur.
Lock casters (when provided) once display is in place to prevent movement.
Remove all debris or obstacles from caster's path before moving.
To remove loose soil and debris, simply spray the soiled areas with a garden hose.
Prior to storage, all surfaces of this product should be sprayed down with water and allowed to dry
completely.
