Poly-Tex FB3025-4 User manual

ASSEMBLY INSTRUCTIO NS
IMPO RTA NT
Please read these instructions carefully before you start to
assemble this display. Save these instructions for future reference.
FB3025-4 v1.0.0

FB2023
BENCH END
(2)
FT3600
NORSTAD CLIP
(4)
FT3200
STACKER CLIP
(4)
FB2539
STABILIZER
(1) NB1924
THUMB SCREW
(8)
RF2548
23" x 4' BENCH TOP
(2)
NB1901
WING NUT
(4)
NB1923
NYLON WASHER
(4)
RF2543
18" x 4' BENCH TOP
(1)
RF2547
12" X 4' BENCH TOP
(1)
No tools are required for the assembly of this product.

1. ATTACH STABILIZER TO
THREADED STUDS ON
BENCH ENDS USING NYLON
WASHERS AND WING NUTS.
2. SET BENCH TOPS IN PLACE.
3. SECURE UPPER BENCH
TOPS WITH STACKER CLIPS.
SEE FIGURE 1
4. SECURE LOWER BENCH
TOPS WITH NORSTAD
CLIPS. SEE FIGURE 2
BENCH TOP
NORSTAD CLIP THUMB SCREW
NORSTAD
CLIP
STACKER
CLIP
FIGURE 2
FIGURE 1
STACKER CLIP THUMB SCREW
BENCH TOP
STABILIZER
BENCH END
FLAT MATE - 4'
USE CAUTION
DURING ASSEMBLY
PINCH HAZARD
USE CAUTION
DURING ASSEMBLY
PINCH HAZARD

BENCH TOP BENCH TOP
BENCH END
BENCH SUPPORT
FIGURE 1
INSTRUCTIONS:
1. ATTACH ADJOINING UNIT'S STABILIZER AND
BENCH END TO THE EXISTING UNIT'S BENCH
END. SET BENCH TOPS OVERLAPPING EXISTING
BENCH TOPS AS SHOWN IN FIGURE 1.
FLAT MATE - 4'
SECURE CLIPS ONLY ON END
UNITS OF MULTIPLE UNITS
JOINED TOGETHER.
ADJOINING UNIT
STABILIZER
EXISTING UNIT
EXISTING UNIT BENCH END
ADJOINING UNIT
BENCH END

FB2044
CASTER RAIL
(1)
FB2026
BENCH END
WITH CASTER
(2)
CASTER RAIL
(FB2044)
BENCH END
WITH CASTER
(FB2026)
CASTER RAIL
THUMB SCREW
BENCH END LEG
ONCE DISPLAY IS IN PLACE,
ALL CASTERS MUST BE LOCKED
TO PREVENT MOVEMENT. THE
BRAKE IS ACTIVATED BY ROTATING
THE LEVER FROM THE "OFF"
POSITION TO THE "ON" POSITION.
INSTRUCTIONS:
1. SLIDE CASTER RAIL INTO
BOTTOM OF BENCH ENDS.
2. TIGHTEN THUMB SCREWS
TO LOCK INTO PLACE.

Limited Warranty
Poly-Tex, Inc. warrants its products to be free from defects in material and workmanship for a
period of (1) year from date of invoice. This warranty is provided to the original purchaser of the
product and is not transferable. Poly-Tex does not warrant parts not manufactured by Poly-Tex,
but does assign any transferable manufacturer or supplier warranties. Should any defect be
found, full repair or replacement will be rendered to the customer at no cost following inspection
by a Poly-Tex representative and the return of the defective product to our Castle Rock, MN
factory. Expenses for removal or reinstallation of defective products will not be covered by the
warranty.
POLY-TEX SHALL NOT BE HELD RESPONSIBLE FOR ANY SPECIAL OR
CONSEQUENTIAL DAMAGES, OR FOR ANY DELAY IN PERFORMANCE OF THIS
WARRANTY BEYOND OUR CONTROL. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF
ALL OTHER WARRANTIES WHETHER IMPLIED,WRITTENORORALINCLUDINGTHE
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
This warranty does not cover damage from customer abuse, misuse, improper installation,
customer modifications, customer negligence in performing normal maintenance, damage
resulting from acts of nature.
Contact information
Poly-Tex, Inc. PO Box 458
27725 Danville Ave Castle Rock, MN 55010
Toll free [phone] Fax [phone]
www.poly-tex.com
Do not climb, sit on, or use this product as a ladder. Injuries may occur.
Do not place or install electrical items on this product. Wet conditions are typical and
electrical shock may occur.
Do not place this product on a slope that exceeds 3 degrees.
Do not move this display after product is in place. Damage to display and injuries may occur.
Lock casters (when provided) once display is in place to prevent movement.
Remove all debris or obstacles from caster's path before moving.
To remove loose soil and debris, simply spray the soiled areas with a garden hose.
Prior to storage, all surfaces of this product should be sprayed down with water and allowed to dry
completely.
