Polygroup PoolBot User manual

User Guide
Simple steps to setting up and enjoying your pool pump
©2022
EN
Limited Warranty
Polygroup® makes products at the best quality we are able to offer. Polygroup is
pleased to offer warranty for the repair or replacement of pool products for 1 year
from the date of purchase. The provisions of this Limited Warranty only apply to the
original purchaser. Please keep your original store sales receipt, as this proof of
purchase will be required and must accompany warranty claims to Polygroup or its
designated agents. This Limited Warranty does not apply without proof of purchase;
or should the purchaser modify or repair the product themselves or by unauthorized
people; use non-Polygroup parts or accessories with the product; use the product in
contravention of the manufacturer’s instructions; use improper voltage; abuse the
product in any way; or through accident or negligence. This Limited Warranty will not
cover consequential damages, including claims for loss of water, pool chemicals,
damage, or labor, normal wear-and-tear; nor acts of God outside the control of
Polygroup. Non-manufacturing defects, such as grasses that may grow through the
ground cloth and/or pool liner are examples of which Polygroup cannot be held
responsible for.
In no event shall Polygroup, its authorized agents, related entities, or employees be
liable to the buyer or any other party for direct or consequential damages. Some
states or countries, or other jurisdictions, do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation or exclusion may not
apply to you.
This limited warranty is not extended to close-outs, factory seconds, or resold
products (i.e. garage sales, online auctions, or online retailers not purchased directly
from Polygroup). Any issues with items purchased from these types of vendors /
sellers will need to be addressed through these stores. Items purchased from
seasonal stores will be treated with an “All Sales Final” policy.
Sign up for future
offers and discounts.
Scan the QR Code.
09C3A4USAA16
PoolBot
BC

2
User Guide
Simple steps to setting up and enjoying your pool pump
©2022
EN
Limited Warranty
Polygroup® makes products at the best quality we are able to offer. Polygroup is
pleased to offer warranty for the repair or replacement of pool products for 1 year
from the date of purchase. The provisions of this Limited Warranty only apply to the
original purchaser. Please keep your original store sales receipt, as this proof of
purchase will be required and must accompany warranty claims to Polygroup or its
designated agents. This Limited Warranty does not apply without proof of purchase;
or should the purchaser modify or repair the product themselves or by unauthorized
people; use non-Polygroup parts or accessories with the product; use the product in
contravention of the manufacturer’s instructions; use improper voltage; abuse the
product in any way; or through accident or negligence. This Limited Warranty will not
cover consequential damages, including claims for loss of water, pool chemicals,
damage, or labor, normal wear-and-tear; nor acts of God outside the control of
Polygroup. Non-manufacturing defects, such as grasses that may grow through the
ground cloth and/or pool liner are examples of which Polygroup cannot be held
responsible for.
In no event shall Polygroup, its authorized agents, related entities, or employees be
liable to the buyer or any other party for direct or consequential damages. Some
states or countries, or other jurisdictions, do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation or exclusion may not
apply to you.
This limited warranty is not extended to close-outs, factory seconds, or resold
products (i.e. garage sales, online auctions, or online retailers not purchased directly
from Polygroup). Any issues with items purchased from these types of vendors /
sellers will need to be addressed through these stores. Items purchased from
seasonal stores will be treated with an “All Sales Final” policy.
Sign up for future
offers and discounts.
Scan the QR Code.
Contents
Welcome! .................................................................................................................................. 3
Warranty Information ............................................................................................................... 3
Safety Guidelines ......................................................................................................................
4
Warnings ....................................................................................................................
5
Before Your Begin ......................................................................................................................
6
Packing List ................................................................................................................
6
Product Diagram ......................................................................................................
6
Specifications ............................................................................................................
7
Setting Up the PoolBot ..............................................................................................................
7
Using the PoolBot ......................................................................................................................
8
Adjusting the Maneuvering Pattern .........................................................................
10
Maintaining the PoolBot ...........................................................................................................
11
Troubleshooting Guide ............................................................................................................
12

3
User Guide
Simple steps to setting up and enjoying your pool pump
©2022
EN
Limited Warranty
Polygroup® makes products at the best quality we are able to offer. Polygroup is
pleased to offer warranty for the repair or replacement of pool products for 1 year
from the date of purchase. The provisions of this Limited Warranty only apply to the
original purchaser. Please keep your original store sales receipt, as this proof of
purchase will be required and must accompany warranty claims to Polygroup or its
designated agents. This Limited Warranty does not apply without proof of purchase;
or should the purchaser modify or repair the product themselves or by unauthorized
people; use non-Polygroup parts or accessories with the product; use the product in
contravention of the manufacturer’s instructions; use improper voltage; abuse the
product in any way; or through accident or negligence. This Limited Warranty will not
cover consequential damages, including claims for loss of water, pool chemicals,
damage, or labor, normal wear-and-tear; nor acts of God outside the control of
Polygroup. Non-manufacturing defects, such as grasses that may grow through the
ground cloth and/or pool liner are examples of which Polygroup cannot be held
responsible for.
In no event shall Polygroup, its authorized agents, related entities, or employees be
liable to the buyer or any other party for direct or consequential damages. Some
states or countries, or other jurisdictions, do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation or exclusion may not
apply to you.
This limited warranty is not extended to close-outs, factory seconds, or resold
products (i.e. garage sales, online auctions, or online retailers not purchased directly
from Polygroup). Any issues with items purchased from these types of vendors /
sellers will need to be addressed through these stores. Items purchased from
seasonal stores will be treated with an “All Sales Final” policy.
Sign up for future
offers and discounts.
Scan the QR Code.
Warranty Information
This Funsicle PoolBot is designed and manufactured by Polygroup® Pacific Limited (hereinafter “Polygroup®”).
Polygroup is a global consumer goods leader with companies that design, manufacture and distribute
seasonal home décor and outdoor recreation products that inspire people to play more and celebrate
more. Learn more at Funsicle.com.
Welcome!
Congratulations on your new Funsicle PoolBot – cordless robotic pool cleaner. This guide will walk you
through everything from setting up to maintaining and enjoying your Poolbot.
As always, we’re here to help. For any issues, questions, or extra support, visit funsicle.com/support, or
contact Customer Service at 888-670-4FUN (888-670-4386) or [email protected].

4
• Read the user guide carefully, and use the PoolBot according to the instructions. We are not liable
for any losses or injuries caused by improper use.
• Only use the accessories recommended or sold by the manufacturer.
• This model only applies to swimming pools with a flat floor.
• Do not allow children to ride on the PoolBot or play with it as a toy.
• Use the original and authorized power adapter only.
• The adapter cord should only be repaired/replaced by a qualified electrician.
• Do not turn on the PoolBot when the pool has no water.
• The charging adapter must be connected to a leakage protected and earthed socket when
charging.
• Do not operate the PoolBot when there are people in the pool.
• Always clean and wash the filter screen after use.
• Turn off the PoolBot when maintaining, cleaning or when it is not in use.
• The PoolBot should be stored in a cool and ventilated place, away from direct sunshine.
• While charging, the PoolBot should be kept in a cool place, and not be covered with anything to
prevent the damage of internal electrical components caused by overheating.
• Only certified professionals can disassemble the sealed driving kit of the PoolBot.
• Do not operate the PoolBot while pool filter is running.
• Oil seals for motor contain grease, which may cause water pollution if grease leaks occur.
• Due to the limitation of battery capacity, the PoolBot is only suitable for swimming pools with size
up to 500 ft2 (46.4 m2), otherwise the cleaning effect will be affected.
• When the PoolBot is stored for a long period of time, it should be charged every three months time
to maintain battery life between 40%-60%. Please use the original and authorized power adapter
only. If the PoolBot is not charged for a long time, the battery voltage will be lower than the
over-discharge protection voltage due to the self-discharge of the battery, which may cause fatal
damage.
• Do not use or store the PoolBot near any heat source.
• Do not pierce the exterior of the PoolBot with nails or other sharp objects. Do not hammer, impact
or throw the PoolBot.
• Do not bury the cord. Locate the cord to minimize abuse from lawn mowers, hedge trimmers, and
other equipment.
• Ensure that children do not attempt to access the PoolBot while it is operating.
• Only use the charger provided.
Safety Guidelines
IMPORTANT SAFETY INSTRUCTIONS
When installing and using this product, basic safety precautions should always be followed, including
the following:
READ AND FOLLOW ALL INSTRUCTIONS
Keep this User Guide for future reference. Failure to follow these warnings and
instructions can result in serious injury or death to users, especially children.

5
Warnings
• To reduce the risk of injury, do not permit children to use this product unless they are closely
supervised at all times.
• To reduce the risk of electric shock, replace damaged cord immediately.
• To reduce the risk of electric shock, do not use extension cord to connect unit to electric supply;
provide a properly-located outlet.
FCC Notices
WARNING: Changes or modifications to this unit not approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment causes harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Charger Model: XSG1261000US
POLYGROUP SERVICES N.A. INC.
303 SW 16th Street, Suite 5, Bentonville, AR, 72712, USA
SAVE THESE INSTRUCTIONS

6
Packing List
Quantity
1
1
1
2
1
1
2
Item
PoolBot
Charger
User Guide
Scraper
Flipper
Retrieving Hook
Screws (packed with the user guide)
Before You Begin
Charger Retrieving Hook
Flipper
Top Cover
Filter Screen
Chassis
Scraper
The environmentally-friendly PoolBot is a new type of rechargeable automatic cleaner that filters the pool
water and gets rid of suspended particles without replacing the pool water.
Before assembling your PoolBot, check the contents and become familiar with all the parts.
Product Diagram

7
Setting Up the PoolBot
Before first use
1. Attach the flipper and fix it with the screws provided.
• Model: P56000F24
• Output voltage of adapter: 12.6 V DC
• Rated input voltage of adapter:
100 V AC - 240 V AC
• Battery runtime: Approximately 45 minutes
• Charging time: 3 - 4 hours
• Battery capacity: 2600 mAh
• Maximum cleaning surface: 500 ft2(46.4 m2)
• Optimal pool water temperature:
50°F - 95°F (10°C - 35°C)
• Charging environment temperature:
41°F - 95°F (5°C - 35°C)
• Maximum pool depth: 6 ft (1.8 m)
• Size: 13" L x 13" W x 9" H
(330 mm L x 330 mm W x 230 mm H)
• Weight: 7.3 lb (3.3 kg)
• Storage condition:
41°F - 95°F (5°C - 35°C), RH <75%
Flipper
Nozzle
Power Button
Charging
Socket
Lock Latch
Specifications

8
Using the PoolBot
1. Charge the battery
Fully charge the PoolBot before each use. Attach the charging connector to the charging socket
at the bottom of the PoolBot. Place the PoolBot in its upright position and then, plug in the charger.
The indicator lamp on the charger shall turn red when charging. It should turn green once fully
charged.
NOTE: The PoolBot must be charged indoor.
Power
Button
Charging
Socket
LED Indicator
Red - Charging in Progress
Green - Fully Charged
2. Optional: Install the scrapers to enhance suction effect if the pool floor is full of debris or particles.
It is not recommended to install the scrapers if the pool bottom is uneven or full of pits. That avoids
the PoolBot from getting stuck by the rough floor.
3. Attach the retrieving hook to a standard 1¼ inch diameter pool pole (not included).

9
2. Purge out the air
Hold the PoolBot with two hands and submerge it into the pool. Rotate the PoolBot until no air
bubble is coming out.
3. Turn on the power
While keeping the entire PoolBot underwater, switch on the product by pressing the power button
located at the bottom. Water will begin to flow out from the nozzle.
4. Deploy the PoolBot
Orient the PoolBot in its upright position and slowly release the product. The product shall slowly
sink to the pool floor. In case the PoolBot is flipped upside down, use the floating handle to correct
its orientation.

10
5. Let it clean
The PoolBot shall run around the pool floor and vacuum the debris automatically for about 45
minutes until it runs out of battery and stops.
6. Retrieve the PoolBot
To retrieve the robot, grasp the flipper and pull it out of the water and away from the pool. Use the
retrieving hook if needed.
Adjusting the Maneuvering Pattern
1. This PoolBot comes with 4 wheels: 2 wheels are fixed and 2 wheels are adjustable. By modifying the
combination of these 2 adjustable wheels, it will change the maneuvering pattern of the PoolBot.
2. To adjust the wheel, open the lock latches and remove the top cover. Locate the 2 adjustable
wheels. Detach the wheel by pushing the wheel stem catch. Select the correct combination and
insert the wheel until the catch clicks.
Adjustable Wheels
Fixed Wheel
Wheel Stem
Sleeve
Wheel Stem Catch

11
1. Open all lock latches, detach the top cover and remove the filter screen.
2. Rinse off all the dirt and debris with running water. Use mild dish detergent if necessary.
3. Wipe the PoolBot with a clean cloth and let it air dry.
3. Combinations:
B – A Maximum maneuvering (Factory setting, ideal for round above-ground pool)
B – C Smaller rebounding angle than B – A
C – A Smaller rebounding angle than B – C
C – C Minimum maneuvering (For rectangular or longer pool)
Combination B-A
Maintaining the PoolBot

12
Troubleshooting Guide
Issue Scenario Possible Cause Solution
The PoolBot does not
change direction
(rebound) when
hitting the pool wall.
The flipper does not flip
pward when approaching
the pool wall.
- - - -
- - - -
- - - -
The buzzer does not
beep when removed
from water.
The PoolBot does not
vacuum the entire
pool floor.
No power output from the
wall outlet
The PoolBot keeps bouncing at
the same direction, some
areas are always missed.
Check the power with a
multimeter or another
appliance. Seek help from a
licensed electrician.
The flipper is stuck and does
not turn freely.
The LED indicator does
not light up when the
charger is plugged in.
The pool’s pump filter
system is on.
Water current inside the pool
affects the maneuvering of
the PoolBot.
Battery level is low
Faulty charger
Try different maneuvering
patterns. Refer to the
“Adjusting the Maneuvering
Pattern" section in the
user guide.
Turn off the pool’s filter pump
when using this product.
Recharge the PoolBot.
Improper maneuvering
pattern setting
Irregular pool shape
Call customer service
and request for a
replacement charger.
Hose off the dirt around the
hinge of the flipper. Make sure
the flipper turns freely.

[This page is intentionally left blank.]

[This page is intentionally left blank.]

[This page is intentionally left blank.]

Dear Funtastic Customer,
Thank YOU for choosing one of our Funsicle
products. We’re on a mission to inspire the
world to play more outdoors, which is why
we design products that capture the
summertime spirit of imagination,
connection and fun.
It’s important to us that you have the BEST
experience with this product, and we’re
excited for you to make some happy
outdoor memories.
Need a helping hand? Use the contact info
on this page to reach us.
Once again, we thank you for placing your
trust in us. Happy swimming and playing!
- Your friends, the Funsicle Team
CONTACT US
We’re here to help! For answers to common
questions, setup videos and troubleshooting tips,
visit funsicle.com/support or scan the QR code.
DO NOT RETURN PRODUCT TO STORE.
If you encounter any issues with your Funsicle
product, do not return it to the place of purchase.
Contact CUSTOMER SERVICE:
Phone: [phone]FUN (888-670-4386)
Email: [email protected]
WARRANTY
For warranty information, visit
funsicle.com/warranty.
NEED PARTS?
To order parts and accessories, visit funsicle.com.
REGISTER YOUR PRODUCT
Scan the QR code
Distributed by:
Polygroup Pacific Limited
Unit 606, 6th Floor, Fairmont House,
No.8 Cotton Tree Drive, Central, Hong Kong.
