Polypipe Ufh4zw User manual

Model: UFH4ZW

Wiring Centre2

UFH4ZW – Installation Manual

Description

The UFH4ZW isan4 Zone & Hot water wiring centre for use with Polypipe

230v thermostats.

The UFH4ZW can be used to control any actuator or valve which requires

a 230v AC signal to open. For mid position valves and those requiring

a closing signal, a changeover relay is required. At the same time the

UFH4ZW oers the ability to operate a boiler or other heat source through

a volt free output.

An additional output designed for use with underoor heating

systems, is also included as standard. This is the pump/valve Output,

which would normally operate a manifold pump or a manifold valve.

The H/W output provides a 230v hot water enable signal to the valve,

the auxiliary wires of the valve are wired to the Gr & Or terminals.

Zone 4 can be used as an isolated radiator zone by using the

Yes/No switch.

If the switch is set to NO;

When zone 4 calls for heat this will provide an output to a radiator

zone valve and the boiler but WILL NOT enable the underoor heating

pump/valve output.

If the switch is set to YES;

When Zone 4 calls for heat, this will act as an underoor heating zone,

by enabling the actuator, boiler and pump/valve outputs.

Any output which is not needed can be ignored.

3Model: UFH4ZW

Installation

The UFH4ZW can be mounted directly to a wall using four screws or

alternatively, the unit can be DIN rail mounted.

WhenDIN Rail mounting, you rst need to insert the two clips

provided on the back of the UH4, as shown in the image;

• On the back of the UFH4ZW, position the clip in the middle

and slide down.

• Points A and B locate in the corresponding holes and

lockinto place.

• Locate the UFH4ZW onto the DIN rail from the top.

• Pull the clip down and push the bottom of the UFH4ZW onto

the DIN rail.

• Releasing the clip will lock the UFH4ZW in place on the DIN rail.

To remove the UFH4ZW, pull both clips down and remove from the DIN rail.

Insert clip here.

Then Slidedown to lock in place.

Wiring Centre4

H/W

This output is used to control a hot water valve via a cylinder

thermostat

L = Live

E = Earth

N = Neutral

Gr = Grey

Or = Orange

The auxiliary wires of the valve, usually grey & orange, are wired to the

Gr & Or terminals.

Zones 1…4

Zones outputs are clearly marked

L = live out to actuator or valve

N = neutral to actuator or valve

There are two connections live (L)and neutral (N), both terminals

marked L are the same and both terminals marked N are the same.

Each zone output corresponds to the thermostat wired in at the

top of the pcb.

Connections

Mains Supply

Power supply into the UFH4ZW which should be fused at 5 amps these

connections are marked

L =live or phase 230v AC 50/60Hz

N = Neutral

E =Earth

Heat Enable

This is the main call for heat for the system, there are 3 connections;

LS = Live Supply

E =Earth

LR = Live Return

Electrically this is a volt free switch, whatever supply is placed on the

LS connection, is fed to the LR connection when there is a call for heat.

UFH4ZW Wiring

5Model: UFH4ZW

Manifold Pump/Valve

Connections are clearly marked

L =Live

E =Earth

N = Neutral

the live & neutral output will supply 230v to the manifold pump/valve.

It is recommended that this is fed through a high limit switch placed

on the heating manifold, to protect against mechanical failure of the

manifolds temperature control.

Fuses

Fuse 1.5amp, 20mmanti-surge fuse, thisfuse supplies

power to all 230v outputs from the board itprotects the zone,

pump/valve outputs.

Used for an underoor heating manifold pump and or valve.

When an under-oor heating zone sends a call for heat to the UFH4ZW,

Wiring Centre6

MANIFOLD PUMP

OR VALVE

BOILERPOWER

HEATENABLE

MAINS

SUPPLY

BOILER

ENABLE

MAINS

ELS LR E

UFH

5A FUSE

LS AND LR

VOLT FREE

UFHVALVE

Wiring UFH4ZW to SmartStat – 3 x Underoor Heating, 1 x Radiator zone & Hot Water.

(Manifold Valve & Pump connections)

This equipment should be installed by an appropriately

Fully read the instructions for proper wiring before applying power.

The warranty does not cover damage from improper wiring

or installation.

EARTH

END SWITCH AND

BOILER ENABLE

UFM UNDER FLOOR MANIFOLD

LIVE

SWITCH LIVE

NEUTRAL

PUMP

THREE CORE AND

EARTH 1.5 CABLE

RADIATOR TIMER

NNNNN --- -1A1A1A1A-A1 2TR2TR2TR2TR 1TR1TR1TR1TR2TR 2A2A2A2A1TRA2 LLLLL

UFH

NEO STAT

UFH

NEO STAT

UFH

NEO STAT

RADIATOR

NEO STAT

TIMER

NEO STAT

7Model: UFH4ZW

ZONE 2 ZONE 3 HOT WATER VALVEZONE 4ZONE 1

ZONE 4 MANIFOLD PUMP CONTROL SWITCH

SELECT YES FOR UNDERFLOOR HEATING

AND NO FOR ALL OTHER SYSTEMS

NNNNN

NN NNN

--- -1A1A1A1A-A1 2TR2TR2TR2TR 1TR1TR1TR1TR2TR 2A2A2A2A1TRA2

LSLS SLSLSL

ZONE 3 HOT WATERZONE 4ZONE 2ZONE 1

LLLLL

EE EELLE LLL

LLLL LLLL N

LGR

NNNN N

YES

NNN OR

LNN

ZONE 2ZONE 2

ZONE 1

VALVE WITH

ENDSWITCH

HOT WATER STAT

HOT WATER VALVE

UFH

RADIATOR

VALVE

SmartStat

UFH UFH

NOTE

THE HOT-WATER VALVE LIVE FEED MUST BE

CONNECTED THROUGH THE CYLINDER HIGH

LIMIT THERMOSTAT

ACTUATORS

230V

ACTUATORS

230V

ACTUATORS

230V

SmartStat SmartStat SmartStat SmartStat

Wiring Centre8

N SLL

ZONE 2

ZONE 1

ACTUATORS

230V

ACTUATORS

230V

UFH UFH

UFHDIALW

HEAT ENABLE

MAINS

SUPPLY

BOILER

ENABLE

UFH PUMP

THREE CORE AND

EARTH 1.5 CABLE

5A FUSE

LS AND LR IS

VOLT FREE

MANIFOLD PUMP

OR VALVE

BOILER

POWER ZONE 1

ZONE 1

MAINS

LEN

LEN SL

LLN N

ZONE 2

LEN SL

LLN N

LEN

LS ELR

UFH4ZW – Polypipe 230v Thermostat Wiring

This equipment should be installed by an appropriately

Fully read the instructions for proper wiring before applying power.

The warranty does not cover damage from improper wiring

or installation.

EARTH

END SWITCH AND

BOILER ENABLE

UFM UNDER FLOOR MANIFOLD

LIVE

SWITCH LIVE

NEUTRAL

qualied/registered electrician.

N SLL

UFHDIALW

RADIATOR

VALVE

9Model: UFH4ZW

ZONE 4 MANIFOLD PUMP CONTROL SWITCH

SELECT YES FOR UNDERFLOOR HEATING

AND NO FOR ALL OTHER SYSTEMS

-2A A1RT2

RT1 RT1

A1 A2

YES

ZONE 2

VALVE WITH

ENDSWITCH

HOT WATER STAT

HOT WATER VALVE

RADIATOR

VALVE

NOTE

THE HOT-WATER VALVE LIVE FEED MUST BE

CONNECTED THROUGH THE CYLINDER HIGH

LIMIT THERMOSTAT

ACTUATORS

230V

UFH HEATINGHOT WATER

SmartStat

ZONE 3

LEN SL

LLN N

ZONE 4

LEN SL

LLN N

HOT WATER

HOT WATER VALVE

LEN SL

LEN GR OR

Ratings

Numberof Heating Zones 4

Numberof Hot Water Zones 1

Neon Indication Y

DIN Rail Mounting Y

Supply230v AC 50Hz 1 Phase

Relay Load Max 3 Amp Resistive

Total Load Max 5 Amp Resistive

IP ProtectionIP20

Installed Dimensions (L,H,D) 384 x 148 x60mm

Weight 800g

UFHPROGW

- A1RT2 RT1 A2 L

SmartStat

Wiring Centre10

System Conguration PLEASE COMPLETE DURING INSTALLATION

UFH4ZW Title:

In Use Zone Type Zone Title

Under-Floor Radiator

Zone 1

Zone 2

Zone 3

Zone 4

Hot Water

11Model: UFH4ZW

Notes

............................................................................................................................................................................................................................................................................................................................................
