PondMAX 02PS015 User manual

SOLAR BATTERY
BACKUP (INCL BATTERY)
INSTRUCTION MANUAL
DATE
OCT 2021 v1.0
MODEL
02PS015
www.pondmax.com.au
PMAX Solar Battery Backup Instructions.indd 1PMAX Solar Battery Backup Instructions.indd 1 5/10/21 11:54 am5/10/21 11:54 am

PONDMAX.COM.AU
TECHNICAL SPECIFICATIONS
Description
PART NUMBER 02PS015
LEAD ACID BATTERY 12V, 7AH
CHARGING VOLTAGE 12V-24V
OUTPUT VOLTAGE 12V-24V
MAXIMUM INPUT POWER 20W
MAXIMUM OUTPUT POWER 12W
SIZE 19 X 15 X 12.5CM
NET WEIGHT 2.95KG
CABLE LENGTH 5M
• Do not connect the solar battery backup to any
AC voltage power for charging; it is ONLY for
DC voltage power.
• Do not leave this battery backup in bad
weather conditions or a bad ambient
environment.
• Do not leave the battery backup in direct
sunlight or expose it to extreme heat or cold
temperatures.
• Do not expose this battery backup system to
water.
IMPORTANT SAFEGUARDS
Please read these instructions and familiarize yourself with the equipment before placing it in service. Correct and safe
use of the system requires strict compliance with the safety instructions. For safety reasons persons less than 16 years
of age or people that are not familiar with these instructions should not use this equipment.
WELCOME TO THE WORLD OF PONDMAX™.
YOU MADE THE RIGHT CHOICE INVESTING IN THIS
QUALITY PRODUCT. THANK YOU AND ENJOY.
BEFORE USING THIS PRODUCT, PLEASE READ THESE INSTRUCTIONS CAREFULLY AND MAKE
YOURSELF FULLY FAMILIAR WITH THE UNIT. PLEASE KEEP THESE INSTRUCTIONS IN A SAFE PLACE
FOR FUTURE REFERENCE.
PMAX Solar Battery Backup Instructions.indd 2PMAX Solar Battery Backup Instructions.indd 2 5/10/21 11:54 am5/10/21 11:54 am

SOLAR BATTERY
BACKUP UNIT (INCL BATTERY)
PONDMAX.COM.AUPONDMAX.COM.AU
DESIGN HIGHLIGHTS
• This Solar Battery Backup is designed to store solar energy for the PondMAX Solar Pump Kits and has
enough charge to run pump for 3-4 hours on its own.
• 1 Year Warranty
• The battery backup has built-in overcharge protection.
• LED indicator lights provide the working status of the battery backup.
• The output voltage can be adjusted in the range of 12V-24V, for optimal pump performance.
INSTALLATION AND MAINTENANCE
INSTALLATION AND MAINTENANCE
1. Connect the “INPUT” cable from the battery backup, to the solar panel (provided separately with
solar pump kit) and tighten the threaded connection.
2. Make sure the pump is fully underwater prior to operation.
3. Insert the pump cable to the “OUTPUT” socket of the battery backup, and tighten the threaded
connection.
4. Press the switch on the battery backup to the “System On” position. The green LED should then
illuminate and the solar pump should start to operate. However the red LED may illuminate while it
operates for the first time, if the battery lost charge while in inventory. In this case the battery will
need to be charged for 2 to 3 hours while the solar panel is in direct sunshine, then the green LED
should illuminate to indicate that battery is charged and the pump will begin to work.
5. The pump will automatically stop running when the battery runs out of charge and the red LED
should illuminate.
6. The pump will automatically resume running when the battery is recharged to its starting voltage and
the green LED illuminates.
7. If you want to have longer operating time in the evening, then press the switch on the battery backup
to the “System O” position during the day and press to “System On” position whenever you need it.
Note: The battery will be always charge when the solar panel is in the sunlight no matter whether the
switch is on “System On” or “System O” position! The system will automatically cut o the charging
current when the battery reaches maximum charging capacity (fully charged).
If after a period of time the RED indicating light is always illuminated, and the pump does not operate
even though the solar module is in full sunlight, please troubleshoot per the below possible failures:
• Bad or no connection to the solar module-check connection to the solar module.
• The battery is out of its service life and needs to be replaced.
PMAX Solar Battery Backup Instructions.indd 3PMAX Solar Battery Backup Instructions.indd 3 5/10/21 11:54 am5/10/21 11:54 am

Please consult your retailer for quality original PondMAX replacement parts.
Visit wwwpondmax.com.au for your nearest stockists. E.&O.E.
LIMITED WARRANTY
• This product is warranted to the initial
purchaser to be free of defects in materials
and manufacture workmanship at the time of
initial purchase and for a period of 1 year after.
Some parts are consumable (e.g. battery) and
may need to be replaced as part of ongoing
product maintenance and are not covered by
this Warranty. In the event this unit malfunctions
within 1 year from the date of purchase, the sole
obligation of PondMAX™ (hereinafter referred
to as PondMAX™) will be to repair the unit
or replace with an equivalent new or factory
refurbished unit at PondMAX’s discretion,
subject to the following condition:
• The malfunction is proved attributable
to a defect in materials or manufacture
workmanship, including repairs performed
under this warranty. Malfunction for any other
reason including but not limited to misuse,
negligence, accident, or tampering with parts,
incorrect wiring, or improper installation-will not
be remedied under this warranty.
• PondMAX™ specifically does not guarantee
chemical compatibility, and expressly does not
warrant units from any problems caused by
chemical attack or failure due to incompatibility
of fluid used near this aeration system.
• All warranty repairs must be performed
by PondMAX™ or a PondMAX™ authorized
company.
• Purchaser must retain the purchase receipt
and present it with this certificate as proof of
ownership and entitlement to warranty repairs.
Unauthorized repairs will not be compensated
by PondMAX™, and are not the responsibility
of PondMAX™, and if such repairs damage the
product, such damages are not remedied under
this warranty.
• Purchaser shall bear all onsite labor, shipping,
packing and insurance costs and all other costs,
excluding in house labor and parts necessary to
eectuate repairs under this warranty.
• This warranty is in lieu of all other express
warranties which now or hereafter might
otherwise arise with respect to this product.
Any and all limited warranties, including the
warranties of merchantability and fitness
for particular purpose, shall have no greater
duration than the duration period of the express
written warranty applicable to this product, and
shall terminate automatically the expiration of
such duration period.
• Some states do not allow limitations on how
long an implied warranty lasts, so the above
limitation may not apply to you. No action shall
be brought for breach of any implied or express
warranty after one year subsequent to the
expiration of the duration period of the express
written warranty.
• Incidental and consequential damages caused
by malfunction, defect, or otherwise, and
with respect to breach of any express or
implied warranty, are not the responsibility
of PondMAX™, and, to the extent permitted
by law, are hereby excluded for property
damage, loss of livestock and, to the extent not
unconscionable, for personal injury damage.
Some states do not allow the exclusion or
limitation of incidental or consequential
damages, so the above limitation or exclusion
may not apply to you.
• This warranty does not apply to any
malfunction arising out of any application of
this product other than normal use, unless
such application is upon request specifically
approved in writing by PondMAX™.
• The provisions of this warranty are severable
and if any provision shall be deemed invalid, the
remaining provisions shall remain in full force
and eect.
• Rights under this warranty are not assignable
without the express prior consent in writing by
PondMAX™ and, regardless of the terms of such
consent in writing, such assignee shall have
no greater rights than his assignor had against
PondMAX™.
