Poniie PN-G100 User manual

User Manual
Model No.: PN-G100
DUAL POWER
60/100W
AC 100~240V/50~60Hz
HEAVY DUTY
Thank you for purchasing the Dual Power Glue Gun by Poniie. Please read
this manual carefully before using this product.

1. Constant Temperature & Quick Preheating.Built with high-tech ceramic
PTC heater and electronically self-regulating system.
2. Compact & Solid Housing. Made of 100% heat-resistant materials.
3. Built-in Safety Fuse. With build-in fuse to prevent over-heat and can be
used from AC 100V to 240V.
4. Dual Power 60/100W. Make working task easy and flexible.
5. Adjustable Gun Nozzle. Unique nozzle design in combination with the
ergonomic trigger enable to control glue flow rate much easier.
6. All-in-one Heat Body. Integrated light weight body is more durable and has
a longer lifespan.
1. Silicone Sleeve 2. Lead Wire 3. Sealing Stopper
4. Aluminum Chamber 5. Heating Chamber 6. Adjustable Nozzle
7. Ceramic PTC Heater 8. Integrate Plastic-Aluminum 9. Glue stick
Warning
To avoid electric shock or personal injury, read the “Safety Information”
carefully before using the Glue Gun.

1.Be sure to read, understand and comply with all the instructions in this manual.
2. Before using this product, check to see if there is any crack or short of
plastic parts on the shell. Please do not use the product if it is damaged.
3. Do not touch the nozzle area and melted glue, because they are under high
temperature when working. Any direct body touch is prohibited.
4. Supervise children. Ensure that children do not play with the glue gun.
5. Do not use it at any flammable or explosive circumstance.
6. Do not raise the gun high or leave the nozzle upward when in working. The
glue gun shall be positioned on its stand when not in use.
7. Do not abuse of inappropriate glue sticks that might lead to reverse flow of
melt adhesive or cause damage.
8. Put the gun at a dry and ventilated place instead of humid or wet condition.
○
1E APreparation Work
--Check workspace and walkways to ensure no slip and safe circumstance.
--Long and loose hair must be contained when operating this glue gun.
--Ensure the correct size glue stick is selected.
--Insert a 0.43'' (diameter) glue stick into the gun hose from the rear.
A
○
2E APower on /off
Directly plug the glue gun into the power supply socket, and it will start to
work; disconnect the power supply to shut down.

Note: Slight smoke may appear after power on glue gun for the first time. This does
not indicate any problem. After a few minutes, the smoke should auto disappear.
○
3E APreheat Stage
After power on, you need to wait a few minutes for glue gun to heat up:
---3~5 minutes on 100wsetting
---6~8 minutes on 60w setting
Highly recommended: For shorter preheat time on the 60w setting, preheat on the
100w setting for the first 3 minutes then switch it back to 60w.
A
○
4E AAdjust Glue Flow
--After preheat, pull the trigger and squeeze, the melt adhesive will come out.
When a glue stick becomes too short to squeeze, please add a new one at the
rear to continue.
--When the nozzle is properly heated, you can use a spanner to adjust flow rate.
--Loose the tip to get a faster flow rate and tighten to limit a slower flow.
Note: Flow rate also depends on the trigger propulsion. Do not leave the
switched-on glue gun unattended. Please plug off the gun if it is not used for more
than 20 min, otherwise, the adhesive might flow inversely and damage the gun.
IMPORTANT:
1. Please DO NOT try to adjust the nozzle when it is completely cooled down,
otherwise, it may cause an inner damage of the nozzle. Always use a tool to adjust
the nozzle, any direct body touch is prohibited.
2. Please DO NOT loose off the tip completely, otherwise, you may need a heat
gun to reinstall the nozzle, since the glue will firm up after cooled down.

3. Please DO NOT try to pull out the remained stick at the end of use, otherwise,
it may damage glue gun severely. The remainder can be used directly next time.
1. Repair a leak or crack as waterproof material in bucket, rain gutter, etc.
2. Adhere or joint two work pieces when repair furniture, fix electrical wire,
install floors, fix toy and model, etc.
3. Seal cartons or any other packages.
4. Applicable for different surfaces, such as wood, plastics, foam, fabrics,
paper, cardboard, ceramics, etc.
•1 x PN-G100 Professional Glue Gun
•1 x User Manual
The warranty period for quality related issues of this product is one year. If the
device does not operate properly or has any other faults, please always feel free
to contact Poniie Customer Service at any time. We will provide you with best
service and do our best to help you out.
