Porcher 89050 Programming manual

800012-100
- 1 -
Roughing-in Dimensions
NOTE: • DIMENSIONS SHOWN FOR LOCATION OF SUPPLIES AND "P" TRAP ARE SUGGESTED.
INTRODUCTION
Thank you for selecting our Porcher product.To ensure that your installation
proceeds smoothly, read these instructions carefully before you begin. Also,
review the recommended tools and materials section. Carefully unpack and
examine your new plumbing fixture.
ALL INSTALLATION PROCEDURES MUST COMPLY IN STRICT ACCORDANCEWITH APPLICABLE LOCAL
PLUMBING AND BUILDING CODES
Stanza Cabinet 89050
ASSEMBLY & INSTALLATION
INSTRUCTIONS
Most of the procedures require the use
of common tools and materials, which
are available from hardware and
plumbing, supply stores.It is essential
that the tools and materials be on hand
before work is begun.
Adjustable Wrench
Channel Locks
Regular Screwdriver
Phillips Screwdriver
10'
Pipe Wrench
Putty Knife
Drill
Saber Saw
Level
Basin Wrench
Plumbers' Putty or
Caulking
Tubing Cutter
Tape
Measure
Hacksaw
To maintain the beauty of the finish, avoid placing the furniture in direct sunlight, as sunlight causes fading. Also avoid
extreme changes in temperature by arranging furniture away from radiators, heat and air vents, and air conditioning units.
Avoid placing furniture directly under windows.
Tools and Materials Required
DEPTH WITH DRAWER OPEN 24"
41-1/2"
(1054mm)
FINISHED WALL
21-1/4"
(540mm)
3-1/4" (83mm)
8-1/2"
(216mm)
8"
(203mm)
1-3/4" DIA.
STD. DRAIN
OUTLET
13-3/4"
(349mm)
3-1/4"
(83mm)
★ 22"
(559mm)
★ 20"
(508mm)
4" (102mm)
1-1/4" O.D.
WASTE
SUPPLIES AS
REQUIRED
1-1/4" O.D.
TAILPIECE
FINISHED
FLOOR
37-1/8"
(943mm)
✭ 1-1/4" X 7/8" (32 X 22mm)
LAVATORY ANCHOR
SCREW HOLES (4)
2-3/4"
(70mm)
7-1/2"
(191mm)
1-1/2"
(38mm)
41-1/2" (1054mm)

800012-100
- 2 -
C/L of 2 x 6
Reinforcement
Finished
Floor
*
Suitable reinforcement is required for anchoring the
vanity and sink to the wall. Determine horizontal
centerline location " *" of support from fixture. (see
Figure 1)
If molding is present, either notch the molding to seat the
vanity flush against the wall or provide suitable spacer.
(see Figure 2)
Rough in supply lines and waste per rough in dimensions.
NOTE: If current supply lines are greater than 4" on
center, they may interfere with cutout in rear of vanity or
vanity shelf.
Move the vanity into place and anchor it to the wall
through at least 2 of the mounting holes in the rear
of the vanity. The glides can be adjusted outward up to
3/4" but it is recommended not to exceed 1/2" if possible.
Continue with installation appropriate for top and sink
options chosen.
VANITY INSTALLATION
FIGURE 1
MOLDING
ADJUSTABLE GLIDES
(LOCATED UNDER
EACH FOOT)
SPACER
FIGURE 2
C/L
C/L
22-3/4"
(578mm)

800012-100
- 3 -
Two people recommended for this
installation
Install faucet and drain in accordance with
manufacturer's instructions. Be certain to apply
a bead of sealing putty on the underside of the
drain (Part "A") in order to ensure a watertight
seal between the sink and drain. Remove
excess putty after installing the drain on the
sink.
Apply a 1/4" bead of silicone adhesive to the rim
of the vanity as shown.
Place the Sonnet top centered left to right on
the vanity and with the back edge of the top
even with the rear of the vanity. Clean up any
excess silicone.
After top is replaced, connect the trap to the
drain assembly hand tight to check alignment.
It may be necessary to cut off part of the
tailpiece (area "B") or part horizontal leg of the
trap (area "C").
Connect hot and cold supply lines to the shut off
valves. Tighten trap joints for watertight
assembly.
BC
INSTALLING THE RIVIERA TOP (20301)…
A
Shut-Off
Valves

800012-100
- 4 -
Care and Cleaning of Vanity
Clean the product by using soft, slightly damp cloth. Buff the product by using a soft dry cloth. Avoid using silicone
cleaners and waxes.
Clean up excess water and spills immediately. Use a blotting rather than a wiping action. Water left over a long
period of time will cause white spots in the finish.
NOTE: Please note that some chemicals may damage the finish. Take care to avoid the following: iodine, hair dye,
after shave lotion, shaving cream, alcohol, perfume, Lestoil®, Lysol Tub and Tile Cleaner®, Lysol Spray Disinfectant®,
Dow Disinfectant®, acetone, paint remover, Formula 409®, Tile-X®, and Nair®.
To maintain the beauty of the finish, avoid placing the furniture in direct sunlight, as sunlight causes fading. Also avoid
extreme changes in temperature by arranging furniture away from radiators, heat and air vents, and air conditioning
units. Avoid placing furniture directly under windows.
PORCHER FURNITURE LIMITEDWARRANTY
If inspection of this Porcher plumbing product, within one year after its initial purchase, confirms that it is defective in materials or
workmanship, Porcher will repair or, at its option, exchange the product for a similar model.Variations in actual wood color and
finishes which may result from natural characteristics of the wood, such as grain patterns, mineral streaks and the like, are not
defects and are not covered by this warranty.
This warranty applies only to the original purchaser and installation of these products.In the event of a claim, proof of purchase
will be required; save your receipt.
This limited warranty does not apply to local building code compliance. Since local building codes vary considerably, the
purchaser of this product should check with a local building or plumbing contractor to insure local code compliance before
installation.
This warranty is void if the product has been moved from its initial place of installation; if it has been subjected to faulty
maintenance, abuse, misuse, accident or other damages;if it was not installed in accordance with Porcher’s instructions; or if it
has been modified in a manner inconsistent with the product as shipped by Porcher.
Porcher’s option to repair or exchange the product under this warranty does not cover any labor or other costs of removal or
installation, nor shall Porcher be responsible for any other incidental or consequential damages attributable to a product defect or
to the repair or exchange of a defective product, all of which are expressly excluded from this warranty. This limited warranty does
not cover any liability for consequential or incidental damages, all of which are hereby expressly disclaimed, or the extension
beyond the duration of this limited warranty of any implied limited warranties, including those of merchantability or fitness for an
intended purpose.(Some states or provinces do not allow the exclusion or limitation of implied warranties, so this exclusion may
not apply to you).
This warranty gives you specific legal rights. You may have other statutory rights that vary from state to state or province to
province, in which case this warranty does not affect such statutory rights.
