PortKeys HS7T User manual

IT8U
TIFO[IFO!QPSULFZT!FMFDUSPOJD!UFDIOPMPHZ!DP/-MUE

HS7T HS7T1 2
Parameter
Product appearance size Standard accessories
EXIT Dvtupn!gvodujpo
lfzt
Power Switch
Fyufoe!Joufsgbdf
Tmjejoh!nfov
倗wpmvnf,0.倛
JOQVU
ED!qpxfs
Bvejp!ifbeqipof
pvuqvu
IENJ
TEJ VTC!vqhsbefф
qpsu
2:1nn
235nn
31nn
7”
Operating temperature range: 0 ℃ ~ 40 ℃
Size
Dimension
Viewing Angle
Brightness(nit)
Resolution
Contrast Ratio
Weight
Color
Backlight
Material
Input Voltage
Power Consumption
Signal input
Signal output
Headphone
Menu Language
7"
190x124x20mm
178°H/178°V
1200
1920X1200
1200:1
300g
8bit（16.7M Color）
LED
ABS Engineering Plastics
DC 7 ~24V
11W
3G/HD/SD-SDI、4K HDMI、HDMI、USB
3G/HD/SD-SDI、4K HDMI、HDMI
Output
简体中文/English
Screen Cleaning Wipe X1
7" Matte Glass Screen Protector X2
D-Tap cable to 4-Pin Female
Headphone Cable x1
HS7T Monitor X1
Pocket X1
U Disk X1
-
+OUT
+IN
Picture Size: 7 inch
Resolution: 1920X1200
Luminance: 1200 nits
Color: 16.7M
Operating Volts:DC 7~24V
HDMI Input/output: 480i/p 576i/p
720p 1080i/p 2160p
3G-SDI Input/Output: 480i/p 576i/p
720p 1080i/p
TEL：[phone]www.pkscorp.com

HS7T HS7T3 4
【MAIN】
Off/80%/90%/15:9/1.33:1/
1.5:1/1.85:1/2:1/2.35:1/Custom
Guides Press MENU, Then
[Guides]
User
Aspect
Wide
Height
Back
Press MENU
Press MENU, Then
Press MENU, Then
Press MENU, Then
50~100
50~100
User/Full/16:9/15:9/
1.33:1/1.5:1/1.85:1/2:1/2.35:1
Back
Brightness
Contrast
Chroma
Sharpness
Tint
Color Temperature
Backlight
Manual
Red
Green
Blue
Back
0~255
0~255
0~255
H（Custom）
V（Custom）
Guide Masks
Crosshair
Grids
Back
1%～100%
Off/On
1%～100%
Off/On
1/2/3/4/5/6/7/8/9/10/Off
Press MENU
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
0～100
0～100
0～100
0～100
5600K/6500K/7500K/9300K/Manual
Low/Middle/High
0/10/20/30/40/50/60/70/80/90/100
[Video Config]
Press MENU, Then User/Full/16:9/15:9/
1.33:1/1.5:1/1.85:1/2:1/2.35:1
Aspect
Supported input resolution and frame rate
SDI Signal
1920×1080p@50fps,59.94fps,60fps
1920×1080p@50Hz,59.94Hz,60Hz YUV422
1920×[email protected],24Hz,25Hz,29.94Hz,30Hz YUV444/YUV422/RGB444
1920×[email protected],24Hz,25Hz,29.97Hz,30Hz YUV444/YUV422/RGB444
1920×1080i@50Hz,59.94Hz,60Hz YUV444/YUV422/RGB444
1280×720p @50Hz,59.94Hz,60Hz YUV444/YUV422/RGB444
720×480i @59.94Hz YUV422
720×576i @50Hz YUV422
HDMI Signal
4096×2160p@24Hz
3840×[email protected],24Hz,25Hz,29.97Hz,30Hz
1920×[email protected],24Hz,25Hz,29.97Hz,30Hz,50Hz
1920×[email protected],24Hz,25Hz,29.97Hz,30Hz
1920×1080i@,50Hz,59.94Hz,60Hz
1280×720p@50Hz,59.94Hz,60Hz
720×576p&720×576i@50Hz
720×480p&720×480i@50Hz,59.94Hz,60Hz
Supported output resolution and frame rate
SDI Signal
1920×1080p@50fps,59.94fps,60fps
1920×1080p@50Hz,59.94Hz,60Hz YUV422
1920×[email protected],24Hz,25Hz,29.94Hz,30Hz YUV444/YUV422/RGB444
1920×[email protected],24Hz,25Hz,29.97Hz,30Hz YUV444/YUV422/RGB444
1920×1080i@50Hz,59.94Hz,60Hz YUV444/YUV422/RGB444
1280×720p @50Hz,59.94Hz,60Hz YUV444/YUV422/RGB444
720×480i @59.94Hz YUV422
720×576i @50Hz YUV422
HDMI Signal
4096×2160p@24Hz
3840×[email protected],24Hz,25Hz,29.97Hz,30Hz
1920×[email protected],24Hz,25Hz,29.97Hz,30Hz,50Hz
1920×[email protected],24Hz,25Hz,29.97Hz,30Hz
1920×1080i@,50Hz,59.94Hz,60Hz
1280×720p@50Hz,59.94Hz,60Hz
720×576p&720×576i@50Hz
720×480p&720×480i@50Hz,59.94Hz,60Hz
TEL：[phone]www.pkscorp.com

HS7T HS7T5 6
5Sec/10Sec/15Sec/20Sec/25Sec/30Sec/Off
Low/Middle/High/Off
Press MENU, Then
Press MENU, Then
Press MENU, Then
[System Config]
OSD-Language
OSD-Duration
OSD-Transparancy
Menu Setup
System Reset Press MENU Are you sure? Yes/No
Press MENU, Then
Press MENU, Then
Low Battery ALM
Back
Off/On
Press MENU
Display Flip Mode
H Flip
V Flip
Osd Flip Mode
H Flip
V Flip
Back
Off/On
Off/On
Off/On
Off/On
Off/On
Off/On
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Flip Control
User1/User2/User3/User4/User5
TEL：[phone]www.pkscorp.com
Function 2（Same function 1）
Function 3（Same function 1）
Function 4（Same function 1）
Back
Function 1 Press MENU
*Audio Meters
5D II Rec
*Pixel To Pixel
Brightness*
Contrast*
Chroma*
Sharpness*
Tint*
Color Temperature*
Aspect*
Backlight*
Display Flip
Osd Flip
Check Field*
H/V Delay*
*Guides*
*Cross Hair
*Grids*
*Peaking
*Programmable False Color
*Clip Guide
*UnderScan
DSLR Scaling*
*Histogram
*Easy to Zoom in/out
[Function Setup]
[Firmware]
Firmware Ver HS7T-V1.01.18
Press MENU
Press MENU Are you sure? Yes/No
Press MENU, Then
Version Information
Update (USB)
Back
Please pay attention to the official website (www.pkscorp.com) update the latest firmware!
*Note: Set these functions in the
custom shortcut function key,
long press in 3 seconds to display
the menu of this function.
* Note: Continuous click on the
button, you can cycle switch.
* Note: Click on the button and
toggle the wheel to adjust
parameters.
简体中文/English
*LUT file could be stored repeatedly,to delete,please enter the user storage interface and delete it
by the above steps.LUT file format Cube，support16/17/32/33/64/65 precision (LUT_3D_SIZE).
Copied the cube format LUT file to the U disk, then insert it to HS7T USB interface.
Press MENU Press MENU
Press MENU
Press MENU
Press MENU
Press EXIT
USB Looks 3D LUT
USB drive
Return
EXIT
Press MENU
Press MENU
Stored from
USB
Select LUT fileStored LUT configuration
Back
Apply 3D LUT mode and it will be
saved automatically to "user storage"
+
[LUT Config]
)Offet!up!cf!qfsgpsnfe!jo!uif!tubuf!pg!bddftt!tjhobm*
Back
LUT File Deletion
Ztf0Op
Hold the MENU Delete
Are you sure?
Press MENU
Stored from
USB
Stored LUT configuration

HS7T HS7T7 8
Long press in 3 sec set "Guides" onto one custom function key
[Guides Setting]
Off/80%/90%/15:9/1.33:1/
1.5:1/1.85:1/2:1/2.35:1/Custom
1%-100%
1%-100%
0~50
Off/On
White/Red/Green/Blue/Black
Guides
H（Custom）
V（Custom）
Color
Thickness
Guide Masks
Exit
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Long press in 3 sec set "Cross Hair" onto one custom function key
[CrossHair Setting]
0%~100%
0%~100%
On/Off
White/Red/Green/Blue/Black
Crosshair
Color
X Offset
Y Offset
Exit
Press MENU, Then
Press MENU, Then
Press MENU, Then
Press MENU, Then
Grids
Color
Exit
[Grids Setting]
Off/1/2/3/4/5/6/7/8/9/10
White/Red/Green/Blue/Black
Long press in 3 sec set "Grids" onto one custom function key
Press MENU, Then
Press MENU, Then
Red/Green/Blue/Black/White
[Peaking Setting]
Long press in 3 sec set "Peaking" onto one custom function key
Factor
Color
Exit
1/2/3/4/5/6/7/8/9/10
Press MENU, Then
Press MENU, Then
Under Warn
Over Warn
Tooltip
Exit
85～110
-10～15
Press MENU, Then
Press MENU, Then
Press MENU, Then Off/On
*Shortcut keys (hidden menu operation) Operation：
[Exit]
-240~+240
-240~+240
Middle/L+T/R+T/R+B/L+B/User
[Pixel To Pixel Setting]
Long press in 3 sec set "Pixel To Pixel" onto one custom function key
Position
X Offset
Y Offset
Exit
Press MENU, Then
Press MENU, Then
Press MENU, Then
The resolution of the input signal is different and the offset value changes.
Long press in 3 sec set "Audio Meters" onto one custom function key
On/Off
[Audio Meters ]
Audio Meters
Position
Blending
Exit
0~100
Top/Left/Division/Right/Bottom
Press MENU, Then
Press MENU, Then
Press MENU, Then
TEL：[phone]www.pkscorp.com
[False Color Setting]
Long press in 3 sec set"False Color"onto one custom function key

HS7T HS7T910
This manual is prepared based on the software version installed at the factory. With the
continuous upgrade of the software, the software operation after the upgrade may be
different from the book, and it will be changed without further notice,please have your
understanding.
Long press in 3 sec set "Clip Guide" onto one custom function key
[Clip Guide Setting]
On/Off
85～110
-10～15
Under Warn
Over Warn
Tooltip
Exit
Press MENU, Then
Press MENU, Then
Press MENU, Then
[UnderScan Setting]
Long press in 3 sec set "UnderScan" onto one custom function key
Exit
Fator 50～100
Press MENU, Then
Long press in 3 seconds "MENU" button to display the custom function
key and image configuration information
Position
X Offset
Y Offset
Middle/L+T/R+T/R+B/L+B/User
-480~+480
-270~+270
Press MENU, Then
Press MENU, Then
Press MENU, Then
The resolution of the input signal is different and the offset value changes.
Ratio
H:
V:
Exit
User/X1.5/X2/2.5/X3
X1.01~x3.00
X1.01~x3.00
Press MENU, Then
Press MENU, Then
Press MENU, Then
[Histogram Setting]
On/Off
Small/Large
R+B/L+B/L+T/R+T
Position
Size
Transparent
Exit
Press MENU, Then
Press MENU, Then
Press MENU, Then
Long press in 3 sec set "Histogram" onto one custom function key
TEL：[phone]www.pkscorp.com
[Zooming Setting]
Long press in 3 sec set "Zooming" onto one custom function key
