Portronics SCANNY 4 User manual

SCANNY 4 Manual
1. Key features
Color /Monochrome (Mono) scan selection
600/300 dpi scan selection
Directly save JPG or PDF file to micro D/micro DHC card
upports micro D/micro DHC card up to 32GB
Color LCD Display
Driver free to download for Windows® XP, Windows® Vista™,
Windows® 7 and Mac O ® 10.4 or above
(direct plug-in, driver installation not required)
2. Functional parts
Part
Function
1 Battery
door For 2x AA alkaline batteries
2
Power On/ Off: Press and hold this key for 2
seconds to turn power on or off. In power on mode,
press this button to start scan, press this button
again to stop
3 can LED
indicator Ready for scan: Green LED on
4 Error LED
indicator Over speed: Red LED on
5 LCD
screen canning status display
6 UP/DOWN
In MENU mode: Press UP/DOWN buttons to
navigate the setup menu.
In PREVIEW mode: Preview NEXT or PREVIOU
image file.
In ZOOM Mode: Navigate upper and lower area of
the image file.
Press MENU/OK/RIGHT button to enter MENU
setting mode.
In ZOOM mode: Move to view right side of the
image file.
8
Press PREVIEW/LEFT button to enter PREVIEW
mode. Press again to select ZOOM options.
In ZOOM mode: Move to view left side of image file.
9 U B
interface
Download photo to a computer via U B cable
provided.
10 micro D
card slot micro D card storage location.
3. Explanation of the status icons
Item Function Description
1 D card indicator Photos will be stored in micro D card
2
Counting indicator how scanned files in micro D card
3
Battery indicator Battery is full Empty battery
4
elected resolution Fine : 900 DPI High:600 dpi / Low:300 dpi
5
Effect indicator Color or Mono
4. LED light indications
5. Using the scanner
5.1 Installing the battery
1. Open the battery door by sliding the battery compartment downwards as
indicated by the arrow in the diagram below.
2. Insert 2x AA alkaline batteries into the battery compartment.
3. Turn on the scanner by pressing the [POWER] button for 2 seconds
5.2 Inserting a microSD memory card (not included)
To operate the scanner, you must insert a micro D Card (not supplied) to
record and store your pictures. Inserting the micro D memory card:
1. Turn ON the scanner.
2. Insert the micro D card into the micro D card slot (with metal
side facing upwards). Gently press in until card is clicked in and
latched. The D card indicator must appear on the LCD
screen.
Note: Do not force the card into the slot; forcing may damage scanner and
the micro D memory card. Align micro D card position (as marked)
and try again.
Note: The micro D memory card must be formatted before scanning.
(Attention: all data which saved in Micro D card will be deleted after
formatting, and can’t be recovered) Please refers 5.3.6 for detail.
5.3 MENU Setup mode
1. Press [MENU] button to enter MENU etup
2. Press [POWER/ CAN] button to exit MENU mode
5.3.1 QUALITY setting
1. Press [MENU] button to enter MENU etup
2. Press UP/DOWN buttons to select QUALITY
3. Press [OK] to enter QUALITY mode
4. Press UP/DOWN buttons to select options: High resolution
(600dpi)/ Low resolution (300dpi)
5. Press [OK] to confirm
6. QUALITY setting will be saved and will exit to return to the
previous Menu etup screen
5.3.2 COLOR setting
1. Press [MENU] button to enter MENU setting mode
2. Press UP/DOWN buttons to select COLOR
3. Press [OK] to enter COLOR mode
4. Press UP/DOWN to select options: Color/Mono (black and white
scans)
5. Press [OK] to confirm
6. COLOR setting will be saved and will exit to return to the
previous Menu etup screen
5.3.3 TIME setting
1. Press [MENU] button to enter MENU etup
2. Press UP/DOWN buttons to select TIME ETUP
3. Press [OK] to enter TIME ETUP mode
4. Press UP/DOWN buttons to set the YEAR
5. Press [OK] to set the MONTH  DAY  HOUR  MINUTE 
ECOND
6. After setting the date and time, press [OK] to save and exit to
return to the previous Menu etup screen
5.3.4 AUTO POWER OFF setting
1. Press [MENU] button to enter MENU etup
2. Press UP/DOWN buttons to select AUTO POWER OFF
3. Press [OK] to enter AUTO POWER OFF mode
4. Press UP/DOWN buttons to select options: 1Min/ 3Min/ 5Min/Off
5. Press [OK] to confirm
6. AUTO POWER OFF setting will be saved and will exit to return to
the previous Menu etup screen
5.3.5 DEFAULT Setting
1. Press [MENU] button to enter MENU etup
2. Press UP/DOWN buttons to select DEFAULT
3. Press [OK] to enter DEFAULT mode
4. Press UP/DOWN buttons to select DEFAULT options: Yes/No
5. Press [OK] to confirm
6. DEFAULT setting will be saved and will exit to return to the
previous Menu etup screen
5.3.6 FORMAT the microSD memory card
Note: All contents on the micro D card will be erased during formatting.
All manuals and user guides at all-guides.com
all-guides.com

1. Insert a micro D card into the scanner with metal side facing
upwards
2. Press [MENU] button to enter MENU etup
3. Press UP/DOWN buttons to select FORMAT
4. Press [OK] to enter FORMAT mode
5. Press UP/DOWN buttons to select FORMAT options
a. YE : To FORMAT and erase contents in micro D card
b. NO: To exit FORMAT mode and return to previous Menu
setup screen
6. Press [OK] to confirm selection and return to Menu etup screen
5.3. DELETE FILE setting
1. Press [MENU] button to enter MENU etup
2. Press UP/DOWN buttons to select DELETE FILE
3. Press [OK] to enter DELETE FILE mode
4. Press UP/DOWN buttons to select DELETE FILE options:
a. DELETE ONE: To delete last image scanned
b. DELETE ALL: To delete all files on micro D card
5. Press [OK] to confirm selection and return to Menu etup screen
5.3.8 Software VERSION
To view scanner’s version number:
1. Press [MENU] button to enter MENU etup
2. Press UP/DOWN buttons to select VER ION
3. Press [OK] to confirm selection to display version number
4. Press [MENU] to exit and return to Menu etup screen
5.4 How to calibrate the scanner
Note: Perform calibration only when white balance needs adjustment
1. With the dry cleaning cloth provided, clean the scanning lens
located on the bottom of the scanner.
2. Turn on the scanner by pressing the [POWER] button. Place the
scanner on the white area of the White Balance Calibration paper
provided.
3. Press and hold the UP button. While holding the UP button,
press the [POWER] button and then release both buttons to
enter into auto-calibration mode. D symbol will flash and
then stop. “GREEN” and “RED” LED light will turn on.
4. Do not move the scanner. Wait until the “RED” LED turns off.
“GREEN” LED will stay on.
5. With only the “GREEN” LED light on, start scanning the white
paper by sliding the scanner across the paper until the “GREEN”
LED light turns off. ( lide the scanner backwards if necessary).
6. Press and hold the [POWER] button to power off the scanner.
Calibration is complete.
5.5 How to scan
Note: To scan, make sure your scanner is not connected to the
computer.
1. Turn on the scanner by pressing the [POWER/ CAN] button for
2 seconds.
2. Hold the document firmly with one hand on a flat surface.
3. Place the scanner on the edge of the paper approximately 5/8 to
3/4 of an inch onto the page to ensure the whole document can
be scanner. Make sure to keep the scanning area in between the
scanning width indicators marked on the side of the scanner.
4. Hold the scanner flat against the material and then press the
[ CAN] button once.
5. lide the scanner slowly, keeping your hand stable to get the
best quality picture.
6. Press the [ CAN] button again to stop scanning.
5.6 How to PREVIEW image
1. Press [PREVIEW] button to enter picture PREVIEW mode.
2. Press UP/DOWN buttons to preview previous image
3. Press [PREVIEW] button again to adjust ZOOM rate
(x1/x2/x4/x8)
4. Press [OK] to confirm selected zoom rate
5. Press UP/DOWN or LEFT/RIGHT to view image in zoom mode.
6. To exit PREVIEW mode press the [ CAN] button once
5. Viewing your scan on a computer
1. Connect your scanner to your computer and then turn on your
scanner.
2. Your computer should recognize the scanner as a “Removable
Disk.” Click “Open folder to view files” to view and import scans.
NOTE: If the Removable Device window did not launch automatically, go to
your “My Computer” (PC) and find the device under Removable
torage.
6. Specifications
Image sensor Color Contact Image ensor
Resolution
Fine Resolution : 900 DPI
High resolution: 600 dpi(default)
Low resolution : 300 dpi
Color mode Color mode (default)
Black & white mode
Maximum scanning
speed for A4 size
document
Color High resolution: 12.0 econds
Mono High resolution: 8.0 econds
Color Low resolution: 5.0 econds
Mono Low resolution: 3.0 econds
Capacity (Based on
1GB micro D card.
can A4 size file,
the quantity of scans
varies depending on
the content complexity)
600dpi color: 220 Photos(Min.)
600dpi mono: 290 Photos(Min.)
300dpi color: 780 Photos(Min.)
300dpi mono: 1280 Photos(Min.)
can width Approx. 8.35"
Approx. can length 300DPI: 46.5"(Max), 600DPI: 24.2"(Max)
File format JPEG and PDF
LCD canning status display
Auto Power Off 1mins, 3mins (default), 5mins, off,
U B Port U B 2.0 high speed
External memory micro D Card
tandard Battery 2XAA alkaline batteries
. Computer system minimum requirement
Operating ystem
Windows® XP, Windows® Vista™, Windows® 7 and
Mac O ® 10.4 or above
(direct plug-in, driver installation not required)
CPU Pentium II or above
RAM 64MB
Interface U B port
8. Troubleshooting
Problem
Cause
Solution
Cannot turn on the
scanner
1.
Low battery power.
2. Battery not inserted
properly
1.
Replace or install
the battery correctly
Pictures cannot be
saved when you are
scanning them
1. m
ic
ro D card has not
been installed
2. Memory is full
3. The micro D card has
not been formatted
properly
1. Install micro D card
.
Refer to ection 5.2
2. Download the
pictures from the
scanner to the
computer to create
storage space
3. Format the micro D
card. Refer to
ection 5.3.6
Computer does not
recognize scanner
when connected. (You
cannot find
removable disk)
Connection failure.
1.
Make sure all cable
connections are
secured. Restart the
computer if
necessary
The battery life is
very short
Use wrong type of
battery
1.Replace with new
2x AA alkaline
batteries
Blurry images
1
.
ca
nner sensor
protective glass is dirty
2. Contact Image ensor
aged.
1.
Clean the sensor’s
protective glass
with clean, soft
cloth.
2. Re-calibrate the
scanner
LED ERR.
i
s on after
power on
C
alibration
data i
s off set
1.
Re
-
calibrate the
scanner. Refer to
ection 5.4
ERR. LED is on when
scanning a document
canning speed is too
fast
1.Press the
Power/ can button
to reset and scan th
e
document again
AM-POR440-GB- TD-1
