POSIFLEX PD-6807U User manual

PD-6807U/6807R
Package Contents
7” Rear-Mount Customer Display
with Bracket (x 1)
3-10L Self-Tapping Screw (x 4)
USB Cable for PD-6807U (x 1)
RS-232 Cable for PD-6807R (x 1)
User Manual (x 1)
Product Features
OPOS application support
7” graphical customer line display
TFT LCD panel with resolution up to 800 x 480
Adjustable font and background color
JPEG graphics display support
Support to 13 code pages, each having 128 characters
Support to 12 international character sets, each having 12 characters
Slide show and screen saver support
Command emulations support: ADM, Aedex, ESC/POS, Futaba,
Noritake, UTC
Powered through the USB or COM port
Virtual COM port supported for USB interface
Rear-mount for PS-3000 series terminal
PD-6807U/6807R
Rear-Mount Customer Display
User Manual
19520905020 Ver. A0
1

Views of the PD-6807U/PD6807R
Front View
Rear View
Bottom View of PD-6807U
Bottom View of PD-6807R
Screw Holes
TFT LCD Panel
USB Port
DC-IN Power Jack
(Reserved)
USB Port
RJ45 Port
2

Mounting the Rear-Mount Display onto a POS Terminal
This section provides step-by-step instructions to assist you in installing
PD-6807U/6807R to PS-3000 series POS terminal. As a reminder,
please ensure that your POS terminal is completely shut down before
proceeding with installation of PD-6807U/6807R.
1. Remove the rear I/O cover of your
PS-3000 series POS terminal.
2. Insert the USB or RS-232 cable into the POS terminal.
For PD-6807U model, align the A type connector of the USB
cable with the USB port of your POS terminal; for PD-6807R
model, have the RJ50 connector of RS-232 cable with a label
describing “To Host” attached to RJ50 port of the POS terminal.
PD-6807U
PD-6807R
3. Align the four screw holes of the
customer display bracket with the four
screw holes on the rear side of the POS
terminal.
Align
To Host
3

4. Fix the bracket to the terminal using the
four screws.
5. Insert the USB or RS-232 cable into the customer display.
For PD-6807U model connect the B type connector of USB cable
to the USB port of the customer display; For PD-6807R model,
attach the RJ45 connector of the RS-232 cable with a label
describing “To PD” to RJ45 port of the customer dispaly.
PD-6807U
PD-6807R
6. Tilt the customer display all the way
down. Be careful not to touch the LCD
panel whiel tilting the screen.
7. Break the tab for cable exit from the rear I/O cover by using a
diagonal cutting nipper.
To PD
4

8. Tuck the extra cable into the rear I/O
compartment.
9. Before putting the rear I/O cover back
into place, make sure the cable can be
threaded through the cable exit as shown
in the figure.
10.Press down the cover to close the rear
I/O compartment.
11.Make sure that the customer display is
well mounted onto the POS terminal.
12.Adjust the customer display up and down in the direction shown
by the arrow to the desired angle.
Cable Exit
Do NOT press the displaying area of panel!
5

Installing the Virtual COM Driver for PD-6807U
Refer to the following steps for the driver installation.
1. Connect the USB cable of PD-6807U to your POS terminal.
2. Locate the “SA_PD_LM” folder from
the “Drivers” folder in the Local Disk
(C:) of your POS terminal
3. You will find the “USB_VCOM”
folder and double click it.
4. Then double click the
“USB_VCOM_v519bx” folder.
5. In the folder, double click the PDF
named USB VCOM Drivers
Installing Guide to open.
6. Then, refer to this installation guide to complete the driver
installation.
Setting up the PD-6807U Customer Display
POS Graphics Display Tool is a helpful tool designed to assist PD-
6807U users in managing the customer display settings according to
your personal preference. To start with the tool, you will need to access
the executable file, GraphicsDisplay_Setup Tool.exe, under the
directory
C:\Drivers\ SA_PD_LM\ GraphicsDisplay_Setup Tool\. As for the
more detailed instructions on the operation of the tool, please refer to
the file named by PD6X07 Setup Tool Guide.pdf in the same directory.
Before using the tool to configure the display, determine that you have
installed the Microsoft .NET Framework 3.5 or above. Also, to avoid
users from damaging the main board of the display, it is highly
recommended that the configuration is implemented by professional
technicians.
6

Specifications
PD-6807U
PD-6807R
LCD Panel 7" TFT LCD
Surface Treatment
(Up Polarizer) Anti Glare
Language Code Support PC437/PC850 (Western Euro)/PC860 (Portuguese)/
PC863 (Canadian, French)/PC865 (Nordic)/
PC866 (Cyrillic2)/PC864 (Arabic)/PC858 (Euro)/
PC737 (Greek)/W1257 (Baltic)/W1253 (Greek)/
PC857_Turkish/PC775 (Baltic)/PC855 (Cyrillic)/
W1254_Turkish/W1255 (Hebrew)/
W1251 (Cyrillic)/PC862 (Hebrew)/W1252 (Latin)/
PC852 (Latin)/JIS (Japanese)/BIG5 (Traditional Chinese)/
GB2312 (Simplified Chinese)
Number of Characters 40 characters x 12 rows max. for Alphanumerical characters
20 characters x 12 rows max. for Chinese characters
Dot Matrix / Resolution 800 x 480 display resolution
Display Color Font: Red / Green / Blue / Yellow / Orange / White / Black
Background: Black / White / Blue
Multimedia Support JEPG graphics support
JEPG Graphics Size
4MB for each (max.) / 90MB for total (max.)
Active Area 154.08 (H) x 85.92 (V)
Pixel Pitch 0.1926 (H) x 0.1790 (V)
Pixel Configuration RGB Vertical Stripe
Color Depth 16.7M
Viewing Angle 60/70/70/70 degree (U/D/L/R)
Contrast Ratio 500 : 1
Response Time 25 ms (Raising) / 25 ms (Falling)
Brightness
250 cd/m2
Display Interface
USB
RS232
Power Supply Powered by standard USB
ports Powered by standard COM ports
Dimensions 124 mm (H) x 188 mm (W) x 80 mm (D)
Environmental Operation temperature: 0ºC ~ +50ºC
Operating humidity: 20% to 85%, non-condensing
Storage temperature: -10ºC ~ +70ºC
Storage humidity: 5% to 90%, non-condensing
7
