Positron Teleline 750003 Operating and installation instructions

Teleline™
Wall-Mount Power Supply Chassis model 750003
Description and Installation
925W751051-02E

Contents
Chapter 1 – General Information
1.1 Publication Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
1.2 About this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Related Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Positron Products and Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3 Service and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Technical Customer Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Customer Training. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Repair Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.4 Teleline Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Limitation of Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cancellation and Rescheduling Charges . . . . . . . . . . . . . . . . . . . . . . . 11
Chapter 2 – Overview
2.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2.2 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Input/Output terminal block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Power Supply/Battery Back-up terminal block . . . . . . . . . . . . . . . . . . . 18
Input fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Ground lug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Ground jumper setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.3 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Chapter 3 – Installation
3.1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
3.2 Chassis Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
3.3 Earthing Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Wall-Mount Power Supply Chassis model 750003
3.4 Input Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.5 Chassis Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
24 V systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
48 V systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Adding redundancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Adding Battery Back-up to a 24 V system . . . . . . . . . . . . . . . . . . . . . . . 30
Adding Battery Back-up to a 48 V system . . . . . . . . . . . . . . . . . . . . . . . 30
Appendix A – Acronyms
Acronyms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Chapter 1
General Information

6
Wall-Mount Power Supply Chassis model 750003
1.1 Publication Information
© 2012 Positron Inc.
Wall-Mount Power Supply Chassis model 750003
Description and Installation Guide
Part number: 925W751051-02E
Publication date:
May 1, 2012
Published By
Positron Inc.
5101 Buchan Street, Suite 220
Montreal, Quebec, Canada
H4P 2R9
Telephone: US and Canada: 1-888-577-5254
International: 1-514-345-2220
Trademarks
Teleline is a trademark of Positron Inc.
Product names, other than Positron’s, mentioned herein may be trademarks and/or registered
trademarks of their respective companies
Confidentiality Notice
The information contained in this document is the property of Positron Inc. Except as specifically
authorized in writing by Positron Inc., the holder of this document: 1) shall keep all information
contained herein confidential and shall protect same in whole or in part from the disclosure and
dissemination to all third parties, and 2) shall use same for operating and maintenance purposes only.
Disclaimer Notice
Although Positron Inc. has made every effort to ensure the accuracy of the information contained
herein, this document is subject to change without notice.

7
About this Guide
1.2 About this Guide
This guide introduces you to the Wall-Mount Power Supply Chassis model
750003, its features and applications, and describes how to install it. This guide
was designed to be read from beginning to end.
1.2.1 Related Documentation
The other guides in the Teleline set are listed below. To order any manuals, please
contact your customer service representative.
QTeleline System Manual
QTeleline System Overview
QTeleline Product Guide
1.2.2 Positron Products and Services
Positron engineers and manufactures high voltage isolation products to protect
personnel and telecommunications circuits in high voltage areas that are
susceptible to the effects of Ground Potential Rise (GPR).
Positron is the leader in isolation technology with its Teleline wireline products and
TeleLite optical fiber wireline isolation/protection product families. Positron
provides total flexibility in product configuration – from standalone units protecting
a single circuit to high-capacity, multi-shelf HVI preconfigured systems.
Positron also provides a wide range of consulting, analysis and training services
for communications companies and electrical utilities.
Full details and contact information are available at www.PositronPower.com.

8
Wall-Mount Power Supply Chassis model 750003
1.3 Service and Support
Table 1: Positron Contact Information
General information: Positron Inc.
5101 Buchan Street, Suite 220
Montreal, Quebec, Canada
H4P 2R9
US and Canada: 1-888-577-5254
International: 1-514-345-2220
Fax: [phone]
E-mail: [e-mail]
Website: www.PositronPower.com
Customer Service and
Repairs:
US and Canada: 1-888-577-5254
International: 1-514-345-2220
E-mail: [e-mail]
1.3.1 Technical Customer Support
Positron is committed to providing excellent ongoing technical support to its
customers. A team of specialists is always available for telephone consultations or
for on-site visits to assist in the maintenance and troubleshooting of Positron
equipment.
For pricing information or assistance in the planning, configuration and
implementation of the installation of equipment, contact Technical Customer
Service.
1.3.2 Customer Training
Full customer training courses on High Voltage Interface (HVI) are also available.
For more information, contact Positron.

9
Service and Support
1.3.3 Repair Service
All warranty repairs are performed at no cost. Positron reserves the right to repair
or replace any equipment that has been found to be defective.
For information about out-of-warranty repairs, contact Positron’s Repair
Department. Due to the varied nature of repairs, no specific turnaround can be
guaranteed, but average turnaround time is 20 working days from date of receipt.
In emergency situations, special arrangements can be made. All repaired items
are warranted for a period of 90 days.
Before returning any items to Positron for repair, warranty repair or replacement,
call the Repair department to obtain a Return Material Authorization (RMA)
number. Parts returned without RMA numbers cannot be accepted. The RMA
number must always be clearly marked on all boxes, crates, and shipping
documents. Bulk repairs (more than five items) will require additional processing
time, so please take this into consideration when requesting an RMA number.
To accelerate the repair process, whenever possible, include a report detailing the
reason for return with the unit(s). Also, please include the name and phone
number of a person who can be contacted should our Repair department need
further information.
When packing items being returned for repair, please ensure they are properly
packed to avoid further damage. TeleLite plug-in cards should never be shipped
while installed in a shelf; this will cause damage that can extend the repair period.

10
Wall-Mount Power Supply Chassis model 750003
1.4 Teleline Warranty
Subject to the provisions of this paragraph, Positron warrants that the equipment
shall perform in accordance with Positron's specifications. The warranty remains
valid for five (5) years from the date of shipment. The warranty fully covers
workmanship, materials and labor. Positron shall, at its sole discretion, repair or
replace the problem unit.
Freight costs to ship defective equipment to Positron are borne by the Customer,
with return of replaced or repaired equipment to be at Positron's expense.
1.4.1 Limitation of Liability
Subject to anything to the contrary contained herein, Positron's sole obligation
and liability and the customer's sole remedy for Positron's negligence, breach of
warranty, breach of contract or for any other liability in any way connected with or
arising out of, the equipment or any services performed by Positron shall be as
follows:
QIn all situations involving performance or non-performance of the
equipment or any component thereof, the customer's sole remedy shall
be, at Positron's option, the repair or replacement of the equipment or
said component.
QFor any other claim in any other way related to the subject matter of any
order under, the customer shall be entitled to recover actual and direct
damages; provided that Positron's liability for damages for any cause
whatsoever, and regardless of the form of the action, whether in contract
or in tort (including negligence), shall be limited to the value of the order.
Positron shall not be obligated to repair or replace any item of the equipment
which has been repaired by others, abused or improperly handled, improperly
stored, altered or used with third party material or equipment, which material, or
equipment may be defective, of poor quality or incompatible with the equipment
supplied by Positron, and Positron shall not be obligated to repair or replace any
component of the equipment which has not been installed according to Positron
specifications.
IN NO EVENT SHALL POSITRON BE LIABLE FOR ANY INDIRECT,
INCIDENTAL, SPECIAL, CONSEQUENTIAL, PUNITIVE, EXEMPLARY OR
SIMILAR OR ADDITIONAL DAMAGES INCURRED OR SUFFERED INCLUDING

11
Teleline Warranty
LOSS OF PROFITS, LOSS OF REVENUES, LOSS OF DATA, LOSS OF
BUSINESS INFORMATION, LOSS OF GOODWILL, LOSS OF EXPECTED
SAVINGS OR BUSINESS INTERRUPTION ARISING OUT OF OR IN
CONNECTION WITH THE EQUIPMENT, A PURCHASE ORDER, SUPPLIES,
MAINTENANCE SERVICES OR OTHER SERVICES FURNISHED
HEREUNDER, EVEN IF POSITRON HAS BEEN ADVISED OR IS AWARE OF
THE POSSIBILITY OF SUCH DAMAGES.
EXCEPT AS EXPRESSLY SET FORTH IN THIS AGREEMENT, POSITRON
DISCLAIMS ANY FURTHER CONDITIONS, REPRESENTATIONS OR
WARRANTIES, WHETHER WRITTEN OR ORAL, EXPRESSED OR IMPLIED,
INCLUDING THE CONDITIONS AND WARRANTIES OF MERCHANTABILITY,
MERCHANTABLE QUALITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE,
PERFORMANCE AND THOSE ARISING FROM STATUTE, TO THE EXTENT
PERMITTED BY LAW. POSITRON DOES NOT WARRANT THAT THE SYSTEM
WILL OPERATE WITHOUT INTERRUPTION OR THAT IT WILL BE ERROR
FREE.
1.4.2 Cancellation and Rescheduling Charges
Should the customer cancel, prior to shipment, any part of an order, the customer
agrees to pay to Positron cancellation charges, not as a penalty, which shall total
all expenses, including labor expenses, incurred by Positron prior to said
cancellation. Equipment that has been specially developed for the customer's
specific applications shall not be subject to cancellation. Cancellation or
rescheduling is not permissible after shipment of the System.

Chapter 2
Overview

14
Wall-Mount Power Supply Chassis model 750003
2.1 Introduction
The Wall-Mount Power Supply Chassis provides a means to use any of the
Teleline Power Supplies (751313MC, 751316, 751318MC, 751319MC, 751324)
or Battery Backup Module (751312) outside of the Teleline Shelves. The Chassis
mounts either flat on a wall or perpendicular to the wall to save space. Multiple
modules can be used to provide redundancy or backup. The Chassis has an
input/output terminal block and a battery backup terminal block to connect other
Chassis to it. The Chassis is equipped with spring-loaded locking mechanisms to
prevent cards from dislodging due to vibration.
The Wall-Mount Chassis allows the user to configure the output to floating
(24 Vdc/48 Vdc), negative voltage (-24 Vdc/-48 Vdc) or positive voltage
(+24 Vdc/+48 Vdc) through a jumper setting (W1) located on the backplane of the
Chassis.
QThe default setting is for -24 Vdc/-48 Vdc.
For a view of the Power Supply Chassis, see Figure 1 on page 15.
For a view of the jumper W1, refer to Figure 3 on page 19.

15
Introduction
Figure 1: Wall-Mount Chassis
QThe fuse is a FAST, 5A/125V, 3AG type fuse.
N OTE

16
Wall-Mount Power Supply Chassis model 750003
2.2 Description
Below is a description of the Chassis. For a view of the detailed section, please
refer to Figure 1 on page 15.
2.2.1 Input/Output terminal block
Input power is brought to the Chassis through the bottom three contacts of the
terminal block. Depending on the Power Supply being used, it can be fed either
120 Vac, 130 Vdc, 48 Vdc or 24 Vdc. Although the Power Supply Modules are not
polarity-sensitive, the power has to be wired according to the polarity indications
on the terminal blocks.
The output from the Power Supply comes out of the top three pins of the terminal
block. The top contact is the positive lead, the second contact provides the
negative lead of a 24 V power output and the third contact provides the negative
lead of a 48 V power output.
The fourth and fifth output pins provide alarm contacts. Whenever the output of a
Power Supply fails, the alarm contact on the unit will close, these alarm contacts
are provided through these two pins. When two Power Supplies are used with two
Power Supply Chassis, the alarm contacts of each of the Chassis can be wired in
parallel or separately to provide an alarm for the system or each Chassis. If one
unit fails, then an alarm is raised while the second unit still provides power to the
system.
For a view of the terminal block, refer to Figure 2 on page 17 and
Table 2 on page 18.

17
Description
Figure 2: Wall-Mount Chassis Terminal Block View

18
Wall-Mount Power Supply Chassis model 750003
2.2.2 Power Supply/Battery Back-up terminal block
This terminal block provides charging power to a second Chassis used to house a
Battery Back-up Module 751312.
When a second Chassis is used to provide redundancy, its output will be
connected to this terminal block on the primary Chassis.
It is also possible to provide 48 V battery back-up using two 751312 units by
wiring the output accordingly. See section 3.5 on page 25 for more information.
For a view of the terminal block, refer to Figure 2 on page 17 and Table 2 on page
18.
2.2.3 Input fuse
The input fuse is connected in series with the Live lead of the input power feeding
the Chassis to provide overcurrent protection in case of damaging surges or
failure of the Power Supply Module. The fuse is a FAST, 5A/125V, 3AG type fuse
and must be replaced with the same type of fuse.
2.2.4 Ground lug
The Chassis must be grounded through the ground lug to a solid local ground
using a #10 AWG or bigger, wire.
Table 2: Input/Output Terminal Block pinout
Terminal
Block Pin
Function
OUTPUTS: 0V Positive output of 24 V/48 V
-24 V Negative output of 24 V
-48 V Negative output of 48 V
ALM Normally open relay contact provides dry contact closure for an audio or
visual indication of an output power failure.
ALM
INPUTS: GND Input cable ground wire
N/- Power input Neutral wire (for AC input) or negative wire (for DC input)
L/+ Power input Live wire (for AC input) or positive wire (for DC input)

19
Description
Table 3: Power Supply/Battery Back-up Terminal Block pinout
Terminal Block Pin Function
0 V Positive voltage to/from battery back-up or redundant power supply Chassis
-24 V Negative of 24 V to/from battery back-up or redundant power supply
Chassis
-48 V Negative of 48 V from battery back-up or redundant power supply Chassis
CHRG Negative of 48 V to battery back-up Chassis
2.2.5 Ground jumper setting
The backplane of the Wall-Mount Chassis is equipped with a jumper setting, W1,
that allows the output to be configured as floating, negative voltage or positive
voltage referenced to ground. The unit is set at the factory to provide negative
voltages (-24 Vdc/-48 Vdc) for Teleline/TeleLite installations.
The configurations are well indicated on the backplane at the different locations
where W1 can be installed.
QFor a view of the jumper W1, see Figure 3 on page 19.
Figure 3: Ground Jumper (W1)

20
Wall-Mount Power Supply Chassis model 750003
2.3 Specifications
Table 4: Physical Specifications
Parameter Specification
Weight 1 kg (2.3 lbs.)
When installed flat against the wall
Height 20.8 cm (8.2”)
Width 24.9 cm (9.8”)
Required space at left of Chassis to insert modules 17.7 cm (7.0”)
Depth 9.3 cm (3.7”)
When installed perpendicular to the wall
Height 20.8 cm (8.2”)
Width 9.3 cm (3.7”)
Required space at right of Chassis for connections 8.9 cm (3.5”)
Depth 24.9 cm (9.8”)
Table 5: Environmental Specifications
Parameter Specification
Operating temperature -40ºC to +85ºC (-40ºF to 185ºF)
**Will be limited by operating temperature of Power Module inserted
in Chassis.
Storage temperature -40ºC to +85ºC (-40ºF to 185ºF)
Humidity (non-condensing) 20% to 80%
Altitude -61m to 3048m (-200ft to 10,000ft) above sea level
Table 6: Electrical Specifications
Parameter Specification
Maximum input current 5 A
Maximum output current 5 A
Alarm contact rating 2 A@30 Vdc, 0.5 A@125 Vac, 105operations
