MMF Quick Start Guide
More information available at POSMicro.com

Placement of Cash Drawer
MMF POS
HeritageHeritage™ 15”™ 15”
Quick Installation Instructions
Printer-Driven Interface Connection
(Epson/Star Printer Kwick-Kable (P/N:226-199EPST1000) INCLUDED)
• If your printer does not support Epson/Star emulation wiring, please contact
your dealer or MMF POS to purchase proper printer cable.
• Connect one side of the corresponding printer-specific MMF RJ-12 Cable to
the interface connection located under the cash drawer. The end of the cable
that has a label with the MMF cable part number will plug into the Cash
Drawer and the end that has a label that reads: “Connect to Printer” would
plug into the receipt printer.
• Follow the set-up instructions from the printer manufacturer to properly
connect the cash drawer to the receipt printer.
Preventive Maintenance:
•Lubricate the slides and latch mechanism periodically. Inspection
and lubrication will vary based on operating conditions.
• Remove any debris from slides, if present.
• A thin film of lithium-based grease or a few drops of general
purpose oil should be maintained on the ball bearing tracks of the
Media
Slots
Currency
Tray/Till
Inner Drawer
Media Slots
NOTE: For a list of additional accessories and/or replacement parts,
contact your supplier or visit our website at http://www.mmfpos.com
Lock
Chassis Color: Black or Putty
Front Panel: Stainless Steel
Till: US 5 Bills / 5 Coins
Models:
226-113151312-04 (Black)
226-113151312-89 (Putty)
Metal Bill
Weights
Placement of Cash Drawer
• Prepare a location for the cash drawer by selecting a secured, leveled
surface that is no smaller than the cash drawer.
• Operating temperature should be controlled at 20°F to 100°F (-7°C to
37°C)
• Position the cash drawer and remove any packing tape or guards from
the tray.
• It is recommended to anchor the cash drawer to counter surface or if
mounting under counter at all times to prevent any injuries if cash drawer
is over loaded.
2 function Plunger Lock Functionality:
• 12 o’clock position – Drawer is Locked & Electronically ON
• 2 o’clock position & Push IN – Manually Unlock Drawer
Troubleshooting:
Cash Drawer does not open electronically
• Consult the documentation or manuals for your particular printer for the
proper open codes.
• Verify the correct end of the RJ-12 printer cable is connected to the cash
drawer as well as the printer.
• Verify correct position of the lock. To open electronically the lock would
need to be in the 12 o’clock position.
Cash Drawer does not open manually or electronically
• Make sure all packing tapes were removed from the cash tray and that
no foreign objects are obstructing the cash tray from opening.
Warnings/Safety Instructions:
• Avoid breaking coin rolls on the drawer front or the currency tray.
• Do not clean roller bearings or slides with any water or substance
cleaners; use a lint-free fabric to wipe old grease and/or debris.
For more information on the Heritage 15” Cash Drawer visit www.mmfpos.com or for FREE Technical Support call 1-800-769-1954.
purpose oil should be maintained on the ball bearing tracks of the
slides
To avoid the possibility of losing, damaging, or breaking the key from the lock
during transactions, please place lock in the 12 o’clock position and remove key.
Heritage 15” Electronic Quick Inst. Sheet
Last Rev.7-18-11
P/N:531-7304-00
