Potterton Paramount three 30 User manual

Installation manual
Gas condensing boiler
Paramount three 30-115 kW

Table of contents
1. About this manual............................................................................................................................... 5
1.1 Manual contents...................................................................................................................... 5
1.2 Overview table......................................................................................................................... 5
1.3 Used symbols........................................................................................................................... 6
1.4 For whom is this manual intended?............................................................................................ 6
2. Safety................................................................................................................................................ 7
2.1 Usage according to purpose...................................................................................................... 7
2.2 General safety instructions........................................................................................................ 7
2.3 Regulations and standards........................................................................................................ 8
2.4 Liquid gas under ground............................................................................................................ 8
2.5 CE-Marking.............................................................................................................................. 8
2.6 Conformity declaration............................................................................................................. 9
3. Technical Data Paramount Three 30-115............................................................................................... 10
3.1 Dimensions and connections..................................................................................................... 11
3.2 Specification............................................................................................................................ 13
3.3 Wiring diagram........................................................................................................................ 15
3.4 Sensor value tables................................................................................................................... 17
4. Prior to installation............................................................................................................................. 18
4.1 Air Supply Openings................................................................................................................. 18
4.1.1 Clean combustion air!................................................................................................. 18
4.2 Corrosion protection................................................................................................................. 18
4.3 Requirements for heating circuit water...................................................................................... 18
4.3.1 Further information on the heating water.................................................................... 18
4.4 Treating and preparing the heating water.................................................................................. 19
4.4.1 Determining the system volume.................................................................................. 19
4.4.2 Additives................................................................................................................... 19
4.4.3 Antifreeze.................................................................................................................. 20
4.4.4 Maintenance instruction............................................................................................. 21
4.5 Practical information for heating contractors.............................................................................. 21
4.6 Operation in wet rooms............................................................................................................ 22
4.7 Notes for installation location................................................................................................... 22
4.7.1 Installation room........................................................................................................ 22
4.8 Application example................................................................................................................. 24
4.9 Legend.................................................................................................................................... 28
5. Installation......................................................................................................................................... 29
5.1 Connect heating circuit............................................................................................................. 29
5.2 Safety valve............................................................................................................................. 29
5.3 Condensate............................................................................................................................. 29
5.4 Sealing and filling of the plant................................................................................................... 29
5.5 Flue gas connection.................................................................................................................. 29
5.6 Exhaust gas system.................................................................................................................. 30
5.7 Assembly of the exhaust gas system.......................................................................................... 31
5.7.1 Assembly with downward slope................................................................................... 31
5.7.2 Working gloves.......................................................................................................... 31
5.7.3 Shortening of the pipes............................................................................................... 31
5.8 Working with the exhaust gas system KAS.................................................................................. 31
5.8.1 Minimum dimensions of the shaft............................................................................... 32
5.9 Cleaning and inspection openings.............................................................................................. 32
5.10 Gas connection........................................................................................................................ 32
5.11 Check tightness........................................................................................................................ 33
5.11.1 Purging the gas line.................................................................................................... 33
2 Paramount three 30-115 kW 7308272-03 03.14

5.12 Factory settings........................................................................................................................ 33
5.13 Supply pressure........................................................................................................................ 33
5.14 CO2 -Content........................................................................................................................... 33
5.15 Changing over from LPG to natural gas and vice versa.................................................................. 33
5.16 Gas valve................................................................................................................................. 34
5.17 Controller Stop Mode (Manual Adjustment of Burner Load).......................................................... 35
5.18 Guide Values for Injector Pressure.............................................................................................. 35
5.19 Electrical connection (general)................................................................................................... 36
5.19.1 Cable lengths............................................................................................................. 37
5.19.2 Strain relief fittings..................................................................................................... 37
5.19.3 IP rating IPx4D........................................................................................................... 37
5.19.4 Circulating pumps...................................................................................................... 37
5.19.5 Fuses......................................................................................................................... 37
5.19.6 Connection sensor / components................................................................................. 37
5.19.7 Replacing cables......................................................................................................... 38
5.19.8 Contact protection and international protection IPx4D.................................................. 38
6. Commissioning................................................................................................................................... 39
6.1 Menu-Commissioning.............................................................................................................. 39
6.2 Switching on............................................................................................................................ 39
6.3 Temperatures for heating and drinking water............................................................................. 40
6.4 Individual time programme....................................................................................................... 40
6.5 Programming of necessary parameters....................................................................................... 40
6.6 Emergency operation (Manual operation)................................................................................... 40
6.6.1 Set emergency operation............................................................................................ 40
6.6.2 Adjusting setpoint manual control............................................................................... 40
6.7 Instruction of the customer....................................................................................................... 41
6.7.1 Instruction................................................................................................................. 41
6.7.2 Documents................................................................................................................ 41
6.8 Guide for commissioning.......................................................................................................... 42
7. Operation........................................................................................................................................... 43
7.1 Operating elements.................................................................................................................. 43
7.2 Display.................................................................................................................................... 44
7.3 Stop heating operation............................................................................................................. 44
7.4 Stop domestic hot water operation............................................................................................ 45
7.5 Setting room setpoint............................................................................................................... 45
7.6 Display information.................................................................................................................. 46
7.7 Error message.......................................................................................................................... 46
7.8 Servicing message.................................................................................................................... 47
7.9 Chimney-sweep function.......................................................................................................... 47
8. Programming...................................................................................................................................... 48
8.1 Programming procedure........................................................................................................... 48
8.2 Modification of parameters....................................................................................................... 49
8.3 Setting table............................................................................................................................ 51
8.4 Explanations for setting table.................................................................................................... 76
8.5 Time and date.......................................................................................................................... 76
8.6 Operator section...................................................................................................................... 77
8.7 Radio....................................................................................................................................... 78
8.8 Time programs......................................................................................................................... 78
8.9 Holiday programs..................................................................................................................... 79
8.10 Heating circuits........................................................................................................................ 80
8.11 DHW....................................................................................................................................... 88
8.12 Consumer circuits/Swimming pool circuit................................................................................... 90
8.13 Swimming pool........................................................................................................................ 91
8.14 Primary contr/system pump...................................................................................................... 91
8.15 Boiler...................................................................................................................................... 92
8.16 Cascade................................................................................................................................... 95
7308272-03 03.14 Paramount three 30-115 kW 3

8.17 Solar....................................................................................................................................... 96
8.18 Solid fuel boiler........................................................................................................................ 99
8.19 Buffer storage.......................................................................................................................... 100
8.20 DHW-storage........................................................................................................................... 102
8.21 Configuration.......................................................................................................................... 106
8.22 LPB-system.............................................................................................................................. 114
8.23 Fault....................................................................................................................................... 115
8.24 Service / special operation......................................................................................................... 116
8.25 Input/output test..................................................................................................................... 117
8.26 State....................................................................................................................................... 117
8.27 Diagnostics cascade/heat generation/consumers........................................................................ 123
8.28 Burner control.......................................................................................................................... 124
8.29 Info Option.............................................................................................................................. 124
9. General.............................................................................................................................................. 125
9.1 Room device RGT...................................................................................................................... 125
9.2 Occupancy button.................................................................................................................... 125
10. Maintenance...................................................................................................................................... 126
10.1 Inspection and need dependent service...................................................................................... 126
10.2 Replace quick-de-aerator........................................................................................................... 126
10.3 Siphon for condensate.............................................................................................................. 126
10.4 Removing gas burner................................................................................................................ 127
10.5 Protection against contact......................................................................................................... 128
10.6 Boiler view Paramount.............................................................................................................. 129
10.7 Disassembling heat exchanger.................................................................................................. 131
10.8 At the end of the maintenance work.......................................................................................... 131
10.9 Check Electrodes...................................................................................................................... 132
10.10 Fault switch-off........................................................................................................................ 132
10.11 Fault code table........................................................................................................................ 134
10.12 Maintenance code table............................................................................................................ 137
10.13 Operating phases of the Control Centre LMS............................................................................... 137
4 Paramount three 30-115 kW 7308272-03 03.14

1. About this manual
Read this instruction thoroughly before operating the device!
These instructions are from the original German document.
1.1 Manual contents This manual contains the instructions for the installation of gas-fired boilers of the
series Paramount for standard application with 1 pump heating circuit and 1 DHW
storage tank.
If an EWM extension module is installed, an application with one or two mixed
heating circuits is possible.
Here, an overview of the further documents belonging to this heating system. Re-
tain all documents at the installation location of the gas boiler.
1.2 Overview table
Documentation Contents Intended for
Technical information - Planning documents
- Description of function
- Technical data/circuit diagrams
- Basic equipment and accessories
- Application examples
- Call-for-tender texts
Planner, Heating spe-
cialist
Installation Handbook - Usage according to purpose
- Technical data/circuit diagram
- Regulations, standards, CE
- Notes for installation location
- Application example Standard application
- Commissioning, operation and programming
- Maintenance
Heating specialist
Operating Instructions - Commissioning
- Operation
- User settings/programming
- Disturbance table
- Cleaning/maintenance
- Energy saving tips
Customer
Programming and
Hydraulic system manual - Setting table including all parameters and explanations - further application examples Heating specialist
Online database - Anwendungsbeispiele für registrierte Benutzer auf der
Internetseite www.broetje.de Planner, Heating specialist
Asset ledger - Commissioning report
- Check list for commissioning
- Maintenance
Heating specialist
Brief instruction - Operation in brief Customer
Servicing booklet - Report of carried out services Heating specialist
Accessories - Installation
- Operation Heating specialist, customer
About this manual
7308272-03 03.14 Paramount three 30-115 kW 5

1.3 Used symbols Danger! Danger exists for body and life in case it is not observed.
Danger of electric shock! In case it is not observed, danger from electricity exists
for body and life!
Caution! If warning is not observed, danger exists for environment and the device.
Note/tip: Here, you can find background information and useful tips.
Reference to additional information in other documents.
1.4 For whom is this manual
intended? This installation manual is intended for the heating specialist.
About this manual
6 Paramount three 30-115 kW 7308272-03 03.14

2. Safety
Danger! Observe the following safety information! Otherwise you are endangering
yourself and others.
2.1 Usage according to purpose The gas fired devices of the series Paramount are intended to be used according to
BS 5440, BS 6644 and DIN EN 12828 as heat generators in water-heating plants.
They conform to DIN EN 483 and 677.
- Installation type B23,B23P, B33, C13x, C33x, C43x, C53, C63x, C83 and C93x
- Destination GB: Category II2H3+
2.2 General safety instructions Danger! Danger of life!
A danger of signifficant damages to persons, environment and property exists dur-
ing installation of heating plants. Therefore, heating systems must only be instal-
led by specialist companies and commissioned by specialists of the installing com-
pany!
Risk of electric shock! Danger to life due to live components!
All electrical work in connection with the installation must only be carried out by a
trained electrician!
Danger! Danger to life if heating unit used improperly!
- This unit can be used by children aged 8 years and above and persons with re-
duced physical, sensory or mental capabilities or lack of experience and knowl-
edge when they have been given supervision or instruction concerning the safe
use of the device and understand the resulting risks. Do not let children play
with the appliance. Cleaning and user maintenance must not be carried out by
children without supervision.
Danger! Danger to life through modifications to the device!
Unauthorised conversions and modifications of the device are not permitted, as
this can endanger persons and lead to damage of the device. In case of not observ-
ing this, the approval of the device becomes void.
Setting, maintenance and cleaning of the device must only be carried out by a
qualified gas heating specialist!
Used accessories must comply with the technical rules and have been approved in
connection with these device by the manufacturer.
Caution! Only original spare parts must be used.
Safety
7308272-03 03.14 Paramount three 30-115 kW 7

2.3 Regulations and standards Beside the general technical rules, the relevant standards, regulations, ordinances
and guidelines should be followed:
- DIN 4109; Noise protection in construction engineering
- DIN EN 12828; Heating plants in buildings
- EnEV - Energy saving regulation
- Federal Immission Control Ordinance 3. BImSchV
- DVGW-TRGI 1986 (DVGW-worksheet G 600); Technical Rules for gas installation
- TRF; Technical Rules LPG
- DVGW-Data sheet G 613 Gas appliances- Installation, maintenance and operat-
ing instructions
- DIN 18380; Heating plants and central hot water plants (VOB)
- DIN EN 12831; Heating plants in buildings
- DIN 4753; Hot water plants for drinking and water supply
- DIN 1988; Technical Rules for drinking water installations (TRWI)
- VDE 0700-102, DIN EN 60335-2-102: Safety of electrical appliances for house-
hold use and similar purposes: Special requirements for gas-, oil- und solid fuel
appliances with electrical connections
- Fuel Ordinance, State Ordinances
- Regulations of the local Electricity Board
- Obligation to register (possibly. Group Exemption Regulation )
- ATV-Code-of-practrice M251 of the waste water technology association
- Regulations of the Public Authorities for the run-off of condensate.
2.4 Liquid gas under ground The Paramount complies with DIN EN 126 and DIN EN 298 and, therefore does not
need an additional shut-off valve for operation with liquid gas under ground
2.5 CE-Marking The CE-marking means that the gas-fired fuel value devices meet the require-
ments of the gas devices guideline 2009/142/EG, the low voltage guideline
2006/95/EG, as well as, the guideline 2004/108/EG (electro-magnetic compatibili-
ty, EMV) of the Commission to balance the legal regulations of the member states.
Meeting the protection requirements according to guideline 2004/108/EG is only
guaranteed by operation of the boiler according to purpose.
The ambient conditions according EN 55014 must be met.
Operation is only allowed with correctly fitted casing.
Correct electrical earthing has to be ensured by regular check (e.g. annual inspec-
tion).
When replacing device parts, only original parts as specified by the manufacturer
must be used.
The gas condensing-boilers fulfill the basic requirements of the Efficiency Guide-
line 92/42/EG as condensing boiler.
When natural gas is used, the gas condensing-boiler emit less than 60 mg/kWh NOX
corresponding to the requirements as per §6 of the Ordinance regarding small fir-
ing places dated 26.01.2010 (1. BImSchV).
Safety
8 Paramount three 30-115 kW 7308272-03 03.14

2.6 Conformity declaration
Declaration of conformity
Product Condensing gas boiler
Trade mark Paramount
Product ID number CE-0085 CL 0072
Type, Model Paramount three 30, 40, 60, 80, 95, 115
EU directives 2006/95/EEC, 2004/108/EEC, 2009/142/EEC, 1992/42/EEC
Standards DIN VDE 0722
DIN EN 50081-1, DIN EN 50082-2
DIN EN 60335-1, DIN EN 483
DIN EN 677, DIN EN 625
EC type examination DVGW Deutsche Vereinigung des Gas- und Wasserfaches e.V.
53123 Bonn
Notified Body 0085
Surveillance procedure Yearly surveillance audit
DVGW Deutsche Vereinigung des Gas- und Wasserfaches e.V.
53123 Bonn
The producer states the following:
The above named products fulfil the requirements of the directives and standards. They are identical with the
prototype examined. The production process follows the guidelines of the surveillance procedure. The above
named products are only for installations in hot water heating systems. The installer has to assure that the
directives fot installation and operation are being followed.
................................... ...................................
ppa. H. Wilken
Leiter Entwicklung
i.V. U. Patzke
Leiter Versuch/Labor und
Dokumentationsbevollmächtigter
Safety
7308272-03 03.14 Paramount three 30-115 kW 9

3. Technical Data Paramount Three 30-115
Technical Data Paramount Three 30-115
10 Paramount three 30-115 kW 7308272-03 03.14

3.1 Dimensions and connections
Fig. 1: Dimensions and connections
aGR030B
B
C
851
130
185
177
120
260
192
116
100
50
30/40 kW
60-115 kW
30/40 kW: 900 60-115 kW: 975
30/40 kW: 877 60-115 kW: 883
30/40 kW: Ø125
60-115 kW: Ø160
30/40 kW: Ø80
60-115 kW: Ø110
Technical Data Paramount Three 30-115
7308272-03 03.14 Paramount three 30-115 kW 11

Tab. 1: Dimensions and connections
Model Paramount
three 30/40 Paramount three 60 Paramount three 80 Paramount three 95 Paramount three 115
HV - Heating flow G 1" G 1 1/2“
HR - Heating return G 1" G 1 1/2“
Gas - Gas connection G 1“
SiV - Safety valve G 3/4“
KA - Condensated water connection Ø 25 mm
Dimension A [mm] 407 447 542 585
Dimension B [mm] 240 168 163
Dimension C [mm] 130 132 152
Technical Data Paramount Three 30-115
12 Paramount three 30-115 kW 7308272-03 03.14

3.2 Specification
Tab. 2: Specification
Model Paramount three 30 40 60 80 95 115
Product-ID-No. CE-0085BL0514
VDE-Reg.-No. VDE-mark
International protection IPx4D
Gas category II2H3+
Device categories B23, B33, C13X, C33X, C43X, C53, C63X, C83
Nominal heat input
range Natural Gas Heating mode kW 5,6-30,0 9,0-38,0 14,0-58,0 21,0-77,0 20,0-95,0 25,0-115,0
Nominal heat out-
put range Natural Gas 80/60°C kW 5,4-29,2 8,7-36,8 13,4-56,3 20,3-74,7 19,4-92,2 24,3-111,7
50/30°C kW 6,0-31,3 9,6-39,0 14,9-60,1 22,6-79,7 21,4-98,1 26,7-118,6
Standard efficiency
(DIN 4702) 75/60°C 106,0 106,0 106,0 106,0 106,0 106,0
40/30°C 109,0 109,0 109,0 109,0 109,0 109,0
pH-value condensate - 4-5 4-5 4-5 4-5 4-5 4-5
Volume condensate 40/30°C l/h 0,83-3,00 1,19-2,84 1,78-4,71 2,53-6,46 2,75-8,42 3,85-9,61
NOX-Standard emission factor mg/
kWh 17 20 20 20 25 25
CO-Standard emission factor mg/
kWh 5 10 10 10 20 20
Data for design of the chimney to EN 13384 (room sealed operation)
Exhaust gas tem-
perature (full load) Full load 80/60°C °C 66 75 71 73 73 77
Low load °C 53 56 59 59 59 60
Full load 50/30°C °C 46 53 54 54 51 56
Low load °C 33 35 34 35 32 33
Exhaust gas mass
flow Natural Gas 80/60°C g/s 2,8-14,8 4,4-18,7 6,9-28,5 10,3-37,9 9,8-46,7 12,3-56,6
50/30°C g/s 2,5-14,1 4,1-18,0 6,4-27,4 9,7-36,4 9,1-44,8 11,3-54,4
Exhaust gas mass
flow Propane 80/60°C g/s 2,6-14,1 4,2-17,8 6,6-27,2 9,8-36,1 14,1-44,6 16,4-53,9
50/30°C g/s 2,4-13,4 3,9-17,1 6,1-26,1 9,2-34,6 13,3-42,6 15,4-51,7
CO2-content
natural gas Natural Gas % 8,3 - 8,8
CO2-content LPG Propane % 10,3 - 10,7
Draft requirement mbar 0
Max. delivery pressure at exhaust gas out-
let mbar 1,1 1,1 1,1 1,1 1,5 1.8
Exhaust gas/air supply connection mm 80/125 110/160
Exhaust gas value group to DVGW G636 - G6
Technical Data Paramount Three 30-115
7308272-03 03.14 Paramount three 30-115 kW 13

Model Paramount three 30 40 60 80 95 115
Heating water
Adjustment range heating water temper-
atur °C 20 - 85
Max. temp °C 100
Operating pressure min. bar 1,0
MPa 0,1
max. bar 3,0 4,0
MPa 0,3 0,4
Hydraulic resistance
Flow rate @20K kg/h 1254 1583 2150 3311 4085 4945
Hydraulic resistance @20K kPa 10,4 14,7 6,8 8,5 12,5 17,8
Flow rate @11K kg/h 2280 2879 4535 6020 7427 8991
Hydraulic resistance @11K kPa 26,1 37,0 26,9 25,9 38,6 55,9
Gas-connected loads
Supply pressure for natural
gas mbar min. 18 - max. 25
Connected loads Natural gas
[HUB 9,45 kWh/m³] m³/h 0,59-3,20 0,95-4,00 1,48-6,10 2,22-8,10 2,12-10,1 02,65-12,20
Supply pressure for propane mbar min. 42,5 - max. 57,5
Propane
[HU12,87 kWh/kg] kg/h 0,44-2,33 0,70-2,95 1,09-4,51 1,63-5,98 2,33-7,38 2,72-8,94
Propane
[HU24,64 kWh/m³] m³/h 0,23-1,22 0,37-1,54 0,57-2,35 0,85-3,13 1,22-3,86 1,42-4,67
Electrical power consumption
Electrical connec-
tion V/Hz 230 V / 50 Hz
max. electr. power consumption W 55 70 100 108 170 200
Heating mode protective mode W 3 3 3 3 3 3
Dimensions
Boiler weight kg 53 53 61 72 84 84
Boiler water con-
tent l 3,6 3,6 4,7 5.8 7,8 7,8
Height mm 852
Width mm 480
Depth mm 407 407 447 542 570 570
Connections
Gas connection 3/4" 1"
Heating flow 1" 1 1/2"
Heating return 1" 1 1/2"
Technical Data Paramount Three 30-115
14 Paramount three 30-115 kW 7308272-03 03.14

3.3 Wiring diagram
Fig. 2: Wiring diagram Paramount three 30 & 40
Technical Data Paramount Three 30-115
7308272-03 03.14 Paramount three 30-115 kW 15

Fig. 3: Wiring diagram Paramount three 60-115
Technical Data Paramount Three 30-115
16 Paramount three 30-115 kW 7308272-03 03.14

3.4 Sensor value tables
Tab. 3: Resistance values for outside temperature sensor ATF
Temperature [°C] Resistance [Ω]
-20 8194
-15 6256
-10 4825
-5 3758
0 2954
5 2342
10 1872
15 1508
20 1224
25 1000
30 823
Tab. 4: Resistance values for flow sensor KVS, drinking water sensor TWF, return
sensor KRV, sensor B4
Temperature [°C] Resistance [Ω]
0 32555
5 25339
10 19873
15 15699
20 12488
25 10000
30 8059
35 6535
40 5330
45 4372
50 3605
55 2989
60 2490
65 2084
70 1753
75 1481
80 1256
85 1070
90 915
95 786
100 677
Technical Data Paramount Three 30-115
7308272-03 03.14 Paramount three 30-115 kW 17

4. Prior to installation
4.1 Air Supply Openings In case of ventilation based operation of the Paramount an adequately sized open-
ing for combustion air must be present in the place of installation. It should be
pointed out to the customer that this opening must never be closed or blocked and
that the connecting piece for combustion air on the upper side of the Paramount
must be kept free.
Concentric Flue Applications
The air supplied for the boiler space ventilation shall be such that the maximum
temperatures shall not exceed 25°C at floor level or 100 mm above, 32°C at mid
level (1.5 m above floor level) and 40°C at ceiling level or 100 mm below ceiling
level.
Refer to BS5440 2000 for boiler installations up 70 kW net and BS6644 2005 for
boilers above 70 kW net for further details.
The following tables give the total free area of the vents required for single boiler
installations in room sealed and open flue applications.
4.1.1 Clean combustion air!
Caution! Danger of damaging the device!
The Paramount must only be installed in rooms with clean combustion air. By no
means should pollen or similar particles be able to get into the equipment through
the suction holes!
4.2 Corrosion protection
Caution: Danger of damaging the device!
The combustion air must be free from corrosive elements - especially fluorine and
chlorine containing vapours which are found, for example, in solvents and clean-
ing agents, propellant gases etc.
When connecting heat generators to under-floor heating systems, employing plas-
tic pipe work which is not impervious to oxygen in accordance to DIN 4726, heat
exchangers must be used for separation purposes.
Note: Prevention of damage in hot water heating systems caused by corrosion on
the water side or scaling.
4.3 Requirements for heating
circuit water 4.3.1 Further information on the heating water
- The water must not have any foreign matter, such as sweat beads, rust particles,
scale or sludge. During filling, flush the system until only clean water runs out.
When flushing the system,ensure that the water does not flow through the heat
exchanger in the boiler, that the thermostatic radiator valves are removed and
the valve inserts are set to the maximum flow rate.
- If additives are used it is important to follow the instructions of the manufactur-
er.
If, in a special case, it is necessary to use additives in a mixture (e.g. hardness
stabiliser, frost protection agent, sealing agent,etc.) it has to be observed that
the agents are compatible with each other and the pH-value is not altered. Pref-
erably, agents from the same manufacturer should be used.
- For buffer cylinders in conjunction with solar thermal systems or solid fuel boil-
ers, take the buffer capacity into consideration when determining the fill water
volume.
Prior to installation
18 Paramount three 30-115 kW 7308272-03 03.14

4.4 Treating and preparing the
heating water 4.4.1 Determining the system volume
The total water volume in the heating system is composed of the system volume
(= fill water volume) plus the top-up water volume. In the POTTERTON boiler-spe-
cific diagrams, only the system volume is given to make them easier to use. Over
the entire service life of the boiler, a maximum top-up volume of twice the system
volume is assumed.
4.4.2 Additives
The following products are currently approved by BRÖTJE:
- „Full heating protection“ from Fernox (www.fernox.com)
- „Sentinel X100“ from Guanako (www.sentinel-solutions.net)
- „Jenaqua 100 and 110“ from Guanako (www.jenaqua.de)
- „Vollschutz Genosafe A“ from Grünbeck
- "Care Sentinel X100" from Conel (www.conel-gmbh.de)
Complete softening
As a general rule, fully desalinated water can always be used, although a pH value
stabiliser is also required. The following products for producing fully desalinated
water have been tested and approved:
- „Complete softening (VE) GENODEST Vario GDE 2000" from Grünbeck
(www.gruenbeck.de)
- "Complete softening cartridge SureFill" from Sentinel (www.sentinel-solu-
tions.net)
- more devices on request
Prior to installation
7308272-03 03.14 Paramount three 30-115 kW 19

Partial softening
The following products are currently approved by BRÖTJE:
- Sodium ion exchanger "Fillsoft" from Reflex (www.reflex.de)
- "Heifisoft" from Judo (www.judo-online.de)
- "Heating water softening 3200“ from Syr (www.syr.de)
- "AQA therm" and "HBA 100" from BWT Wassertechnik (www.bwt.de)
- "SoluTECH" from Firma Cillit (www.gc-gruppe.de)
It must be ensured with an automatic blending device that the min. hardness
does not go under 6°dH .
The specifications of the manufacturer must be followed.
Further products are currently undergoing testing. Please ask BRÖTJE for more in-
formation.
Caution! If non-approved products are used, the guarantee becomes void.
4.4.3 Antifreeze
Using antifreeze with Potterton gas condensing boilers with aluminium heat ex-
changers
The heat transfer medium (Lasacor®LS 1) offered for solar thermal systems is also
used in heating systems (e.g. holiday houses) as an antifreeze. In the mixture sup-
plied in the canisters (42 % Lasacor®LS 1, 58 % water) the freezing point ("crystal
formation point") is -28 °C. Due to the thermal capacity, which is lower than that
of pure water, and the higher viscosity, boiling noises may occur in some systems.
For most heating systems, frost protection down to -28 °C is not required; -15 °C is
usually sufficient. To set this operating point, the heat transfer medium should be
diluted with water in a ratio of 2:1. This mixing ratio has been test by Potterton in
relation to its practical suitability for use with gas condensing boilers.
Note: The heat transfer medium Lasacor®LS 1 up to a mixing ratio of 2,5:1 is ap-
proved as an antifreeze down to -15 °C for use with Potterton gas condensing boil-
ers.
Caution! Keep the installation room free of frost.
If antifreeze is used, pipework, radiators and gas condensing boilers are protected
against frost damage. For the gas condensing boiler to be ready for operation at
any time, suitable measures must also be taken to keep the installation room free
of frost. If applicable, please also note special measures for any installed DHW
heaters.
The table shows the relevant amounts of heat transfer medium and water, that
need to be mixed together for varying volumes of water. If other frost protection
temperatures are required in exceptional cases, individual calculations can be
made.
Prior to installation
20 Paramount three 30-115 kW 7308272-03 03.14
