Powel Antica AntiCa++ User manual

0
Powel Antica, s.r.o.
Prešov
Slovak Republic
HardWaterDescaler
House Protection
Installation Manual
Www.HardWaterDescaler.com
[e-mail]

1
Why HardWaterDescaler?
Small but clever AntiCa++ HardWaterDescaler House Protection is a reasonable choice which
offers reliable protection of whole house! Easy installation for any pipe material can be handled by
anyone in a very short time Neither salts nor chemicals ensure safe protection against scale in your
house without any harmful effects on you or your family This innovative product includes all
AntiCa++ knowledge and experience and takes care of any hard scale problem in your home
Safety instructions
1 Read these instructions
2 Keep these instructions
3 Heed all warnings
4 Follow all instructions
5 Install in accordance with the manufacturer’s
instructions
6 Only use attachments/accessories specified by the
manufacturer
7 The device should be mounted close to the power
supply
8 The device cannot be mounted on the wall
9 Clean only with dry cloth
AC power cord
Observe the followings to prevent the AC power cord from being damaged If the AC power cord
isdamaged, it may result in a fire or an electric shock Stop using it and ask your dealer to exchange
it Do not pinch, bend, or twist the cord excessively The core lines may be bared and cut, and
causing a short-circuit, resulting in a fire or an electric shock Do not convert or damage the power
cord Do not allow anything to rest on or roll over the power cord Do not pull the power cord Plug
the device only to the power supply of 220 – 230 V
Wall outlet
Do not use a poor fitting outlet Insert the plug fully into the outlet If it is loose, it may cause arcing
and result in a fire Contact your electrician to have the outlet changed
Wiring
When connecting cables, be sure to unplug the AC power cord for your safety
Electric shock
Do not touch the AC power cord with a wet hand If you plug/unplug the AC power cord from the
wall outlet with a wet hand, it may cause electric shock
Children
Do not allow children to play with the device The small accessories cannot be kept within the
grasp of children because they could be swallowed by mistake
Description
AntiCa++ HardWaterDescaler is an electronic device for physical water treatment The
electromagnetic field created by AntiCa++ HardWaterDescaler changes the physical properties of

2
water which results in water scale elimination in boilers, water networks, flushing toilets
mechanism and so on The treated water has the unchanged chemical properties therefore remains
potable and hygienic
Installation
AntiCa++ HardWaterDescaler can be installed directly by the user without the need of special
technical help Install the device according to the pictures in this manual The pipe material does
not have influence on the proper functioning of the device
Installation procedure (see pictures on the front page :
The device can be mounted on the horizontal, vertical or leaning pipeline It only requires
approximately 300 mm of straight part of pipe
1. step - choose the place of installation According to the placement of pipeline (horizontal or
vertical), stick the two anchors on the device in one of two possible ways (see the pictures below):
a horizontally on the back side of the
device - if the pipeline is situated
horizontally, stick the clips in
horizontal position
b vertically on the back side of the device
– if the pipeline is situated vertically, stick
the clips in vertical position
2. step - put the straps through the anchors Fix the device on the pipe with the straps
3. step - fix the beginnings of the two cables with the straps onto the pipe close to the device – the
right cable (which is situated in a lower position) to the right side close to the bottom of the pipe,
left cable (which is situated in a higher position) to the left side close to the top of the pipe (see the
picture on the front page or on the last page of this manual)
4. step - wrap the right cable around the pipe Start wrapping the right cable underneath the pipe
and continue turning in counter clockwise direction until there are 13 turnovers together that serve
as coil Fix the end of the coil with a strap
5. step - wrap the left cable around the pipe Start wrapping the left cable over the pipe and
continue turning in clockwise direction so that there are 13 turnovers together that serve as coil
Fix the end of the coil with a strap
6. step - if the free ends of cables are too long, cut them to the required distance
7. step - conductively connect both ends of both cables with the connector that is included in the
delivery Place both ends of cables into connector from the opposite sides and squeeze the
connector with the pliers
8. step - plug the device into the power supply The blue LED diode lights up This indicates
correct function of device

1
Putting into operation
After the plugging of the device to the
power supply, blue LED diode lights up
The device is operating correctly The
electric signal inside the coil affects the
supermolecular structures of the treated
water and creates a large amount of crystal
centers of CaCO3 in the water and at the
same time prevents their depositing on the
surfaces of water network pipelines The
crystal centers are washed away from the
water system through the outflow places
Maintenance
The device does not require special
maintenance during its operation In case
of failure (when the Blue LED diode is not
lit up) make sure that the device is
connected properly into the power supply
and check the connection of the two
cables If the connection of the two cables
is ok and the blue LED diode still does not
light up, contact the seller who sold you
the device From time to time check the
straps if they are fixed enough – if they get
loose, fix them again
Technical parameters
Diameter of pipe: 3/8“ - 1”
Electric input: max 1 W
Power supply: 220 – 230 V, 50 – 60 Hz
IP code: IP 54
Dimensions (w x h x d): 90 mm x 60 mm x
30 mm
Weight: 0,350 kg
The length of the power cord: 1,6 m
The length of the cable for coils: 1,55 m +
1,55 m
Warranty on electrical function: 24
months
Working temperature: 0 – 40°C
Temperature of pipe: max 60°C
Content of delivery
1 pc of device, 2 pcs of anchors, 6 pcs of
straps, 1 pc connector, installation manual
