Power bass PS-ADF110T User guide

AMPLIFIED DOWNFIRING BASS SYSTEM
Application Guide
Please read through this manual to familiarize yourself with your new speakers. Should your PowerBass
Autosound speakers ever require service, you will need to have the original dated receipt.
PS-ADF110T
PS-ADF110T

Thank you and Congratulations
Congratulations on your purchase of PowerBass Autosound speakers.You now own a speaker of uncompromising
design and engineering from a factory that truly believes in the relentless pursuit of perfection. Incorporating the
highest quality parts and state-of-the-art materials, these speakers display the ultimate balance between
high fidelity, performance and long-lasting reliability.
At PowerBass USA, Inc. we are confident you will have many years of outstanding enjoyment from this
great SPEAKER investment. For maximum performance we recommend that you have your new PowerBass
Autosound product installed by an Authorized PowerBass Autosound Dealer.
To learn more about PowerBass, please visit us on the World Wide Web at
http://www.powerbassusa.com
∆Warning ∆
Continuous exposure to sound pressure levels in excess of 100 dB can cause permanent hearing loss. PowerBass Autosound Speakers
are capable of producing sound pressure levels well over 170 dB. Please observe all local sound ordinances while listening to your
PowerBass Autosound system. PowerBass USA, Inc. accepts no liability for hearing loss, bodily injury, or property damage due to the
result of use or misuse of this product.
3

POWERBASS AMPLIFIED BASS SYSTEM FEATURES
Built-in High Powered Amplifier: Contains a high power Class A/B monaural amplifier complete with chassis
mounted adjustable Gain, Low Pass Filter and Bass Eq controls for sonic integration into most existing factory or
aftermarket car stereo systems and engineered perfectly to power the subwoofer.
Heavy-duty Box Design: This enclosure is constructed from non-resonant 5/8” panels that have been glued,
braced and sealed. Each box is finished in a stylish two tone RFG aviation grade vinyl covering.
Remote Subwoofer Level Control: This wired remote functions as a Bass Level control and can provide output
adjustments from the driver's seat. The remote will not increase the output beyond the GAIN setting on the am-
plifier. Supplied with 18ft of cable it can reach your dash even when the bass enclosure is mounted in the trunk.
Injection Molded Cone with Rubber Surround: A thermoplastic polymer cone was selected to help resist
moisture and other elements while the rubber surround offers more excursion as well as protection against
deterioration than other materials.
KSV High Temperature Voice Coil: These specially designed resin coated high temperature Kapton® voice
coils measure a full 2-inches in diameter to ensure high power handling and precise linear excursion while
maximizing thermal heat dissipation.
Additional Features: Vinyl enclosure, professional mounting hardware and wiring harness adds further value
to your investment.
Custom Mounting Brackets: Two brackets each with one side marked Vehicle and the other Enclosure. Use
two of the brackets on each enclosure to properly secure the cabinet.
Auto Remote Turn-On Circuit (High Level Input Mode): In the ‘ON’ position, the Auto Turn-On circuit will
sense an input signal and turn the internal amplifier on without using a remote turn on lead.
Kapton® is a registered trademark of E.I. du Pont de Nemours and Company
4
Vehicle Cabinet
Custom Mounting Bracket

5
DOWNFIRING SUBWOOFER SYSTEM
(Due to Constant Improvements, Specifications and Parameters are subject to change without notice.)
Model Size System
Impedance
Frequency
Response
Sensitivity
1W/1M
Magnet
Size
Voice Coil
Dia.
Power RMS/
Peak
PS-ADF110T Single 10” 4-ohm 38Hz-280Hz 91dB 40 oz. 2.0” 175W/350W
UNPACKING THE ENCLOSURE AIR SUSPENSION
Every attempt has been made to transport your new PowerBass Downfiring Subwoofer system safely.
Carefully unpack the enclosure and inspect it thoroughly for any damage that may have occurred during
shipping. Notify your local PowerBass dealer immediately should you notice any damage prior to installing
the unit. Be sure to keep the carton and packing material until your system is operational. The original
boxes will do the best job of protecting your speaker system if they need to be transported.
INSTALLATION EXPERIENCE
Installation of PowerBass Autosound Speakers requires experience with a variety of mechanical and electrical
procedures. This manual only provides general installation and operating instructions. If you have any reservations
about your installation skills or lack the proper tools, please contact your local PowerBass Autosound dealer
for assistance.
ENCLOSURE PLACEMENT RECOMMENDATIONS
Your PowerBass Downfiring Subwoofer system accurately reproduces the lowest portion of the audible
frequency range, which is generally considered to be non-directional. As such, the placement within the
vehicle is not as critical to achieve good sound reproduction as with full range systems. Typical locations
include behind or under the seat in a pick-up truck, crew cab, hatchback and trunks in cars or wherever
space is limited.
Use the mounting brackets and hardware supplied to secure the enclosure to the vehicle.
WARNING: Permanent mounting is not only the safest installation, but usually produces
the best sound quality. To avoid vehicle damage or personal injury please ensure that the
enclosure is securely mounted to a surface with adequate strength and rigidity to support it.

The following placement recommendations and installation tips are the result of many hours of development and
experimentation. These examples are provided to you as a guide line. Please feel free to experiment yourself as
you may find that other placements can provide you with superior results.
• Make sure all moving parts and factory electrical wires are out of your way and will not interfere after
installation.
• Should you choose to install the enclosure with the woofer facing down, make sure there is nothing
between the cone and the floor of the vehicle.
• Leave a little slack in the wire to prevent pulling or stretching, this is even more important if the wires will
be run under or through the factory interior.
• Use cable ties and wire clamps to prevent the wires from getting caught or shorted.
• We do not recommend placing or installing loaded enclosures where they might be subjected to moisture.
• RCA cables should be electrically and physically isolated from the vehicle and routed away from any fac-
tory wiring that carries high currents or noise (ie, ABS brake systems and engine computer signals).
• Use power wire large enough to carry the full power of your amplifier. 16-gauge or larger should be
adequate. (Speaker wire not included)
• Check before drilling any mounting holes
• When all connections are made the final step should be to secure the enclosure using the mounting
brackets provided so it remains securely in place.
Your PowerBass Downfiring Subwoofer system needs to be installed some place where it can operate efficiently
and not endanger the occupants of the vehicle. The location and orientation of your enclosure will affect the
quality and quantity of the bass. If the enclosure is to be mounted all the way in the back of the vehicle, it
works best to point the woofer toward the front of the vehicle. Conversely, if the enclosure is going to be mount-
ed closer to the back seat, pointing the woofer toward the rear of the vehicle will give you the best results.
WARNING: Make sure where ever you choose to place the enclosure it’s a dry location on a solid surface. Take
care that none of the mounting screws will pierce any wiring harnesses, brake or fuel lines, the vehicles fuel tank,
spare tire or any other parts of the vehicle. Some or all of these may be located behind or under the mounting
surface.
6

7
B
C
A
Mounting
Bracket
Mounting
Bracket
CARE AND CLEANING
The enclosure is constructed of the same non-resonant material used for premium quality home audio
speakers, but covered in a combination of vinyl and carpet instead of veneer. A damp cloth is best to wipe
down any dirt on the vinyl surface. Avoid using strong cleaners that may discolor the vinyl wrap. Never apply
water or cleaner to the woofer cones.
ENCLOSURE DIMENSIONS AND MOUNTING EXAMPLES
Model A B C
PS-ADF110T 12.4”/315mm 17.9”/455mm 5.6”/143mm

8
PS-ADF AMPLIFER CONTROL PANEL LAYOUT
Fig.2
1. LOW INPUT (RCA) Jacks
These RCA style input jacks are for use with source units that have RCA line level inputs. A source unit with
a minimum output of 100mV is required for proper operation. However, this input can accept levels up to
6Vrms.
2. HIGH INPUT
Use the High Input 4-pin Molex style jack when connecting to the speaker leads directly from a factory radio
without the use of a low level convertor. Be sure to observe the correct speaker polarity. (Do not use if you
are using the LOW INPUT from the RCA jacks).
3. REMOTE LEVEL (RJ45 Jack)
This is the connector port for the PS-ADF Remote Level control. Now the amplifiers secondary gain circuit
can be adjusted from the driver’s seat.
4. AUTO TURN ON (HIGH LEVEL INPUT MODE ONLY)
In the 'ON' position, the Auto Turn-On circuit will sense an input signal and turn the internal amplifier on
without using a remote turn on lead.

5. PHASE Switch
This switch will reverse the phase of the speaker output without having to touch any wiring. 0 is normal.
180 reverses the output. Select whichever setting provides the most bass.
6. LPF (Low Pass Filter) Control
This filter allows the low pass of frequency and has an adjustable crossover point from 50Hz to 200Hz. A
setting of 50Hz will produce only the low frequencies (deep bass). A max setting of 200Hz will allow the
amplifier to produce a more punchy (higher) bass response.
7. BASS EQ Control
This equalization circuit is used to enhance the low frequency response of the vehicles interior. With up to
12dB of boost centered at 45Hz the Bass EQ can be adjusted to meet your personal taste. Please note that
by boosting the Bass EQ to its full +12dB you are asking the amplifier to work 10 times harder!
8. GAIN Control
This control is used to match the sensitivity of the amplifier to the particular source unit (radio) that you are
using up to 6 volts in Low Input Mode and up to 10 volts in High Input Mode. Please note the GAIN control is
not a volume control, it is a level match.
9. POWER Indicator
This RED L.E.D. lights up when the power is on and the system is wired correctly. The LED will shut off if the
unit is either in protect mode or powered down.
10. FUSE
For convenience most PowerBass AutoSound amplifiers utilize common automotive ATC type fuses. For
continued protection in the event that a fuse blows, replace the fuse only with the same value.
CAUTION: These power fuses on the amplifier chassis are for protecting the amp against over current
situation. To protect the vehicles electrical system, an additional fuse should be used within 18-inches of the
battery on the 12V+ cable.
11. BATT+ (12 Volt Positive)
This terminal is the main power input for the amplifier and must be connected directly to the positive (+)
terminal of the battery. A minimum of 10ga cable is required.
12. REM (Remote)
The amplifier in your PS-ADF enclosure can be turned on by applying 12 volts to this terminal. This can be
on the rear of the source unit (radio) in the form of an electric antenna output or remote output. If this is not
available you can wire up to the ACC position on the ignition key switch. An 18ga wire is sufficient to run the
remote. NOTE: If this unit is used in High Level Input Mode and the Auto Turn-On is switched on,
there is no need to hook the remote wire up.
13. GND (Ground Input Connection)
A good quality ground is required for the amplifier to operate a peak performance. A short length of cable
the same gauge as your power cable (8ga is recommended) should be used to attach the ground terminal
directly to the chassis of the vehicle. Make sure that all of the paint is sanded or scraped away to ensure a
good quality ground connection.
9

POWER WIRING AND SIGNAL CONNECTIONS
POWER CONNECTION
BATT+ The amplifier should be wired directly to the vehicle battery using a 8ga power cable. Start at the
vehicle battery and run the power cable through the vehicle’s firewall using grommets to the amplifier’s BATT +
screw terminal. If factory grommets are not available install grommets yourself to protect the cable from sharp
metal edges.
Avoid running the power cable over the engine components and near heater cores. The use of an in-line fuse
or circuit breaker is a must, this will prevent the risk of potential fire caused by a short in the power cable. Con-
nect the fuse holder or circuit breaker as close to the battery positive (+) terminal as possible (no farther than
18-inches from the battery).
The fuse or breaker amperage should be no greater than the fuse rating found on the amplifier control panel lo-
cated on the side of the PS-AWB enclosure. You can now connect the cable to the battery, but remember to leave
the fuse out or the circuit breaker “off” until the other cable connections are made. It is highly recommended that
the cable end connecting to the amplifier is terminated with a spade or ring terminal.
IMPORTANT—You MUST install a fuse holder with an appropriate fuse in line with the power cable
no further than 18-inches from the battery.
REM Run 18ga wire (not included) to the radio power antenna lead or remote output. This wire is responsible
for turning the amplifier on and off. If the source unit (radio) is not equipped with a Remote lead you can connect
this wire to an accessory or ignition point at the vehicle fuse block. In this type of installation, the amplifier will
be on whenever the ignition is on.
GND A cable of the same size (gauge) as the power cable should be used to ground the amplifier. Connect
the ground wire from the screw terminal marked GND on the amplifier control panel to the nearest bare-metal
surface on the vehicle. Keep the length of the ground cable to an absolute minimum using a spade terminal at
the amplifier end and ring terminal as shown in below at the chassis end (Fig 3).
Bolt
Note: Remove any paint
below ring connector
Star Washer
Ring Connector
Ground Wire
Fig.3
10

INPUT SIGNAL
(CHOOSING THE HIGH OR LOW INPUTS)
The PS-ADF amplifer control panel input signal connects to the head unit’s High Level (speaker wire) output
OR Low Level (RCA) output—provided the radio is so equipped with Line Out. A dedicated subwoofer or low
level signal will deliver the best performance. If unavailable use the high level inputs, as will be the case
with most factory head units. (Note once you have chosen whether you will use the High Level or Low Level
inputs follow the corresponding wiring diagrams on the following pages)
NOTE: Never use BOTH High and Low Level inputs at the same time. You must select one or the other!
High Level Input Connections (fig 4)
For radios with only speaker outputs (including most Factory source units). Using the 4-pin Molex style wiring
harness provided, splice directly into the radio’s speaker outputs. Do not break the connection with the
source (radio) and the speakers. Be sure to maintain proper speaker polarity.
Another option is to tap off the existing front or rear full range speakers. Once again be sure to follow the
correct polarity
Wire Color Connect to
Red
Black
Red
Black
Left +
Left -
Right +
Right -
11

Fig.4 High Level Connections
NOTE: Use 8ga power/ground wire for BATT+ and GND connections
12
LR
Remote Turn On
to Power Antenna
CHASSIS
GROUND
12V Battery
GROUND
Fuse
Within 18”
of battery

Low Level Input and RCA Interconnect Wiring (fig 5)
For radios that have RCA line outputs. You will need to connect the low-level RCA style inputs from the PS-
ADF to the line-outputs from the radio (source) via an RCA interconnect commonly called a “stereo patch
cord”. Choose the correct length and style of RCA interconnects for your needs. Always use high quality
RCA audio cables (not supplied) for signal connections—those with multiple layers of shielding or a twisted
pair variety for better noise rejection.
Be extra careful when routing your RCA audio interconnect cables. Car environments are notorious for
poorly insulated wires. This means that hiss, engine noise and fan noise can be easily picked up through
RCA cables if run incorrectly. Take care to make sure the power and audio signal are not on the same side
of the vehicle and they do not cross each other.
Fig.5 Low Level Connections
NOTE: Use 8ga power/ground wire for
BATT+ and GND connections
13

SET UP ADJUSTMENTS
Your PS-ADF enclosure uses several controls to provide sonic integration with virtually any vehicles unique
acoustic properties. Please read the following section carefully to familiarize yourself with the function of
each control.
The following adjustment sequence is recommended to properly tune your PS-ADF enclosure. By first
adjusting the GAIN, the LPF, then the PHASE switch, followed by the BASS EQ (in this order) will give you the
best results.
Input GAIN Control
This control allows you to match the input level of the amplifier to the output level of your head unit (Fig 6).
Matching the input can be accomplished in four simple steps:
1. Make sure the remote gain control is not plugged in until after the master gain control is set.
2. Set the GAIN control on the amplifier to MIN (completely counter clock wise).
3. Turn on the head unit and adjust the volume to 2/3 maximum, and set the BASS and TREBLE on the radio
(source) to zero or flat.
4. Turn the GAIN control clockwise until the sound just begins to distort, then back off slightly to cut distortion
and operate at optimum gain.
Remember, the GAIN control is not a volume control. Ignoring these four steps above may leave you with a
damaged woofer and/or damaged amplifier.
LPF (Low Pass Filter) Crossover Adjustment
Since musical tastes vary, adjust the crossover by ear while listening to the music of your choice. Turn the
crossover LPF adjustment all the way down to 50Hz. Then slowly turn the knob up until desired sound is
achieved. Normal listening level should be right around 100Hz to 150Hz. Use common sense when adjusting
the crossover. When properly adjusted, the bass from the PS-ADF enclosure should blend in with the rest
of your speakers and not overpower the music. Be sure to set the tone controls of your radio (source unit) to
flat while dialing in the crossover. (Fig 7)
Fig.6 GAIN Control
GAIN
MINMAX
Fig.7 Low Pass Control (LPF)
50Hz
LPF
200Hz
14

Setting the PHASE switch
Start with the PHASE switch set at 0˚ and play a favorite music track that contains some solid bass (make
sure the BASS EQ control is set at the 12 o’clock position). Then flip the switch to 180˚ and listen to the
same musical track again. Choose the setting that provides the best bass response according to your taste.
BASS EQ Adjustment
This special feature is designed to provide you with more powerful sound quality and it allows you to increase
the Bass up to +12dB. Keep in mind that more is not always better. Adjusting the control to the MAX (12dB)
position will stress the amplifier and the woofer which could result in damage. (Fig 9)
NOTE: Although this adjustment sequence will in most cases provide the best tuning results, the actual
process may include several readjustments of each of the controls since their settings interact with each
other. If necessary, consult your Authorized PowerBass dealer for help tuning your system.
Fig.9 Bass EQ Control
Fig.8 PHASE Switch
15

Remote Level Controller
Your PowerBass PS-ADF enclosure includes a wired Remote Level Subwoofer control module. It uses
standard telephone wire and telephone RJ45 connectors. To connect the Remote Subwoofer Gain control
to the amplified enclosure, simply insert one end of the telephone plug into the REMOTE gain port. Plug
the other end into the back of the remote module. Mount the module within easy reach or under your dash.
(Fig 10)
NOTE: DO NOT plug in or disconnect the remote bass level controller when the amplifier is on!
Break In Period
To get the most from your woofer we recommend a "break-in" period of at least 40 hours (typically 2 weeks)
at no more than 1/3 of maximum volume.
During this time the cone and spider assembly will gradually break in resulting in greater performance and
more listening enjoyment.
Fig.10 Connection with RJ45 Jack
16

TROUBLESHOOTING TIPS
Problem Solution
Power LED not ON With a Volt OHM Meter (VOM) check:
• +12 Volt power terminal (should read +12 to +16VDC
• Remote turn-on terminal (should read +12 to +16VDC)
• Ground Terminal
Power LED lights RED, no output • Check RCA connections
• Test speaker outputs with known good speaker
• Substitute known good Source Unit
• Check for signal on the RCA cable with VOM in
AC position
The RED LED is ON, no output and
1. Amp is VERY HOT
2. Amp shuts down ONLY when the
vehicle is running
• Thermal protection is engaged. Check for proper im-
pedance at speaker terminals. Also check for adequate
air flow around the amplifier.
• Voltage protection engaged. Voltage to the amp is not
within the 10-16 VDC operating range. Have the bat-
tery/charging system inspected.
Alternator noise (varies with RPM) • Check for damaged RCA cable.
• Check routing of RCA cable
• Check Source Unit for good ground
• Check amp gain setting, turn down if set too high
This manual is the exclusive property of PowerBass USA, Inc.
Any reproduction of this manual, or use other than its intentions is strictly prohibited without the express consent of PowerBass USA, Inc.
Copyright 2017 PowerBass USA, Inc.
17

This manual is the exclusive property of PowerBass USA, Inc. Any reproduction of this manual, or use other than its intentions is
strictly prohibited without the express consent of PowerBass USA, Inc. Copyright 2017 PowerBass USA, Inc.
WARRANTY NOTES
Should a warranty issue arise with our complete subwoofer enclosure PowerBass will replace the defective
woofer or amplifier only. Do not send the entire enclosure, unless the enclosure is defective itself. Power-
Bass does not warranty the cosmetics of the enclosure once installed in the vehicle.
Product Disposal –Certain international, national and/or local
laws and/or regulations may apply regarding the disposal of this prod-
uct. For further detailed information, please contact the retailer where
you purchased this product or the PowerBass Importer/Distributor in
your country.
WE WANT YOU LISTENING FOR A LIFETIME
Dear Customer,
Selecting fine audio equipment such as the speakers you’ve just purchased is only the start of your musical
enjoyment. Now it’s time to consider how you can maximize the fun and excitement your equipment offers.
PowerBass and the Consumer Electronics Association (CEA) want you to get the most out of your equipment
by playing at a safe level. One that lets the sound come through loud and clear without annoying, blaring or
distortion – and, most importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of sound.
So what sounds “normal” can actually be loud and harmful to your hearing. Guard against this by setting
your equipment at a safe level BEFORE your hearing adapts.
PowerBass and the CEA want you listening for a lifetime!
18

POWERBASS AUTOSOUND LIMITED WARRANTY POLICY
PowerBass USA, Inc. offers limited warranty on PowerBass products under normal use on the following terms:
PowerBass Autosound Speakers are to be free of defects in material and workmanship for
a period of one (1) year.
This warranty applies only to PowerBass products sold to consumers by Authorized PowerBass Dealers in the United States
of America. Products purchased by consumers from a PowerBass dealer in another country are covered only by that country’s
Distributor and not by PowerBass USA.
This warranty covers only the original purchaser of PowerBass product. In order to receive service, the purchaser must
provide PowerBass with a valid purchase receipt from an authorized reseller stating the consumer name, dealer, product
and date of purchase.
Products found to be defective during the warranty period will be repaired or replaced (with a product deemed to be equivalent)
at PowerBass’s discretion and will not be liable for incidental or consequential damages. PowerBass will not warranty this
product under the following situations:
• Speakers received with bent frames or water damage
• Abuse such as holes in the cone, surround or ripped spider
• Voice coil damage due to amplier clipping or distortion
• Product that has not been installed according to this owners manual
Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the period of the
express warranty set forth above. Some states do not allow limitations on the length of an implied warranty, so this limitation
may not apply. No person is authorized to assume for PowerBass any other liability in connection with the sale of this product.
Please call [phone] for PowerBass Customer Service. You must obtain an RA# (Return Authorization Number)
to return any product to PowerBass. The RA number must be prominently marked on the outside of the shipping
carton or the delivery will be refused. Please pack your return carefully; we are not responsible for items damaged in
shipping. Return the defective product along with a copy of the original dated retail sales receipt, plus $12.00 for handling
and diagnostic evaluation to:
PowerBass USA, Inc.,
Attn: Returns (RA#__________)
2133 S. Green Privado, Ontario, CA 91761
Residents of HI, AK and US territories will be charged for return shipping. All inquires regarding service and warranty should
be sent to the above address.
Removed or altered serial numbers will void this warranty

PowerBass Autosound – A division of PowerBass USA, Inc.
2133 S. Green Privado – Ontario, CA 91761
Tel. [phone] – Fax [phone]
www.powerbassusa.com
