Moki BASSBURGER User manual

• BassBurger Bluetooth Pocket Speaker
• USB + 3.5 mm (1⁄8 in) Recharge and Audio Cable
• Carry Pouch
• User Guide
CABLE FEATURES
3.5 mm (1⁄8 in) audio plug
Standard USB - for recharge only
Mini USB - attach to BassBurger
1.
2.
3.
A
B
C
D
Power Bluetooth/LINE/OFF switch
Control dial button
Mini USB charge and audio port
Microphone
Expanded Top Base
OVERVIEW AND CONTENTS
Closed
E
F
G
H
Bass chamber
Speaker driver
LED indicator
Non-slip feet

1.
2.
3.
4.
Note: Bluetooth function and control dial button will have no use when
connected via 3.5 mm (1⁄8 in) audio plug.
RECHARGE
Insert mini USB plug into BassBurger.
Insert standard USB plug into a port for approximately three hours.
Recharge via PC, laptop or USB wall adaptor (not included).
LED will glow red when battery is being recharged.
LED will glow blue when battery reaches full capacity.
•
•
•
•
•
Note: Distortion on some computers may occur after recharging or
when battery reaches full capacity. Disconnect the USB plug from the
computer and lower volume. This will allow BassBurger power levels
to even and volume may again be increased after a couple of minutes.
Play via audio cable
Insert mini USB into “CHARGE/AUDIO” port on BassBurger.
Insert 3.5 mm (1⁄8 in) audio plug into audio player socket.
Turn on BassBurger to “LINE” at switch (LED glows blue if charged).
Play music and adjust volume using player controls.
OPERATING INSTRUCTIONS
LINE OFF

Pair and play via Bluetooth
1.
2.
3.
4.
5.
Place BassBurger and a Bluetooth device within one metre.
Enable Bluetooth on your Bluetooth device and search for devices
under Bluetooth settings.
Switch on your BassBurger to the Bluetooth setting (you will hear a
quick “double beep” and LED will start flashing blue).
The BassBurger will scan for new Bluetooth devices or auto
reconnect to last paired device if it is nearby. After a few seconds
you should see “BT SPEAKER” listed under available devices.
Select “BT SPEAKER” to connect or enter passkey “0000” if
requested depending on the Bluetooth version of your device.
Note: Only one audio player or phone may connect to the BassBurger
at a time. If you have a problem pairing check that no other nearby
devices are reconnecting automatically. To re-scan simply turn
BassBurger power o, wait for five seconds and turn power back on.
Dial button control
•
•
•
•
•
Press control dial button in one time to play.
Press again to pause.
Flick control dial button left < restart the track.
Flick control dial button right > advance to next track.
Double flick left << go to previous track.
LINE OFF

Note: Because the in-built microphone is close to the speaker, it has
custom signal processing designed to reduce noise interference and
echo feedback. If the caller has trouble hearing you please ensure
the microphone is facing toward you and position yourself closer to
it if necessary.
Volume control
1.
2.
To increase volume hold control dial button to right > for 5-10
seconds until desired volume is reached (audio player volume
should also be set at an appropriate level).
To decrease volume hold control dial button to left < for 5-10
seconds until desired volume is reached.
Tip: Volume will aect playtime. For the best result set player volume
high and decrease the BassBurger volume to desired level.
Hands-free calls
1.
2.
3.
If a call is received when listening to music playing from a mobile
phone, the music will pause and the phone will ring over the
BassBurger speaker.
To answer flick control dial button to right >.
To end press control dial button.

Open
Close
Twist top-cap forward and
align top and bottom marks
to lock closed.
EXPAND FOR BASS
Hold base in left hand and
top-cap with right hand.
Twist base forward so bass
chamber springs open.
Hold BassBurger as Step 1.
Then push top-cap and
base together.
Tip: When new, the bass chamber may not expand to its full extent.
A solid internal spring with firm bass chamber walls is vital to ensuring
bass stability and superior acoustics. The chamber will expand over
time and the bass performance will continue to improve. Allow your
BassBurger to remain open whenever possible during the first couple
of weeks (even when not in use), the bass chamber will stretch itself
out quicker.

CAUTION
Model: ACC BBTM
Power Output: 3 W
Speaker Driver: Ø 45 mm (14⁄5 in) x 1
Sensitivity: => 80 dB, 280 Hz - 16 kHz
Charge Time: 2.5 - 3 hrs via USB
Closed Dimensions: Ø 6.5 cm x H 5 cm (23⁄5 in x 2 in)
Operating Temp: 0˚C ~ 45˚C (32˚F ~ 113˚F)
Weight: 100 g (3.5 oz)
SPECIFICATIONS
•
•
•
•
•
•
•
•
Do not forcibly extend chamber.
Damage to internal parts is likely
to result.
Do not dispose of speaker in fire
or expose to excessive heat.
Do not store, use or recharge in
damp or high temperature areas.
Do not insert anything into BassBurger body.
Do not touch silver speaker part with any hard or sharp object.
Do not attempt to disassemble or change battery.
Do not apply excessive force to cables or connection points.
Please keep out of reach of young children and pets.
