Power Industries Vapor-Eze 5100 User manual
Model: Vapor-Eze 5100
THANK YOU FOR CHOOSING THE
VAPOR-EZE
5100 !
PLEASE READ THIS BOOKLET BEFORE USING.
Power Industries Inc
Toll Free: (800) 763-9375 Fax: (630) 443-0671
www.vaporeze.com
Copyright December 2009 Vapor-Eze
Copyright December 2009 by Vapor-Eze
TM
TM
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ THESE SAFETY INSTRUCTIONS BEFORE USING THIS
PRODUCT. KEEP THEM AVAILABLE FOR FUTURE REFERENCE.
1. Do not use the unit in temperature exceeding 110 degrees Fahrenheit.
2. This unit works on 12 Volts D C.Applying a higher voltage may cause a
fire hazard or electric shock.
3. Use only the AC ( home ) or Auto adapter supplied for your Vapor-Eze
5100 Unit. Use of another adapter will void your warranty.
4. Always place the unit on a dry level surface.
5. The unit is intended for use in a single room or in your vehicle.
6. For warranty purposes, you should mark the date of first use and all
filter changes on the label located at the bottom of the unit. This system
is not a toy. Do not let children play with it.
7. To reduce the risk of electric shock, do not expose the unit or flexible
cord to moisture in any way.
8. Turn the unit off to avoid electric shock before cleaning or opening to
replace filters.
9. Do not attempt to disassemble the unit other than to replace filters.
10. Do not operate if the unit is damaged in any way.
11. Do not insert metallic items of any type into this unit.
12. Do not wet or soak the unit. Clean only with a slightly damp cloth and
allow drying before using again.
13. Do not use in places where flammable or explosive materials are stored.
14. Do not let unit sit in direct high sunlight or near high temperature objects.
-1-
WARRANTY & SERVICE
WE GUARANTEE THE UNIT TO BE FREE FROM DEFECTS IN MATERIAL
OR WORKMANSHIP FOR A PERIOD OF ONE (1) YEAR FROM THE DATE
OF PURCHASE.
Operating this unit with an adapter other than the one supplied or any attempts
made to service or modify the unit, will VOID THE WARRANTY.
For your convenience, please record the complete model number and the date
of purchase below, and attach your receipt as proof of purchase.
Date of Purchase: ______________________________________
Name and address of Purchaser: __________________________
____________________________________________________
____________________________________________________
Telephone: ______________________________________
If you believe the unit to be defective, return directly to us at the address
shown on the back of this booklet.
Be sure to send via traceable means and the above information must be
completed and included with the return.
-6-
Attach your purchase receipt here
MAINTENANCE INSTRUCTIONS
CLEANING AND STORAGE
1. Turn the unit OFF and unplug it before cleaning.
2. Use only a water dampened, soft cloth to clean the unit.
3. Never use solvents or other chemicals.
4. Store the unit in a cool, dry place when it is not in use.
REPLACING THE FILTERS
1. Remove and replace the filters at least once every 6 months. We
recommend that all of the replaceable filters be changed at the same time.
2. The life of the filters is affected by the amount of use and the
concentration of pollutants in the air.
3. When replacing filters, please follow these instructions:
Loosen the screw Open the upper cover Replace the filters
ADDING THE AROMATHERAPY OILS ( OPTIONAL )
1. Refill / Replace the fragrance pad at least every 45 days.
2. Keep the fragrance pad away from children. NOT TO BE EATEN !
3. Please replace the fragrance as shown in following instructions:
Press the fragrance cover in Turn the container over Add the Essential oil(s)
and let it pop out again. and slide the cover off. of your choice to cotton pad.
-5-
NAME OF PARTS
Our unique two fan system uses the fan on the right side to draw air
in from the room, to purify it as described below:
①HEPA Filter removes particles and contamination.
②Photo - Catalyst Filters work with UV lamp to break down and destroy
odors, germs, viruses, bacteria, mildew and fungus.
③Ultraviolet Lamp
④Activated Carbon Filter
-2-
Outlet Power Speed Inlet
Fragrance cover Upper cover
PURIFIED
AIR
OUT
AIR CLEANING PROCEDU
RE
④②③② ①
DIRTY
AIR
IN
OPERATING INSTRUCTIONS
IMPORTANT…
DO NOT OPERATE THE UNIT WITHOUT FILTERS AND UV LIGHT
INSTALLED.
1. One HEPATYPE filter, one activated carbon filter, Ultraviolet light and
two photo - catalytic filters are pre-installed. There is nothing further to
install in order to start using the unit.
2. To use the built in Aromatherapy function, press the cover in to release
the tray, then remove the plastic cover and add the fragrance of your
choice to the cotton pad. Replace the cover and tray into the unit.
To remove or replace the tray simply, “push in”.
3. Plug the adapter into the proper power source.
4. Press the POWER button to turn the unit ON and the LED on the left
side will glow Red. Press the POWER button again to turn the unit
OFF and the LED light will also turn OFF. The UV light will always be on
when the power for the unit is turned ON.
5. Press the SPEED button to adjust the airflow to HIGH = (Red indicator)
or LOW = ( Green indicator )
PLEASE NOTE:
For quick air cleaning, set the speed control to HIGH setting. After
about 30 minutes, set the speed control to the LOW speed setting.
To maintain fresh air at all times, set the speed control to LOW speed
setting. The unit uses very little electricity.
For evening quiet use, set the speed control to the LOW speed setting.
-3-
MAIN FEATURES
Combining the advanced technologies of UV light and multi-layer filters…
the Vapor-Eze 5100 reduces the air pollution caused by dust, germs, bacteria,
harmful gases, smoke, odors and vehicle exhaust.
Detailed features
1. The HEPA filter: Traps particles as small as 0.3 microns
( allergens, pollen, dust, smoke, pet dander, etc. )
2. Activated carbon filter: Absorbs smoke and odors.
3. UV light and photo-catalytic filter:
--Breaks down poisonous fume and VOC’s, i.e. formaldehyde, ammonia.
--Kills germs, viruses and bacteria.
--Kills mold, mildew and fungus spores.
--Eliminates the smell of smoke, and other annoying odors.
4. Aromatherapy: Add the essential oil of your choice.
TECHNICAL SPECIFICATIONS
1. Rated Voltage: 12 Volts DC
2. Rated Power: 8 Watts (on high setting)
3. Airflow: 30 Cubic Meters / hour - 18 Cubic feet / minute ( High )
15 Cubic Meters / hour - 9 Cubic feet / minute ( Low )
4. UV Light: Wavelength: 365 nanometers
Lamp life:Approx. 20,000 hours
5. Weight: 2.5 Pounds (with adapter)
6. Dimensions: 8.27’’W x 4.72’’D x 2.95’’H or ( 210 x 120 x 75 mm )
7. Coverage Area: Approx. 180 Sq. Feet ( room size = 12’ x 15’ )
-4-
POWER
SPEED
