Powerfix 10181 User manual

IAN 78526
MOTION SENSOR
MOTION SENSOR
Operation and Safety Notes
CZUJNIK RUCHU
Wskazówki dotyczące obsługi i bezpieczeństwa
BEWEGUNGSMELDER
Bedienungs- und Sicherheitshinweise

Before reading, unfold the page containing the illustrations and familiarise yourself
with all functions of the device.
Przed przeczytaniem proszę rozłożyć stronę z ilustracjami, a następnie proszę
zapoznać się z wszystkimi funkcjami urządzenia.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich
anschließend mit allen Funktionen des Gerätes vertraut.
GB Operation and Safety Notes Page 5
PL Wskazówki dotyczące obsługi i bezpieczeństwa Strona 25
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 45

TIME LUX
D5 6
a1
b
432
PIR
L (BROWN)
N (BLUE)
A (RED)
NOMINAL
LOAD
L N
INPUT∼
OUTPUT∼
L (BRAUN)
N (BLAU)
A (ROT)
LAST
EINGANG∼
AUSGANG∼
C3

5GB
Introduction.........................................................Page 6
Intended use ..............................................................Page 7
Technical Data...........................................................Page 7
Parts description.........................................................Page 9
Safety........................................................................Page 9
Mounting
Select a suitable place for installation......................Page 13
Installation..................................................................Page 13
Start-up
Setting the lighting duration of the device ...............Page 15
Setting the light sensitivity..........................................Page 16
Error Analysis ....................................................Page 17
Cleaning and Care.........................................Page 19
Disposal...................................................................Page 20
Warranty and Service
Service address .........................................................Page 21
Manufacturer.............................................................Page 23
Table of contents

6 GB
Introduction
Introduction
Motion Sensor
Introduction
Congratulations on the purchase of your new
device. You have selected a high quality
product. The instructions for use are a part of
this product. They contain important information about
safety, use and disposal. Before using the product,
please familiarise yourself with all the operating and
safety instructions. Only use the product as instructed
and only for the specified applications. When passing
this product on to others please be sure to also include
all of its documentation.

7GB
Introduction
Introduction
Intended use
The motion detector is intended for the automatic control
of light sources. The product turns on, respectively turns
off sources of light if persons move within the sensor de-
tection area. Other uses or changes to the product con-
stitute improper use and carry serious risks of accidents.
The manufacturer is not liable for any damages due to
improper use. The product is not intended for commer-
cial use.
Technical Data
Type: 10181
Model No.: ST09
Rated voltage: 220–240V∼ 50Hz
Nominal load: max. 1200 watt (for light
bulb lighting material)
max. 300 watt (for

8 GB
Introduction/Safety
Introduction
energy saving lighting
material)
Protection class: II/
Delay time min.: 10 sec. - +/- 3 sec.
Delay time max.: 7 min. +/- 2 min.
Surrounding light: 3–2000 Lux (can be set)
Range: max. 12m
Coverage area: max. 180°
Operating temperature: -20–40°C
Operating humidity: <93% rF
Recommended
installation height: 1.8–2.5 m

9GB
Introduction/Safety
Introduction
Parts description
1Sensor
2Base plate
3Screw terminal
4Screw with screw anchor (ø approx. 6mm)
5Control dial TIME („Time“)
6Control dial LUX („Light sensitivity“)
Safety
Please read all the safety information and instructions.
Failure to observe the safety information and instructions
can result in electric shock, fire and/or serious injury.
The manufacturer is not liable for cases of material dam-
age or personal injury caused by incorrect handling or
non-compliance with the safety instructions. In such
cases, the warranty is voided.

10 GB
Safety
Safety
PLEASE KEEP ALL SAFETY INSTRUCTIONS AND IN-
STRUCTIONS FOR USE FOR FUTURE REFERENCE!
Avoid the danger of death
from electric shock!
Before installation, check the motion detector, as
well as connection cords to ensure that these are
intact. A defective product and defective cords in-
crease the risk of electrical shock. A defective prod-
uct and defective cords increase the risk of electrical
shock.
DANGER TO LIFE BY ELECTRIC
SHOCK! Before installation or performing any
work on the lamp, switch off the electrical circuit at
the circuit breaker box or remove the fuse from the
fuse box.

11GB
SafetySafety
Only install the motion detector while wearing dry
clothing and preferably, shoes with rubber soles or
while using an insulation mat.
If not working properly, only allow the sensor 1to
be repaired by an electrician.
Never take the product apart.
How to avoid personal injury and
damage to the product!
RISK OF FATAL
INJURY AND ACCIDENT HAZARD
FOR TODDLERS AND SMALL CHIL-
DREN! Never leave children unattended with the
packaging material or the product. The packaging
material poses a suffocation hazard, and there is a
risk of fatal injury by electric shock. Children often
underestimate dangers. Please keep children away
from the device at all times.

12 GB
Mounting
Safety
Children or persons who lack the knowledge or ex-
perience to use the device or whose physical, sen-
sory or intellectual capacities are limited, must never
be allowed to use the device without supervision or
instruction by a person responsible for their safety.
Children must be supervised at all times so that they
do not play with the device.
CAUTION! EXPLOSION HAZARD! Do not
operate the motion detector in potentially explosive
environments containing flammable vapours, gases
or dusts.
Never exceed the maximum rated supply voltage of
240V∼.
Avoid extreme temperature fluctuations. Install the
product only if the ambient temperatures are accept-
able.
Installation should be performed by an electrician
who is familiar with the regulations and risks.
Never take the product apart.

13GB
MountingSafety
Mounting
Select a suitable place for
installation
Ensure that
– the motion detector will not be functionally inhibited at
the desired place of installation due to obstacles or
constantly moving objects.
– the motion detector is not installed where there are
strong temperature fluctuations, e.g. due to heating
devices or air conditioners.
Installation
DANGER TO LIFE BY ELECTRIC
SHOCK! Before installation, switch off the electri-
cal circuit at the circuit breaker box or remove the
fuse from the fuse box.

14 GB
Mounting/Start-up
Mounting
Note: The recommended installation height is be-
tween 1.8 and 2.5 m.
Note: Before installation, ensure an optimal direc-
tion of motion. The motion detector reacts more
sensitively to movement from the side than to motion
from the front (see Ill. A). Therefore, we recommend
installing the motion detector 1to the side of the
direction of movement.
Note: To attach the base plate 2it is necessary
to drill two holes. We recommend a drill with a
6 mm diameter.
Remove the screws 4from the front of the motion
detector by screwing them in the direction of
rotation (see Ill. B).
Insert the cable through the cable opening of the
base plate 2.
Screw the base plate 2to the desired position.
Connect the cable to the screw terminal 3of the
motion detector as depicted in Ill. C.

15GB
Mounting/Start-upMounting
Attach the cover of the connection area back to the
base plate 2by screwing the screws 4in the
direction of rotation .
Start-up
Turn the electricity back on. The device is now ready
for use.
Setting the lighting duration of the
device (Ill. D)
Note: the lighting duration of the device can be set
from min. 10 sec. to max 7 min.
Turn the control knob TIME 5in the direction „-” in
order to decrease the lighting duration of the device.

16 GB
Error Analysis
Start-up
Turn the control knob TIME 5in the direction „+“
in order to increase the lighting duration of the
device.
Note: The lighting duration is always calculated
based on the respective last movement recorded by the
sensor 1.
Setting the light sensitivity (Ill. D)
Turn the control knob LUX 6in the direction „ “.
The sensor 1is in the night operation mode and
does not react to light values below 3 Lux.
Turn the control knob 6in the direction „ “. The
sensor 1is in the night and day operation mode.
Note: the intermediate range is for various light
values.

17GB
Error Analysis
Start-up
Error Analysis
Note: The function of the device is dependent on on
the outside temperature. Functional errors may occur
due to strong temperature fluctuations.
Problem Solution
The connected
lighting does
not illuminate.
a) Check to ensure that the elec-
trical cord and the device are
connected correctly.
b) Replace defective lighting
material.
c) Check the setting of the light
sensitivity.

18 GB
Error Analysis/Cleaning and Care
Error Analysis
The sensor de-
tection is im-
paired.
a) Check if the sensor 1is
covered by an object.
b) Check the setting of the light
sensitivity.
c) Check if the object to be de-
tected is outside of the sensor
range 1.
d) Check if the recommended
installation height has been
observed.
The lighting
does not turn
off.
a) Check if there is an object in
the range of the sensor 1,
which is constantly moving
and provides for constant
activation of the lighting.
b) Check the setting of the light-
ing duration.

19GB
Error Analysis/Cleaning and Care
Error Analysis
The lighting
does not turn
off.
c) Check if the nominal voltage
conforms with the technical
data of the product.
d) Change the location of the
motion detector, respectively
avoid air conditioners, fans,
heating devices, etc. in the
sensor range of the motion
detector.
Cleaning and Care
Never use cleaners or a rough cloth. These may
damage the sensor 1.
Clean the product with a dry, lint-free cloth.

20 GB
Warranty and Service
Disposal
Disposal
The packaging is made of environmentally
friendly materials that can be disposed at
your local recycling facilities.
Contact your local refuse disposal authority for more
details on how to dispose of your worn-out product.
When your device has come to the end of its
life, please do not throw it out with your
household refuse, but in the interest of the en-
vironment, take it to a suitable centre where it
can be disposed of properly. Please contact
your local authority for information on collec-
tion points and their opening hours.
