PowerPac IVAC POWER2 PPV2000 User manual

IVAC POWER2 VACUUM CLEANER
PPV2000

Parts & Description s
ON/OFF Button
Nozzle
Suction Control
Switch
Hose
Cable Rewind Button
Dust Cup Dust Cup Handle
Extension Tube
3-Pin Plug
Air Outlet
Hose
Socket
Suction Head
Floor Brush
Dust Cup Filter Cover
Big Wheel
Hose Handle
Handle

How to Assemble s
Hose Connection
To connect Hose: Insert the Hose
Socket of the Hose into the
Suction Head; tightens with a
“click” sound.
To disconnect Hose: Press the two
buttons on the side of the Hose
Socket of the Hose and pull out the
Hose Socket.
Tube Connection
To connect Hose: Insert the Nozzle
of the Hose (narrow end) into the
Extension Tube (wider end) and
twist.
To disconnect Hose: Hold the
Nozzle of the Hose (narrow end)
and the Extension Tube (wider
end) and untwist.
To both extend and retract the
Extension Tube: Press the button
forward and concurrently either pull
out to extend or push in to retract,
the Extension Tube.
To connect: Insert the Extension
Tube into the
Floor Brush
Crevice Nozzle
 Bristle Brush
and twist. Untwist to disconnect.
Floor Brush
withdraw brush for cleaning carpet;
extend brush for cleaning floor.
Floor use
Carpet use
2 buttons
on
Hose
Socket
Suction Head
Nozzle
Extension Tube
Push button forward

Crevice Nozzle
for reaching into corners or cracks
Bristle Brush
for cleaning bookshelves, curtains
or furniture.
Suction Control
The Suction Control Switch
situated at the Hose Handle allows
the control of suction power.
ON/OFF Button
Press the ON/OFF Button to turn
the appliance ON or OFF.
Crevice
Nozzle
Bristle
Brush
Cable Rewind
Button
ON / OFF
Button
3-Pin Plug
Air Outlet
Air Outlet Filter
Hose Handle Suction Control Switch

Tube Connection
Hose Connection
Suction Control
ON/OFF Button
To connect: Insert the
Nozzle of the Hose
(narrow end) into the
Extension Tube (wider
end) and twist.
Untwist to disconnect
To connect: Insert
the Hose Socket
of the Hose into
the Suction Head.
Tightens with a
“click” sound
To disconnect:
Press the two
buttons on the side
of the Hose Socket
of the Hose and pull
out the Hose
The Suction
Control switch
situated at the
Hose Handle
allows the control
of suction power
Press the
ON/OFF Button
to turn the
appliance ON or
OFF
Floor Brush
Crevice
Nozzle
Bristle Brush
Dust Meter
Storing
Cable Rewind
Button
withdraw brush for
cleaning Carpet; extend
brush for cleaning floors
for
corners,
cracks
for
bookshelf,
curtains,
furniture,
sofa.
after the
Dust Meter
changes
colour to
red,
replace the
Dust Bag.
You can store
items such as
the Brush Clip
into the rear of
the unit
Rewind the power
cable by pressing
the Cable Rewind
Button.
Floor use
Carpet use

Warnings s
ATTENTION :
Read this booklet carefully as it contains important instructions for a safe installation, use
and maintenance.
Important instructions to be kept for future reference.
The following basic precautions should always be followed when using electrical
appliances:
1. Read all instructions before using the appliance.
2. This appliance must be used only for the purpose it was expressly designed; any use
NOT complying with the instructions contained in the manual is considered
inappropriate and dangerous. The manufacturer is NOT responsible for possible
damages caused by the inappropriate and/or unreasonable use.
3. This appliance is NOT suitable to be used or stored near heat sources (open flame,
ovens, heaters, stoves, etc.) and/or in an explosive environment (in the presence of
flammable substances such as gas, vapour, mist or dust, in atmospheric conditions
when, after ignition, the combustion is spread in the air). Items containing these
substances should never be placed in the appliance, and never be used to clean the
appliance in order to avert the risk of fire or explosion.
4. This appliance must NOT be used for vacuuming burning, smoking, toxic, volatile or
flammable substances. The appliance must NOT be used to clear sewers. An
explosion may occur if the machine suctions sewer gases. Sewer gases inhalation
may lead to unconsciousness and death.
5. It is NOT recommended to use the appliance for cleaning open stoves or other devices
that contains oil or grease, soot, clay dust, plaster or other similar materials that are
resistant to water action.
6. DO NOT vacuum mud, gypsum material, wall powder, blade, kindling, clumps of hair,
large pieces of paper and other items such as sharp metal objects as that may make
the absorbing inlet, tube, hose and filter get blocked and the motor get burned. An
indication of blockage may manifest as an abnormal sound or poor suction. If these
small particles were absorbed, please disconnect the power cord and remove them
from the dust bag or filter immediately.
7. The packing materials (plastic bags, expanded polystyrene, etc.) must be kept out of
the reach of children or disabled persons since they represent potential sources of
danger.
8. The installation/assembly of the appliance will be made in accordance with the
indications of the manufacturer. A wrong procedure may cause damages to persons,
animals or objects, for which the manufacturer cannot be considered responsible.
9. Place and use the appliance on a horizontal, stable and heat-resistant surface.
10. Before use, check the integrity of the appliance and power cable. In case you are not
sure, contact a qualified person. If the power cable is damaged, it must be replaced by
the manufacturer or its service agent or a qualified technician in order to avoid a shock
hazard.

11. Before powering the appliance make sure the rating (voltage and frequency)
corresponding to the grid and the socket is suitable for the plug of the appliance, and
that the wall socket is properly grounded.
12. DO NOT power the appliance using multiple sockets. If possible, avoid the use of
adapters and/or extension cables; if their use is absolutely necessary, use only
materials in compliance with the current safety regulations and according to the
electrical parameters of the adapters.
13. The appliance must NOT be switched on using external timers and/or other remote
control appliances which are not specified in this manual.
14. Only use original components & accessories provided by the manufacturer. Any non-
original components & accessories NOT recommended by the manufacturer may
cause injuries to persons or damage to the appliance.
15. If you are using the appliance for the first time, you should:
a. Use the appliance only if the Air Inlet Filter, Air Outlet Filter & Dust Cup Filter are
installed! This is especially so if the surroundings to be vacuumed is extremely
dusty. Failure to do so will only send the dust back out after being suctioned. DO
NOT use other filters except the ones attached to the appliance by the
manufacturer.
b. Use the appliance only if the turbine (motor) is in a good working condition before
turning on this appliance. Failure to do this could cause a risk of injury to persons
and would defeat the utility of the appliance.
c. Be extra careful when vacuum cleaning on stairs as the machine might topple.
d. Switch off the appliance and unplug the socket from the electric mains when not in
use and before filling, emptying and cleaning the appliance
e. Should there be a need to stop the appliance from operating, simply press the
ON/OFF Button, switch off the electric mains and unplug the power cable.
Make sure to remove any label or protective sheet which may prevent its proper
functioning.
DO NOT:
cover the appliance during functioning;
obstruct totally nor partially the air outlet with anything that may reduce the suction,
such as dust, lint, hair, etc.;
insert objects or body parts inside the protection cover of the appliance;
use the appliance for more than 20 minutes without turning it off for at least 10
minutes for a total usage of 2 hours in a single day – failure to heed this warning
may result in motor failure;
leave the appliance unsupervised during operation.
14. Plug and unplug the power cable with dry hands and hold it firmly. Always unplug the
power cable to avoid overheating and avoid stretching it. DO NOT pull it, tug it or use it
to drag the appliance to which is connected. Before unplugging the appliance, press

the ON/OFF switch on the appliance to ‘OFF’ and switch off the electric mains.
15. Hold the plug when rewinding the power cable. DO NOT allow the plug and the cable
to whip around when rewinding. DO NOT use the cable as a handle, pull or carry the
appliance by the cable, pull the cable around sharp edges, abrasive surfaces or
corners, run the appliance over the cable or close a door on the cable. Keep the cable
away from heated surfaces, abrasive or sharp surfaces or in positions where it can be
damaged easily.
16. Avoid bending, stamping and dragging the hose. DO NOT use the vacuum cleaner if
the hose is damaged.
17. During operation, DO NOT touch the appliance with wet body parts, and it is
recommended to have between you and the standing surface, an isolating element (for
example, wearing shoes with rubber soles).
18. DO NOT use the appliance to clean up liquids outdoors, upon an earth floor. If it
should be necessary to step on a wet or damp floor to pick up water, do not touch the
metallic parts of ANY electric device, lamp or switch while performing this operation.
19. DO NOT soak the appliance in water or other liquids, wash it under the tap, or let any
liquid flow into the internal casing of the appliance to prevent electric shock. In case of
accidental fall in water, DO NOT try to take it out, but first of all unplug immediately the
power cable from the socket.
20. The appliance should NOT be placed on a surface or in the vicinity of objects which
can be damaged by heat, such as carpets or plastics. When using the appliance, the
surface that the appliance is placed upon as well the surface immediately above (e.g.
a wooden cabinet above the appliance), may become very hot. If the appliance is
operated on wooden furniture, use a protective pad to prevent damage to delicate
finishes.
21. Avoid placing the power cable on abrasive or sharp surfaces or in positions where it
can be damaged easily. The cable must NOT be placed under carpets, or covered with
throw rugs, runners or similar. Arrange the cable away from the high traffic area, and
where it will NOT be tripped over.
22. Always remember to unplug the power cable of the appliance if it is NOT used for a
long period, before storing, cleaning or performing any maintenance operation.
23. Avoid carrying out operations which are NOT specified in this manual (such as
disassembling and/or altering).
24. In case of malfunction or anomaly during the functioning, switch off the appliance
immediately, turn off the power and check the cause of the anomaly, if possible, with
the support of a qualified person.
25. If smoke is observed coming out of the appliance, unplug the power cable
immediately.
26. This appliance is NOT intended for commercial use but to be used in households and
similar applications, such as:
Staff kitchen areas in shops, offices and other working environments;
Dormitories;
By clients in hotels, motels and other residential environments;

Bed and breakfast type environment.
27. DO NOT use or store the appliance outdoors. Store and use the appliance only
indoors, or in any case, protected from weathering such as rain, direct radiation of the
sun and dust.
28. This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall NOT play
with the appliance. Cleaning and user maintenance shall NOT be made by children
unless they are older than 8 and supervised. Keep the appliance and its cable out of
reach of children less than 8 years old.
29. Save these instructions.

How to clean s
WARNING: The appliance must NEVER be used without the HEPA filter contained within
the Dust Cup. Always place it back after cleaning it. When the suction power decreases,
the filter might be clogged. Using the appliance with a clogged filter puts additional strain
on the motor. Prompt removal of dust and dirt not only improves the efficiency of the
appliance but only extends its working life.
Press the ON/OFF Button to turn
the appliance OFF.
Unplug the power cable firmly using
dry hands.
Pull out the Air Outlet Cover from
the main body by pressing down on
the Air Outlet Cover Lever.
Remove the Air Outlet Filter.
Clean the filter by shaking the filter
free of dust and rinsing it under
running water.
Wash the Air Outlet Cover with
detergent and rinse under running
water. Dry the Air Outlet Cover &
Air Outlet Filter by airing it under
the Sun.
Insert the Air Outlet Filter onto the
Air Outlet Cover.
Replace the Air Outlet Cover to its
original position and insert the cover
by pressing down on the Air Outlet
Cover Lever.
Cable Rewind
Button
ON / OFF
Button
3-Pin Plug
Air Outlet
Air Outlet Filter
Air Outlet Cover Lever
Air Outlet Cover
(Front)
Air Outlet Cover
(Back)
Air Outlet Filter

Press the Lock Button to remove
the Dust Cup from the main body
by lifting it up.
Place the Dust Cup in a vertical
position with the Dust Cup Cover
(back in colour) at the bottom,
directly above a trash bag.
Press the Dust Cup Cover Button
and the Dust Cup Cover should
rotate downwards (in a 3 o’clock to
6 o’clock position), causing the
contents of the Dust Cup to fall into
the trash bag.
Separate the parts of the Dust Cup
Holding the Dust Cup Handle in
one hand and the Dust Cup Filter
Cover in the other, twist the Dust
Cup Filter Cover anti-clockwise.
Lift the Dust Cup Filter Cover out
of the Dust Cup.
Lift the Dust Cup Filter out of the
Dust Cup.
Wash the Dust Cup & Dust Cup
Filter Cover with detergent and
rinse under running water.
Shake the dust from the Dust Cup
Filter (HEPA Filter). Rinse the Dust
Cup Filter under running water.
Dry the Dust Cup, Dust Cup Filter
Cover & Dust Cup Filter by airing it
under the Sun.
Dust Cup Handle Dust Cup Filter Cover
Dust Cup Cover Button
Dust Cup
Lock Button
Dust Cup Cover
(bottom)
Dust Cup Filter Dust Cup Filter

Lift the Dust Cup Filter out of the
Dust Cup, rinse or replace, replace
after drying.
Reinstating the parts of the Dust
Cup
Place the Dust Cup Filter (HEPA
Filter) in the correct position.
Holding the Dust Cup Handle in
one hand and the Dust Cup Filter
Cover in the other, twist the Dust
Cup Filter Cover clockwise.
The Dust Cup Filter Cover is now
secured to the Dust Cup.
Lift the Dust Cup
Filter out of the
Dust Cup, rinse
under running
water, dry
Dust Cup Handle
Dust Cup
Dust Cup Filter

Insert your thumb and middle finger
into the openings (upper & lower
holes) of the Air Inlet Filter and
turn anti-clockwise. Pull out the Air
Inlet Filter from the appliance.
Separate the black sponge from the
Air Inlet Filter and rinse both the
sponge and the Air Inlet Filter
under running water. Dry the
sponge and the Air Inlet Filter by
airing it under the Sun.
Replace the sponge to its original
position in the Air Inlet Filter.
Put the Air Inlet Filter into the main
body by inserting your thumb and
middle finger into the openings
(upper & lower holes) of the Air
Inlet Filter and turn clockwise all
the way until a sound is heard.
Attach the Dust Cup into the main
body by holding the Dust Cup
Handle and pushing it into position.
A “click” sound is heard when the
Dust Cap securely attaches to the
main body.
DO NOT lift up the appliance by the
Handle if the click is NOT heard.
Air Inlet Filter
Air Inlet openings
black sponge
Air Inlet Filter
(front)
Air Inlet Filter
(back)
Dust Cup

Problem Solving s
Problem
Possible Causes
How to Solve
The motor will not start
The plug is not properly
inserted in the power
socket.
Insert the plug into the
power socket. Do not use
adaptors or extensions.
The switch at the electric
mains is not switched on
and/or the ON/OFF Button
is not pressed.
Turn the electric mains
and/or the ON/OFF Button
on.
The motor has
overheated.
Disconnect the appliance
from the electric mains
and leave the motor to
cool.
The power cable is
defective.
Have the power cable
replaced at an authorised
Service Centre.
Lack of power.
Check that the house main
breaker is on.
The appliance vibrates
The appliance is not
resting on a stable
surface.
Place the appliance on a
flat, stable surface.
The wheels are worn out.
Have them replaced at an
Authorised Service
Centre.
The speed used is too
high.
Set a lower speed.
The Dust Cup has not
been correctly locked into
the main body.
Check that the Dust Cup is
correctly locked into the
main body and ensure the
Dust Cup has been
emptied.
Suction power becomes
weak
The Dust Cup Filter Cover
is not tightly locked in the
Dust Cup.
Check that the Dust Cup
Filter Cover is locked in
the Dust Cup
The Dust Cup is full.
Empty the Dust Cup.
The Hose, Extension
Tubes, Floor Brush,
Crevice Nozzle, Bristle
Brush and the Filters (Dust
Cup/Air Inlet/Air Outlet)
are clogged.
Unclog the attachments.

Power cable will not fully
rewind.
The power cable may be
twisted.
Pull out the power cable
and lay out the power
cable to untwist. Press the
Cable Rewind Button,
alternating with pulling out
the power cable several
times.

ENVIRONMENTAL TIP s
This appliance, along with all other electronic appliances, should, when it is no longer
capable of functioning, be disposed with the least possible environmental damage
according to the local regulations in your area. In most cases you can discard the
appliance at your local recycling center.
DISPOSAL: Do not dispose this appliance as unsorted municipal waste. Collection of such
waste separately for special treatment is necessary.
WARRANTY s
The manufacturer provides warranty in accordance with the legislation of the customer’s
own country of residence, with a minimum of 1 year, starting from the date on which the
appliance is sold to the end user.
The warranty covers defects in material and workmanship.
The repairs under warranty may only be carried out by an authorised service centre. When
making a claim under the warranty, the original bill of purchase (with purchase date clearly
indicated) must be submitted.
The warranty will not apply in cases of:
normal wear and tear
if the steps (as laid out in the section regarding Warnings) have not been observed
e.g. overloading of the appliance, use of non-approved accessories
if the appliance has not been properly maintained, if force has been used against it or
if it has been damaged in any other way
damage caused by non-observance of the user manual or non-compliance with the
installation instructions
errors or faults owing to defects in the distribution system
if the appliance has been repaired or modified or changed in any way or by any person
not properly authorized
SPECIFICATION s
MODEL
VOLTAGE
POWER
PPV2000
220 – 240 V ~50 – 60 Hz
2000 W
