Powerplus Garden POW63172 User manual

POW63172 EN
Copyright © 2015 VARO P a g e | 1www.varo.com
1APPLICATION..................................................................................2
2DESCRIPTION (FIG A) ....................................................................2
3PACKAGE CONTENT LIST.............................................................2
4SYMBOLS........................................................................................2
5GENERAL POWER TOOL SAFETY WARNINGS ..........................3
5.1 Working area...........................................................................................................3
5.2 Electrical safety.......................................................................................................3
5.3 Personal safety .......................................................................................................4
5.4 Power tool use and care.........................................................................................4
5.5 Service.....................................................................................................................4
6SPECIFIC SAFETY INSTRUCTIONS..............................................4
7ASSEMBLY......................................................................................5
7.1 Assembling the tubes (Fig 1, 2)..............................................................................5
7.2 Shoulder strap.........................................................................................................5
7.3 Leaf bag (Fig 3) .......................................................................................................5
8OPERATION.....................................................................................5
8.1 Steps prior to operation..........................................................................................5
8.2 Switching ON/OFF...................................................................................................5
8.3 Use/Operation .........................................................................................................6
8.4 Switching operating mode (Fig 4)..........................................................................6
8.5 Leaf bag...................................................................................................................6
9CLEANING AND MAINTENANCE...................................................6
9.1 Cleaning...................................................................................................................6
9.2 Replacing carbon brushes.....................................................................................6
9.3 Maintenance............................................................................................................6
10 TECHNICAL DETAILS.....................................................................7
11 NOISE...............................................................................................7
12 WARRANTY.....................................................................................7
13 ENVIRONMENT ...............................................................................8
14 DECLARATION OF CONFORMITY ................................................8

POW63172 EN
Copyright © 2015 VARO P a g e | 2www.varo.com
GARDEN BLOW/VAC 3000W
POW63172
1 APPLICATION
The blower/vacuum is designed to blow/vacuum leaves as well as lawn debris such as grass
clippings and small twigs. It is not to be used for any other purpose. The device is only to be
used on dry surfaces. The device is intended for non-commercial use in private home and
gardens. Under no circumstances is it to be used in public outdoor areas, sports stadiums or
in agricultural or forestry settings.
WARNING! For your own safety, read this manual and the general safety
instructions carefully before using the appliance. Your power tool should
only be given to other users together with these instructions.
2 DESCRIPTION (FIG A)
1. Bottom tube section
2. Rollers
3. Top tube section
4. Leaf bag securing clip on motor
casing
5. Leaf bag
6. Blow - Vacuum function selector
lever
7. Motor casing
8. Shoulder strap
9. ON/OFF switch
3 PACKAGE CONTENT LIST
Remove all packaging materials.
Remove remaining packaging and packing inserts (if included).
Check that the package contents are complete.
Check the appliance, the power cord, the power plug and all accessories for transportation
damage.
Keep the packaging materials as far as possible until the end of the warranty period. Then
take it to your local waste disposal system.
WARNING Packaging materials are not toys! Children must not play with
plastic bags! There is a danger of suffocation!
Blower/vacuum
Leaf bag
Shoulder strap
2 wheels
Manual
If any parts are missing or damaged, please contact your dealer.
4 SYMBOLS
The following symbols are used in this manual and/or on the machine:

POW63172 EN
Copyright © 2015 VARO P a g e | 3www.varo.com
Denotes risk of personal
injury or damage to the
tool.
Keep bystanders away.
Read manual before use
Warning: the fan is still rotating
when open or close the cover, be
careful, especially the inlet cover
Warning: Wear eye and
ear protection
Class II - The machine is double
insulated; Earthing wire is
therefore not necessary.
Switch off and unplug the
device before cleaning or
performing maintenance
on it.
5 GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to heed warnings and follow instructions
may result in electric shock, fire and/or serious injury. Keep safety warnings and instructions
for future reference. The term "power tool" in the safety warnings refers to your mains-
operated (corded) power tool or battery- operated (cordless) power tool.
5.1 Working area
Keep working area clean and well lit. Untidy and dark areas can lead to accidents.
Do not operate power tools in potentially explosive surroundings, for example, in the
presence of inflammable liquids, gases or dust. Power tools create sparks which may
ignite the dust or fumes.
Keep children and bystanders at a distance when operating a power tool. Distractions can
cause you to lose control of it.
5.2 Electrical safety
Always check that the power supply corresponds to the voltage on the rating
plate.
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
adapter plugs with earthed power tools. Unmodified plugs and matching outlets will reduce
the risk of an electric shock.
Avoid body contact with earthed surfaces such as pipes, radiators, kitchen ranges and
refrigerators. There is an increased risk of an electric shock if your body is earthed.
Do not expose power tools to rain or wet conditions. If water gets inside a power tool, it will
increase the risk of an electric shock.
Do not damage the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep the cord away from heat, oil, sharp edges or moving parts. Damaged or

POW63172 EN
Copyright © 2015 VARO P a g e | 4www.varo.com
entangled cords increase the risk of an electric shock. If a retractable cord is used, the
cord should be fully reeled out to avoid heating up.
If operating a power tool in a damp location is unavoidable, use a power supply protected
by a residual current device (RCD). Using an RCD reduces the risk of an electric shock.
5.3 Personal safety
Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool when you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention when operating a power tool may result in serious
personal injury.
Use safety equipment. Always wear eye protection. Using safety equipment such as a
dust mask, non-skid safety shoes, a hard hat, or hearing protection whenever it is needed
will reduce the risk of personal injury.
Avoid accidental starts. Ensure the switch is in the off position before inserting the plug.
Carrying power tools with your finger on the switch or plugging in power tools when the
switch is in the on position makes accidents more likely.
Remove any adjusting keys or spanners before turning on the power tool. A spanner or
key left attached to a rotating part of the power tool may result in personal injury.
Do not reach out too far. Keep your feet firmly on the ground at all times. This will enable
you retain control over the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from the power tool. Loose clothes, jewellery or long hair can become
entangled in the moving parts.
If there are devices for connecting dust extraction and collection facilities, please ensure
that they are attached and used correctly. Using such devices can reduce dust-related
hazards.
5.4 Power tool use and care
Do not expect the power tool to do more than it can. Use the correct power tool for what
you want to do. A power tool will achieve better results and be safer if used in the context
for which it was designed.
Do not use the power tool if the switch cannot turn it on and off. A power tool with a broken
switch is dangerous and must be repaired.
Disconnect the plug from the power source before making adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
Store power tools, when not in use, out of the reach of children and do not allow people
who are not familiar with the power tool or these instructions to operate it. Power tools are
potentially dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or jammed moving parts, breakages or any
other feature that might affect the operation of the power tool. If it is damaged, the power
tool must be repaired. Many accidents are caused by using poorly maintained power tools.
Use the power tool, accessories and cutting tools, etc., in accordance with these
instructions and in the manner intended for the particular type of power tool, taking into
account the working conditions and the work which needs to be done. Using a power tool
in ways for which it was not intended can lead to potentially hazardous situations.
5.5 Service
Your power tool should be serviced by a qualified specialist using only standard spare
parts. This will ensure that it meets the required safety standards.
6 SPECIFIC SAFETY INSTRUCTIONS
Make sure the power cord is kept behind and away from the device while you work.

POW63172 EN
Copyright © 2015 VARO P a g e | 5www.varo.com
Always position yourself horizontally to the slope and make sure your feet are firmly
planted. Exercise particular caution whenever you change directions while working on a
slope.
Walk at a measured pace while operating the blower. DO NOT RUN.
Never direct the suction/blown air opening toward persons or animals.
The Vac-Blower must not be used or starting until it has been fully assembled.
Make sure the power cord is kept behind and away from the device while you work.
If the power cord or extension cord are damaged while you work, unplug the blower
immediately.
Never use the power cord as a handle to lift or carry the device.
Always unplug the device under the fol lowing circumstances:
When the blower is not in use, is being carried/transported, or is left unattended.
While examining, cleaning or unclogging the device.
When cleaning the device, performing maintenance on it, or attaching accessories to it.
If the device strikes a foreign object or begins vibrating abnormally.
Use the blower in daylight or with adequate illumination.
Bear in mind that the force generated by an electrical device can make you lose your
balance. Therefore, make sure that your feet are firmly planted and that your body is well
balanced when you are operating the device.
Never operate the blower on damp or wet grass.
Using the blower on sloping areas: Do not work in areas with unduly steep slopes.
Use the blower as follows when working on slopes:
Always position yourself horizontally to the slope and make sure your feet are firmly
planted. Exercise particular caution whenever you change directions while working on a
slope.
Keep the air outlet unobstructed and clean at all times.
Never direct the suction/blown air opening toward persons or animals.
7 ASSEMBLY
Your new blower vac requires very little assembly work before it is ready for use.
7.1 Assembling the tubes (Fig 1, 2)
Screw the top tube (3) onto the motor housing.
Screw the bottom tube section (1) onto the top tube.
7.2 Shoulder strap
Attach the shoulder strap (8) to the forseen hook on the handle. To adjust the shoulder strap
to the required length, simply slide the adjustable strap buckle forward or backwards.
7.3 Leaf bag (Fig 3)
To secure the leaf bag(5) to the machine, simply attach the buckle to the top tube section
and pull the expanding bag opening over the leaf discharge point on the bottom of the motor
casing.
8 OPERATION
8.1 Steps prior to operation
Only operate the device after completely assembling it. Prior to each use, check the power
cord for signs of damage. Under no circumstances should the power cord be used if it shows
any signs of damage.
Ensure that the blower vac is only connected to conventional sockets with a 230 - 240V
alternating current supply.
8.2 Switching ON/OFF
Press the On/Off switch(9) to start machine.

POW63172 EN
Copyright © 2015 VARO P a g e | 6www.varo.com
To stop the machine simply let go of the On / Off switch(9).
8.3 Use/Operation
The easiest way to use the blower vac is to place the shoulder strap in a comfortable
position over your shoulder and hold the rear handle at hip height so that the majority of
the tool’s weight rests on the rollers.
When using the blower vac to pick up leaves it is best to move the tool on its rollers. This
ensures that the blower vac is at the perfect height above the ground. The blower vac is
designed only to pick up leaves. To avoid l damage to the tool that is not covered by the
warranty, do not use it to pick up branches, stones or other hard materials.
When using the tool as a leaf blower always work away from solid objects such as walls,
fences, etc. Whilst you work do not place the blower vac tube too close to the leaves. The
tool will be more effective if you keep it at a certain distance away from the leaves and
blow the leaves forwards.
8.4 Switching operating mode (Fig 4)
To switch the tool from blower mode to vacuum mode, simply switch it off at the main
switch and move the function selector lever to the other position.
Up vac /Down blow
8.5 Leaf bag
Note: Before you remove and empty the leaf bag ensure that the tool has
been disconnected from the mains power supply.
To empty the leaf bag simply open the zip fastener, empty the bag and then close the zip
fastener again
When the leaf bag is open you can also check the function of the blower vac’s slide control.
If there is a blockage in the tool, check this function and remove the blockage.
9 CLEANING AND MAINTENANCE
Attention! Before performing any work on the equipment, pull the power
plug.
9.1 Cleaning
Keep the ventilation slots of the tool clean to prevent overheating of the engine.
Regularly clean the tool housing with a soft cloth, preferably after each use.
If the dirt does not come off use a soft cloth moistened with soapy water.
Never use solvents such as petrol, alcohol, ammonia water, etc. These solvents may
damage the plastic parts.
9.2 Replacing carbon brushes
Remove and check the carbon brushes regularly. Replace when they have worn down to the
limit mark. Keep the carbon brushes clean and free to slip in the holders. Both carbon
brushes must be replaced at the same time. Only use original carbon brushes.
9.3 Maintenance
Our tools have been designed to operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends upon proper tool care and regular
cleaning.

POW63172 EN
Copyright © 2015 VARO P a g e | 7www.varo.com
10 TECHNICAL DETAILS
Model nr.
POW63172
Voltage / frequency :
230-240V~50 Hz
Power
3000W
No load speed :
15000 min-1
Max airspeed
270 km/h
Max air volume
13.2 m³/min
Dust bag
35 L
Shredding ratio :
10: 1
11 NOISE
Noise values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
85 dB(A)
Acoustic power level LwA
102 dB(A)
ATTENTION! The sound power level may exceed 85 dB(A), in this case
individual hearing protection shall be worn.
aw (Vibration)
4.8 m/s²
K = 1,5 m/s²
12 WARRANTY
This product is warranted as provided by law for a 24 -month period effective from the
date of purchase by the first user.
This warranty covers all material or production flaws excluding : batteries, chargers,
defective parts subject to normal wear & tear such as bearings, brushes, cables, and
plugs, or accessories such as drills, drill bits, saw blades, etc. ; damage or defects
resulting from maltreatment, accidents or alterations; nor the cost of transportation.
Damage and/or defects resulting from inappropriate use also do not fall under the
warranty provisions.
We also disclaim all liability for any bodily injury resulting from inappropriate use of the tool.
Repairs may only be carried out by an authorised customer service centre for Powerplus
tools.
You can always obtain more information at the number 00 32 3 292 92 90.
Any transportation costs shall always be borne by the customer, unless agreed otherwise
in writing.
At the same time, no claim can be made on the warranty if the damage of the device is the
result of negligent maintenance or overload.
Definitely excluded from the warranty is damage resulting from fluid permeation, excessive
dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate
usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not
following the instructions given in the manual), inexpert assembly, lightning strike,
erroneus net voltage. This list is not exhaustive.
Acceptance of claims under warranty can never lead to the prolongation of the warranty
period nor commencement of a new warranty period in case of a device replacement.
Devices or parts which are replaced under the warranty therefore remain the property of
Varo NV.
We reserve the right to reject a claim whenever the purchase cannot be verified or when it
is clear that the product has not been properly maintained. (Clean ventilation slots, carbon
brushes serviced regularly, etc.).

POW63172 EN
Copyright © 2015 VARO P a g e | 8www.varo.com
Your purchase receipt must be kept as proof of date of purchase.
Your appliance must be returned undismantled to your dealer in an acceptably clean state,
(in its original blow-moulded case if applicable to the unit), accompanied by proof of
purchase.
13 ENVIRONMENT
Should your appliance need replacement after extended use, do not dispose of it
with the household refuse, but in an environmentally safe way.
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for
recycling advice.
14 DECLARATION OF CONFORMITY
VARO N.V. - Joseph Van Instraat 9 - BE2500 Lier - BELGIUM, declares that,
product: Leaf blower
trade mark: POWERplus
model: POW63172
is in conformity with the essential requirements and other relevant provisions of the applicable
European Directives, based on the application of European harmonized standards. Any
unauthorized modification of the apparatus voids this declaration.
European Directives (including, if applicable, their amendments up to the date of signature);
2011/65/EU
2006/42/EC
2004/108/EC
2000/14/EC Annex V LwA 100dB(A) / 102dB(A)
European harmonized standards (including, if applicable, their amendments up to the date of
signature);
EN60335-1: 2012
IEC60335-2-100: 1.0: 2002
EN55014-1: 2006
EN55014-2: 1997
EN61000-3-2: 2006
EN61000-3-3: 2008
Keeper of the Technical Documentation : Philippe Vankerkhove, VARO –Vic. Van Rompuy
N.V.
The undersigned acts on behalf of the company CEO,
Philippe Vankerkhove
Regulatory Affairs –Compliance Manager
27/02/2015
