Powerplus XQ POWXQG5030 User manual

POWXQG5030 EN
Copyright © 2013 VARO P a g e | 1www.varo.com
1APPLICATION ................................................................................3
2DESCRIPTION (FIG. A) ..................................................................3
3PACKAGE CONTENT LIST............................................................3
4SYMBOLS.......................................................................................4
5GENERAL POWER TOOL SAFETY WARNINGS.........................4
5.1 Working area..........................................................................................................4
5.2 Electrical safety .....................................................................................................4
5.3 Personal safety......................................................................................................5
5.4 Power tool use and care........................................................................................5
5.5 Service....................................................................................................................5
6MACHINE-SPECIFIC SAFETY WARNINGS..................................6
7ASSEMBLY.....................................................................................6
7.1 Height adjustment .................................................................................................6
7.2 Fitting the collection bag.......................................................................................6
7.3 Fitting the shoulder harness.................................................................................6
7.4 Front handle adjustment.......................................................................................7
7.5 Rake adjustment....................................................................................................7
8OPERATION....................................................................................7
8.1 Before starting.......................................................................................................7
8.2 Starting the vacuum / blower................................................................................7
8.3 Stopping the vacuum / blower..............................................................................7
8.4 Using the vacuum / blower....................................................................................7
8.4.1 Blower mode............................................................................................................7
8.4.2 Vacuüm mode .........................................................................................................8
9CLEANING AND MAINTENANCE .................................................8
9.1 Cleaning.................................................................................................................8
9.2 Maintenance...........................................................................................................8
10 TECHNICAL DETAILS....................................................................8
11 SOUND EMISSION .........................................................................8
12 WARRANTY....................................................................................9

POWXQG5030 EN
Copyright © 2013 VARO P a g e | 2www.varo.com
13 ENVIRONMENT ............................................................................10
14 DECLARATION OF CONFORMITY .............................................10

POWXQG5030 EN
Copyright © 2013 VARO P a g e | 3www.varo.com
BLOW/VAC 300W
POWXQG5030
1 APPLICATION
The blower/vacuum is designed to blow/vacuum leaves as well as lawn debris such as grass
clippings and small twigs. It is not to be used for any other purpose.
The device is only to be used on dry surfaces.
The device is intended for non-commercial use in private homes and gardens. Under no
circumstances is it to be used in public outdoor areas, sports stadiums or in agricultural or
forestry settings
It is not designed for professional use.
WARNING! Read this manual and general safety instructions carefully
before using the appliance, for your own safety. Your power tool should
only be passed on together with these instructions.
2 DESCRIPTION (FIG. A)
1. Hook
2. Collection Bag
3. Window knob
4. Front handle
5. Suction/Blower tube
6. Wheels
7. Vacuum/Blower selector lever
8. Speed selector
9. Shoulder harness
3 PACKAGE CONTENT LIST
Remove all packaging materials.
Remove remaining packing and package inserts (if included).
Check that the package contents are complete.
Check the appliance, the power cord, the power plug and all accessories for
transportation damage.
Keep the packing materials as far as possible till the end of the warranty period. Dispose
it into your local waste disposal system afterwards.
WARNING: Packaging materials are not toys! Children must not play with
plastic bags! Danger of suffocation!
The packaging contains:
Air blower / Vacuum
Shoulder strap
Collection bag
Instruction manual
If any parts are missing or damaged, please contact your dealer.

POWXQG5030 EN
Copyright © 2013 VARO P a g e | 4www.varo.com
4 SYMBOLS
In this manual and/or on the machine the following symbols are used:
Warning / Danger!
Keep bystanders away.
Read manual before usage.
Remove plug from the mains
immediately if the cable is
damaged or cut.
In accordance with essential
applicable safety standards of
European directives.
Switch off and unplug the
device before cleaning or
performing maintenance on
it.
Never operate or leave the
machine in the rain or in damp
or wet conditions. Moisture is
an electrical shock hazard.
Wear ear guards and
goggles.
Class II - The machine is
double insulated; Earthing
wire is therefore not
necessary.
Rotating impeller blades can
cause sever injury.
5 GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to heed warnings and follow instructions
may result in electric shock, fire and/or serious injury. Keep safety warnings and instructions
for future reference. The term "power tool" in the safety warnings refers to your mains-
operated (corded) power tool or battery- operated (cordless) power tool.
5.1 Working area
Keep working area clean and well lit. Untidy and dark areas can lead to accidents.
Do not operate power tools in potentially explosive surroundings, for example, in the
presence of inflammable liquids, gases or dust. Power tools create sparks which may
ignite the dust or fumes.
Keep children and bystanders at a distance when operating a power tool. Distractions can
cause you to lose control of it.
5.2 Electrical safety
Always check that the power supply corresponds to the voltage on the rating plate.
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
adapter plugs with earthed power tools. Unmodified plugs and matching outlets will
reduce the risk of an electric shock.
Avoid body contact with earthed surfaces such as pipes, radiators, kitchen ranges and
refrigerators. There is an increased risk of an electric shock if your body is earthed.
Do not expose power tools to rain or wet conditions. If water gets inside a power tool, it
will increase the risk of an electric shock.
Do not damage the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep the cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of an electric shock.

POWXQG5030 EN
Copyright © 2013 VARO P a g e | 5www.varo.com
When operating a power tool outdoors, use an extension cable suitable for outdoor use.
Using a cord suitable for outdoor use reduces the risk of an electric shock.
If operating a power tool in a damp location is unavoidable, use a power supply protected
by a residual current device (RCD). Using an RCD reduces the risk of an electric shock.
5.3 Personal safety
Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool when you are tired or under the influence of drugs, alcohol
or medication. A moment of inattention when operating a power tool may result in serious
personal injury.
Use safety equipment. Always wear eye protection. Using safety equipment such as a
dust mask, non-skid safety shoes, a hard hat, or hearing protection whenever it is needed
will reduce the risk of personal injury.
Avoid accidental starts. Ensure the switch is in the off position before inserting the plug.
Carrying power tools with your finger on the switch or plugging in power tools when the
switch is in the on position makes accidents more likely.
Remove any adjusting keys or spanners before turning on the power tool. A spanner or
key left attached to a rotating part of the power tool may result in personal injury.
Do not reach out too far. Keep your feet firmly on the ground at all times. This will enable
you retain control over the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from the power tool. Loose clothes, jewellery or long hair can become
entangled in the moving parts.
If there are devices for connecting dust extraction and collection facilities, please ensure
that they are attached and used correctly. Using such devices can reduce dust-related
hazards.
5.4 Power tool use and care
Do not expect the power tool to do more than it can. Use the correct power tool for what
you want to do. A power tool will achieve better results and be safer if used in the context
for which it was designed.
Do not use the power tool if the switch cannot turn it on and off. A power tool with a
broken switch is dangerous and must be repaired.
Disconnect the plug from the power source before making adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
Store power tools, when not in use, out of the reach of children and do not allow people
who are not familiar with the power tool or these instructions to operate it. Power tools are
potentially dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or jammed moving parts, breakages or any
other feature that might affect the operation of the power tool. If it is damaged, the power
tool must be repaired. Many accidents are caused by using poorly maintained power
tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to jam and are easier to control.
Use the power tool, accessories and cutting tools, etc., in accordance with these
instructions and in the manner intended for the particular type of power tool, taking into
account the working conditions and the work which needs to be done. Using a power tool
in ways for which it was not intended can lead to potentially hazardous situations.
5.5 Service
Your power tool should be serviced by a qualified specialist using only standard spare
parts. This will ensure that it meets the required safety standards.

POWXQG5030 EN
Copyright © 2013 VARO P a g e | 6www.varo.com
6 MACHINE-SPECIFIC SAFETY WARNINGS
Always direct the cable to the rear, away from the appliance.
If a cord becomes damaged during use, disconnect the supply cord from the mains
immediately.
Operate the appliance only in daylight or in good artificial light.
Walk, never run.
Keep all cooling air inlets clear.
Do not attempt to modify the power tool in any way. The use of any attachment or
accessory over than those recommended in this instruction manual could result in
damage to the power tool and injury to the operator.
Never feed hard objects such as stones, bottles, cans or pieces of metal into the Vac-
Blower. They can cause damage to the machine and possibly injury to the operator and
bystanders.
If a foreign body, or other debris, is accidentally feed into the Vac-Blower, stop it
immediately and do not use the Vac-Blower until it has been checked and you are sure
that the entire Vac-Blower is in a safe operating condition.
If the Vac-Blower makes any unusual noise or starts to vibrate abnormally STOP
immediately remove the plug from the mains supply and investigate the cause. Excessive
vibration can cause damage to the Vac-Blower and injury to the operator.
Never operate the appliance while people, especially children, or pets are nearby
The operator or user is responsible for accidents or hazards occurring to otherpeople or
their property.
Before using ,always check the appliance including supply and extension cord for signs
of damage and aging
Never operate the appliance with defective guards or shields, or without safety devices,
for example debris collector in place
7 ASSEMBLY
The Vac-blower must not be used or switched on until it has been fully
assembled.
7.1 Height adjustment
Press the button and slide the air duct. It can be adjusted up to 300mm.
7.2 Fitting the collection bag
Before fitting the collection bag ensure that the Vacuum/Blow selector lever
operates smoothly and that it is not obstructed by debris from the previous
use.
To install the collection bag:
Turn the support frame into the correct position of the housing
Lock the support at its place.
To dismantle the collection bag:
Press the support to release.
7.3 Fitting the shoulder harness
The Vacuum-Blower is provided with a shoulder harness this is attached to the top of the
main body of the Vacuum-Blower as shown . The shoulder harness is provided to reduce
fatigue and aid comfort when using the Vacuum-Blower and can be worn in a position to suit
the operator.

POWXQG5030 EN
Copyright © 2013 VARO P a g e | 7www.varo.com
7.4 Front handle adjustment
Press the adjustment buttons.
Adjust the front handle to a comfortable angle
Release the adjustment buttons. They automatic reset to lock front handle
7.5 Rake adjustment
Rotate knob 90°, rake will automatic pop-up.
Lock knob by rotating 90°
8 OPERATION
8.1 Before starting
Plug the Vacuum-Blower into the mains supply via the (R.C.D.) and switch on. Check that the
(R.C.D.) is operating correctly.
8.2 Starting the vacuum / blower
To start the Vacuum-Blower Ensure that the intermediate suction/blower tube is fitted correctly
and attach the collection bag. Without the collection bag assembled, you cannot start the
vacuum / blower, since there is a security at the connection point.
Warning! Before selecting either the Vacuum or Blow function ensure that
the selector lever operates smoothly and that it is not obstructed by debris
from the previous use.
Select either the Vacuum or Blow function using the selector lever on the side of the machine
and press the switch button .If more power is required slide the speed controller from position
1 to position max..
8.3 Stopping the vacuum / blower
To turn off the machine you can simply release the switch button.
8.4 Using the vacuum / blower
Do not attempt to pick up wet debris, allow fallen leaves etc., to dry out before using the
Vacuum Blower. The Vacuum-Blower can be used to blow debris from patios, paths,
driveways, lawns, bushes and borders. It will also pick up leaves, paper, small twigs and wood
chippings. When using the Vacuum Blower in Vacuum mode the debris is sucked up the
suction tube before being ejected into the debris collection bag, as the debris passes through
the suction fan it is partially shredded. The shredded organic debris is ideal to use as mulch
around plants.
Any hard objects, such as stones, tin cans glass etc, will damage the
suction fan.
Do not use the Vacuum-Blower to suck up water or very wet debris.
Never operate the Vacuum-Blower without the debris collection bag fitted.
8.4.1 Blower mode
Inspect the area to be worked before starting. Remove any objects or debris that
could be thrown, jammed or become entangled in the Vacuum-Blower.
Select the blow function using the selector lever on the side of the machine and switch on.
With the Vacuum- Blower resting on its wheels move the Vacuum-Blower forwards directing
the nozzle at the debris to be cleared.

POWXQG5030 EN
Copyright © 2013 VARO P a g e | 8www.varo.com
Alternatively hold nozzle just above the ground and swing the machine from side to side,
moving forwards and direct the nozzle at the debris to be cleared. Blow the debris into a
convenient heap then use the vacuum function to collect the debris.
8.4.2 Vacuüm mode
Inspect the area to be worked before starting. Remove any objects or debris that could be
thrown, jammed or become entangled in the Vacuum-Blower. Select the vacuum function
using the selector lever on the side of the machine and switch on. With the Vacuum-Blower
resting on its wheels move the Vacuum-Blower forwards directing the nozzle at the debris to
be collected. Alternatively with the Vacuum-Blower held just above the ground swing the
machine from side to side, moving forwards and directing the nozzle at the debris to be
collected. Do not force the nozzle into the debris as this will block the suction tube and reduce
the efficiency of the machine.
Organic materials such as leaves contain a large amount of water that can cause them to stick
to the inside of the suction tube. To reduce sticking the material should be left for a few days
to dry out.
9 CLEANING AND MAINTENANCE
9.1 Cleaning
Keep the ventilation slots of the machine clean to prevent overheating of the engine.
Regularly clean the machine housing with a soft cloth, preferably after each use.
Keep the ventilation slots free from dust and dirt.
If the dirt does not come off use a soft cloth moistened with soapy water.
Never use solvents such as petrol, alcohol, ammonia water, etc. These solvents may
damage the plastic parts.
9.2 Maintenance
Our machines have been designed to operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends upon proper machine care and
regular cleaning.
Keep all nuts, bolts and screws tight to be sure the appliance is in safe working
condition.
Check the debris collector frequently for wear or deterioration.
Replace worn or damaged parts.
Use only genuine replacement parts and accessories
Store the appliance only in a dry place
10 TECHNICAL DETAILS
Rated voltage
230-240V / 50Hz
Rated power
3000W
No-load speed
10 000 - 16 500 min-1
Shredding ratio
15:1
Collection bag content
45l
11 SOUND EMISSION
Noise emission values measured according to relevant standard.
Sound pressure level LPA
88dB(A) K=3
Sound pressure level
LPA
Sound power level LWA
104dB(A) K=3
Sound power level LWA

POWXQG5030 EN
Copyright © 2013 VARO P a g e | 9www.varo.com
ATTENTION ! The sound power pressure may exceed 85 dB(A), in this
case individual hearing protection must be worn.
12 WARRANTY
This product is warranted for a 5-year period effective from the date of purchase by the
first user.
This warranty covers all material or production flaws. It does not include defective parts
subject to normal wear & tear such as bearings, brushes, cables, and plugs, or
accessories such as drills, drill bits, saw blades, etc. ; damage or defects resulting from
maltreatment, accidents or alterations; nor the cost of transportation.
This warranty covers all material or production flaws, excluding batteries, chargers,
defective parts subject to normal wear and tear such as, in particular, bearings, brushes,
cables, plugs… Accessories such as drills, drill bits, saw blades etc. also do not fall under
this warranty.
Damage and/or defects resulting from inappropriate use also do not fall under the
warranty provisions.
We also disclaim all liability for any bodily injury resulting from inappropriate use of the
tool.
Repairs may only be carried out by an authorised customer service centre for Powerplus
tools.
You can always obtain more information at the number 00 32 3 292 92 90.
Any transportation costs shall always be borne by the customer, unless agreed otherwise
in writing.
At the same time, no claim can be made on the warranty if the damage of the device is the
result of negligent maintenance or overload.
Definitely excluded from the warranty is damage resulting from fluid permeation, excessive
dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate
usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not
following the instructions given in the manual), inexpert assembly, lightning strike,
erroneus net voltage. This list is not exhaustive.
Acceptance of claims under warranty can never lead to the prolongation of the warranty
period nor commencement of a new warranty period in case of a device replacement.
Devices or parts which are replaced under the warranty therefore remain the property of
Varo NV.
We reserve the right to reject a claim whenever the purchase cannot be verified or when it
is clear that the product has not been properly maintained. (Clean ventilation slots, carbon
brushes serviced regularly, etc.).
Your purchase receipt must be kept as proof of date of purchase.
Your appliance must be returned undismantled to your dealer in an acceptably clean state,
(in its original blow-moulded case if applicable to the unit), accompanied by proof of
purchase.

POWXQG5030 EN
Copyright © 2013 VARO P a g e | 10 www.varo.com
13 ENVIRONMENT
Should your appliance need replacement after extended use, do not dispose of it
with the household refuse, but in an environmentally safe way.
Waste produced by electrical machine items should not be handled like normal
household rubbish. Please recycle where recycle facilities exist. Check with your
Local Authority or retailer for recycling advice.
14 DECLARATION OF CONFORMITY
VARO N.V. - Joseph Van Instraat 9 - BE2500 Lier - BELGIUM, declares that,
Product:
Trade mark: POWERplus
Model: POWXQG5030
is in conformity with the essential requirements and other relevant provisions of the applicable
European Directives as they relate to European harmonized standards. Any unauthorized
modification of the apparatus voids this declaration.
European Directives (including, if applicable, their amending directives):
2004/108/EC
2006/42/EC
2011/65/EU
2000/14/EC Annex V LwA 102dB(A) / 104dB(A)
European harmonized standards, and their amendments:
EN60335-1 : 2002
IEC60335-2-100 : 1.0 : 2002
EN55014-1 : 2006
EN55014-2 : 1997
EN61000-3-2 : 2006
EN61000-3-11 : 2000
The undersigned acts on behalf of and under the power of attorney granted by the company
management,
Philippe Vankerkhove
Certification Manager
Date: 30/04/2013
