Powerplus POWX0057 User manual

POWX0057 EN
Copyright © 2015 VARO P a g e | 1www.varo.com
1APPLICATION ................................................................................3
2DESCRIPTION (FIG A) ...................................................................3
3PACKAGE CONTENT LIST............................................................3
4SYMBOLS.......................................................................................4
5GENERAL POWER TOOL SAFETY WARNINGS.........................4
5.1 Working area..........................................................................................................4
5.2 Electrical safety .....................................................................................................4
5.3 Personal safety......................................................................................................5
5.4 Power tool use and care........................................................................................5
5.5 Battery tool use and care......................................................................................5
5.6 Service....................................................................................................................6
6ADDITIONAL SAFETY INSTRUCTIONS FOR BATTERIES AND
CHARGERS ....................................................................................6
6.1 Batteries.................................................................................................................6
6.2 Charger...................................................................................................................6
7OPERATION....................................................................................7
7.1 Charging the battery pack (fig 2) ..........................................................................7
7.2 Installing and Removing a Bit and a Drill (fig 3) ..................................................8
7.3 Removal / insertion of battery (Fig. 4)..................................................................8
7.4 Switch (Fig. 5 & Fig. 6)...........................................................................................9
7.4.1 Rotation (right/left/lock)............................................................................................9
7.4.2 Variable speed.........................................................................................................9
7.5 Adjusting the torque..............................................................................................9
7.6 Speed selector (Fig. 7).........................................................................................10
7.7 LED light...............................................................................................................10
7.8 Magnetic Drill/Bit Holder and Bit Holder ............................................................11
7.9 To recharge the battery pack..............................................................................11
7.10 Drilling..................................................................................................................11
7.10.1 Drilling in wood......................................................................................................12
7.10.2 drilling in metal.......................................................................................................12
8CLEANING AND MAINTENANCE ...............................................12

POWX0057 EN
Copyright © 2015 VARO P a g e | 2www.varo.com
9TECHNICAL DETAILS..................................................................12
10 NOISE............................................................................................12
11 WARRANTY..................................................................................13
12 ENVIRONMENT ............................................................................13
12.1 Battery pack.........................................................................................................13
13 DECLARATION OF CONFORMITY .............................................14

POWX0057 EN
Copyright © 2015 VARO P a g e | 3www.varo.com
DRILL/SCREWDRIVER 18V 3 BATT
POWX0057
1 APPLICATION
Your rechargeable drill/screwdriver has been designed for drilling in wood, metal and plastics
and for screw driving applications. It is not designed for commercial use.
WARNING! Read this manual and general safety instructions carefully
before using the appliance, for your own safety. Your power tool should
only be passed on together with these instructions.
2 DESCRIPTION (FIG A)
1 Keyless chuck
2 Torque setting ring
3 Two-speed selector
4 LCD battery level display
5 Button of LCD battery level display
6 Direction of rotation selector
7 ON/OFF switch trigger
8 Soft grip
9 Hand strap
10 Release latch for battery pack
11 Battery pack
12 Magnetic drill/bit holder
13 LED work-light
3 PACKAGE CONTENT LIST
Remove all packaging materials.
Remove remaining packing and package inserts (if included).
Check that the package contents are complete.
Check the appliance, the power cord, the power plug and all accessories for transportation
damage.
Keep the packing materials as far as possible till the end of the warranty period. Dispose it
into your local waste disposal system afterwards.
WARNING: Packaging materials are not toys! Children must not play with
plastic bags! Danger of suffocation!
1x cordless drill 18V
1x 3-5h charger
3x batteries
1x Manual
6x bits
6x drills
1x magnetic bit holder
If any parts are missing or damaged, please contact your dealer.

POWX0057 EN
Copyright © 2015 VARO P a g e | 4www.varo.com
4 SYMBOLS
Denotes risk of personal
injury or damage to the tool.
In accordance with essential
requirements of the
European directive(s)
Read manual before use
"Class II - The machine is
double insulated; Earthing
wire is therefore not
necessary (only for charger)
Ambient temperature 40°C
max. (only for battery)
Do not expose charger and
battery pack to water
Use battery and charger only
in closed rooms
Do not incinerate battery
pack or charger
5 GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to heed warnings and follow instructions
may result in electric shock, fire and/or serious injury. Keep safety warnings and instructions
for future reference. The term "power tool" in the safety warnings refers to your mains-
operated (corded) power tool or battery- operated (cordless) power tool.
5.1 Working area
Keep working area clean and well lit. Untidy and dark areas can lead to accidents.
Do not operate power tools in potentially explosive surroundings, for example, in the
presence of inflammable liquids, gases or dust. Power tools create sparks which may
ignite the dust or fumes.
Keep children and bystanders at a distance when operating a power tool. Distractions can
cause you to lose control of it.
5.2 Electrical safety
Always check that the power supply corresponds to the voltage on the
rating plate.
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
adapter plugs with earthed power tools. Unmodified plugs and matching outlets will reduce
the risk of an electric shock.
Avoid body contact with earthed surfaces such as pipes, radiators, kitchen ranges and
refrigerators. There is an increased risk of an electric shock if your body is earthed.
Do not expose power tools to rain or wet conditions. If water gets inside a power tool, it will
increase the risk of an electric shock.
Do not damage the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep the cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of an electric shock.
When operating a power tool outdoors, use an extension cable suitable for outdoor use.
Using a cord suitable for outdoor use reduces the risk of an electric shock.
If operating a power tool in a damp location is unavoidable, use a power supply protected
by a residual current device (RCD). Using an RCD reduces the risk of an electric shock.

POWX0057 EN
Copyright © 2015 VARO P a g e | 5www.varo.com
5.3 Personal safety
Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool when you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention when operating a power tool may result in serious
personal injury.
Use personal protective equipment. Always wear eye protection. Using safety equipment
such as a dust mask, non-skid safety shoes, a hard hat, or hearing protection whenever it
is needed will reduce the risk of personal injury.
Avoid accidental starts. Ensure the switch is in the off position before inserting the plug.
Carrying power tools with your finger on the switch or plugging in power tools when the
switch is in the on position makes accidents more likely.
Remove any adjusting keys or spanners before turning on the power tool. A spanner or
key left attached to a rotating part of the power tool may result in personal injury.
Do not reach out too far. Keep your feet firmly on the ground at all times. This will enable
you retain control over the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from the power tool. Loose clothes, jewellery or long hair can become
entangled in the moving parts.
If there are devices for connecting dust extraction and collection facilities, please ensure
that they are attached and used correctly. Using such devices can reduce dust-related
hazards.
5.4 Power tool use and care
Do not expect the power tool to do more than it can. Use the correct power tool for what
you want to do. A power tool will achieve better results and be safer if used in the context
for which it was designed.
Do not use the power tool if the switch cannot turn it on and off. A power tool with a broken
switch is dangerous and must be repaired.
Disconnect the plug from the power source before making adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
Store power tools, when not in use, out of the reach of children and do not allow people
who are not familiar with the power tool or these instructions to operate it. Power tools are
potentially dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or jammed moving parts, breakages or any
other feature that might affect the operation of the power tool. If it is damaged, the power
tool must be repaired. Many accidents are caused by using poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to jam and are easier to control.
Use the power tool, accessories and cutting tools, etc., in accordance with these
instructions and in the manner intended for the particular type of power tool, taking into
account the working conditions and the work which needs to be done. Using a power tool
in ways for which it was not intended can lead to potentially hazardous situations.
5.5 Battery tool use and care
Recharge only with the charger specified by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of fire when used with another battery pack.
Use power tools only with specifically designated battery packs. Use of any other battery
packs may create a risk of injury and fire.
When battery pack is not in use, keep it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects, that can make a connection from
one terminal to another. Shorting the battery terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from the battery; avoid contact.

POWX0057 EN
Copyright © 2015 VARO P a g e | 6www.varo.com
If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.
5.6 Service
Your power tool should be serviced by a qualified specialist using only standard spare
parts. This will ensure that it meets the required safety standards.
6 ADDITIONAL SAFETY INSTRUCTIONS FOR BATTERIES AND
CHARGERS
6.1 Batteries
Never attempt to open for any reason.
Do not store in locations where the temperature may exceed 40 °C.
Charge only at ambient temperatures between 4 °C and 40 °C.
Charge only using the charger provided with the tool.
When disposing of batteries, follow the instructions given in the section “Protecting the
environment”.
Do not cause short circuits. If connection is made between the positive (+) and negative (-)
terminal directly or via accidental contact with metallic objects, the battery is short circuited
and an intense current will flow causing heat generation which may lead to casing rupture
or fire.
Do not heat. If batteries are heated to above 100 °C, sealing and insulating separators
and other polymer components may be damaged resulting in electrolyte leakage and/or
internal short circuiting leading to heat generation causing rupture or file. Moreover do not
dispose of the batteries in fire, explosion and/or intense burning may result.
Under extreme conditions, battery leakage may occur. When you notice liquid on the
battery, proceed as follows:
- Carefully wipe the liquid off using a cloth. Avoid skin contact.
- In case of skin or eye contact, follow the instructions below:
Immediately rinse with water. Neutralize with a mild acid such as lemon
juice or vinegar.
In case of eye contact, rinse abundantly with clean water for at least 10
minutes. Consult a physician.
Fire hazard! Avoid short-circuiting the contacts of a detached battery. Do
not incinerate the battery.
6.2 Charger
Use the charger provided with the tool only to charge the battery
Never attempt to charge non-rechargeable batteries.
Have defective cords replaced immediately.
Do not expose to water.
Do not open the charger.
Do not probe the charger.
The charger is intended for indoor use only.

POWX0057 EN
Copyright © 2015 VARO P a g e | 7www.varo.com
7 OPERATION
7.1 Charging the battery pack (fig 2)
Fig. 2
The battery pack has been shipped in a low charge condition to prevent possible problem. You
should charge them prior to use.
Note: Batteries will not reach full charge the first time they are charged. Allow several cycles
(drilling followed by recharging) for the item to fully charge. The battery should only be used
indoors.
The battery as supplied is not fully charged. Therefore, let the tool charge initially for 7 hours.
After the initial Charge, under normal usage, your tool should be fully charged in 3 to 5 hours.
The battery pack will become slightly warm to the touch while charging, this is normal and
does not indicate a problem.
Do not place the charger in an area of extreme heat or cold, it will best at normal room
temperature.
Charging indication:
When the charger station is plugged in the red LED turns on
When the charger station is pushed on to the battery the green LED will also light.
Battery pack
Charger station
Red light
adaptor

POWX0057 EN
Copyright © 2015 VARO P a g e | 8www.varo.com
7.2 Installing and Removing a Bit and a Drill (fig 3)
Fig. 3
This drill has a keyless chuck (1) to prevent
the bit or drill from loosening.
1 Hold ring Aof the drill chuck tight with
one hand.
2 Turn upper ring Banticlockwise with
the other hand until the drill chuck
opening is large enough to accept the
tool.
3 3 Insert the drill or the screwdriver bit
into the drill chuck.
4 Turn ring Bclockwise until the tool is
clamped tightly.
Remove the tool in the opposite way.
7.3 Removal / insertion of battery (Fig. 4)
Fig. 4
WARNING: Before making any adjustments
ensure the drill is switched off with the
direction of rotation selector (6) in the center
position.
1 Hold the drill with one hand and the
battery pack (11) with the other.
2 To install: pull and slide battery pack
into battery port, make sure the latch
(10) on the both side of the battery
snap into place and battery is secure
before begging operation.
3 To remove: use your thumb and
fingers, press the battery release
latches in and pull the battery pack off
at the same time.

POWX0057 EN
Copyright © 2015 VARO P a g e | 9www.varo.com
7.4 Switch (Fig. 5 & Fig. 6)
Fig. 5 Fig. 6
The drill is started and stopped by depressing and releasing the ON/OFF switch trigger (7).
This cordless drill is equipped with an electric brake, when the ON/OFF switch trigger is
released completely the chuck stops immediately.
7.4.1 Rotation (right/left/lock)
Direction of rotation is controlled by the direction of rotation selector (6) located above the
switch trigger.
Right : To select forward rotation, release the on/off switch and push the forward/reverse lever
to the left side of the tool.
Left : To select reverse rotation, push the lever to the right side of the tool.
Lock: When the selector is in the center position, the switch trigger is locked. (See Fig. 6)
This helps to reduce the possibility of accidental starting when not in use
7.4.2 Variable speed
This tool has a variable speed switch that delivers higher speed and torque with increased
trigger pressure. The rotational speed is controlled by the amount of switch trigger depression.
7.5 Adjusting the torque
The torque is adjusted by rotating the torque setting ring (2); the torque is greater when the
torque setting is set on a higher position. The torque is less when the torque setting ring is set
on a low position. Position“1”denotes the lowest and “ ” denote the highest.
The torque force is set by means of a torque setting according to the size of screw and the
kind of material. Select the suitable torque for the job to be performed .. long screws and/or
hard material require a higher torque setting.

POWX0057 EN
Copyright © 2015 VARO P a g e | 10 www.varo.com
7.6 Speed selector (Fig. 7)
Fig. 7
NOTE：the -mark is the “Low speed”position, the -mark is the “High speed”
position (marks moulded in the button of two speed selector (3).)
The drill has a two-speed gear box designed for drilling at (LOW) or (HIGH)
speed. The gear selector is located on top of the drill to select either low or high speed. When
you push the button (5) forward and select low speed range, the speed will decrease but will
provide more power and torque. When using the drill in the high speed range, the speed will
increase but will provide less power and torque. Use the low speed for high power and torque
applications and the high speed for fast drilling applications.
Important: NEVER adjust this two speed selector（3）while the drill is running. Always let it
come to a complete stop.
7.7 LED light
Fig. 8
The LED work-light（13）can be lit
prior to motor running.
Press the on/off switch lightly, to keep
the work area lighted.
it also lights during operation.
WARNING:
Do not stare directly at the light beam.
Never aim the beam at any person or
an object other than the work piece.
Do not deliberately aim the beam at
personsl
Low speed
High speed

POWX0057 EN
Copyright © 2015 VARO P a g e | 11 www.varo.com
7.8 Magnetic Drill/Bit Holder and Bit Holder
Fig. 9
At the base of the cordless drill there is a
magnetic drill/bit holder (12).
It can be used to hold various drill/bits while
completing a job.
7.9 To recharge the battery pack
Fig. 10
If you press the button for LCD battery
capacity indicator (5) on the cordless drill,
you can check the capacity status of the
battery. Before use the machine, please
press the button to check if the battery is full
enough for properly working.
The battery status display shows the
capacity level of the battery. (%)
NOTE: Please charge the battery after each
use, it is necessary to charge the battery
once per month if the machine is not used .
NI-CD : (POWX0057)
NOTE : before recharging, always make
sure the battery is exhausted, just topping
upthe charge affects the capacity of your
Ni-Cd battery negatively (it will diminish).
7.10 Drilling
Before drilling, the torque setting should be set on the drill position “ ”.
When drilling hard smooth surface, use a center punch to mark the desired hole location. This
will prevent the drill bit from slipping off center as the hole is started. Hold the tool firmly and
place the tip of the drill or bit into the work piece, applying only enough pressure to keep the
bit cutting. Do not force or apply side pressure to elongate a hole.

POWX0057 EN
Copyright © 2015 VARO P a g e | 12 www.varo.com
7.10.1 Drilling in wood
For maximum performance, use high speed steel (HSS° drills for wood drilling, turn the torque
setting on the drill position“ ”. Begin drilling at a very low speed to prevent the bit from
slipping off the starting point. Increase the speed as the drill bit bites into the material. When
drilling through holes, place a block of wood behind the work piece to prevent ragged or edges
on the back side of the hole.
7.10.2 drilling in metal
For maximum performance, use high speed steel (HSS) drill bits for metal or steel drilling.
Turn the torque setting on the drill position“ ”. Begin drilling at a very low speed to prevent
the bit from slipping off the starting point. Maintain a speed and pressure which allows cutting
without overheating the bit. Applying too much pressure will overheat the drill, wear the
bearings, bend or burn bits, produce off-center or irregular shaped holes.
When drilling large holes in metal, it is recommended that you drill with a small bit at first, then
finish with a large bit, also lubricate the bit with oil to improve drilling action and increase bit life.
8 CLEANING AND MAINTENANCE
Attention! Always remove the battery before cleaning.
Remove dust and dirt with a cloth slightly dampened with detergent solution. In doing so,
ensure that no water gets into the machine.
Clean drillings and dust out of the chuck regularly.
The cordless drill is permanently lubricated and does not require oiling.
9 TECHNICAL DETAILS
Model nr.
POWX0057
No-load speed
0-400 / 0-1100 min-1
Drill chuck capacity:
0.8 - 10mm
Torque setting:
20+1 positions
Left /right (clockwise/ counter-clockwise rotation)
yes
Battery
NI-CD
Voltage
18V
capacity
1200 mAh
charger
ERP
Charge time
3-5h
10 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
67 dB(A)
Acoustic power level LwA
78 dB(A)
ATTENTION! Wear hearing protection when sound pressure is over 85
dB(A).
aw (Vibration)
2.6 m/s²
K = 1,5 m/s²

POWX0057 EN
Copyright © 2015 VARO P a g e | 13 www.varo.com
11 WARRANTY
This product is warranted for a 36-month period effective from the date of purchase by the
first user.
This warranty covers all material or production flaws excluding : batteries, chargers,
defective parts subject to normal wear & tear such as bearings, brushes, cables, and
plugs, or accessories such as drills, drill bits, saw blades, etc. ; damage or defects
resulting from maltreatment, accidents or alterations; nor the cost of transportation.
Damage and/or defects resulting from inappropriate use also do not fall under the
warranty provisions.
We also disclaim all liability for any bodily injury resulting from inappropriate use of the
tool.
Repairs may only be carried out by an authorized customer service center for Powerplus
tools.
You can always obtain more information at the number 00 32 3 292 92 90.
Any transportation costs shall always be borne by the customer, unless agreed otherwise
in writing.
At the same time, no claim can be made on the warranty if the damage of the device is the
result of negligent maintenance or overload.
Definitely excluded from the warranty is damage resulting from fluid permeation, excessive
dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate
usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not
following the instructions given in the manual), inexpert assembly, lightning strike,
erroneus net voltage. This list is not exhaustive.
Acceptance of claims under warranty can never lead to the prolongation of the warranty
period nor commencement of a new warranty period in case of a device replacement.
Devices or parts which are replaced under the warranty therefore remain the property of
Varo NV.
We reserve the right to reject a claim whenever the purchase cannot be verified or when it
is clear that the product has not been properly maintained. (Clean ventilation slots, carbon
brushes serviced regularly, etc.).
Your purchase receipt must be kept as proof of date of purchase.
Your appliance must be returned undismantled to your dealer in an acceptably clean state,
(in its original blow-moulded case if applicable to the unit), accompanied by proof of
purchase.
Your tool must be charged at least 1x per month to ensure optimal operation of this tool.
12 ENVIRONMENT
Should your appliance need replacement after extended use, do not dispose of it
with the household refuse, but in an environmentally safe way.
Waste produced by electrical machine items should not be handled like normal
household rubbish. Please recycle where recycle facilities exist. Check with your
Local Authority or retailer for recycling advice.
12.1 Battery pack
This product contains nickel-cadmium. To preserve natural resources, please recycle or
dispose of batteries properly. Local, state or federal laws may prohibit disposal of nickel-
cadmium batteries in ordinary trash. Consult you local waste authority for information
regarding available recycling and/or disposal options.

POWX0057 EN
Copyright © 2015 VARO P a g e | 14 www.varo.com
13 DECLARATION OF CONFORMITY
VARO N.V. - Joseph Van Instraat 9 - BE2500 Lier - BELGIUM, declares that,
Product: Cordless drill/screwdriver 18V
Trade mark: POWERplus
Model: POWX0057
is in conformity with the essential requirements and other relevant provisions of the applicable
European Directives, based on the application of European harmonized standards. Any
unauthorized modification of the apparatus voids this declaration.
European Directives (including, if applicable, their amendments up to the date of signature);
2004/108/EC
2006/42/EC
2011/65/EU
European harmonized standards (including, if applicable, their amendments up to the date of
signature);
EN60745-1 : 2009
EN60745-2-1 : 2010
EN60745-2-2 : 2010
EN55014-1 : 2006
EN55014-2 : 1997
Keeper of the Technical Documentation : Philippe Vankerkhove, VARO –Vic. Van Rompuy
N.V.
The undersigned acts on behalf of the company CEO,
Hugo Cuypers
Regulatory Affairs –Compliance Manager
15/10/2014
