PowerPoint P467TTIBMDW User manual

Single Door with Ice box
P467TTIBMDW
INSTRUCTIONS:
Please read and keepsafe forfutureuse.
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

ProductOverview…………………………………………………………………………………..
Transportationinstructions.........................................................................
Introduction & safety warnings..................................................................
Electrical Requirements …………………...........................................................
Installation ………………………………..................................................................
Food Storage …………………………………………………………………….……………………..
Arrangement of Food………………………………………………………….……………………
Temperature Control ………………………………………………………………………………..
Cleaning and Care………………........................................................................
Replacing Bulb/Top Tips ….........................................................................
Problem solving...........................................................................................
Health and Safety........................................................................................
Warranty Information..................................................................................
Customer Care ………………………………………………………………………………………….
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Description
Small Door
Thermostat
Drain Tray
Steel Wire Shelf
Adjustable Foot
Wire Steel Bar
PRODUCT OVERVIEW
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

When transporting, never tilt appliance to more than 45 degrees
The appliance should be transported only in a vertical upright position
The packaging as supplied must be intact during transportation
If during the course of transport the appliance has to be transported
horizontally, it must only be laid on its left hand side when standing in
front of the appliance. After bringing it to the upright position, it must
not be operated for at least 4 hours to allow the system to settle. The
manufacturer will not be held responsible if these instructions are
disregarded.
The appliance must be protected against rain and moisture
When positioning your appliance take care not to damage your
flooring, kitchen furniture, related parts and doors, pipes, wall
coverings etc.
Empty any water in the drain tray before moving. See section
‘Defrosting’ and ‘Care & cleaning’ for further information
Do not move the appliance by pulling by the door
Hold the base and lift the refrigerator carefully
Never hold the door handle as support
Never place the refrigerator upside down or lie it down
Move refrigerator by using its roller feet as an axis and then tilting it
slightly to move
Make sure that the defrost water pipe at the back of the product is
fixed to the plastic evaporating pan on the top of the compressor, to
avoid defrost water spillage on the floor.
TRANSPORTATION INSTRUCTIONS
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

IMPORTANT: Do NOT connect your appliance to the electricity supply until
All packing and transit protectors have been removed.
Leave to stand for at least 4 hours before switching on to allow
compressor oil to settle if transported horizontally
Wipe the inside of the Fridge with a weak solution of bicarbonate of
soda. Then rinse with warm water using a damp sponge or cloth.
Wash the baskets and shelves in warm soapy water and dry
completely
If you are discarding an old refrigerator with a lock or latch fitted to
the door, disable the lock/latch,ensure that it is left in a safe
condition to prevent the entrapment of young children
This fridge/freezer must only be used for its intended purpose i.e. the
storing andfreezing of edible foodstuff
Do not dispose of the appliance on a fire
Take care not to damage, the cooling circuit, if damagedimmediately
ventilate the room where the appliance is situated
This appliance should not be used in an unheated, cold room i.e.
Garage, conservatory, annex, shed, out-house etc.
Ensure that the plug remains readily accessible
Failure to observe these instructions may invalidate your right tofree
service during the guarantee period
We recommend a separate switch be used to ensure easy switch on /
off
Children should be supervised to ensure that they do not play with the
appliance
This appliance is intended to be used in a household environment
Do not use mechanical devices or other means to accelerate the
defrosting process
INTRODUCTION AND SAFETLY WARNING
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

WARNING: Keep ventilation openings in the appliance enclosure or
In the built-in structure clear of obstruction.
IMPORTANT: Care must be taken while cleaning / carrying the appliance to
Avoid touching the bottom of the condenser metal wires at
The back of the appliance as you may injure your fingers and
hands. Make sure that mains cable is not caught under the
Appliance during and after carrying / moving the appliance,
to avoid the mains cable becoming cut or damaged.
Before you insert the plug into the wall socket make sure that the voltage and
Frequency shown in the rating plate inside the appliance corresponds to
Your electricity supply. We recommend that this appliance is connected to the
mains supply via a suitable switched and fused socket in a readily accessible
position.
Should the mains lead of the appliance become damaged or should it need
Replacing at any time, it must be replaced by a special purpose made mains
Lead which can only be obtained from Shomar Ltd.
WARNING! THIS APPLIANCE MUST BE EARTHED
If the fitted plug is not suitable for your socket, then the plug should be
removed and an appropriate plug fitted. Destroy the old plug which is cut off
as a plug with bared cord could cause a shock hazard if inserted into a socket.
The plug on this appliance incorporates a 13 A fuse. Should the fuse need to
be changed a fuse of the same rating must be used. Ensure that the fuse cover
is refitted.
ELECTRICAL REQUIREMENTS
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Install the refrigerator on a flat surface in order to prevent vibration
and noise. If required adjust the levelling feet at the front by turning
them.
Choose a dry well-ventilated place.
Minimum space in the room where the refrigerator is being installed
is 10 cubic metres.
Choose a location where there is no heat source. Keep the refrigerator
away from direct sunlight,oven etc.
If inserting into a cabinet there must be clearance of 9 cm at the back
of the Refrigerator and 2cm at the side.
Before Use Check That:
1. The interior is dry and air can circulate freely at the rear of the
cabinet.
2. Interior is cleaned as recommended under "CLEANING AND CARE."
3. Insert the plug into the wall socket and switch on the electricity
supply.
4. You will hear a noise as the compressor starts up. The liquid and gases
sealed within the refrigeration system may also give rise to noise,
whether the compressor is running or not which is quite normal.
5. Set the thermostat to 4 and close door. After 30 minutes you should
observe a drop in temperature.
6. Frontedges of the cabinet may feel warm. This is normal.
7. Do not load the appliance immediately it is switched on. Wait until the
Correct storage temperature has been reached. We recommend that
The temperature be checked with an accurate thermometer or wait
24Hours.
INSTALLATION INSTUCTIONS
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

How to Use the Refrigerator Compartment:
Cooked /fresh foods may be stored in your refrigerator. Hot foods
must first be allowed to reach room temperature before storage
Eggs and Bottle’s should be stored on the shelves provided in the door
Meat and fish should be covered to prevent loss of moisture and
odours. Wrap such foods in aluminium foil or polythene or store in an
airtight container
It is advisable to store cooked food on top shelves and fresh food on
the lower shelves to prevent cross contamination
ARRANGEMENT OF FOOD IN THE FRIDGE
The following guidelines and recommendations are suggested to obtain the
best results:
1. The fridge compartment is for the short term storage of fresh food
and drinks.
2. Cooked dishes must be stored in airtight covered containers.
3. Fresh wrapped produce can be placed on the shelf. Fresh fruit and
vegetables should be cleaned and stored in the crisper bins.
4. Bottles can be placed in the door section.
5. To store raw meat, wrap in polythene bags and place on the lowest
shelf. Do not allow to come into contact with cooked food to avoid
contamination. For safety, only store raw meat for two to three days.
6. Keep the food packed, wrapped or covered. Allow hot food and
beverages to cool before placing them in the fridge. Do not store
explosive substances.
7. High proof alcohol must be stored upright in sealed containers.
8. Left over canned food should not be stored in the can.
9. Fizzy drinks should not be frozen and products such as flavoured
water ices should not be consumed too cold.
USING YOUR F
RIDGE
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

10. Some fruit andvegetables suffer damage if kept at too low a
temperature
11. Place chilled cooked food near the rear of the fridge inner liner where
the cold wall is located.
12. Shelves, racks,crisper bins, drawers are all removable.
13. Donot leave frozen food at room temperature to thaw; the best way
to defrost food is to put it in the fridge to thaw slowly.
14. For hygiene reasons, always wrap food using a suitable packaging
material before storing in your appliance to avoid contact with the
appliance surface.
1. The thermostat located on the left-hand side wall of the refrigerator
compartment controls the temperature of the refrigerator
2. Turnthe thermostat knob to ‘’Med’’ to increase the temperature.
3. “off” is “OFF” AND “MAX” represents the lowest temperature
When the appliance is switched on for the first time, the setting knob should
be adjusted so thatafter 24 hours, the average fridge temperature is no
higher than +5 degrees Celsius. Some sections of the fridge may be cooler or
warmer (such as the salad crisper and the top part of the cabinet . The
temperature ofthe freezer compartment should be should be between -18°C
and -25°C.
TEMPERATURE CONTROL
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

We recommend thatyou switch off the appliance at the socket outlet
and pull out the mains plug before cleaning
Never use any sharp abrasive instrument, soap, household cleaner,
detergent and wax polish for cleaning
Wash with a weak solution of bicarbonate of soda. Then rinse with
warm water using a damp sponge or cloth and wipe dry.
Wipe the inside and outside of refrigerator with a damp soft cloth, a
soft cloth with a mild detergent may also be used if required
Check door seals regularly to ensure they are clean and free from food
particles
To remove door racks, remove all the contents and then simply push
the door rack upwards from the base
If you are going away on holiday or for any other reason, wish to leave the
refrigerator idle for any period of time, proceed as follows:
Disconnect the refrigerator from the electric power supply by
removing the plug from the wall socket
Remove all food
Clean and dry the inside as instructed in the directions above for
cleaning
Leave the doors open to prevent any unpleasant smells from building
up while the refrigerator is not used
Clean and defrost your appliance and chiller box regularly
Keep raw meat and poultry below cooked food and dairy products
CLEANING AND CARE
TOP TIPS
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Take off any unusable leaves on vegetables and wipe off any soil
Wrap cheese firstly in greaseproof paper
Wrap raw meat and poultry loosely in polythene or aluminium foil
Wrap fish and offal in polythene bags
Wrap food which have a strong odour in polythene bags,aluminium
foil or place in an airtight container
Wrap bread well to keep it fresh
Keep food for as short a time as possible and adhere to "Best
Before"/"Use by" etc. dates
Don'tstore bananas or melon in your fridge compartment
Don'tstore poisonous or any dangerous substances in your appliance
Don't consume food which has been stored for an excessive time in
the fridge
Don'tleave the door open for long periods as this will make the
appliance more costly to run and cause excessive ice formation
Don'tput hot food into the appliance
Don't put liquid-filled bottles or sealed cans containing carbonated
liquids into the freezer as they may burst
Keep electrical cable away from all sources of heat
To maintain efficiency keep door opening to a minimum
Keep ventilation openings clear of obstructions
The appliance should only be used indoors and should not be exposed
to rain or moisture
Don'tplace heavy objects onto the refrigerator.
ENERGY SAVING TIPS
Ensure your appliance is installed in a well ventilated area. If the
ambient temperature is low (but in no case lower than 10 degrees C),
then the energy saving will be more
Do not leave the door of your appliance openlonger than necessary
and ensure they are closed properly after each opening
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Check the following:
That the plug is inserted properly in the socket and that the power
supply is on
That the fuse has blown/circuit breaker has tripped/main distribution
switch has been turned off
That the temperature control has been set correctly
That the plug is wired correctly if you have changed the fitted plug
If the appliance is still not operating after the above checks, please contact
Shomar Ltd, see contact details.
Please ensure that theabove checks have been made as a charge will be made
if no fault is found.
Working Defects and Failures
Symptom: Appliance will not work at all.
Cause: The power supply plug is not inserted in the wall socket or the
plug and the outlet is loose.
To test the supply socket a lamp or small electrical appliance may be used to
check that the socket is working.
Symptom: Noisy running.
Cause: The appliance has not been properly levelled.
The refrigerator may be in contact with the wall or the accessories in the
refrigerator may be placed in the wrong position.
PROBLEM SOLVING
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Symptom: Appliance does not cool sufficiently.
Cause: Door has been opened too often, or for too long a time
There may be toomuch food in the refrigerator,possible incorrect
temperature selection
Symptom: Smell inside the appliance.
Cause: Some of the food is not properly wrapped or covered.
The inside of the refrigerator needs cleaning; Liquids such as milk may have
been spilled in the fridge.
The following are normal:
Refrigerant running in pipes gives a gentle sound of water running in
pipes
In high humidity the outer surface of the refrigerator may be covered
with condensation that should simply be wiped away
The compressor and the rear condenser will become hot and should
notbe touched.
If after checking all of the above and the problem persists contact the Shomar
Service Department Ph 01 4505327.
The use of any electrical appliance requires the following common sense
safety rules. There is danger of injury or death to the person and damage to
the appliance.
HEALTH AND SAFETY
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Location
This appliance is intended to be used in household and residential
type environments. It is not suitable for use in shops, offices and
other working environments
Do not use outdoors or in a bathroom
Do not place appliance on a highly polished wooden surface as
damage may occur to the surface
Do not place the appliance on or near a hot surface
This appliance should not be used in an unheated, cold room i.e.
Garage, conservatory, annex, shed, out-house etc.
Mains Cable
Do not let the lead run across an open space
Do not let the cable run across a cooker or hot area which may
damage the cable
The mains cable should reach from the socket to the base unit without
straining the connections
The power cord cannot be replaced
Personal Safety
Avoid touching moving parts. Keep hands, hair and clothing and
utensils away from the appliance and fan to prevent personal injury
and/or damage to the appliance.
To protect against the risk of electric shock ensure the electrical
connections are kept dry
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities
Children
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Children should be supervised to ensure that they do not play with
this appliance
Teach children to be aware of dangers in the kitchen
Do not allow children to play with the appliance or tamper with the
controls
Childrenunder the age of 8 should not use this appliance
Other Safety Considerations
Do not operate any appliance with a damaged cord or plug or after
the appliance malfunctions or has been damaged in any manner
The use of attachments or tools not pertaining to this appliance may
cause fire, electric shock or injury
Do not use the appliance for anything other than its intended purpose
Unplug from the outlet when not in use or unattended and before
assembling, disassembling and cleaning
Make sure the appliance is switched off before connecting to or
disconnecting from the mains supply
If the appliance is dropped or damaged in any manner, return the
appliance to the nearestauthorized dealer or after-sales service
centre for examination, repair, electrical or mechanical adjustment
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Registering Your 2 Year Guarantee
Your standard one year guarantee is extended for an additional 1 year when
you register the product within 28 days of purchase with the supplier Shomar
Ltd. If you do not register the product with Shomar Ltd within 28 days, your
product is guaranteed for 1 year. To validate your 2year guarantee register
with us visit www.powerpointappliances.ie
Please note that the 2 year guarantee is only available in Ireland.
Please refer to the one year guarantee for more information.
One Year Guarantee
It is importantto retain the retailer’s receipt as proof of purchase. Staple your
receipt to this back cover for future reference.
Please quote the following information if the product develops a fault. These
numbers can be found on the product.
Model no.
Serial no.
Subjectto the exclusions set out below (see Exclusions), the faulty appliance
will then be repaired or replaced. If for any reason, this item is replaced during
the guarantee period,the guarantee on the new item will be calculated from
original purchase date.Therefore it is vital to retainyour original till receipt or
invoice to indicate the date of initial purchase.
To qualify for the 1 year guarantee, the appliance must have been used
according to the instructions supplied.
WARRANTY INFORMATION
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Exclusions
Shomar Ltd shall not be liable to replace or repair the goods under the terms
of the guarantee where:
The fault has been caused or is attributable to accidental use, misuse,
negligent use or used contrary to the manufacturer’s
recommendations or where the fault has been caused by power
surges or damage caused in transit.
The appliance has been used on a voltage supply other than that
stamped on the products.
Repairs have been attempted by persons other than our service staff.
The appliance has been usedfor hire purposes ornon-domestic use.
The appliance is second hand.
This guarantee does not confer any rights other than those expressly set out
above and does not cover any claims for consequential loss or damage. This
guarantee is offered as an additional benefit and does not affect your
statutory rights as a consumer. This guarantee is valid in Ireland and the UK
only.
PowerPoint products are intended for household use only. See usage
limitations in “safety instructions”. Shomar Ltd has a policy of continuous
improvement in product quality and design. The company, therefore reserves
the right to change the specification of its models at any time.
The After Sales Division for PowerPoint Appliances is located at the offices of
the Brand owner and Distributor –
Shomar Ltd, Unit 9 Western Industrial Estate, Dublin 12, Republic Of Ireland.
Helplines (office hours) & Spare Parts contact number is 01-4505327 or email
[email protected]
WARRANTY INFORMATION
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

.
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)
