PowerPoint P65555FFM2GLB User manual

1
Fridge Freezer
P65555FFM2GLB
Please read and keep safe for future use.
Serial No.
ser

2
Features………………………………………………………………………………………………….. 3
Transportation instructions......................................................................... 4
Introduction & safety warnings.................................................................. 5
Electrical Requirements/Installation ………………… ........................................6
Food Storage …………………………………………………………………….…………………….. 7
Defrosting/Arrangement of Food ................................................................ 9
Temperature Control ………………………………………………………………………………..10
Cleaning and Care………………........................................................................ 11
Top Tips ……………........................................................................................ 12
Problem solving ........................................................................................... 14
Technical data/Health & Safety .................................................................. 16
Disposal/Warranty Information................................................................... 18
Customer Care …………………………………………………………………………………………. 20
INSTALLATION AND USER INSTRUCTIONS

3
1. Lamp Box Assembly 7. Freezer Drawer
2. Glass Shelf 8. Adjustable Foot
3. Crisper Cover 9. Egg Tray
4. Salad Crisper 10. Bottle Rack (Upper)
5. Upper Freezer Drawer 11. Bottle Rack (Lower)
6. Glass Shelf (Freezer)
Features

4
When transporting, never tilt to more than 45 degrees
The appliance should be transported only in a vertical upright position
The packaging as supplied must be intact during transportation
If during the course of transport the appliance has to be transported
horizontally, it must only be laid on its left hand side when standing in
front of the appliance. After bringing it to the upright position, it must
not be operated for at least 4 hours to allow the system to settle. The
manufacturer will not be held responsible if these instructions are
disregarded.
The appliance must be protected against rain and moisture
When positioning your appliance take care not to damage your
flooring, kitchen furniture, related parts and doors, pipes, wall
coverings etc
Do not move the appliance by pulling by the door
Hold the base and lift the refrigerator carefully
Never hold the door handle as support
Never place the refrigerator upside down or lie it down
Move refrigerator by using its two hind roller feet as an axis and then
tilting it slightly to move
IMPORTANT: Do NOT connect your appliance to the electricity supply until
all packing and transit protectors have been removed.
Leave to stand for at least 4 hours before switching on to allow
compressor oil to settle if transported horizontally, if the appliance is
switched off at any time, wait 30 minutes before switching back on to
allow the coolant fluid to settle
Before First Use
Transportation of your Appliance

5
If you are discarding an old refrigerator with a lock or latch fitted to
the door, disable the lock/latch, ensure that it is left in a safe
condition to prevent the entrapment of young children
This fridge/freezer must only be used for its intended purpose i.e. the
storing and freezing of edible foodstuff
Do not dispose of the appliance on a fire
Take care not to damage the cooling circuit, if damaged immediately
ventilate the room where the appliance is situated
This appliance should not be used in an unheated, cold room i.e.
garage, conservatory, annex, shed, out-house etc.
Ensure that the plug remains readily accessible
Failure to observe these instructions may invalidate your right to free
service during the guarantee period
We recommend a separate switch be used to ensure easy switch
on/off
Children should be supervised to ensure that they do not play with the
appliance
This appliance is intended to be used in a household environment
IMPORTANT WARNINGS:
Keep ventilation openings in the appliance enclosure and the built-in
structure clear of obstruction.
Make sure that mains cable is not caught under the appliance during
and after carrying / moving the appliance, to avoid the mains cable
becoming cut or damaged.
Care must be taken while cleaning / carrying the appliance to avoid
Touching the bottom of the condenser metal wires at the back of the
Appliance as you may injure your fingers and hands.
Make sure that mains cable is not caught under the appliance
During and after carrying / moving the appliance, to avoid the mains
Cable becoming cut or damaged.

6
Before you insert the plug into the wall socket make sure that the voltage and
The frequency shown in the rating plate inside the appliance corresponds to
Your electricity supply. We recommend that this appliance is connected to the
mains supply via a suitable switched and fused socket in a readily accessible
position.
Should the mains lead of the appliance become damaged or should it need
Replacing at any time, it must be replaced by a special purpose made mains
Lead which can only be obtained from Shomar Ltd.
WARNING! THIS APPLIANCE MUST BE EARTHED
If the fitted plug is not suitable for your socket, then the plug should be
removed and an appropriate plug fitted. Destroy the old plug which is cut off
as a plug with bared cord could cause a shock hazard if inserted into a socket.
The plug on this appliance incorporates a 13 A fuse. Should the fuse need to
be changed a fuse of the same rating must be used. Ensure that the fuse cover
is refitted.
1. Install the refrigerator on a flat surface in order to prevent vibration
and noise.
2. The cord should be secured behind the appliance to avoid injury
3. Choose a dry well-ventilated place
4. Minimum space in the room where the refrigerator is being installed
is 10 cubic metres.
5. Choose a location where there is no heat source. Keep the refrigerator
away from direct sunlight, oven etc.
Electrical Requirements
Installation Instructions

7
6. Do not place the appliance near cookers, radiators or in direct sunlight
as this will cause your appliance to work harder.
7. Don’t install this appliance in a wall recess or into fitted cabinets.
8. Allow a gap of 3.5” between the back grille and the wall.
9. Allow a gap of 2 cm either side of the unit.
10. To ensure that your appliance is level adjust the levelling feet at the
front by turning them
Before you start using the refrigerator check that:
1. The interior is dry and air can circulate freely at the rear of the
cabinet.
2. Clean the interior as recommended under "CLEANING AND CARE."
3. Insert the plug into the wall socket and switch on the electricity
supply.
4. You will hear a noise as the compressor starts up. The liquid and gases
sealed within the refrigeration system may also give rise to noise,
whether the compressor is running or not which is quite normal.
5. Front edges of the cabinet may feel warm. This is normal.
6. Do not load the appliance immediately it is switched on. Wait until the
Correct storage temperature has been reached. We recommend that
You check the temperature with an accurate thermometer or wait 24
hours.
How to Use the Refrigerator Compartment:
Cooked /fresh foods may be stored in your refrigerator. Hot foods
must first be allowed to reach room temperature before storage
Eggs and Bottle’s should be stored on the shelves provided in the door
Meat and fish should be covered to prevent loss of moisture and
odours, wrap such foods in aluminium foil or polythene or store in an
airtight container
Food Storage

8
It is advisable to store cooked food on top shelves and fresh food on
the lower shelves to prevent cross contamination
How to Use the Freezer Compartment:
Pre-packed commercially frozen food should be stored in accordance
with the frozen food manufacturer's instructions for a frozen
food storage compartment
To ensure that the high quality achieved by the frozen food
manufacturer and the food retailer is maintained, the following
should be observed:
- Put packets in the freezer as quickly as possible after purchase.
- Ensure that contents are labelled and dated.
- Do not exceed "Use By" or "Best Before" dates on the packaging
If there is a power failure do not open the door. Frozen food should
not be affected if the failure lasts for less than 14 hrs. If the failure is
longer, then the food should be checked and either eaten
immediately or cooked and then refrozen
Freezing Fresh Food:
Do not freeze too large a quantity at any one time. The quality of the
food is best preserved when it is frozen right through as quickly as
possible
Do not exceed the freezing capacity of your appliance in 24 h which is
4 kg (9 lb)
Placing warm food into the freezer compartment causes the
refrigeration compressor to operate continuously until the food is
frozen solid. This can temporarily lead to excessive cooling of the
refrigeration compartment.
Defrosting

9
This appliance defrosts automatically.
WARNINGS!
The fan inside the freezer compartment circulates cold air.
Never insert any object through the guard.
Do not allow children to play with the freezer fan.
Never store products that contain inflammable propellant gas (eg
dispensers, spray cans etc.) or explosive substances.
Don’t cover the shelves with any protective materials, which may obstruct
air circulation.
Do not allow children to play with the appliance or tamper with the controls.
Do not obstruct the freezer fan guard.
ARRANGEMENT OF FOOD IN THE FRIDGE/FREEZER
The following guidelines and recommendations are suggested to obtain the
Best results:
1. The fridge compartment is for the short term storage of fresh food
and drinks.
2. The freezer compartment is rated and suitable for the freezing and
storage of pre frozen food. The recommendation for storage as
stated on the food packaging should be observed at all times.
3. Cooked dishes must be stored in airtight covered containers.
4. Fresh wrapped produce can be placed on the shelf. Fresh fruit and
vegetables should be cleaned and stored in the crisper bins.
5. Bottles can be placed in the door section.
6. To store raw meat, wrap in polythene bags and place on the lowest
shelf. Do not allow to come into contact with cooked food to avoid
contamination. For safety, only store raw meat for two to three days.
7. Keep the food packed, wrapped or covered. Allow hot food and
beverages to cool before placing them in the fridge. Do not store
explosive substances.
8. High proof alcohol must be stored upright in sealed containers.

10
9. Left over canned food should not be stored in the can.
10. Fizzy drinks should not be frozen and products such as flavoured
water ices should not be consumed too cold.
11. Some fruit and vegetables suffer damage if kept at too low a
temperature.
12. Place chilled cooked food and similar food near the rear of the fridge
inner liner where the cold wall is located.
13. Shelves, racks, crisper bins, drawers are all removable.
14. Do not leave frozen food at room temperature to thaw; the best way
to defrost food is to put it in the fridge to thaw slowly.
15. For hygiene reasons, always wrap food using a suitable packaging
material before storing in your appliance to avoid contact with the
appliance surface.
Control Panel
Air Volume Control
1. The display panel is located at the top of the refrigerator
compartment and it controls the temperature
2. To allow for seasonal temperature change, set temperature to
between 4 and 6 in spring and Autumn with air volume control in the
Temperature Control

11
middle position. In the Summer adjust temperature to level 2 with
the air volume control in a minimum position
3. To quickly chill food select the “Fast Cool” function
4. Increasing the air volume control lowers the temperature and vice
versa.
When the appliance is switched on for the first time, the setting knob should
be adjusted so that after 24 hours, the average fridge temperature is no
higher than +5 degrees Celsius. Some sections of the fridge may be cooler or
warmer (such as the salad crisper and the top part of the cabinet. The
temperature of the freezer compartment should be should be between -18°C
and -25°C.
We recommend that you switch off the appliance at the socket outlet
and pull out the mains plug before cleaning
Never use any sharp abrasive instrument, soap, household cleaner,
detergent and wax polish for cleaning
Use lukewarm water to clean the cabinet of the appliance and wipe it
dry
Wipe the inside and outside of refrigerator with a damp soft cloth, a
soft cloth with a mild detergent may also be used if required
The grille of the condenser at the back the adjacent components can
be vacuumed using a soft brush attachment.
If the appliance is not going to be used for a long period of time
unplug the appliance, remove all food, clean it and leave the door ajar
Check door seals regularly to ensure they are clean and free from food
particles
If you are going away on holiday or for any other reason, wish to leave the
refrigerator idle for any period of time, proceed as follows:
Disconnect the refrigerator from the electric power supply by
removing the plug from the wall socket
Cleaning and Care

12
Remove all food
Clean and dry the inside as instructed in the directions above for
cleaning
Leave the doors open to prevent any unpleasant smells from building
up while the refrigerator is not used
Clean your appliance regularly
Keep raw meat and poultry below cooked food and dairy products
Take off any unusable leaves on vegetables and wipe off any soil
Wrap cheese firstly in greaseproof paper
Wrap raw meat and poultry loosely in polythene or aluminium foil
Wrap fish and offal in polythene bags
Wrap food which have a strong odour in polythene bags, aluminium
foil or place in an airtight container
Wrap bread well to keep it fresh
Keep food for as short a time as possible and adhere to "Best
Before"/"Use by" etc. dates
Store commercially frozen food in accordance with the instructions
given on the packets
Wrap frozen food when you buy it and put it in to the freezer as soon
as possible
Prepare fresh food for freezing in small portions to ensure rapid
freezing
Don't store bananas or melon in your fridge compartment
Don't store poisonous or any dangerous substances in your appliance
Don't consume food which has been stored for an excessive time in
the fridge
Don't leave the door open for long periods as this will make the
appliance more costly to run and cause excessive ice formation
Don't put hot food into the appliance
Top Tips

13
Don't put liquid-filled bottles or sealed cans containing carbonated
liquids into the freezer as they may burst
Don't exceed the maximum freezing loads (4 kg in any 24 hours) when
freezing fresh food
Don't give children ice-cream and water ices direct from the freezer.
The low temperature may cause 'freezer burns' on lips
Don't freeze fizzy drinks
Don't try to keep frozen food which has thawed, it should be eaten
within 24 hours or cooked and refrozen
Don’t leave frozen food at room temperature to thaw; put it in the
fridge to thaw slowly
Keep electrical cable away from all sources of heat
To maintain efficiency keep door opening to a minimum
Keep ventilation openings clear of obstructions
The appliance should only be used indoors and should not be exposed
to rain or moisture
Don't place heavy objects onto the refrigerator.
ENERGY SAVING TIPS
Ensure your appliance is installed in a well ventilated area. If the
ambient temperature is low (but in no case lower than 5 degrees C),
then the energy saving will be more
Ensure the time between buying chilled/frozen food and placing them
in your appliance is kept at minimum, particularly in summer
Do not leave the door of your appliance open longer than necessary
and ensure they are closed properly after each opening
Check the following:
Problem Solving

14
That the plug is inserted properly in the socket and that the power
supply is on
That the fuse has blown/circuit breaker has tripped/main distribution
switch has been turned off
That the temperature control has been set correctly
That the plug is wired correctly if you have changed the fitted plug
If the appliance is still not operating after the above checks, please contact
Shomar Ltd, see contact details.
Please ensure that the above checks have been made as a charge will be made
if no fault is found.
Working Defects and Failures
Symptom: Appliance will not work at all.
Cause: The power supply plug is not inserted in the wall socket or the
plug and the outlet is loose.
To test the supply socket a lamp or small electrical appliance may be used to
check that the socket is working.
Symptom: Noisy running.
Cause: The appliance has not been properly levelled.
The refrigerator may be in contact with the wall or the accessories in the
refrigerator may be placed in the wrong position.
Symptom: Appliance does not cool sufficiently.
Cause: Door has been opened too often, or for too long a time
There may be too much food in the refrigerator, possible incorrect
temperature selection
Symptom: Smell inside the appliance.

15
Cause: Some of the food is not properly wrapped or covered.
The inside of the refrigerator needs cleaning; Liquids such as milk may have
been spilled in the fridge.
The following are normal:
Refrigerant running in pipes gives a gentle sound of water running in
pipes
In high humidity the outer surface of the refrigerator may be covered
with condensation that should simply be wiped away
The compressor and the rear condenser will become hot and should
not be touched.
If after checking all of the above and the problem persists contact the Shomar
Service Department.
Tecical Data

16
The use of any electrical appliance requires the following common sense
safety rules. There is danger of injury or death and damage to the
appliance.
Location
This appliance is intended to be used in household and residential
type environments. It is not suitable for use in shops, offices and
other working environments
Do not use outdoors or in a bathroom
Do not place appliance on a highly polished wooden surface as
damage may occur to the surface
Do not place the appliance on or near a hot surface
Health & Safety

17
This appliance should not be used in an unheated, cold room i.e.
garage, conservatory, annex, shed, out-house etc.
Mains Cable
Do not let the lead run across an open space
Do not let the cable run across a cooker or hot area which may
damage the cable
The mains cable should reach from the socket to the base unit without
straining the connections
The power cord cannot be replaced
Personal Safety
Avoid touching moving parts. Keep hands, hair and clothing and
utensils away from the appliance and fan to prevent personal injury
and/or damage to the appliance.
To protect against the risk of electric shock ensure the electrical
connections are kept dry
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities
Children
Children should be supervised to ensure that they do not play with
this appliance
Teach children to be aware of dangers in the kitchen
Do not allow children to play with the appliance or tamper with the
controls
Children under the age of 8 should not use this appliance
Other Safety Considerations

18
Do not operate any appliance with a damaged cord or plug or after
the appliance malfunctions or has been damaged in any manner
The use of attachments or tools not pertaining to this appliance may
cause fire, electric shock or injury
Do not use the appliance for anything other than its intended purpose
Unplug from the outlet when not in use or unattended and before
assembling, disassembling and cleaning
Make sure the appliance is switched off before connecting to or
disconnecting from the mains supply
If the appliance is dropped or damaged in any manner, return the
appliance to the nearest authorized dealer or after-sales service
centre for examination, repair, electrical or mechanical adjustment
Dispose of used electrical appliances in an environmentally friendly manner.
This product should not be disposed with other household wastes throughout
the EU. This Fridge Freezer bears the symbol for waste electrical and electronic
equipment (WEEE). This means that this equipment must be handled in
accordance with European Directive 2002/96/EC for recycling to minimise
damage to the environment. Before disposing of the appliance, cut off the
power cable plug and remove the door to avoid accidents.
Warranty Information.
Disposal

19
Registering Your 2 Year Guarantee
Your standard one year guarantee is extended for an additional 1 year when
you register the product within 28 days of purchase with the supplier Shomar
Ltd. If you do not register the product with Shomar Ltd within 28 days, your
product is guaranteed for 1 year. To validate your 2 year guarantee register
with us by visiting our website www.powerpointappliances.ie
One Year Guarantee
It is important to retain the retailer’s receipt as proof of purchase. Staple your
receipt to this back cover for future reference. Please quote the following
information if the product develops a fault. These numbers can be found on
the product.
Model no.
Serial no.
Subject to the exclusions set out below (see Exclusions), the faulty appliance
will then be repaired or replaced. If for any reason, this item is replaced during
the guarantee period, the guarantee on the new item will be calculated from
original purchase date. Therefore it is vital to retain your original till receipt or
invoice to indicate the date of initial purchase. To qualify for the 1 year
guarantee, the appliance must have been used according to the instructions
supplied.
Exclusions
Shomar Ltd shall not be liable to replace or repair the goods under the terms
of the guarantee where:
1. The fault has been caused or is attributable to accidental use, misuse,
negligent use or used contrary to the manufacturer’s
recommendations or where the fault has been caused by power
surges or damage caused in transit.
2. The appliance has been used on a voltage supply other than that
stamped on the products.

20
3. Repairs have been attempted by persons other than our service staff.
4. The appliance has been used for hire purposes or non-domestic use.
5. The appliance is second hand.
This guarantee does not confer any rights other than those expressly set out
above and does not cover any claims for consequential loss or damage. This
guarantee is offered as an additional benefit and does not affect your
statutory rights as a consumer.
This guarantee is valid in Ireland only.
PowerPoint products are intended for household use only. See usage
limitations within the location safety instructions.
Shomar Ltd has a policy of continuous improvement in product quality and
design. The company, therefore reserves the right to change the specification
of its models at any time.
The After Sales Division for PowerPoint Appliances is located at the offices of
the Brand owner and Distributor –
Shomar Ltd, Unit 9 Western Industrial Estate, Dublin 12, Republic Of Ireland.
Helplines (office hours) & Spare Parts contact number is 01-450 5327 or email
[email protected]e
Warranty registration www.powerpointappliances.ie
.
Contact Details
