powersoft M-Force Series User manual

Keep this manual
for future reference
©2019 Powersoft
USER GUIDE
SE ST5
MATERIAL
TREATMENT
DESCRIPTION
ITEM
DATE SCALE AUTHOR APPROV. SHEETS
UNI-ISO
2768-M
GENERAL
TOLERANCES
ACCORDING WITH THE LAW, WE RESERVE THE
PROPERTY OF THIS DRAWING. IT CANNOT BE
REPRODUCED OR OTHERWISE MAKE KNOW TO
OTHER COMPANIES OR COMPETITORS
WITHOUT OUR PERMISSION
DRAWING
CODE
WEIGHT
VOLUME
REV
REV. DATA DESCRIPTION AUTHOR
01 - - -
02 - - -
03 - - -
04 - - -
A1 Format - 841 x 594
POWERSOFT S.p.A.
Via E.Conti, 5 - 50018 Scandicci (FI) - Italy
Tel. [phone] - fax [phone]
http://www.powersoft.it
( )
3.2 0.8
Note: -
-
19/10/2018
1:2 lombardi 1 / 1
M-Force 00
22589,7 g
4886,9 cm^3
.
M-Force
.
.
.
M-Force
265
298
236
100 100
2525
100
277
286
111 ±0,5
127 ±0,5
55
M-Force Engine Kit
DO000252.00 Rev 0
Moving Magnet Linear Motor Transducer
for low frequency applications
M-Force 01 (PF000399) and M-Force 02 (PF000327) versions

DO000252_powersoft_MForceEK_UG_EN
Data are subject to change without notice.
For latest update please refer to the
online version available on www.powersoft-audio.com.

M-Force User Guide
Table of contents
1.Important safety instructions ii
Importantes instructions de sécurité iii
Instrucciones de seguridad importantes iv
Importanti istruzioni di sicurezza v
2.M-Force 1
2:1.Welcome 1
2:4.Disposal of the packing material 1
2:2.Unpacking & checking for shipping damage 1
2:2.1.Needed tools 1
2:3.Optional and accessories 1
3.Mechanical Drawings 2
4.Installation instructions 4
4:1.Fasten the brackets to the cabinet 4
4:2.Fasten the motor to the brackets 4
4:3.Plug the motor to the amplifier 5
4:4.Verify the alignment of the diaphragm 5
4:4.1.Troubleshooting the mechanical alignment 6
4:5.Diaphragm bay design tollerance 7
5.Important notes 10
5:1.Preset HPF 10
5:2.No mechanical load 10
5:3.Nuts tightening torque 10
5:4.Engine diaphragm spacer nut 10
5:5.Rim and baffle cutout diameters 10
5:6.Thermal considerations 10
5:7.Mechanical strength of the cabinet 10
5:8.Mechanical balancing 10
5:9.Acoustic load balancing 10
6.Appendix A 11
6:1.Building your own cables 11
7. Specifications 12
CLASS3
WIRING
Table of contents | i

CAUTION
RISK OF ELECTRICK SHOCK
DO NOT OPEN
Electrical energy can perform many useful functions. This unit has
been engineered and manufactured to ensure your personal safety. But
IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR
FIRE HAZARD.
In order not to defeat the safeguards incorporated into this product,
observe the following basic rules for its installation, use and service.
Please read these “Important Safeguards” carefully before use.
Important safety instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this equipment near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Only use attachments/accessories specified by the manufacturer.
10. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT ATTEMPT TO OPEN ANY PART OF THE UNIT. NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE,
DRIPPING OR SPLASHING LIQUIDS. OBJECTS FILLED WITH
LIQUIDS, SUCH AS VASES, SHOULD NOT BE PLACED ON THIS
APPARATUS.
EXPLANATIONS OF GRAPHICAL SYMBOLS
The triangle with the lightning bolt is used to alert the
user to the risk of electric shock.
The triangle with the exclamation point is used to
alert the user to important operating or maintenance
instructions.
The CE-mark indicates the compliance with the low
voltage and electromagnetic compatibility.
Symbol for earth/ground connection.
Symbol indicating that the equipment is for indoor
use only.
Symbol for conformity with Directive 2002/96/EC
and Directive 2003/108/EC of the European
Parliament on waste electrical and electronic equip-
ment (WEEE).
WHEN THE UNIT IS INSTALLED INTO A CABINET FOR LOW
FREQUENCY LOUDSPEAKERS, MAKE SURE THAT IT HAS
SUFFICIENT SPACE ON ALL SIDES TO ALLOW FOR PROPER
VENTILATION.
Important safety instructions 1
CLASS3
WIRING
CLASS3
WIRING
ii | M-Force Engine Kit | User guide

Importantes instructions de sécurité
AVIS
RISQUES D’ÉLECTROCUTION
NE PAS OUVRIR
L’énergie é lectrique peut remplir beaucoup de fonctions utiles. Cet appa-
reil a été conçu et fabriqué pour assurer votre propre sécurité. Mais UNE
UTILISATION INCORRECTE PEUT ENTRAÎNER UN RISQUE POTENTIEL
D’ÉLECTROCUTION OU D’INCENDIE. Afin de ne pas annuler les dispositifs de
sécurité incorporés dans cet appareil, observez les règles fondamentales suiv-
antes pour son installation, son utilisation et sa réparation. Veuillez lire atten-
tivement ces “Importantes mesures de sécurité” avant d’utiliser l’appareil.
Importantes instructions de sécurité
1. Lisez les directives suivantes.
2. Conservez ces directives.
3. Observez et respectez tous les avertissements.
4. Suivez toutes les directives.
5. N’utilisez pas cet appareil près de l’eau.
6. Nettoyez cet appareil uniquement avec un chiffon sec.
7. Ne bouchez pas les fentes de ventilation. Respectez les directives
du fabricant pour l’installation de l’appareil.
8. N’installez pas l’appareil à proximité d’une source de chaleur telle
qu’un radiateur, une bouche d’air chaud, une cuisinière ou tout au-
tre appareil (y compris des amplificateurs) émettant de la chaleur.
9. Utilisez uniquement les éléments de raccordement et les acces-
soires recommandés par le fabricant.
10. Pour toute réparation, adressez-vous à un réparateur qualifié.
Faites réparer l’appareil s’il a été endommagé de quelque manière
que ce soit, par exemple si le cordon d’alimentation ou sa fiche
sont endommagés, si du liquide ou tout autre corps étranger a
pénétré dans l’appareil, si l’appareil a été exposé à la pluie ou à
l’humidité, s’il ne fonctionne pas normalement ou s’il est tombé.
MISE EN GARDE : AFIN DE RÉDUIRE LES RISQUES DE CHOC
ÉLECTRIQUE, N’ESSAYEZ PAS D’OUVRIR L’UNITÉ, MEME EN
PARTIE. AUCUNE PIÈCE A L’INTERIEUR NE PEUT ETRE CHANGÉE PAR
L’UTILISATEUR. LAISSEZ L’ENTRETIEN A UN PERSONNEL QUALIFIÉ.
AFIN DE RÉDUIRE LES RISQUES D’INCENDIE ET
D’ÉLECTROCUTION, N’EXPOSEZ PAS CET APPAREIL À LA
PLUIE OU À L’HUMIDITÉ. L’UNITÉ NE DOIT JAMAIS ÊTRE EXPOSÉ AUX
ÉCLABOUSSURES, AU DÉVERSEMENT OU À L’ÉGOUTTEMENT DE
LIQUIDES, QUELS QU’ILS SOIENT.
Le marquage CE indique la conformité à la directive de
basse tension et la compatibilité électromagnétique.
Symbole pour la connexion à la terre.
Symbole indiquant que l’équipement est destiné à
l’emploi à l’intérieur.
Symbole pour la conformité al la Directive 2002/96/
EC et la Directive 2003/108/EC du Parlement
Européen sur les équipements électriques et élec-
troniques (WEEE).
EXPLICATION DES SYMBOLES GRAPHIQUES
La triangle avec le symbol du foudre est employée
pour alerter l’utilisateur au risque de décharge élec-
trique.
Le triangle avec un point d’exclamation est employée
pour alerter l’utilisateur d’instruction importantes
pour lors opérations de maintenance.
QUAND L’APPAREIL EST INSTALLÉ DANS UNE CAISSON POUR
HAUT-PARLEURS DE BASSE FRÉQUENCE, ASSUREZ-VOUS
QU’IL Y À UN ESPACE SUFFISANT TOUT AUTOUR POUR PERMETTRE
UNE BONNE VENTILATION.
CLASS3
WIRING
CLASS3
WIRING
Important safety instructions | iii

Instrucciones de seguridad importantes
PRECAUCIÓN
RIESGO DE CHOQUE ELÉCTRICO
NO ABRA LA UNIDAD
La energìa eléctrica puede realizar numerosas funciones útiles. Esta uni-
dad ha sido diseñada y fabricada para brindarle un funcuionamento seg-
uro. Sin embargo, el USO INCORRECTO O PUEDE PRODUCIR INCENDIOS
O DESCARGAS ELÉCTRICAS. Para no anular las salvaguardas incor-
poradas a este producto, asegúrese de respetar las reglas básicas si-
guientes para su instalacíon, uso y servicio. Por favor lea atentamente
estas “Salvaguardas importantes” ante del uso.
Instrucciones de seguridad importantes
1. Lea estas instrucciones.
2. Guarde estas instrucciones.
3. Respete todas las advertencias.
4. Siga todas las instrucciones.
5. No utilice este aparato cerca del agua.
6. Límpielo únicamente con un paño seco.
7. No bloquee los orificios de ventilación. Instale el aparato según las
instrucciones del fabricante.
8. No lo instale cerca de fuentes de calor como radiadores, calefac-
tores, hornos u otros aparatos (incluidos los amplificadores) que
generen calor.
9. Utilice únicamente los complementos o accesorios especificados
por el fabricante.
10. Solicite servicio técnico únicamente a personal de servicio técnico
especializado. Será necesario solicitar servicio técnico si el aparato
ha sufrido daños como, por ejemplo, si el cable de alimentación o
el enchufe están dañados, se ha vertido líquido o se ha caído algún
objeto dentro del aparato, o bien si dicho aparato ha sido expuesto a
la lluvia o a humedad, no funciona correctamente o se ha caído.
PRECAUCIÓN: PARA REDUCIR EL RIESGO DE DESCARGA
ELÉCTRICA, NO DESMONTE LA TAPA (NI EL PANEL TRASERO).
NO HAY PIEZAS REPARABLES POR EL USUARIO EN EL INTERIOR.
LLÉVELO A REPARAR A PERSONAL DE SERVICIO CUALIFICADO.
NO EXPONGA ESTE UNITAD A LA LLUVIA O LA HUMEDAD,
GOTEO O SALPICADURAS. NO COLOQUE OBJETOS LLENOS DE
LÍQUIDOS, TALES COMO VASIJAS, SOBRE EL APARATO.
La marca CE indica el cumplimiento de la directiva
de bajo voltaje y de compatibilidad electromagnética.
Símbolo de la conexión a tierra.
Símbolo que indica que el equipo es sólo para uso
en interiores.
Símbolo de conformidad con la Directiva 2002/96/
EC y Directiva 2003/108/EC del Parlamento Europeo
sobre los aparatos eléctricos y electrónicos (WEEE).
EXPLICACIÓN DE LOS SÍMBOLOS GRÁFICOS
El triángulo con el símbolo de rayo eléctrico es usa-
do para alertar al usuario de el riesgo de un choque
eléctrico.
El triángulo con el signo de admiración es usado
para alertar al usuario de instrucciones importantes
de operación o mantenimiento.
CUANDO LA UNIDAD SE INSTALA EN UNA CAJA POR ALTAVOZ
POR LAS BAJAS FRECUENCIAS, ASEGÚRESE QUE TENGA
SUFICIENTE ESPACIO EN TODOS LOS LADOS PARA PERMITIR LA
VENTILACIÓN ADECUADA.
CLASS3
WIRING
CLASS3
WIRING
iv | M-Force Engine Kit | User guide

Importanti istruzioni di sicurezza
L’elettricità viene usata per svolgere molte funzioni utili, ma può anche
causare danni personali o agli oggetti se applicata in modo improprio.
Questo prodotto è stato progettato e realizzato con la massima atten-
zione alla sicurezza. Tuttavia, UN USO IMPROPRIO PUÒ PRODURRE
SCOSSE ELETTRICHE E/O INCENDI. Per evitare potenziali pericoli, os-
servare le seguenti istruzioni durante l’installazione, l’utilizzo e la pulizia
del prodotto. Per garantire la sicurezza e prolungare la vita utile del
monitor LCD, leggere attentamente le seguenti precauzioni prima di
usare il prodotto.
Importanti istruzioni di sicurezza
1. Leggere queste istruzioni.
2. Conservare le istruzioni.
3. Tenere conto di tutti gli avvisi.
4. Seguire tutte le istruzioni.
5. Non usare l'apparecchio in prossimità di acqua.
6. Pulire solo con un panno asciutto.
7. Non ostruire le prese di ventilazione. Installare secondo le indica-
zioni del produttore.
8. Non installare vicino a fonti di calore quali radiatori, bocchette
dell'aria calda, stufe o altri apparecchi (compresi gli amplificatori)
che producono calore.
9. Usare solo accessori specificati dal produttore.
10. Ricorrere a personale qualificato per qualsiasi intervento. Tali
interventi sono necessari in caso di guasti dell'apparecchio
quali danneggiamento del cavo di alimentazione o della spina,
versamento di liquidi o caduta di oggetti nell'apparecchio, es-
posizione a pioggia o umidità o se l'apparecchio non funziona
normalmente o è caduto
ATTENZIONE
RISCHIO DI SCOSSE
ELETTRICHE, NON APRIRE
ATTENZIONE: PER RIDURRE IL RISCHIO DI SCOSSE
ELETTRICHE, NON TENTARE DI APRIRE ALCUNA PARTE
DELL’UNITÀ. NON CI SONO PARTI INTERNE AD USO DELL’UTENTE.
RIVOLGERSI A PERSONALE QUALIFICATO PER L’ASSISTENZA.
NON ESPORRE QUESTO APPARECCHIO ALLA PIOGGIA,
UMIDITÀ O SOSTANZE LIQUIDE. OGGETTI PIENI DI LIQUIDI,
COME VASI, NON DEVONO ESSERE COLLOCATI SU QUESTO APPARATO.
SPIEGAZIONE DEI SIMBOLI GRAFICI
Il triangolo con il lampo è utilizzato per avvisare
l’utente del rischio di scossa elettrica.
Il triangolo con il punto esclamativo è utilizzato per
avvisare l’utente di importanti istruzioni d’uso e ma-
nutenzione.
Il marchio CE indica la conformità del prodotto a
tutte le direttive europee applicabili
Simbolo della connessione di terra.
Simbolo che indica che l’apparecchio è solo per uso
interno.
Simbolo di conformità alla Direttiva 2002/96/CE e
alla Direttiva 2003/108/CE del Parlamento Europeo
sulle apparecchiature elettriche ed elettroniche
(RAEE).
QUANDO L’UNITÀ È INSTALLATA IN UN MOBILE PER
ALTOPARLANTI A BASSA FREQUENZA, ASSICURARSI CHE
RIMANGA SPAZIO SUFFICIENTE SU TUTTI I LATI PER CONSENTIRE
UN’ADEGUATA VENTILAZIONE.
CLASS3
WIRING
CLASS3
WIRING
Important safety instructions | v

Page intentionally left blank

M-Force User Guide 2
2:1.Welcome
Congratulations on your purchase of the Powersoft
M-Force.
We know you are eager to use M-Force, but please take
a moment to read this guide, the safety instructions and
Section: Important notes (p. 10). In case you have any
questions, please do not hesitate to contact your dealer or
Powersoft.
M-Force is an innovative and unique transducer based
on a patented moving magnet linear motor structure.
Unbelievable performance in terms of power handling,
electromagnetic conversion, reliability and maximum SPL
are a few of the incredible features and improvements with
respect to conventional moving coil arrangement.
The M-Force is a true paradigm shift from the old and
fashionable coil and cone. Unlike conventional loudspeak-
ers M-Force’s moving magnet motor is a genuine push-pull
motor where magnetic elds interactions guarantee linearity
in power requirement versus moving element displacement.
This, coupled to the the fact that no electical conductors
are present in the motor’s moving parts, brings forth high
efciency of the transducer: the moving magnet linear
motor ensures high force factor yielding negligible power
compression and very low input impedance.
With respect to conventional loudspeakers, M-Force
drives less power from the amplier to reach high audio per-
formance, high SPL and low distortion; robust and reliable,
its performance withstand years of abuse and operation.
M-Force has been designed with an eye to the environ-
ment: high power efciency, high thermal inertia, low usage
of Neodymium (at equal SPL in comparison to conventional
design) are distinctive features of the Powersoft’s Green
Audio philosophy.
2:2.Unpacking& checking for shipping damage
Your Powersoft product has been completely tested and
inspected before leaving the factory. Carefully inspect the
shipping package before opening it, and then immediately
inspect your new product. If you nd any damage notify the
shipping company immediately.
The M-Force package contains one motor (M-Force 01
or M-Force 02 ) and the spare parts listed in TABLE 1.
Q.ty Code Description
3VI000326 M8x14 inox
hex socket head cap screw
3VI000319 M8 thin nut DIN 936
7VI000197 M8 lock washer 14.8 mm
1VI000328 M8 at washer 16 mm
2VI000206 M5 brass nut
2VI000196 M5 brass at washer 10 mm
1ET000414 M-Force label
1ME001363.01 Spacer
1CN000744 4p 10 mm crimp housing
4CN000745 crimp teminal 10-12 AWG (f)
TABLE 1: Spare parts.
2:2.1.Needed tools
Q.ty Description
1Torque wrench (M13)
1 6 mm hex key
1Adjustable wrench
2:3.Optional and accessories
Code Description
ME000733.00 90° mounting bracket
(needs 2 pcs. per motor)
ME000919.00 45° mounting bracket
(needs 2 pcs. per motor)
ME001089.01 Spider mounting bracket
(needs 2 pcs. per motor)
PF30FP00 30” W 4 mm
PE-HWU diaphragm
PF30SP00 30” V 4 mm
PE-HWU diaphragm
PF40FP00 40” W 4 mm
PE-HWU diaphragm
2:4.Disposal of the packing material
The transport and protective packing has been selected
from materials which are environmentally friendly for dis-
posal and can normally be recycled.
Rather than just throwing these materials away,
please ensure they are offered for recycling.
M-Force | 1

2 | M-Force Engine Kit | User guide
Mechanical Drawings 3
M-Force 01/02 Engine Kits
SE ST5
MATERIAL
TREATMENT
DESCRIPTION
ITEM
DATE SCALE AUTHOR APPROV. SHEETS
UNI-ISO
2768-M
GENERAL
TOLERANCES
ACCORDING WITH THE LAW, WE RESERVE THE
PROPERTY OF THIS DRAWING. IT CANNOT BE
REPRODUCED OR OTHERWISE MAKE KNOW TO
OTHER COMPANIES OR COMPETITORS
WITHOUT OUR PERMISSION
DRAWING
CODE
WEIGHT
VOLUME
REV
REV. DATA DESCRIPTION AUTHOR
01 - - -
02 - - -
03 - - -
04 - - -
A1 Format - 841 x 594
POWERSOFT S.p.A.
Via E.Conti, 5 - 50018 Scandicci (FI) - Italy
Tel. [phone] - fax [phone]
http://www.powersoft.it
( )
3.2 0.8
Note: -
-
19/10/2018
1:2 lombardi 1 / 1
M-Force Engine Kit 00 22472,6 g
4806,0 cm^3
.
M-Force
.
.
.
M-Force Engine Kit
100 100
236
265
298
2525
100
277
286
55
111 ±0,5
127 ±0,5
SE ST5
MATERIAL
TREATMENT
DESCRIPTION
ITEM
DATE SCALE AUTHOR APPROV. SHEETS
UNI-ISO
2768-M
GENERAL
TOLERANCES
ACCORDING WITH THE LAW, WE RESERVE THE
PROPERTY OF THIS DRAWING. IT CANNOT BE
REPRODUCED OR OTHERWISE MAKE KNOW TO
OTHER COMPANIES OR COMPETITORS
WITHOUT OUR PERMISSION
DRAWING
CODE
WEIGHT
VOLUME
REV
REV. DATA DESCRIPTION AUTHOR
01 - - - 02 - - - 03 - - - 04 - - -
A1 Format - 841 x 594
POWERSOFT S.p.A.
Via E.Conti, 5 - 50018 Scandicci (FI) - Italy
Tel. [phone] - fax [phone]
http://www.powersoft.it
( )
3.2 0.8
Note: -
-
19/10/2018
1:2 lombardi 1 / 1
M-Force Engine Kit 00 22472,6 g
4806,0 cm^3
.
M-Force
.
.
.
M-Force Engine Kit
100 100
236
265
298
2525
100
277
286
55
111 ±0,5
127 ±0,5

Mechanical Drawings | 3
SE ST5
MATERIAL
TREATMENT
DESCRIPTION
ITEM
DATE SCALE AUTHOR APPROV. SHEETS
UNI-ISO
2768-M
GENERAL
TOLERANCES
ACCORDING WITH THE LAW, WE RESERVE THE
PROPERTY OF THIS DRAWING. IT CANNOT BE
REPRODUCED OR OTHERWISE MAKE KNOW TO
OTHER COMPANIES OR COMPETITORS
WITHOUT OUR PERMISSION
DRAWING
CODE
WEIGHT
VOLUME
REV
REV. DATA DESCRIPTION AUTHOR
01 - - -
02 - - -
03 - - -
04 - - -
A1 Format - 841 x 594
POWERSOFT S.p.A.
Via E.Conti, 5 - 50018 Scandicci (FI) - Italy
Tel. [phone] - fax [phone]
http://www.powersoft.it
( )
3.2 0.8
Note: -
-
19/10/2018
1:2 lombardi 1 / 1
M-Force Engine Kit 00
22472,6 g
4806,0 cm^3
.
M-Force
.
.
.
M-Force Engine Kit
100 100
236
265
298
2525
100
277
286
55
111 ±0,5
127 ±0,5
FIGURE 1: Main assembly: M-Force 01/02 Engine Kit

Installation instructions 4
Once the cabinet for the M-Force based loudspeaker
has been realized, its time to assemble the motor and the
diaphragm.
Accurate system alignment and proper fastening solu-
tions of the motor and the diaphragm have to be carefully
performed in order to guarantee optimal assembly.
The installation inside the cabinet can be performed in
six steps:
1. fasten the brackets to the cabinet;
2. fasten the motor to the brackets;
3. plug the motor to the amplier;
4. position the diaphragm on the cabinet and verify the
alignment between its vertex to the motor hub;
5. fasten the diaphragm’s vertex to the motor;
6. fasten the diaphragm surround to the cabinet.
4:1.Fasten the brackets to the cabinet
Tight tolerances of brackets positioning guarantee
proper alignment of the motor to the diaphragm.
Powersoft provides optional brackets for placement of
the motor with respect to the mounting surface.
4:2.Fasten the motor to the brackets
Fix the M-Force to the brackets by tightly screwing the
12 M8x14 hex socket head cap screws (6 per side).
Set the M-Force position inside the cabinet so that its
hub is properly aligned to the diaphragm’s vertex expected
position. Take care to:
 correct tilt errors;
 set the proper position of the hub with respect the
diaphragm’s vertex expected position (consider the
compression of the rim’s gasket).
FIGURE 3: Mounting point for fixing
the motor to the brackets.
FIGURE 2: Brackets placement of the motor
with respect to the mounting surface.
4 | M-Force Engine Kit | User guide
CLASS3
WIRING
WARNING! Never use the bolts on
top of the heat sink to secure the
M-Force to the mounting brackets!
Mounting points
Mounting points
Mounting points
A
Mounting surface
Motor
MATERIAL
TREATMENT
DESCRIPTION
ITEM
DATE SCALE AUTHOR APPROV. GENER.
TOLL.
UNI-ISO
2768-M
MEASURES
TO CHECK
ACCORDING WITH THE LAW, WE RESERVE THE PROPERTY OF THIS DRAWING. IT CANNOT BE REPRODUCED OR OTHERWISE MAKE KNOW TO OTHER COMPANIES OR COMPETITORS WITHOUT OUR PERMISSION
PROJECT
CODE
DRAWING
CODE
E-mail:[e-mail] - http://ww w.powersoft.it
Tel.[phone] -f ax+39 055 7356235
ViaE.Conti, 5 - 50018 Scandicci (FI) - Italy
POWERSOFT S.r.l.
Landini
WEIGHT
gr.
VOLUME
cm
3
ALLUMINIO SP. 50/10 SUPPORTO ANGOLATO CORTO MOTORE
M-FORCE-01
19.11.14 1 : 1
ME000733.00 13
M-FORCE-01
213
205
288
n°6 inserti M8
REV
25,5
09.01.14 DA REV.11 A REV.12 - CAMBIATO MATERIALE DA FERRO 30/10 AD ALLUMINIO 50/10, ALLUNGATO SCAVO CENTRALE
5
19.11.14 DA REV.12 A REV.13 - aggiornato sistema codifica Landini
Mounting surface
Motor
B
SE ST5
MATERIAL
TREATMENT
DESCRIPTION
ITEM
DATE SCALE AUTHOR APPROV. SHEETS
UNI-ISO
2768-M
GENERAL
TOLERANCES
ACCORDING WITH THE LAW, WE RE SERVE THE
PROPERTY OF THIS DRAWING. IT CANNOT BE
REPRODUCED OR OTHERWISE MAKE KNOW TO
OTHERCO MPANIES OR COMPETITORS
WITHOUTOUR PERMISSION
DRAWING
CODE
WEIGHT
VOLUME
REV
REV. DATA DESCRIPTION AUTHOR
01 - - -
02 - - -
03 - - -
04 - - -
A0 Format - 1189 x 841
POWERSOFT S.p.A.
ViaE.Conti, 5 - 50018 Scandicci (FI) - Italy
Tel.[phone] - fax [phone]
http://www.powersoft.it
( )
3.2 0.8
Note: -
-
19/11/2014
1:1 landini 1 / 1
ME000919.00 02
1128,2 g
416,0 cm^3
Aluminum, 1060
Aluminum, 1060
.
M-Force
.
.
.
Supporto angolato 45°
20
284
n°6 inserti M8
45°
5
SE ST5
MATERIAL
TREATMENT
DESCRIPTION
ITEM
DATE SCALE AUTHOR APPROV. SHEETS
UNI-ISO
2768-M
GENERAL
TOLERANCES
ACCORDING WITH THE LAW , WE RESERVE THE
PROPERTY OF THIS DRAWING. IT C ANNOT BE
REPRODUCED OR OTHERWISE MAK E KNOW TO
OTHER COMPANIES OR COMPETITORS
WITHOUT OUR PERMISSION
DRAWING
CODE
WEIGHT
VOLUME
REV
REV. DATA DESCRIPTION AUTHOR
01 - - -
02 - - -
03 - - -
04 - - -
A0 Format - 1189 x 841
POWERSOFT S.p.A.
Via E.Conti, 5 - 50018Scandicci (FI) - Italy
Tel. [phone] - fax[phone]
http://www.powersoft.it
( )
3.2 0.8
Note: -
-
09/09/2015
1:1 Landini 1 / 1
ME001089.01 00
1373,6 g
506,5 cm^3
Aluminum, 1060 spessore 5 mm
Aluminum, 1060 5 mm thickness
.
M-Force
.
.
.
Staffa semicestello
xxx
M - FORCE
R5
R5
137°
137°
147,8
271
R366
R388
90°
90°
176
O
13 ±0,25
5
Mounting surface
Motor
C

Installation instructions | 5
4:3.Plug the motor to the amplifier
Take care to match the polarity while plugging the ampli-
er to the M-Force. Ensure that engine polarity matches the
DPC sensor position within the cabinet (refer to the M-Drive
User Guide for more in-depth information).
Polarity mismatch may lead to phase cancellation in
multiway systems, yielding to a wrong frequency response
and poor performances. If reversing the signal polarity is
needed when alighning the cabinets to the system, do it via
DSP, before the amp stage.
The four poles connector on the connector plate ac-
cepts a 10 mm, 1 ROW, 4P housing.
Crimp the terminal on the wire securely and install the
terminals in the housing.
4:4.Verify the alignment of the diaphragm
Place the diaphragm into the cabinet and take care that
it ts the bafe cutout and perfectly lies on its the surface.
No room must be left between the diaphragm an the surface
in order to properly center and x it.
Placing a neoprene foam in between the diaphragm and
the cabinet ensures good sealing and prevent air leakage.
Do not fasten the diaphragm to the
cabinet before having fitted and perfectly
aligned its vertex to the motor’s hub.
Misalignments could bring forth system instability, dis-
tortions and possibly damages.
The exact matching between the diaphragm and the
M-Force’s hub shall guarantee no tensions and displace-
ments at the rest position of the system.
Crimped
terminal
4P Terminal
Housing
Crimped wires
FIGURE 4: Diaphragm mounting sequence;
A: sealing foam; B: diaphragm; C: fastening rim.
FIGURE 5: Diaphragm and M-Force
perfect matching at rest position.
176
37
± 0,5
± 1
C
B
A

6 | M-Force Engine Kit | User guide
4:4.1.Troubleshooting the mechanical alignment
Problem Solution
Strained motor’s suspension
at rest position.
Modify the motor position.
Note: the tightening torque
of the nuts must be 15 N/m.
CLASS3
WIRING
37±1 mm
37±1 mm
wrong
rest
position
39,2±0,5 mm
1,54±0,02 in
move the
engine
Place washers/nuts
on the hub
Place washers/nuts
on the hub
weak mechanical
connection
Bad axial
alignment
37±1 mm
37±1 mm
wrong
rest
position
39,2±0,5 mm
1,54±0,02 in
move the
engine
Place washers/nuts
on the hub
Place washers/nuts
on the hub
weak mechanical
connection
Bad axial
alignment
We recommend to use a torque wrench in order
to apply the proper 15 N/m tightening torque.
We suggest to block the hub by means of an adjustable
wrench to avoid to twist the hub during assembly.
CLASS3
WIRING
CLASS3
WIRING

Installation instructions | 7
4:5.Diaphragm bay design tollerance
30” W 4 mm
PE-HWU diaphragm
PF30FP00
175 1
8,5 ±0,5
717 ±1
717 ±1
18
+6
0
24
+12
0
11,25°
O
732 ±0,5
8,5 ±0,5
O 762 ±0,5

8 | M-Force Engine Kit | User guide
30” V 4 mm
PE-HWU diaphragm
PF30SP00
405 2
24
+12
0
18
+6
0
717 ±1
717 ±1
8,5 ±0,5
11,25°
O
7
3
2
±
0
,
5
8,5±0,5
O762 ±0,5

Installation instructions | 9
40” W 4 mm
PE-HWU diaphragm
PF40FP00
917 ±1
917 ±1
175 u 1
24 +12
0
18 +6
0
8,5 ±0,5
10°
O 932 ±0,5
O
8,5±0,5
O 962 ±0,5

Important notes 5
5:1.Preset HPF
In order to avoid damages to the mobile equipment, we
recommend to set a 15 Hz (at least) High Pass Filter on the
input signal path.
Since the M-Force is characterized by a very low load
impedance, any unwanted DC or low-end content would
pass through the motor to the diaphragm: without an input
HPF this would cause damages to the moving parts.
5:2.No mechanical load
It is highly recommended to limit motor excitation when
the same is not properly connected to a mechanical load.
5:3.Nuts tightening torque
We recommend to use a torque wrench in order to apply
the proper 15 N/m tightening torque.
We suggest to block the hub by means of an adjustable
wrench to avoid to twist the hub during assembly.
5:4.Engine diaphragm spacer nut
The ME001363.01 spacer, found in the spare part kit,
is a special spacer nut that mates the diaphragmn damper
onto the engine. It must be placed rounded side rst into
the diaphragm and torqued to 15 N/m my holding the shaft
as inllusrtated in paragraph 4.4.1.
5:5.Rim and baffle cutout diameters
In order to avoid mechanical interference and provide
the right tightening force to the diaphragm, respect the
tolerance for the internal diameter of the rim and the bafe.
Rounding off the edge of the cut drastically reduces the
stress of the components.
5:6.Thermal considerations
The M-Force is characterized by high thermal inerthia.
This results in a slower variation of the body temperature
during normal operation: the motor appears to stay at low
temperature for long time (expecially during benchmark
tests), but after hours of operation, the system may reach
very high temperatures, making the heat transfer to the sur-
rounding environment an issue.
As any other traditional transducer, it is highly recom-
mended to favor the ventilation of the motor of the M-Force,
taking advantage of the air ow by the diaphragm and/or
exploiting the ventilation offered by the ducts of the cabinet.
When achievable, take into account congurations
where the motor is positioned outside the cabinet.
Note: The optional mounting brackets provided by
Powersoft are made of high thermal conductive Aluminium:
giving the fastening spots, this helps the heat transfer from
the M-Force motor.
Powersoft recommends to mount the M-Force
in a well ventilated position by means of
high thermal conductive brackets.
5:7.Mechanical strength of the cabinet
The M-Force is capable to produce very high static and
dynamic mechanical stresses to the cabinet. Two main ef-
fect must be taken into account:
 the internal sound pressure produced by the
movement of the diaphragm can rise up to 100 g/cm2
(9,8 kPa - 204,8 psf): this pressure dynamically
stresses the cabinet boundaries;
 the anchor points of the brackets to the cabinet are
highly stressed by the applied reactive force: take
into account to strengthen the overall structure and
properly tighten the fastening spots.
5:8.Mechanical balancing
The design of the cabinet shall take into account the
dynamic balancing of the center of mass of the M-Force
and diaphragm assembly.
Stating the high moving mass it is very important to
place the (moving) center of mass of the M-Force as close
as possible to the (static) center of mass of the cabinet.
This will reduce vibration and torque that make the cabinet
instable.
5:9.Acoustic load balancing
The diaphragm is subjected to high acoustic load. In
order to limit cone rocking it is highly recommended to
design the system so that the diaphragm is symmetrically
acoustic loaded.
10 | M-Force Engine Kit | User guide
CLASS3
WIRING

Appendix A 6
11 | M-Force Engine Kit | User guide
6:1.Building your own cables
When the application requires it, you may build your own
cables out of 12 AWG wire, 4 crimp-on terminals, and a 4
pole housing.
Reported below are the part numbers:
 MOLEX 42816-0412 HOUSING 10mm 4P 1ROW 50A
 MOLEX 42815-0114 CRIMP ON TERMINAL FEMALE
CLASS3
WIRING
WARNING! Once installed,
always lock the terminals
with the supplied tab!

12 | M-Force Engine Kit | User guide
Mechanical / Electrical / Thermal parameters
Type Push-Pull
Moving Magnet Linear Motor
Nominal Size (H x W x L) 280 mm x 266 mm x 126 mm
11 in x 10.5 in x 5 in
Linear Displacement ±15 mm / ±0.6 in
Max Displacement ±25 mm / ±1 in
Peak displacement ±37 mm / ±1.45 in
Peak Force Output 4000 N
Weight 21.5 kg
Peak Current Handling 170 A
Peak Voltage Handling 400 V
Power Handling 5 kW / AES
Peak Power Handling 25 kW
Thermal Resistance (pink noise) 0.06 °C/W
Thermal Capacity 11100 J / °C
Electromechanical Parameters
Motor only – no diaphragm
Re 0.260 �
Motor moving mass 1.12 kg
Bl 23. 0 T·m
Le @ 1 kHz 4.3 mH
L1 (LR-2 model) 4.3 mH
L2 (LR-2 model) 1.9 mH
R2 (LR-2 model) 1.10 �
Mechanical resonance 25.6 Hz
Mechanical spring 0.000035 m/N
Mechanical loss 23 N·s/m
Motor strength (Bl)2/Re 2215 ( T·m)2/�
Maximum acceleration 3800 m/s2
Mechanical / Electrical / Thermal parameters
Type Push-Pull
Moving Magnet Linear Motor
Nominal Size (H x W x L) 280 mm x 266 mm x 126 mm
11 in x 10.5 in x 5 in
Linear Displacement ±10 mm / ±0.4 in
Max Displacement ±21 mm / ±0.83 in
Peak displacement ±37 mm / ±1.45 in
Peak Force Output 4000 N
Weight 21.5 kg
Peak Current Handling 170 A
Peak Voltage Handling 400 V
Power Handling 5 kW / AES
Peak Power Handling 25 kW
Thermal Resistance (pink noise) 0.06 °C/W
Thermal Capacity 11100 J / °C
Electromechanical Parameters
Motor only – no diaphragm
Re 0.19 �
Motor moving mass 1.12 kg
Bl 23. 0 T·m
Le @ 1 kHz 3.12 mH
L1 (LR-2 model) 3.10 mH
L2 (LR-2 model) 1.4 mH
R2 (LR-2 model) 1.05 �
Mechanical resonance 25.6 Hz
Mechanical spring 0.000035 m/N
Mechanical loss 23 N·s/m
Motor strength (Bl)2/Re 3000 (T·m)2/�
Maximum acceleration 4800 m/s2
M-Force 02 - PF000327M-Force 01 - PF000399
Specifications 7
M-Force engine kit
