powersoft DEVA User manual

Keep This Manual
For Future Reference
© 2014 Powersoft
DO000147 Rev. 1
DEVA
The revolutionary multimedia unit:
energetically self-sufcient, zero installation costs, solar power ready
USER GUIDE
July 2014

2 |DEVA |User Guide powersoft_DEVA_uguide_v2.7
Table of Contents
1 Unpacking & checking 4
2 Disposal of the packing material 4
3 Package content 4
4 Welcome 5
5 DEVA in a glance 5
6 Dashboard 6
7 Actions and Players 10
7.1 Actions 10
7.2 Players 10
8 Commanders and Triggers 11
8.1 Commanders 11
8.1.1 Live execution 11
8.1.2 Time schedule 11
8.1.3 Events 11
8.1.4 USB key 11
8.2 Triggers 11
9 Warning beeps 12
10 Dashboard LEDs 12
11 Front RGB LED 12
Getting Started 13
12 Battery assembly 13
13 SIM card assembly 14
14 Start-up 14
14.1 DEVA start-up without
external power supply 14
15 Shut down 15
16 USB MP3 playback 15
17 Networking 16
17.1 DEVA in a wireless LAN 16
17.1.1 Mesh network 16
17.2 DEVA in a wired LAN 17
18 Initialization 17
18.1 Initialization in a wireless LAN 17
18.2 Initialization in a wired LAN 18
Setting DEVA 19
19 Setting users permissions 19
20 DEVA general settings 20
21 Setting Zones 21
22 Audio library and playlists 22
22.1 Setting a playlist 22
23 Predened messages 23
24 Setting time schedule 24
25 Setting Events 25

DEVA |3
DEVA
User GUide
26 Live execution 25
27 Advanced network settings 26
27.1 Setting PDD network parameters 26
27.1.1 Setting PDD’s static IP 26
27.2 Setting DEVA network parameters 27
27.3 Conguring a WiFi mesh network 28
27.3.1 Setting DEVA as Gateway 28
27.3.2 Setting DEVA as Node 28
27.4 Revert to DEVA default network settings 29
27.4.1 Wi-Fi intrastructure mode 29
27.4.2 Wi-Fi access point mode 29
Reset and reboot 31
28 DEVA reboot 31
29 DEVA reset 31
29.1 Soft-reset 31
29.2 Hard-reset 32
Software update 33
30 DEVA software update procedure 33
31 Update the DEVA System Manager 34
Accessories 35
32 Mounting kits 35
32.1 Needed tools 35
32.2 Pole and wall mounting kits 35
32.3 Tripod mounting clamp 36
33 Solar panel 36
33.1 Plugging the solar panel 36
34 DEVA passive 38
PDD and DSM 39
A Powersoft DEVA Director – PDD39
A.1 Minimum system requirements for PDD 39
B DEVA System Manager – DSM 39
Regulations and warnings 40
C Warnings about using batteries 40
D Warnings about Wi-Fi 40
Specications 42

4 |DEVA |User Guide
1 Unpacking & checking
Your Powersoft product was completely tested
and inspected before leaving the factory. Carefully
inspect the shipping package before opening it,
and then immediately inspect your new product. If
you nd any damage notify the shipping company
immediately.
2 Disposal of the packing material
The transport and protective packing has been
selected from materials which are environmentally
friendly for disposal and can normally be recycled.
Rather than just throwing these materials away,
please ensure they are offered for recycling.
3 Package content
The main package contains:
fDEVA
fConnectors kit
fPower supply plug:
Phoenix MCVW-1.5/ 2-STF-3.81
fLoudspeaker plug:
Phoenix 1803578 MC 1,5/ 2-ST-3,81
fRS-485 plug:
Phoenix 1817042 1840405 MC 1,5/ 6-ST-3,5
fManual
Optional:
fPole and wall mounting kits
fMounting clamp for stand
fSolar panel
fDEVA Passive
fANSMANN APS2250H DC power supply and adapters

DEVA |5
DEVA
User GUide
4 Welcome
Congratulations on your purchase of the
Powersoft DEVA.
DEVA is a lightweight and compact multifunctional
device that implements bi-directional wireless
communication, audio messaging and video
capturing.
Once congured, DEVA is a self-sufcient device
equipped with sensors – microphone, presence
detector, temperature and pressure probes – and
accessories (e.g. LED light, camera, etc.) that make
it capable to interact with the environment through
the built in loudspeaker and audio/video capturing
feature.
DEVA has been designed to be independent from
any existing infrastructure, without the need for
wiring and with virtually zero installation costs. DEVA
uses green technologies: its highly efcient design
limits power consumption allowing uninterrupted
use powered by the internal rechargeable battery;
a latest generation solar panel can quickly recharge
the battery even in low light conditions.
DEVA's enclosure is weather-resistant IP65,
an ideal solution for outdoor applications from
background music to paging, in combination with
video and/or audio surveillance.
DEVA provides bi-directional messaging and
ambient control; DEVA allows conguration and
monitoring via WiFi as well as wired Ethernet
connections to tablets, pc and mobile phones.
Remote control is available via GSM/GPRS/UMTS.
DEVA is a self-sufcient fully congurable
networking unit that can be installed anywhere!
5 DEVA in a glance
DEVA is capable to perform tasks and react
to certain events on the basis of a scheduled
program and an event list. The interaction with the
environment triggers a set of actions spanning from
sound playback to taking pictures. In systems with
more than one DEVA, scheduled actions – such as
playing audio les – are synchronized by means of
the DEVA System Manager, the control pannel that
provides full management of DEVA, installed into
the Powersoft DEVA Director – PDD.
The DEVA System Manager allows you to stream
live announcements and audio les to all selected
DEVA as well as set:
ftime schedule for actions:
fLight – switch the light on or off.
fPlay message – play a le in the default
audio les list.
fPlay from Audio library – play a le from
the audio library.
fPlay playlist – execute a playlist of audio
les.
fTake Photo – shoot a single ambient photo
or choose to shoot a number of pictures
delayed by the selected time.
Refer to Chapter “7 Actions and Players” for
detailed info.
faction triggers (events):
fPresence sensor
fBattery charge
fNetwork connectivity
fMechanical shocks
Refer to Chapter “8 Commanders and Triggers”
for detailed info.

6 |DEVA |User Guide
6 Dashboard
The DEVA dashboard is located under the rear
panel of the DEVA; it allows the user to access the
main connections (i.e. solar panel, ethernet, etc), the
power switch and other features (refer to the next
chapters for further details).
Refer to FIGURE 1 to locate the following
features on the dashboard.
1. Factory Default Setting push-button
Chapter “29 DEVA reset”
2. ON/OFF push-button
Chapter “14 Start-up”
3. Volume +/– push-button
Chapter “16 USB MP3 playback”
4. Seek track push-button
Chapter “16 USB MP3 playback”
5. Loudspeaker plug
Chapter “34 DEVA passive”
6. RS-485 and switch plug
7. USB connector
Chapter “16 USB MP3 playback”
8. 5.5 mm coaxial power supply plug (16 VDC, 1 Amax)
9. Rear status LEDs – Red, Yellow, Green
Chapter “10 Dashboard LEDs”
10. Network activity LED
11. Ethernet port
12. SIM bay
Chapter “13 SIM card assembly”
13. Wi-Fi default setting selector
Chapter “29 DEVA reset”
14. Cable fastener
15. Phoenix MC 1,5/ 2-ST-3,81 solar panel connector
Chapter “33 Solar panel”
16. Testing connectors for servicing
When triggering events take place, DEVA can
execute one or more of the following actions:
fLight
fPlay message
fRecord with the built in microphone
fTake Photo
fNotify – send an sms to a registered user.
Refer to Chapter “8 Commanders and Triggers”
for detailed info.

DEVA |7
FIGURE 1: DEVA dashboard.
1 2 3 4 5 6
7
8
9
10
11
13
14
12
1516

8 |DEVA |User Guide
A. Built-in loudspeaker
B. LED Light
C. Front status RGB LED
D. Built-in microphone
E. Built-in camera
F. Presence IR sensor
G. Bracket
220 mm300 mm
163 mm
435 mm
440 mm
FIGURE 2: Mechanical drawing
A
B
C
D
E
F
G

Page intentionally left blank
9

10 |DEVA |User Guide
7 Actions and Players
7.1 Actions
Depending on the version, DEVA performs a set
of dened actions:
fPlay audio
fSwitch the light
fTake photo
fRecord audio
fNotify with a message (sms/email)
7.2 Players
DEVA provides four audio players that manage
respectively:
1. live stream of audio
2. playback of single audio le
3. playback FM radio
4. playlist of audio les
The four players can be active at the same time,
but only two of them will play simultaneously,
according to their priority:
live stream > single le > FM radio > playlist
hiGh priorit y > low priority
The four audio players are layered on the basis of
the playback priority:
fthe playback of a live streaming (either an audio
le or from the microphone) has the priority on
the playback of an audio le from the library;
fthe playback of a single audio le has the priority
on the playback of the FM radio;
fthe playback of an FM radio has the priority on
the playback of a playlist.
The player with the lower priority plays in
background (i.e. lower in volume) when a high
priority player starts playing.
NOTE: The default behaviour can be overridden
by changing the volume level during the playback.
Each player provides independent volume control.
The playback volume of each player is a fracion
(expressed in percentage) of the master volume.
Volume 100%
Volume 30%
Time
Play a file
Playlist
Play a filePlaylist
FIGURE 3: The playback of a single audio le has the
priority on a playlist: the volume of the playlist is low-
ered to the 30% and the playback does not stop.
Time
Streaming
Play a file
Volume 100%
Volume 100%
Volume 30%
Volume 100%
Volume 30%
MUTE
Playlist
StreamingPlay a filePlaylist
FIGURE 4: DEVA can reproduce up to two uxes of
audio simultaneously: in this example the playback of
the playlist is muted whilst playing the audiole and
the live streaming.

DEVA |11
8 Commanders and Triggers
8.1 Commanders
DEVA receives commands to perform actions.
Commanders access a subset of actions.
8.1.1 Live execution
The DEVA System Manager provides direct access
to all actions on DEVA; through the DSM you can:
fPlay audio
• stream an announcement/audio le
• play a predened message
• execute a playlist
• play an FM radio
fSwitch the light
fMute audio playback
fTake a photo
Refer to Chapter “26 Live execution”.
8.1.2 Time schedule
The DSM provides a tool to set the executions
of actions on a time schedule. Available actions are:
fPlay audio
• play a predened message
• execute a playlist
• playpack a single audio le
• playback an FM radio
fSwitch the light
fRecord audio
fTake photo
Refer to Chapter “24 Setting time schedule”.
8.1.3 Events
Ambient events can be exploited to activate
some actions:
fPlay audio
• play a default message
fSwitch the light
fRecord audio
fTake photo/video
fNotify with an sms
Refer to Chapter “25 Setting Events”.
8.1.4 USB key
DEVA can start playing audio les from any USB
storage device, such as a USB key, plugged into the
USB port on the DEVA dashboard.
Refer to Chapter “16 USB MP3 playback”.
8.2 Triggers
Triggers are conditions that activate functions of
the DEVA. The tool Events uses triggers.
Events/conditions that trigger DEVA actions can
be chosen among:
fthe signal from the presence sensor
finternal battery voltage (threshold: 11.8V)
fWi-Fi and LAN network connectivity
fmechanical shocks
fexternal switch
When a triggering condition takes place, DEVA
perform the programmed action.
Triggers are ltered by time: you can set the time
interval during which the triggering conditions are
taken into account.

12 |DEVA |User Guide
9 Warning beeps
Many system functionalities are warned
by acoustic signals (beep)s. In the following
table a dot � represents a short beep,
a dash – represents a long beep.
system status beeps combination
BUTTON PRESSED �
SYSTEM BOOTING —
REBOOT ���
STARTING
SOFT RESET ��
STARTING
HARD RESET �–
10 Dashboard LEDs
The status LEDs in the dashboard (ref. FIGURE
5) provide the following information:
battery status
RED
CHARGING SOLID ON
FULL CHARGE SLOW BLINKING
IDLE DISCONTINUOUS BLINKING
NO BATTERY OFF
system status
YELLOW GREEN
NO POWER SUPPLY OFF OFF
BOOTING OFF BLINKING
SYSTEM ON OFF SOLID ON
SYSTEM OFF CAUSED
BY USER SHUTDOWN
SLOW
BLINKING OFF
SYSTEM OFF CAUSED
BY LOW BATTERY
CHARGE
BLINKING OFF
SHUTTING DOWN SOLID ON IRREGULAR
BLINKING
11 Front RGB LED
The front LED is positioned in the center of the
light LED (ref. FIGURE 2). The activity of the front
LED is triggered by the presence sensor: the LED
lights just when the sensor reveals the presence of
people in front of the DEVA.
The color code refers to the battery state; the
lightening state refers to the LAN (both wired and
wireless) connectivity status.
connectivity status
RED BLUE GREEN
LAN CONNECTIVITY
PRESENT
SOLID
ON
SOLID
ON
SOLID
ON
NO LAN
CONNECTIVITY BLINKING BLINKING BLINKING
battery status Color
BATTERY CHARGE
AT WARNING LEVEL
(11. 8 V )
RED
NO CHARGING BLUE
CHARGING GREEN
During system update the LED color turns purple
and blinks until the end of the process.
SYSTEM UPDATING PURPLE
(blinking)
FIGURE 5: Status LEDs.
System
status
Battery
status

Getting Started |13
Getting Started
Before proceeding to the placement of the
DEVA on site (ref. Chapter “32 Mounting kits”),
we recommend to setup the device by following
the assembling and initialization procedure “on the
desk”.
The initialization phase can involve the manual
setup of the device; once properly initialized and
congured, DEVA has been designed to be self-
operating and remotely managed.
The initialization workow includes:
1. battery assembly on the DEVA;
2. SIM assembly;
3. DEVA start-up;
4. initialization of the connections (networking);
We suggest to follows the instruction on this
manual in order to properly setup the DEVA.
12 Battery assembly
DEVA comes with a battery pack already located
into its battery compartment (ref. FIGURE 6). The
battery pack shall be properly connected before
operating.
1. Open the battery compartment.
2. Verify that the battery presents no failures.
3. Plug the battery:
fconnect the red + (positive) faston to the
battery’s positive plug (beware the 4 A fuse);
fconnect the black – (negative) faston to the
battery’s negative plug.
4. Place the battery temperature probe wherever
into the battery compartment, far from the
electric plugs.
5. Reposition the compartment cover and tightly
screw the six hex screws.
In order to ensure full operability,
Powersoft recommends to fully charge the battery
before starting the initialization procedure.
The battery charge can be achieved by means of
either:
fan external power supply capable to deliver 20
VDC and up to 3 Amax (e.g. solar panel, DC power
supply unit, etc.) connected to the Phoenix MC
1,5/ 2-ST-3,81 (ref. FIGURE 1 #15);
fa 16 VDC, 1 Amax power supply plugged to the
5.5 mm coaxial plug (ref. FIGURE 1 #8);
fa 48 VDC PoE via the Ethernet connection (ref.
FIGURE 1 #11).
FIGURE 6: DEVA back view.
Dashboard
compartment
Battery
compartment

14 |DEVA |User Guide
14 Start-up
Once the battery has been properly assembled
(ref. Chapter “12 Battery assembly”), the DEVA can
be switched on. By default, DEVA starts-up when
any external power supply (i.e. solar panel, DC
power supply unit, PoE) is plugged in.
When the DEVA is connected to an external
power supply, the system starts charging the internal
battery: when the power supply delivers more than
12 VDC the DEVA starts-up automatically.
In approximatively 90 seconds the operating
system completes the bootstrap procedure and
makes the device ready to work. During the
bootstrap you can hear a long beep coming from
the DEVA: the presence of this signal means that the
system is booting.
14.1 DEVA start-up without external power supply
In case no power supply is available and DEVA
is off, you can switch on the DEVA by means of the
ON/OFF button (ref. FIGURE 9).
1. Push on the ON/OFF button and keep it
pressed:
2. the green LED switch solid on;
3. still keep the ON/OFF button pressed until the
green LED start blinking (5 s approximatively);
4. release the ON/OFF push button: the
bootstrap procedure takes place and a long
beep is emitted.
Be aware that the start-up procedure without
power supply will not take place if the battery
charge is below 12 VDC.
13 SIM card assembly
DEVA supports GSM and GPRS communication
protocols via a standard SIM – Subscriber Identity
Module – card*. Follows these instructions in order
to install the SIM card.
1. Unlock the SIM by disabling the PIN request
at the switch on: this can be mabe easily by
inserting the SIM into a mobile phone and
disabling the PIN request.
2. Access the dashboard compartment and gently
slide and tilt the SIM card tray (ref. FIGURE 7).
3. Insert the SIM card into the slot a reposition
the tray.
* Not included in the package. Ask to your local IT providers.
The GPRS communication features shall be
activated and managed through the DEVA System
Manager (ref. Chapter “27.2 Setting DEVA network
parameters”)
FIGURE 7: SIM card tray on dashboard.
SIM card
tray
FIGURE 8: System settings: network parameters.

Getting Started |15
15 Shut down
Usually you don’t need to shut down the DEVA
for maintenance: the management can be performed
by means of the DEVA System Manager.
1. Access the DEVA on site and remove the
dashboard cover on the back of the DEVA (ref.
FIGURE 6).
2. In order to completely shut down the DEVA
we suggest to unplug any external power
supply (e.g. solar panel).
3. On the DEVA dashboard, identify the On/Off
push-button (ref. FIGURE 9): keep pressed the
button until the three rear LEDs start blinking.
4. Release the On/Off push-button and wait until
all the LEDs switch off (approximatively one
minute). The system will emit 2 short beep
followed by a long beep to warn you about the
shut down in progress
16 USB MP3 playback
The playback from the USB override any audio
playing on the DEVA: in order to start the playback
of the les from a USB device you have to press
simultaneously the SEEK+ and SEEK– push button
on the DEVA dashboard.
The actual scheduled action does not stop: while
the USB audio content is playing, any scheduled
playlist runs to the 30% of its preset volume.
In order to allow DEVA to reproduce the MP3
les from the USB, the audio les shall be stored
in the AudioFiles folder in the root of the USB
storage device.
DEVA can play only MP3 les, no other le
formats are allowed. Playback of the audio les is
looped in alphabetical order. The commands to
manage the playback from USB are located on the
DEVA dashboard (ref. FIGURE 10):
PL AY/STOP
fpress simultaneously the SEEK+ and SEEK–
push button to toggle PLAY and STOP
VOLUME
fpush once on VOL+ or VOL– button for a
1% volume change accordingly
fpush and keep pressed on VOL+ or VOL–
button for a 5% volume change per second
accordingly
TRACK SEEK
fpress on the SEEK+ and SEEK– push button
to skip track
Take care to properly stop the audio le playing
from the USB before unplug the USB device!
By unplugging the USB device without having
properly stopped the playback you may cause the
USB stop working until next system reboot.
FIGURE 9: ON/OFF button and
status LEDs on dashboard.
ON/OFF
button
Status
LEDs
FIGURE 10: Press simultaneously the
SEEK+ and SEEK– push button
to toggle PLAY and STOP from USB

16 |DEVA |User Guide
17 Networking
DEVA can be set as a stand alone device or
integrated into any existing wired, wireless or mixed
network. A proper network setup includes:
fPowersoft DEVA Director – PDD. The PDD
is a personal computer implementing a custom
GNU/Linux based operating system: the PDD
provides a client-server environment that
allows the user to easily manage the network
of DEVA.
Both the DEVA and the PDD must be
connected to the same network; this means
that all devices have to be either hosted by the
same Wi-Fi access point or wired to the same
thernet switch and sharing the same subnet and
IP range.
fDHCP server (often already implemented into
routers and acces point). Both the DEVA and
the PDD are set to dynamic IP addressing.
fEthernet switching (often already implemented
into routers and acces point) with a proper
number of ports for wired connectivity;
fWi-Fi access point for wireless connectivity;
fOne or more DEVA.
In the following pictures we suggest some network
topologies oriented to a domestic environment,
where the router/AP implements both the DHCP
server and the Ethernet switch.
17.1 DEVA in a wireless LAN
DEVA and the PDD are connected wireless to
the access point. Any further client on the wireless
network can manage the network of DEVA: in order
for the client to manage a DEVA it must to connect
to the PDD.
17.1.1 Mesh network
DEVA can connect to a mesh network, so that to
cooperate in the distribution of data in the network.
In a mesh network topology, each DEVA is a node
that relays data on the network, providing multiple
connections to other DEVA in the mesh.
ACCESS POINT
PDD
PDD
ROUTER WITH
DHCP + switch

Getting Started |17
18 Initialization
The initialization is performed by means of the
PDD – Powersoft DEVA Director –, by connecting
the DEVA to the local network through a wired or
wireless connection.
You may need the following equipment:
fPowersoft DEVA Director – PDD;
fDHCP ser ver or a router with DHCP capability;
fswitch with a proper number of ports for wired
connections;
faccess point – AP – for wireless operating.
18.1 Initialization in a wireless LAN
By default DEVA tries to connect to a Wi-Fi
network whose SSID is set to POWERSOFT.
In order to perform the initialization procedure
we recommend to set your AP as follow.
1. Connect the PDD and the AP to the same
LAN (wired or wireless): ensure that they
share the same IP range.
2. Log-in the PDD and launch the browser.
3. Point your browser to the IP address of the
access point and enter its control panel.
4. Modify the SSID of the access point to
“POWERSOFT” and password “powersoft”.
Save and reboot the access point. While
rebooting you will loose the connection: after
some second, refresh the page on the browser
and reconnect to the AP.
5. By default DEVA looks for the POWERSOFT
Wi-Fi network. Through the AP control panel
you should monitor all connected devices.
17.2 DEVA in a wired LAN
Both the DEVA and the PDD must be connected
to the switch. The DHCP on board of the router
assign a unique IP address to each DEVA and PDD in
order for them to belong to the same subnet.
Through the PDD it is possible to manage the
network of DEVA, set schedules and events, monitor
the performance and launch an announcement on
specied DEVA.
Refer to Chapter “27 Advanced network
settings” for more information on how to congure
the DEVA network parameters and the PDD in
order to match your network environment.
ROUTER WITH
DHCP + switch
PDD

18 |DEVA |User Guide
18.2 Initialization in a wired LAN
In order to perform the initialization procedure
in a wired network environment, all devices have to
be connected to a DHCP server (possibly through
an Ethernet switch) in order to receive unique IP
addresses within the same subnet.
1. Connect the PDD and the DHCP server to
the same network: ensure that they share
the same IP range, i.e. the PDD receives its IP
address from the local DHCP server.
2. Connect each DEVA to the same network of
your PDD and switch them on (ref. Chapter
“14 Start-up”).
3. Now follow the same procedure described in
Chapter “18.1 Initialization in a wireless LAN”
starting from point 6.
6. Open the DEVA System Manager:
on the browser address-bar write
http://localhost:8080
7. Log in the DEVA System Manager: the
administrator account has the following default
credentials:
username: admin
password: admin
Once logged in, the DEVA System Manager
shows the latest saved network conguration:
since you are going to initialize your network, no
one DEVA is listed.
8. Click the button Discovery on the Toolbar: the
DEVA System Manager will start seeking and
connecting new devices on the network.
Now you can start setting DEVA.
FIGURE 11: DEVA system Manager login window.
FIGURE 12: DEVA System Manager at rst login.

Setting DEVA |19
Almost any settings on DEVA are performed by
means of the DEVA system Manager – DSM. The
audio playback from a USB key and the hard-reset
of the system are available just through the DEVA
dashboard.
The DSM offers a user friendly interface for
setting time schedules for actions, event triggers and
full access to DEVA features (ref. Chapter “5 DEVA
in a glance”).
19 Setting users permissions
By assign roles to registered users, it is possible
to control what users can do through the DEVA
System Manager.
Each registered user belongs to just one role.
Permissions are global, i.e. they grant access to
selected features on all networked DEVA. The
DEVA System Manager provides three default roles:
ADMIN, USER and GUEST.
Only the adminstrators can register new accounts
and assign roles to users. Refer to TABLE 1 for an
overview on user roles and permissions.
In order to register new users and set roles:
Setting DEVA
1. Click on the Settings tab in the main bar. The
main window switch to the Settings panel.
2. On the left column, click on Users Management
(ref. FIGURE 14).
3. Add new account or manage registered users
by inserting:
fLogin name
fLogin password
fReal name
fRole
4. Save by clicking on the Update button (ref.
FIGURE 15)
FIGURE 15: Add new user.
3 4
FIGURE 14: Set users account.
2
FIGURE 13: Discover connected DEVA and start settings.
1

20 |DEVA |User Guide
Functions
User role
ADMIN USER GUEST
Zones management  
Audio Library
management  
Playlists management  
Live volume
management  
Live light management  
Events management  
Schedulings
management  
System settings/
congurations 
System and Alarms
monitoring   
Live audio playing (le/
playlist/stream/fm radio)  
Audio Mute  
DEVA Diagnosis 
Take photos   
Delete photos  
Take audio recordings   
Delete audio recordings  
Run DEVA auto-test 
TABLE 1: User roles amd permissions.
20 DEVA general settings
A. Click on the Settings tab in the main bar. The
main window switch to the Settings panel (ref.
FIGURE 16).
B. On the left column, click on System settings
(ref. FIGURE 17).
FIGURE 17: Click on System settings.
B
FIGURE 18: Select one DEVA.
C
FIGURE 16: Discove connected DEVA and start settings.
A
