SLIDING GATE OPENERS
PL600H/PL1000H 24V DC MOTOR

INSTRUCTIONS PL600H/PL1000H 1
Index
1. Warnings 2
2. Product Description and Applications 3
2.1 Applications...........................................3
2.2 Description of The Automation...............3
2.3 Description of Devices............................3
2.3.1 PL600H/PL1000H Electromechanical
Gearmotor..............................................4
2.3.2 Release Keys.........................................4
2.3.2.1 Release Gearmotors……………............4
2.3.3 PH-2 Photocells......................................5
2.3.4 PR-1 Radio Transmitter..........................5
2.3.5 PF-1 Flashing Light................................5
2.3.6 PKS-1 Key selector................................5
2.3.7 PPB-1 Push Button…….........................5
3. Installation 6
3.1 Notes of Motors in Operation.................6
3.1.1 Tools in Installing....................................6
3.1.2 Motors, Components and Its Installation
in Illustration...........................................6
3.2 Power Connection..................................6
3.2.1 Notes for Power Connection..................6
3.3 Preparation for Motor Installation...........7
3.3.1 Installation of The Gearmotor.................9
3.3.1.1 Installing on Gates without Rack............9
3.3.1.2 Installing on Gates with Rack…...........11
3.3.2 PH-2 Photocells....................................12
3.3.3 PF-1 Flashing Light..............................13
3.3.4 PKS-1 Key selector..............................14
3.3.5 PPB-1 Push Button…...........................15
3.3.6 Installation of Green Box......................15
3.4 Power Supply Connections..................16
4. Final Checks and Start Up 16
4.1 Initial Checks........................................16
4.1.1 Design of PL600H/PL1000H control
unit.......................................................16
4.1.2 Recognition of LED Indication…….......17
4.1.3 Checking the Gate Movements…….....17
4.2 Programmable Functions List..............18
4.2.1 Programmable Functions of
LED Display..........................................20
4.2.2 Operations for Function Settings……...21
5. Testing 21
6. Maintenance and Disposal 22
6.1 Maintenance.........................................22
6.2 Disposal................................................22
7. Additional Information 22
7.1 Adding or Removing Device.................22
7.2 Troubles Shooting.................................22
8. Technical Characteristics 23
8.1 PL600H/PL1000H.................................23
8.2 PH-2 Photocells....................................23
8.3 PR-1 Transmitter...................................23
8.4 PF-1 Flashing Light...............................23
8.5 PKS-1 Key Selector..............................23
8.6 PRB-1 Push Button..............................23
CE Declaration of Conformity

INSTRUCTIONS PL600H/PL1000H
2
1) Warnings
Please read this instruction manual carefully before the
installation of gate-automated system.
This manual is exclusively for qualified installation
personnel. Powertech Electronics Inc. is not responsible for
improper installation and failure to comply with local
electrical and building regulations.
Keep all the components of PL600H/PL1000H system and
this manual for further consultation.
In this manual, please pay extra attention to the contents
marked by the symbol:
Be aware of the hazards that may exist in the procedures
of installation and operation of the gate-automated
system. Besides, the installation must be carried out in
conformity with local standards and regulations.
If the system is correctly installed and used following all
the standards and regulations, it will ensure a high degree
of safety.
Make sure that the gates works properly before installing
the gate-automated system and confirm the gates are
appropriate for the application.
Do not let children operate or play with the
gate-automated system.
Do not cross the path of the gate-automated system when
operating.
Please keep all the control devices and any other pulse
generator away from children to avoid the gate-automated
system being activated accidentally.
Do not make any modifications to any components except
that it is mentioned in this manual.
Do not try to manually open or close the gates before you
release the gear motor.
If there is a failure that cannot be solved and is not
mentioned in this manual, please contact qualified
installation personnel.
Do not use the gate-automated system before all the
procedures and instructions have been carried out and
thoroughly read.
Test the gate-automated system weekly and have
qualified installation personnel to check and maintain the
system at least every 6-month.
Install warning signs (if necessary) on the both sides of
the gate to warn the people in the area of potential
hazards.

INSTRUCTIONS PL600H/PL1000H 3
2.1 Applications
2.2 Description of the Automation
PL600H/PL1000H is applied for residential automation of sliding gates. PL600H/PL1000H has to be operated with
electricity and it’s forbidden to be operated by back-up batteries for normal use. Back-up batteries (optional) are only
allowed for emergent operation when there is a power failure, and the gearmotor can be released by the key to move
the gate manually.
The following diagram of PL600H/PL1000H typical installation describes some terms live in whereever you are and
whenever you are and accessories of a gate automation system:
2.3 Description of Devices
H
I
G F C C E
H
516
A
A
BC
DE
PL600H/PL1000H may include the accessories shown in Figure 2.
Please check the accessories the same as the package provided.
Attention: Some accessories of PL600H/PL1000H are not included due to local regulations or customized order.
A) 1 PL600H/PL1000H electromechanically gearmotor
including control unit
B) 2 release keys
C) 1 pair of PH-2 photocells
D) 2 PR-1 radio transmitters
E) 1 PF- flashing light
F) 1 PKS-1 key selector with two keys
G) 1 PPB-1 push button
H) 2 limit switch brackets
I) Various small parts: screws, nuts, etc. (see table1)
J) 4 PRK-1 Rack
K) Green Box
Figure 2
Bent bins / Washers / Nut 2 pcs / 6 pcs / 4 pcs
Foundation Plate 1 pce
Screws with no head 4 pcs
Limit Switch 2 sets
Table 1: List of small parts for PL600H & PL1000H
Figure 1
2) Product Description and Applications
F G H
IJ
K

INSTRUCTIONS PL600H/PL1000H
4
2.3.1 PL600H/ PL1000H Electromechanical Gearmotor
PL600H/PL1000H consists of an electronic control unit
and connector for the optional radio control receiver.
The gearmotor could be released manually by special
release keys when there is power failure. Besides, it has
a back-up battery (optional) which can be used during
the power failure as well.
2.3.2 Release Keys
The two keys enable the gearmotor to be released when
there is power failure.
Figure 3
Figure 4
516
Green Box
Fuse knob
Terminals for devices
RF leaning button
Digital led display
Function setting buttons
Back-up batteries
(optional)
A
B
E
D
C
F
G
2.3.2.1 Release Gearmotor
1) Slide the lock cover disc. 2) Insert and turn the key clockwise.
3) Pull the release handle. 4) Move the leaf manually.

INSTRUCTIONS PL600H/PL1000H 5
3*20 Screw 3 pcs
Nylon screw anchor 3 pcs
Table 2: List of small parts for PPB-1 Quantity
3*20 Screw 3 pcs
Nylon screw anchor 3 pcs
Table 4: List of small parts for PPB-1 Quantity
3*20 Screw 3 pcs
Nylon screw anchor 3 pcs
Keys 3 pcs
Table 3: List of small parts for PKS-1 Quantity
Figure 5
Figure 6
Figure 7
Figure 8
Figure 9
2.3.3 PH-2 Photocells
The pair of PH-2 photocells has to be installed on the
wall and connected to the control panel. The function of
the photocells is to detect the obstacles found on the
optical axis between the transmitter (TX) and the
receiver (RX).
2.3.4 PR-1 Radio Transmitter
PR-1 radio transmitter is used for the remote control of
the gate movement. To use the transmitter, press and
hold the button for 1 second. There are two buttons on
the transmitter and (A) button is “open-stop-close
mode” and (B) button is “pedestrian mode”.
2.3.5 PF-1 Flashing Light
PF-1 flashing light is controlled by PL600H/PL1000H
control unit and blinks when the gate is moving or blinks
3 seconds before the gate moves. The flashing light
stops blinking when the gates
2.3.6 PKS-1 Key selector
The PKS-1 key selector is used for opening the gate
outdoors without the radio transmitter. PKS-1 key
selector is supplied with two keys
2.3.7 PPB-1 Push Button
The PPB-1 push button is used for opening the gate
indoors without the radio transmitter.
TX
RX

INSTRUCTIONS PL600H/PL1000H
6
Figure 10
3.1 Notes of Motors in Operation
3.1.1 Tools in Installing
The PL600H/PL1000H gate openers are applicable to per gate leaf of 600/1000 kg in weight for residential use;
where the performance shall be influenced by the factors such as gate dimension, weight and climate that the driven
torque is necessarily to be adjusted properly.
Please make sure all tools and cables are ready and conform to the industrial safety standard before installation.
Please refer to Figure 10.
The installation procedure of PL600H/PL1000H may be changed due to various accessories and quantities installed.
No wiring cables for accessories are supplied with KIT PL600H/PL1000H.
3) Installation:
3.1.2 Motors, Components and Its Installation in Illustration
The users are advised to read the installation manual carefully before going for it. After getting to know all accessories
and their positions, suggest starting from cable conduit arrangement to prevent the cables from being broken or
damaged.
3.2 Power Connection
1).The installation of power supply cable to the motor should be implemented by a qualified professional electrician.
2).The power supply cable of the motor should be equipped with short circuit protection and leakage protection.
Please make sure to shut off the power before going installation or maintenance.
3.2.1 Notes for Power Connection

INSTRUCTIONS PL600H/PL1000H 7
Check the following items before going for installation:
Figure 11
Figure 12
3.3 Preparation for Motor Installation
PL600H/PL1000H is not applicable to a gate which is inefficient or unsafe, neither to solve the defects due to incorrect
installation nor poor maintenance.
9). The installed at the left side and at the right site as below:
Gate without rack: the distances indicated in Figure 12.
332mm
287mm
91mm
216mm
Check the dimensions of the motors as below:
SX DX
50mm
50mm
50mm
50mm
1). Make sure the weight and dimensions of the gate conform to the operation range of PL600H/PL1000H. Don’t use
PL600H/PL1000H if the gate specifications do not meet the requirements.
2). Make sure the gate structure conform to the criteria of automatic operation and force regulations.
3). Make sure there is no serious friction existing in the opening or closing travel of the gate.
4). Make sure the gate is at horizontal level that the gate will not move aside at any position.
5). Make sure the gate can bear the impact of the motor torque when it is installed on the plate which the surface is
sufficiently sturdy.
6). Make sure that the installation area is not easy to be invaded by flood. If necessary, mount the raised from the
ground.
7). Make sure the photo sensors (optional) are installed on flat surfaces to ensure the two ends of receiving and
transmitting corresponded to each other.
8). Make sure the installation area is suitable to the size of and the area is safe and easy to release the gearmotor.

INSTRUCTIONS PL600H/PL1000H
8
Figure 13
Figure 14 (Left opening)
Figure 15 (Right opening).
Figure 16
Gate with rack: the distances indicated in Figure 13.
10) To install the limit switch brackets, the rack must project from the axis of the pinion by distances indicated in
Figure 14 (Left opening) and Figure 15 (Right opening).
11) If the rack is already installed on the gate, make sure the position of the rack is fitted for the size limits indicated in
Figure16.
DX
SX
50mm50mm
10mm
10mm
170mm
200mm
170mm
200mm
86-88mm

INSTRUCTIONS PL600H/PL1000H 9
B
A
Figure 17
Figure 19 Figure 20
Figure 18
3.3.1 Installation of the Gearmotor
3.3.1.1 Installing on Gates without Rack
The PL600H/PL1000H can be installed in two situations:
1). Installing on gates without rack; in this condition must be installed first, followed by PRK-1 rack.
2). Installing on a gate with rack; in this condition must be connected to the existing rack.
1). Dig the foundations based on “Preparation for Motor Installation” and please notice the distances indicated in
Figure 12.
2). Lay the conduits for the power cables and leave 30-50 cm longer as Figure 17.
3). Fit the two bent bins (as below part in Figure 18) into the foundation and fix them above and below with two
nuts (as below part in Figure 18); make sure the outstanding part does not exceed the maximum height as
Figure 18.
4). Put the foundation plate and make sure the gate keeping the distances shown as Figure 12.
5). Fit the conduits through the hole of the foundation plate.
6). Pour the concrete.
7). Sink the plate into the concrete and make sure it is parallel to the leaf.
8). After the concrete is dry enough, remove the two upper nuts form the plate and cut the cable conduits above the
plate if the conduits are too long.
9). Remove the two caps beside the left and right sides of the gearmotor as shown in Figure 19.
10). Put gearmotor on the plate and then screw the two nuts and washers as Figure 20.
A
B
25~35mm

INSTRUCTIONS PL600H/PL1000H
10
E
Figure 21
Figure 23
Figure 22
11). Release the gearmotor by using the release key if necessary.
12). Fully open the gate and place the first piece of the rack on the pinion so that it projects from the axis of the pinion
by distance followed as Figure 14 or Figure 15, which means, the space reserved for the limit switch brackets.
13). To keep the rack level with the pinion, mark the hole for fixing when the slot matches the axis of the pinion.
Repeat this operation for each fixing point Figure 21.
14). Keep 1~2 mm space as Figure 22 between the rack and pinion so that the gate does not weigh on the
gearmotor. Continually install the other pieces of the rack until the racks are sufficient for work.
15). After fixing the last piece, cut away the unnecessary parts of racks by a hacksaw if necessary.
16). Open and close the gate several times manually and make sure that the rack goes with the pinion smoothly
within a maximum tolerance of 5mm.
17). Fix the two limit switch brackets with the relative dowels as the part in Figure 23.
Slide the gate in the open position keeping at least 2~3 cm from the mechanical stop. And then slide the bracket
along the rack in the opening direction until the limit switch cuts-in. The brackets should be located at a sufficient
distance from mechanical stops in order to keep the gate from crashing.
Operate the same steps for the limit switch in the closed position.
18). For electrically connections of the various devices, please see “4.1.1 Design of PL600H/PL1000H control unit”.
1~2m
E

INSTRUCTIONS PL600H/PL1000H 11
10). Put the gearmotor onto the plate and underneath
the rack. This step of installation can be operated
by tilting the gearmotor so that the pinion can be
easily under the rack. Make sure the gearmotor
lies ideally parallel with the gate. Then fix it by
fastening the two nuts and washers. (as the &
parts in Figure 28)
11). If necessary, adjust the height of the gearmotor
(Max. 10mm) with the 4 dowels. It is better to fix
the gearmotor without dowels as it is fastened
firmly and securely on the plate.
1). Dig the foundations based on “Preparation for Motor Installation” and please notice the distances indicated in
Figure 12.
2). Lay the conduits for the power cables and leave 30-50 cm longer as Figure 24.
3). Fit the two bent bins (as below part in Figure 25) into the foundation and fix them above and below with two
nuts (as the part in Figure 25); make sure the outstanding part does not exceed the maximum height 25~35 mm
as Figure 25.
B
C D
A
Figure 24
Figure 26 Figure 27
Figure 28
Figure 25
3.3.1.2 Installing on Gates with Rack
4). Put the foundation plate and make sure the gate keeping the distances shown as Figure 12.
5). Fit the conduits through the hole of the foundation plate.
6). Pour the concrete.
7). Sink the plate into the concrete and make sure it is parallel to the leaf as below Figure 26.
8). After the concrete is dry enough, remove the two upper nuts (which will no longer be used) form the plate and cut
the cable conduits above the plate if the conduits are too long.
9). Open the cap by the rear of the gearmotor as shown in Figure 27.
A
B
25~35mm
C
D

INSTRUCTIONS PL600H/PL1000H
12
E
12). Keep 1~2 mm space as Figure 29 between the rack and pinion so that the gate does not weigh on the gearmotor.
Continually install the other pieces of the rack until the racks are sufficient for work.
13). Release the gearmotor by using the release key if necessary.
14). Open and close the gate several times manually and make sure that the rack goes with the pinion smoothly
within a maximum tolerance of 5mm
15). Fix the two limit switch brackets with the relative dowels as the part in Figure 30.
Slide the gate in the open position keeping at least 2~3 cm from the limit switch. And then slide the bracket along
the rack in the opening direction until the limit switch cuts-in. The brackets should be located at a sufficient
distance from mechanical stops in order to keep the gate from crashing.
Operate the same steps for the limit switch installed in the closed position.
16). For electrically connections of the various devices, please see “4.1.1 Design of PL600H/PL1000H
Control Unit”.
Figure 29 Figure 30
1~2m
E

INSTRUCTIONS PL600H/PL1000H 13
3.3.2 PH-2 Photocells
The safety photocells are security devices for control automatic gates. Consist of one transmitter and one receiver
based in waterproof covers; it is triggered while breaking the path of the beams.
INSTALLATION:
Wire Connection of PH-2 Photocells See figure 4(2)
TX: Connect terminals 1 and 2 on the transmitter with the terminals Ph+ and GND on the PC600 PCB.
RX: Connect terminals 1, 2 and 4 on the receiver with the terminals Ph+, GND and Ph1 on the PC600 PCB.
And use an extra wire to connect terminals 2 and 5 on the receiver as a bridge.
Detection Method
Sensing Range
Input Voltage
Response Time
Emitting Element
Operation Indicator
Dimensions
Output Method
Current Consumption Max
Water Proof
Through Beam
25M
AC/DC 12~24V
100MS
IR LED
Red LED(RX): ON(When Beam is Broken), Green(TX):ON
96*45*43mm
Relay Output
TX: 35MA/Rx: 38MA (When beam aligned properly);
TX: 35MA/ Rx: 20MA (When beam is broken)
IP54
RX
RX
Lens
Beam Alignmnet
Indicator
Power Led
Indicator
Terminal Block
Power
Terminal Block
COM
N.C.
N.O.
GND
DC (12~24V)
GND
DC (12~24V)
TX
TX
SPECIFICATION:
Figure 4(3)
Figure 4(2)
Figure 4(1)
1 2 3 4 5
1 2 3 4 5 1 2
1 2

INSTRUCTIONS PL600H/PL1000H
14
3.3.3 PF-1 Flashing Light
1). Decide the installation position of the flashing light. The flashing light has to be installed near the gate and easy
to be seen by users and passersby. The flashing light can be installed horizontally or vertically. See Figure 3.3.3 (1).
2). Unscrew the four screws on the light base and separate the base with the bottom as shown in Figure 3.3.3 (2).
3.) Connect the wires and penetrate the wires into the hole of the base. See Figure 3.3.3 (3).
4.) Drill the holes in the wall and fix the bottom to the wall by three screws. See Figure 3.3.3 (4).
3.3.4 PKS-1 Key Selector
1). PKS-1 key selector is installed outside and close to the gate at the height of about 100cm, so that it could be used
by most people. Decide the installation position of PKS-1 first. See Figure 3.3.4 (1).
2). Remove the round cover (A) by prizing it out with a screwdriver. See Figure 3.3.4 (2).
3). Unscrew the two screws beside the lock body. See Figure 3.3.4 (3).
4). Turn the key and separate the bottom of the shell with the lock body. See Figure 3.3.4 (4).
5). Connect the four wires of the light and the antenna to the PCB terminals and place the wires into the conduit if
necessary. See Figure 3.3.3 (5).
6). Tighten the four screws back on the light base. Figure 3.3.3 (6)
7). Replacing the bulb set. See Figure 3.3.3 (7)
7.1) Unscrew the flashing light wires from the PCB terminals and make sure the power of the light is off.
7.2) Release the three screws (A)、(B)、(C) of the flashing light cover.
7.3) Separate the flashing light cover and replace the bulb set with a new one.
7.4) Tighten the three screws (A)、(B)、(C) of the flashing light cover.
Figure 3.3.3 (1) Figure 3.3.3 (2) Figure 3.3.3 (3)
Figure 3.3.3 (5) Figure 3.3.3 (6) Figure 3.3.3 (7)
Figure 3.3.3 (4)
Figure 3.3.4 (1) Figure 3.3.4 (2) Figure 3.3.4 (3) Figure 3.3.4 (4)
1000mm
A
A
B
C

INSTRUCTIONS PL600H/PL1000H 15
3.3.5 PPB-1 Push Button
1). PPB-1 push button is installed indoors at the height of about 100cm, so that it could be used by most people.
2). Remove the round cover (A) by prizing it out with a screwdriver. See Figure 3.3.5 (1).
3). Unscrew the two screws beside the button.
4). Separate the upper shell with the bottom. See Figure 3.3.5 (2).
5). Breach the three holes at the bottom and mark the points by the holes as reference.
6). Drill the holes in the wall and fix the bottom to the wall by three screws. See Figure 3.3.5 (3).
3.3.6 Installation of Green Box
5). Breach the three holes at the bottom and mark the points by the holes as reference.
6). Drill the holes in the wall and fix the bottom to the wall by three screws. See Figure 3.3.4 (5).
7). Connect the electric wires to the terminals as shown in Figure 3.3.4(6), and it’s not required to distinguish any
polarity. The terminals can be removed for connecting the wires easily.
8). Turn the key and insert the shell on the bottom. Turn the key back to the center position and the shell will be fixed
to the bottom.
9). Tighten the lock body with the two screws and insert the round cover by pressing it to attach to the whole unit.
Figure 3.3.4 (5)
Figure 3.3.5 (1) Figure 3.3.5 (2) Figure 3.3.5 (3)
Figure 3.3.4 (6)
A
OFF ON
Green Box
5+
Cable
AC out
AC in
Green Box is for purpose when gate opener is in standby mode to
allow it enter the power saving mode.
Installation manner:
AC IN: connect the electricity
AC OUT: connect the power of gate opener, and connect the transformer
5V CABLE: connect 3 pins white socket of control board
Please make sure the switch of Green Box is off before proceeding the system learning and installation of device. Wait for
the system learning and installation of device to be completed, power on the Green Box
Gate opener will enter power saving mode without receiving any instruction in 1 min, and red LED light on Green Box will
be activated. Gate opener start the operation, red LED light and power saving mode will turn off.
CAUTION:
In case of loop or installation of photocell which need power consumption anytime, please do not install Green Box.

INSTRUCTIONS PL600H/PL1000H
16
4) Final Checks and Start Up
4.1 Initial Checks
4.1.1 Design of PL600H/PL1000H control unit
3.4 Power Supply Connections
Please kindly notice that the operation of power connection should be carried out by a qualified electrician with
following steps:
1). Make sure the gearmotor is not connected to the power supply before the installation is done.
2). Make sure all the wires are firmly connected.
3). Supply the gearmotor with the power.
If the Led display is in normal performing refer to “4.2.1”, you can control the gate by either transmitters or the button
on the board: “UP”-clockwise moving, “SET”- stop and “DOWN”- Counterclockwise moving.
6
6 7
3 4 9 6 8 9
96 9
10 11
LED1 Photocells
LED2 Photocells
LED3 RF Learning
ANT
GND
RF Learn (SW1)
LED Display
UP (SW3)
SET (SW4)
DOWN (SW5)
12345678910 11 12 13 14
Green Box Socket
Inside the Cover

INSTRUCTIONS PL600H/PL1000H 17
2 channel transmitter
4 channel transmitter
(A)Button: “Open- Stop- Close- Stop”
(B)Button: Long Press for other device
turn-on, like garage door system
(A) Button: “Open- Stop- Close- Stop”
(B) Button: Long Press for other device
turn-on, like garage door system
(C) Button: “Pedestrian mode”
Or
(D) Button: “Pedestrian mode”
(A)Button: “Open- Stop- Close- Stop”
(B)Button: “Pedestrian mode”
(A) Button: “Open- Stop- Close- Stop”
(B) Button: “Pedestrian mode”
(C) Button: Long Press for other device turn-on,
like garage door system
Or
(D) Button: Long Press for other device turn-on,
like garage door system
Channel/Functions SW2 switch on SW2 switch off
1). The transmitter Reaction
LED1 Photocells
LED2 Photocells
LED3 RF Learning
LED1 will be on when the first pair of the photocells are activated.
LED2 will be on when the second pair of the photocells are activated.
LED3 will be on when RF-learn button is pressed.
LED Indication Descriptions
4.1.2 Recognition of LED
4.1.3 Checking the Gate Movements
1). Release the gearmotor with the release key and move the gate to the middle so that it is free to move in both
opening and closing directions; then lock the gearmotor.
2). Perform the gate opening and closing several times and make sure the gates reaches the limit switch at least 2~3
centimeters before the mechanical stop.
Important notice:
(1) Jumper 4: ②and ③in place: remote control button (C) usable ;
Jumper 4: ① and ②in place: remote control button (D) usable.
(2) Pedestrian mode follows function “F6-0~F6-5” settings.
2). The transmitter Learning
Press “RF Learn” button for 2 seconds, and the LED3 is on; then press the transmitter (A) button; the LED3 will blink
twice and then be off. The system learning is complete.
3 2 1 3 2 1
Button (C) Usable Button (D) Usable

INSTRUCTIONS PL600H/PL1000H
18
4.2 Programmable Function Settings
LED Display Definition Function Value Description
Options of Gate
Opening direction
Automatic Closing
There actions of the
photocells / safety edge /
loop detector when they
detecting obstacles
Motor Speed
(% full speed)
The deceleration setting
for gate moving
Deceleration Speed
(% full speed)
Over current setting
F1
F2
F3
F4
F5
F6
F7
F1-0
F1-1
F2-0
F2-1
F2-2
F2-3
F2-4
F2-5
F2-6
F2-7
F2-8
F3-1
F3-2
F3-3
F4-1
F4-2
F4-3
F4-4
F5-1
F5-2
F5-3
F5-4
F5-5
F6-1
F6-2
F6-3
F6-4
F6-5
F7-1
F7-2
F7-3
F7-4
F7-5
F7-6
F7-7
F7-8
Clockwise Opening
Counter clockwise Opening
No automatic closing
5 seconds
15 seconds
30 seconds
45 seconds
60 seconds
80 seconds
120 seconds
180 seconds
Please the function setting
afterF8
Operation：50%
Study Speed：25%
Middle operation：50%
Operation：70%
Study Speed：35%
Middle operation：60%
Operation：85%
Study Speed：43%
Middle operation：70%
Operation：100%
Study Speed：50%
Middle operation：80%
75% of full distance
80%
85%
90%
95%
80%
60%
40%
25%
10%
2A
3A
4A
5A
6A
7A
8A
10A
1. The function can adjust the direction of gate opening.
2. The factory setting is "F1-1".
1. This function can cause the gate toclose automatically
after the paused time.
2. The factory setting is"F2-2”: 15 Secs as the pause time.
1. Please the function setting after F
2. Thef actory setting is “F3-1”.
1.The function can adjust the running speed of motor.
2.The factory setting is "F4-4".
1. The factory setting is “F5-1”.
1. The factory setting is “F6-4”
1. The function can adjust the running force of motor to
be compatible with the gate weight.
2. The factory setting is "F7-5".
