Elsema Eclipse MCS Manual

www.elsema.com
MCS : Motor Controller Single
Setup and Technical Information
Includes latest Intelligent Technology
Motor Controller Single Gate
with Eclipse® Operating System (EOS)
4th Edition
Eclipse®
MCS

All installations and testing must be done only after reading and
understanding all instructions carefully. All wiring should be done
only by trained technical personnel. Failing to follow instructions
and the safety warnings may result in serious injury and/or damage
to property.
Elsema Pty Ltd shall not be liable for any injury, damage, cost,
expense or any claim whatsoever to any person or property which
may result from improper use or installation of this product.
Risk in the goods purchased shall unless otherwise agreed in
written pass to the buyer upon delivery of the goods.
Any figures or estimates given for performance of goods are based
upon the company’s experience and is what the company obtains
on tests. The company will not accept liability for failure to comply
with the figures or estimates due to the nature of variable conditions
affecting for example Radio Remote Controls.
Please keep this setup instruction for future reference.
Installed by: _______________________________________
Service date: ______________________________________
Important warning and safety instructions
2Gate & Door Controller with Eclipse®Operating System (EOS)

Contents
Features .............................................................................................................................4
Description.........................................................................................................................4
Part Number.......................................................................................................................5
Menu Structure ..................................................................................................................6
Connection Diagram ..........................................................................................................8
Supply and Motor Inputs ...................................................................................................9
Limit Switches..................................................................................................................10
Setup i-Learning Steps.....................................................................................................11
Menu 1 – Auto Close.......................................................................................................12
Menu 2 – Pedestrian Access Features .............................................................................13
Menu 3 – Input Functions................................................................................................14
Menu 4 – Photoelectric Beam..........................................................................................15
Menu 5 – Relay Output Functions....................................................................................16
Menu 6 – Relay Output ModesRelay Output Modes..................................................................................................................................................................................1919
Menu 7 – Special Features...............................................................................................22
Menu 8 – Motor Obstruction............................................................................................23
Menu 9 – Motor Speed and Slow Speed Area..................................................................24
Menu 10 – Anti-Jam and Braking ....................................................................................25
Menu 11 – i-Learning......................................................................................................26
Menu 12 – Password.......................................................................................................26
Menu 13 – Operational Records.......................................................................................26
Menu 14 – Tools..............................................................................................................27
Accessories......................................................................................................................28
PentaFOB®Programming Instructions.............................................................................30
3www.elsema.com

Description
Features
›Lithium-ion and lead acid battery charger
›Suitable for single swing and sliding gates
›Single motor operation
›Eclipse Operating System (EOS)
›Motor soft start and soft stop
›Slow speed and force adjustment
›Large 4-line LCD to indicate controllers status
and setup instructions
›1-Touch control for easy setup
›Various inputs, push button, open only, close
only, stop, pedestrian and Photoelectric Beam
›Supports limit switch inputs or mechanical stops
›Adjustable Auto Close and Pedestrian Access
›Adjustable lock and courtesy light outputs
›Variable photoelectric safety beam functions
›12 Volt DC Output to power accessories
›Service counters, password protection, holiday
mode and many more features
The Motor Controller Single (MCS) is not just the next generation but the industry game changer. We wanted
to create a controller that is simple to use and does just about any feature required in the gate and door
industry. The MCS is not just the next generation but the “Next Transformation” in the gate and door industry
creating an Eclipse over previously developed motor controllers.
This new intelligent motor controller is the best match for your automatic gate or door motors.
The MCS’s Eclipse® Operating System (EOS) is a user friendly menu driven system that uses the 1-touch
button to control, setup and run automatic gates, doors and barriers. It uses a large 4-line LCD screen showing
live reading of the motor performance and status of all inputs and outputs.
The intelligent controller was built from the ground up, based on customer feedback and using todays
technology. With its rich functions, consumer friendly price and with the focus during development being ease
of use and setup makes this controller the ultimate board to control your motors.
Elsema’s easy options to add remote controls or any type of Photoelectric Beams makes for a very user friendly
approach, while avoiding the lockdown approach to accessories.
The control cards are available with an IP66 rated plastic enclosure for outdoor installations or the card only.
4Gate & Door Controller with Eclipse®Operating System (EOS)

MCS
MCS24E or MCS12E
Part Number:
Part No. Contents Part No. Contents
MCS Single gate and door controller
for 24 / 12 Volt motor, card only
MCS24E Single controller for 24 Volt motors includes IP66
rated plastic enclosure and transformer MCS12E Single controller for 12 Volt motors includes IP66 rated plastic enclosure and transformer
MCS24E2 Same as MCS24E plus 24 Volt 2.3Ah backup battery MCS12E2 Same as MCS12E plus 12 Volt 2.3Ah backup battery
MCS24E7 Same as MCS24E plus 24 Volt 7.0Ah backup battery MCS12E7 Same as MCS12E plus 12 Volt 7.0Ah backup battery
Solar Gates
Solar24SP
Solar kit for double or single gates, includes solar
MPPT charger & 24 Volt 15.0Ah backup battery and a
40 Watt solar panel.
Solar12 Solar kit for double or single gates, includes solar
MPPT charger & 12 Volt 15.0Ah backup battery
MCS is suitable for motors up to 120 Watts. Above 120 Watts use MCSv2.
MCS & MCSv2 control card can be used to control automatic gates, doors, boom gates and automated
windows or louvres.
MCS12E7
5www.elsema.com

Menu Structure Press Master Control for 2 seconds to enter the menu structure
1.0
Auto Close
1.1
Auto Close Time
1.2
AC Time with PE Trig
7.1
RC Open only
7.2
Holiday Mode
4.1
Stop & Open on Close Cycle
13.1
Events History
13.2
Display Operations / Currents
2.1
PA Travel Time
2.2
PA AC Time
5.1
Relay Output 1
Lock / Brake
6.1.1: Open Lock Activation 6.2.1: Courtesy Light
6.3.1: Pre-Open Warning Light
Lock / Brake
Courtesy Light
6.1.2: Close Lock Activation
Courtesy Light
Service Call
6.1.3: Pre-Open Lock
Service Call
Strobe (Warning) Light
6.1.4: Pre-Close Lock
6.1.5: EXIT
Strobe (Warning) Light
5.2
Relay Output 2
9.1
Open Speed (%)
9.2
Close Speed (%)
12.1
Enter Password
12.2
Delete Password
14.1
Battery Type
14.2
Supply Voltage
3.1
PE Polarity
3.2
Limit Sw Polarity
8.1
Open Obstruct
8.2
Close Obstruct
10.1
Open Anti-Jam
10.2
Close Anti-Jam
6.1
Lock Output
6.2
Light Output
2.0
Pedestrian Access
3.0
Input Functions
4.0
PE Safety Beam Function
5.0
Output Functions
6.0
Output Modes
7.0
Special Features
8.0
Motor Obstruct Detect Margin
10.0
Anti-Jam / Electronic Braking
12.0
Password
9.0
Motor Speed, Slow Speed Area & Reverse Time
11.0
Travel Learn
13.0
Operational Records
14.0
Tools
EXIT PROGRAMMING
MAIN
SCREEN
PE Beam Stops Motor
on Close Cycle
6.2.2: EXIT
6Gate & Door Controller with Eclipse®Operating System (EOS)

1.3
AC After Open Obstruct
7.3
Energy Saving
13.3
Reset Max Current Records
13.4
EXIT
2.3
PA AC Time with PE Trig
6.4.1: Service Counters
6.3.1: Pre-Open Warning Light
6.4.2: EXIT 6.3.2: Pre-Close Warning Light
6.3.3: EXIT
5.3
EXIT
9.3
Slow Speed (%)
9.4
Open Slow Speed Area
8.4
Obstruct Det Response
9.5
Close Slow Speed Area
8.5
EXIT
7.4
Automatic Stop/Open on Closing
7.5
Receiver Channel 2 Options
6.5
EXIT
4.2
EXIT
1.5
AC on Seq. Obstruct
6.4
Service Call
2.4
PA AC on Seq. Obstruct
1.4
AC After Power Restored
1.6
AC Only When Fully Open
9.6
Stop Rev Delay Time
9.7
EXIT
12.3
EXIT
14.3
Reset Factory Default
14.4
Test Inputs
3.3
Stop Input Polarity
8.3
Slow Speed Obstruct
10.3
Electronic Braking
6.3
Strobe (Warning) Light
14.5
Travel Timer for Slip Motors
7.6
Press and Hold, Open Input
7.7
Press and Hold, Close Input
7.8
Window / Louvre Mode
7.9
Reserved
PE Beam Stops Motor
on Open & Close Cycle
PE Beam Stops Motor and
Closes on Open Cycle
2.6
EXIT
2.5
PA Hold Gate
14.8
Slow Speed Ramp Down
14.6
Solar Gate Mode
14.7
Fuse Type : 10 or 15 Amps
10.4
Open Obstruction Operation
10.5
Close Obstruction Operation
10.6
EXIT
1.7
EXIT
3.4
EXIT
14.9
Magnetic Limit Switch
7.10
Press and Hold, Remote Ch1
14.10
Exit
7.11
Press and Hold, Remote Ch2
7.12
Exit
7www.elsema.com

MCS Connection Diagram
2
Normally Closed User can change
Fuse
Relay
Open Close Stop
Master
Control
AC Supply
AC Supply
AC Supply
AC Supply
AC Supply
AC Supply
DC Output +
DC Output -
AC Supply
AC Supply
Motor
Motor
AC Supply
AC Supply
Battery +
Battery -
Open Limit
Common
Close Limit
Push Button
Open
Close
Stop
Common
PED Access
Photo Beam
+ 12 VDC
- 12 VDC
Output 1 C
Output 1 NO
AC Supply : 24/12 Volts AC
Model : MCS
Designed by
ELSEMA
IN AUSTRALIA
Normally Closed User can change
ELSEMA
Normally Open User can change
Eclipse operating system
Powered By
Receiver
Program 2
Program 1
Antenna 1
Shield
Antenna 2
90mm
140mm
Output 2 Used with Relay 1-12
Output Rated at 250mA
12 or 24 Volts
AC Supply
Built-in
Receiver
1 Amp Max
8Gate & Door Controller with Eclipse®Operating System (EOS)

Electrical Wiring - Supply, Motors and Inputs
Always switch off power before doing any wiring.
Make sure that all the wiring is completed and that the motor is connected to the control card.
Recommended wire strip length should be 12mm for all connections to the plug in
terminal blocks.
The diagram below shows the supply, motors, and inputs available and the factory default setting for each
input.
Normally Closed
User can change
Fuse
Relay
Open Close Stop
Master
Control
Open Limit
Common
Motor 1
Close Limit
Motor 1
Push Button
Open
Close
Stop
Common
PED Access
Photo Beam
AC Supply : 24/12 Volts AC
Model : MCS
Designed by ELSEMA
IN AUSTRALIA
Normally Closed
User can change
ELSEMA
Normally Open
User can change
AC Supply AC Supply
AC Supply
AC Supply
AC Supply AC Supply
DC Output +
DC Output -
AC Supply AC Supply
Motor 1 Motor 1
AC Supply AC Supply
Battery + Battery -
12 or 24 Volts
AC Supply 1Amp
max
9www.elsema.com

Limit Switches
Controller with
limits connected
By default the limit switch inputs on the control card are normally closed (NC).
This can be changed to normally open (NO) during the setup steps.
Fuse
Close
Master
Control
Open Limit
Common
Close Limit
AC Supply : 24/12 Volts AC
Model : MCS
Designed by ELSEMA
IN AUSTRALIA
AC Supply AC Supply
Motor Motor
Normally Closed
User can change
M
Motor 1
Fuse
Close
Master
Control
AC Supply : 24/12 Volts AC
Model : MCS
Designed by ELSEMA
IN AUSTRALIA
AC Supply AC Supply
Motor Motor
M
Close
Limit
Open
Limit
Diode* Diode*
*6 Amps, 50V or better diode
Elsema : Diode FR604
Controller with limits
in series with motor
If you are using limit switches make sure they are connected properly. The control card can operate
with either the limit switches connected directly to the cards terminal blocks or in series with the
motor. See the diagrams below:
10 Gate & Door Controller with Eclipse®Operating System (EOS)

1. The i-Learning setup can always be interrupted with the stop button or by pressing the Master
Control knob.
2. Enter Menu 11 to start i-Learning or new control cards will automatically prompt you to do the
i-Learning.
3. Look at the LCD and follow the instructions displayed.
4. Buzzer will indicate learning was successful. If there was no buzzer check all electrical wiring
including the power supply then go back to step 1.
5. If you hear the buzzer after the i-Learn, the gate or door is ready for use.
Setup i-Learning Steps:
11www.elsema.com

Auto Close is a feature that automatically closes the gate after a preset time has counted down to zero. The
control card has a normal Auto Close and several special Auto Close features each one having its own
countdown timers.
Elsema Pty Ltd recommends a Photoelectric Beam to be connected to the control card when any of the Auto
Close options are used.
If the Stop input is activated Auto Close is disabled for that cycle only.
Auto Close timer will not count down if the Push Button, Open or Photoelectric Beam input is held active.
Menu No. Auto Close Features Factory
Default Adjustable
1.1 Normal Auto Close Off 1 - 600 seconds
1.2 Auto Close with Photoelectric Trigger Off 1 - 60 seconds
1.3 Auto Close after an Open Obstruction Off 1 - 60 seconds
1.4 Auto Close after Power Restored Off 1 - 60 seconds
1.5 Normal Auto Close on Sequential Obstructions 2 Min = Off,
Max = 5
1.6 Auto Close Only when Fully Opened Off Off/On
1.7 Exit
Menu 1 – Auto Close
1.1 Normal Auto Close
The gate will close after this timer has counted down to zero.
1.2 Auto Close with Photoelectric Trigger
This Auto Close starts counting down as soon as the Photoelectric Beam has been cleared after a trigger
even if the gate is not fully open. If there is no Photoelectric Beam trigger the gate will not Auto Close.
1.3 Auto Close after an Open Obstruction
If the gate opens and hits an obstruction normally the gate will stop and remain in this position. If this
feature is enabled an obstruction will start the timer count down and at zero will close the gate.
12 Gate & Door Controller with Eclipse®Operating System (EOS)

1.4 Auto Close after Power Restored
If the gate is open in any position and then there is a power failure, when power is reconnected the gate will
close with this timer.
1.5 Normal Auto Close on Sequential Obstructions
If the normal Auto Close is set and the gate closes onto an object the gate will stop and reopen. This setting
sets the amount of times the gate will try to Auto Close. After trying for the set limit the gate will remain
open.
1.6 Auto Close Only when Fully Opened
The Auto Close timer will not time out unless the gate is fully open.
Menu 2 – Pedestrian Access
There are several types of Pedestrian Access modes. Pedestrian Access opens the gate for a short time to
allow someone to walk through the gate but does not allow access to a vehicle.
Elsema Pty Ltd recommends a Photoelectric Beam to be connected to the control card when any of the
Auto Close options are used.
Menu No. Pedestrian Access Features Factory
Default Adjustable
2.1 Pedestrian Access Travel Time 3 seconds 3 - 20 seconds
2.2 Pedestrian Access Auto Close Time Off 1 - 60 seconds
2.3 Pedestrian Access Auto Close Time with PE trigger Off 1 - 60 seconds
2.4 Pedestrian Access Auto Close on Sequential Obstructions 2 Min = Off,
Max = 5
2.5 Pedestrian Access with Hold Gate Off Off/On
2.6 Exit
13www.elsema.com

2.1 Pedestrian Access Travel Time
This sets the time the gate opens when a Pedestrian Access input is activated.
2.2 Pedestrian Access Auto Close Time
This sets the countdown timer for automatically closing the gate when a Pedestrian Access input is
activated.
2.3 Pedestrian Access Auto Close Time with PE Trigger
This Auto Close starts counting down as soon as the Photoelectric Beam has been cleared after a trigger,
when the gate is in the Pedestrian Access position. If there is no Photoelectric Beam trigger the gate will
remain in Pedestrian Access position.
2.4 Pedestrian Access Auto Close on Sequential Obstructions
If the Pedestrian Access Auto Close is set and the gate closes onto an object the gate will stop and
reopen. This setting sets the amount of times the gate will try to Auto Close. After trying for the set limit
the gate will remain open. When turned OFF, the gate will always try to Auto Close.
2.5 Pedestrian Access with Hold Gate
If the Pedestrian Access hold gate is ON and the Pedestrian Access input is permanently activated the
gate will remain open in the Pedestrian Access position. Open input, Close input, Push Button input and
remote controls are disable. Used in Fire Exit applications.
Menu 3 – Input Functions
This allows you to change the polarity of Photoelectric Beam, Limit Switch and Stop inputs.
Menu No. Input Functions Factory
Default Adjustable
3.1 Photoelectric Beam Polarity Normally Closed Normally Closed /
Normally Open
3.2 Limit Switch Polarity Normally Closed Normally Closed /
Normally Open
3.3 Stop Input Polarity Normally Open Normally Closed /
Normally Open
3.4 Exit
14 Gate & Door Controller with Eclipse®Operating System (EOS)

The Photoelectric Beam or sensor is a safety device which is placed across the gate and when the beam is
obstructed it stops a moving gate. The operation after the gate stops can be selected in this menu.
Menu No. Photoelectric
Beam Feature
Factory
Default Adjustable
4.1 Photoelectric Beam PE Beam stops and opens
gate on close cycle
PE Beam stops and opens
gate on close cycle
------------------------------------
PE Beam stops gate
on close cycle
------------------------------------
PE Beam stops gate
on open & close cycle
------------------------------------
PE Beam stops and closes
gate on open cycle
4.2 Exit
The factory default for the PE beam input is “normally closed” but this can be changed to normally open in
Menu 3.1.
Elsema Pty Ltd recommends a Photoelectric Beam to be connected to the control card when any of the Auto
Close options are used.
Elsema sells different types of Photoelectric Beams. We stock Retro-Reflective and Through Beam type
Photoelectric Beams.
PE24
(Through-Beam type)
Menu 4 – Photoelectric Beam
PE1500
(Polarised Retro-Reflective Type)
15www.elsema.com

The control card has two outputs, Output 1 and Output 2. The user can change the function of these
outputs to lock / brake, courtesy light, service call, strobe (Warning) light or gate open (gate not fully
closed) indicator.
Output 1 is a relay output with common and normally open contacts. Factory default is lock / brake
release function.
Output 2 is an open collector output. Factory default is courtesy light function.
Menu No. Output
Function
Factory
Default Adjustable
5.1 Output 1 Lock / Brake
Lock / Brake
------------------------------------
Courtesy Light
------------------------------------
Service Call
------------------------------------
Strobe (Warning) Light
------------------------------------
Gate Open
5.2 Output 2 Courtesy Light
Lock / Brake
------------------------------------
Courtesy Light
------------------------------------
Service Call
------------------------------------
Strobe (Warning) Light
------------------------------------
Gate Open
5.3 Exit
Menu 5 – Output Functions
16 Gate & Door Controller with Eclipse®Operating System (EOS)

Lock / Brake Output
The factory default for output 1 is lock/ brake release. Output 1 is a voltage-free relay contact with
common and normally open contacts. Having it voltage-free allows you to connect either 12VDC/AC,
24VDC/AC or 240VAC to the common. The normally open contact powers the device. See diagram below:
Courtesy Light
The factory default for the courtesy light is on output 2. Output 2 is an open collector output. This output
is used to switch an external relay such as Elsema’s REL12-1 which can be purchased separately. See
diagram on the next page.
Relay
Open Close Stop
12VDC/AC
24VDC/AC or
240VAC Supply
+ if DC
Output 1 C Output 1 NO
- if DC
Lock/Brake
17www.elsema.com

Service Call Output
Either output 1 or output 2 can be changed to service call indicator. This will trigger the output when the
software service counter is reached. Used to alert installers or owners when the gate is to be serviced.
Using Elsema’s GSM receiver allows installers or owners to get a SMS message and a call when the
service is due.
Strobe (Warning) Light when Opening or Closing
The relay output is activated whenever the gate is operating. The factory default is Off. Either output 1 or
output 2 can be changed to strobe (Warning) light.
Relay
Stop
Master
Control
Output C
Output NO
Output NC
REL12-1
REL12-1 available
separately
Output 2
Gate Open
The relay output is activated whenever the gate is not fully closed. The factory default is Off. Either
output 1 or output 2 can be changed to gate open.
18 Gate & Door Controller with Eclipse®Operating System (EOS)

Menu 6.1 – Lock / Brake Output Modes
The relay output in the lock / brake mode can be configured in different ways.
Menu No. Lock / Brake Modes Factory
Default Adjustable
6.1.1 Open Lock / Brake Activation 2 seconds 1 – 30 seconds
or hold
6.1.2 Close Lock / Brake Activation Off 1 – 30 seconds
or hold
6.1.3 Open Pre-Lock / Brake Activation Off 1 – 30 seconds
6.1.4 Close Pre-Lock / Brake Activation Off 1 – 30 seconds
6.1.5 Exit
6.1.1 Open Lock / Brake Activation
This sets the time the output is activated in the
open direction. Factory default is 2 seconds.
Setting it to Hold means the output is activated for
the total travel time in the open direction.
6.1.2 Close Lock / Brake Activation
This sets the time the output is activated in the
close direction. Factory default is off. Setting it
to Hold means the output is activated for the total
travel time in the close direction.
6.1.3 Open Pre-Lock / Brake Activation
This sets the time the output is activated before
the motor starts in the open direction. Factory
default is Off.
6.1.4 Close Pre-Lock / Brake Activation
This sets the time the output is activated before
the motor starts in the close direction. Factory
default is Off.
Menu 6 – Relay Output Modes
19www.elsema.com

Menu 6.2 – Courtesy Light Output Mode
The relay output in the courtesy mode can be adjusted from 30 to 300 seconds. This sets the time the
courtesy light is activated. Factory default is 60 seconds.
Menu No. Courtesy Light Mode Factory
Default Adjustable
6.2.1 Courtesy Light Activation 60 seconds 30-300 seconds
6.2.2 Exit
Menu 6.3 – Strobe (Warning) Light Output Mode
The relay output in the strobe (Warning) mode can be configured in different ways:
Menu No. Strobe (Warning) Light Mode Factory
Default Adjustable
6.3.1 Pre-Open Strobe (Warning)
Light Activation Off 1 – 30 seconds
6.3.2 Pre-Close Strobe (Warning)
Light Activation Off 1 – 30 seconds
6.3.3 Exit
6.3.1 Pre-Open Strobe Light Activation
This sets the time the strobe light is activated before the gate operates in the open direction. Factory
default is Off.
6.3.2 Pre-Close Strobe Light Activation
This sets the time the strobe light is activated before the gate operates in the close direction. Factory
default is Off.
20 Gate & Door Controller with Eclipse®Operating System (EOS)
