PowerWasher PW2600 User manual

POWERWASHER .
2600PSI GASOLINE
PRESSURE WASHER
MODEL# PW2600
READ AND SAVE THESE INSTRUCTIONS
Questions, problems, missing parts? Before return i ng to yo ur retailer,please contact our
customer service department at 1-877-FNA-GAS1 (1-877-362-4271)
This product iscovered by US patents and other internat ional patents.
Copyright. All Rights Reserved.
Rev .O 7/09

2
TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
Specifications ...........................................................................................................................
Safety Information ....................................................................................................................
Carton Contents ....................................................................................................................
Assembly Instructions ............................................................................................................
Operating Instructions ........................................................................................................
Maintenance ........................................................................................................
End of Use and Storage Instructions ....................................................................................
Trouble Shooting Guide .......................................................................................................
Accessories ...................................................................................................................
Repairs ..............................................................................................................................
Warranty ..........................................................................................................................
2
5
16
16
17
25
30
33
36
36
37
Max. pressure *
Water flowrate*
Engine
Pump
High pressure hose
Pressure of inlet water
Inlet water
2600 PSI
2.1 GPM
173cc OHV
Axial cam
25 ft
20 - 100 PSI
Cold tap water
* Ratings determined in accordance with PWMA. Standard PW101.
Engine Specifications ............................................................................................................... 3

3
ENGINE SPECIFICATIONS
F07P1ledoM
VHO,gnilooCriAdecroF,ekortS-4,rednilycelgniSepyT
Max. power(kW/3600rpm) 4.0
Max. torque (N·m/rpm) 9.8/2500
Fuel consumption (g/kW·h) 395
Idle speed 1800±150 rpm
Bore X Stroke(mm) 70x45
Displacement(cc) 173
1:8oitaRnoisserpmoC
hsalpSedomgnitacirbuL
tratslioceRedoMgnitratS
)edis.O.T.Pmorf(esiwkcolc-itnAnoitatoR
Valve Clearance Input valve：0.10 ±0.02mm, output valve ：0.15±0.02mm
”130.0–820.0ROmm8.0~7.0ecnaraelcgulpkrapS
noitingIotengamdezirotsisnarTedoMgnitingI
retlifmaoF,htabliO,yrd-imeSrenaelcriA
Dimension(L×W×H)(mm) 470*390*380
Net weight (kg) 13.7

ENGINE SPECIFICATIONS
Serial Number Location
ENGINE TYPE
SERIAL NUMBER
Reco rd the engi ne serial n um ber in the space bel ow . You will need th is se rial n um ber when
or
der i ng parts, a nd when mak ing techni ca l or war ra nt y i nq uires.
En gi ne se rial nu mb er:
Maintenance
Fo ll ow the mai nte nance schedule. Re member th at th isschedule isbased on the ass umption that
yo ur m ac hine will be u sed fo r its desi gned purpose. Su sta ined hi gh- load or high-tempera tu re
operation,or use in unusually
wet or du sty condition s, will require more fr equent service.
Engine Tune-up
ITEM SPECIFICATION
Spark plug gap
0.028-0.031 in
(0.70-0.80 mm)
Va lve cl ea rance
IN :0.10 ±0.02 mm (cold)
EX :0.15 ±0.02 mm (cold)
O
th er speci ca tions No other adjustments needed
Quick Reference Information
En gi ne Oil Type
SAE 1OW-30,A PI SE or SF, f or general use
Capaci
ty
1 P6 1 FA ,1P 65FA:
0.55L(0.146US Ga l, 0.1 191mp Ga l)
1 P68FA, 1 P70F ,1P70 FA: 0. 6L (0 .1 6US Ga l,0.13mp Ga l)
Spa rk Plug Type F7
RT Cor o th erequi va lents.
Gap 0.028 - 0.031 in (0.70 -0.80 mm)
Ca rburetor Idle speed 1800
±1 50 rpm
Eac h u se Checkengine oi l. Check air Ite r.
Maintenan ce
First 5 hou rs Changeengi ne oil.
S ub seq u ent Refer to the maintenan ce
4

A SAFETY INFORMATION
Please read and understand this ent ire manual before attempting to assemb l e, operate or i ns ta ll
the product. Ifyou have any questions regardi ng the product, please contact our customer service
department at 1-877-FNA-GAS1 (1-877-362-4271).
SAFETY GUIDELINES -DEFINITIONS
This ma nual contains information that is important for you to know and under -
stand. This information relates to protecting YOUR SAFETY and PREVENTING
EQUIPMENT PROBLEMS . To help you recognize this information, we use the
symbols below. Please read the manual and pay attention to these symbols.
A DANGER: Indicates an immi-
nently hazardous situ-
a
ti on which, if no t avoided, will result
in death or serious injury.
A WARNING: Indicates a potentially
hazardous situation
which,
if no t avoided, could result in
death or serious in
ju ry.
A CAUTION: Indicates a potentia
ll y
hazardous situation
which,
if not avoided, may result in
minor or moderate in
ju ry.
CAUTION: Used without the
safety alert symbol
indicates a potentia ll y hazardous situ-
ation which,
if not avoided, may result
in property damage.
A WARNING: This
product may not be equipped with a spark arrest-
ing muffler. If the product is not equipped and will be used
around flammable materials,
or on land covered with materials such as
agricultural
crops , forest , brush , grass, or other similar items, then an
approved
spark arrester must be installed and is legally required in the state
of California. It is a violation of California statutes section 130050 and/ or
sections 4442 and 4443 of the California Public Resources Code, unless the
engine is equipped with a spark arrester, as defined in section 4442, and
maintained
in effective working order. Spark arresters are also required on
some U.S. Forest Service land and may also be legally required under other
statutes and ordinances.
AWARNING: This product contains chemicals, known to the State of
Ca li fornia to cause cancer, and birth defects or other repro -
ductive harm. Wash han
ds after handling.
IMPORTANT SAFETYINSTRUCTIONS
A WARNING: Do
no t operate this unit until you have read and understand
this Operators Manual and the Engine Owners Manual for
Safet
y, Operation, and Maintenance Instructions.
READ AND SAVE THESE INSTRUCTIONS
A DANGER: RISK OF EXPLOSION OR FIRE
WHAT CAN HAPPEN
• Spilled gasoline and it's vapors
can become ignited from ciga -
rette sparks, electrical arcing,
exhaust gases and hot engine
components such asthe
muf-
fl er.
HOW TO PREVENT IT
•
Sh ut off engine and a ll ow it to cool
before adding fu el to the tank.
• Use care in filling tank to avoid spilling
fuel. Move pressure washer away from
fueling ar ea before starting engine.
5

A SAFETY INFORMATION
Please read and un de rstand this ent ire manual before attempting to assembl e, operate or insta ll
the product. If yo u have any questions regarding the product, please contact our customer service
department
at 1-877- FN A-GAS1 (1-877-362-4271).
• Heat will expand fuel in the
tank which could result in spill-
age and possible fire explosion.
• Operating the pressure washer
in an explosive environment
could result in a fire.
• Materials placed against or
near the pressure washer can
interfere with its proper ventila-
tion fe atures causing overheat-
ing and possible igmtion
of the
materials.
• Muffler exhaust heat can dam-
age painted surfaces, melt any
material sensitive to heat (such
as siding, plasti
c, rubbe r, vinyl,
or the pressure hose itself), and
damage live plants
• Improperly stored fuel could
lead to accidental ignition. Fuel
improperly secured could get
into the hands
of children or
other unqualified persons.
• Use of acids, toxic or corrosive
chemicals, poisons, insecticides,
or any kind of flammable solvent
with this product could result in
serious injur or death.
• Fill tank to 1/2" (12.7mm) below bottom
of filler neck to provide space for fuel
ex ansi on.
• Operate and fuel equipment in well-
vent
il ated areas free from obstructions.
Equip areas with fire extinguishers suit-
able for gasoline fires.
• Never operate pressure washer in an
area containing dry brush or weeds.
• Always keep pressure washer a mini-
mum of 4' (1.2m) away from surfaces
(such as houses, automobiles, or live
plants) that could be damaged from
muffler exhaust hea t.
• Store fuel in an OSHA-approved
container, in a secure location away
from the work area.
• Do not spray flammable liquids.
A DANGER: RISK TO BREATHING (Asphyxiation)
WHAT CAN HAPPEN
• Breathing exhaust fumes wi ll
cause serious injury or death!
Engine exhaust contains car-
bon monoxide, an odorless and
deadly gas.
• Some cleaning fluids contain
substances wnich could cause
injury to skin, eyes, or lungs.
HOW TO PREVENT IT
• Operate Pressure washer in a well-
vent
il ated area. Avoid enclosed areas
such as garages, basements, etc.
• Never operate unit in a location occu-
pied by humans or animals.
• Use only cleaning fluids specifically
recommended for high-pressure wash-
ers. Fa
ll ow manunfacturers
recommendations. Do not use chlorine
bleach or any other corrosive compound
6

A SAFETY INFORMATION
Please read and understand this entire manual before attempting to assembl e, operate or install
the product. If you have any questions regardi ng the product, please contact our customer service
department at 1-877-FNA-GAS1 (1-877-362-4271).
A DANGER:
RISK OF FLUID INJECTION AND LACERATION
WHAT CAN HAPPEN
•Your pressure washer operates
at fluid pressures a nd veloci-
ties high enough to penet ra te
human and animal flesh, which
could result in amputation or
other serious injury.
Lea ks
caused by loose fittings or
worn or damaged hoses can
fesult in injection injuries. DO
NOT TREAT FLUID INJEC
TI ON
AS A SIMPLE CUT! See a phy-
sician immediately!
•Injuries can result if system
pressure is not reduced before
attempting maintenance or
disassembly.
HOW TO PREVENT IT
•Ins pect the high-pressure hose regular-
ly. Replace the hose immediately if it is
damaged, worn,
ha s melted from con-
tacting the engine, or shows signs of
crack
s, bubble s, pinholes, or other
leakage. Never grasp a high-pressure
hose that is leaking or damaged.
•Nevertouch, grasp, or attempt to cover
a pinhole or similar water leak on the
high pressure hose. The stream
of
water IS under high pressure a nd WILL
penetrate sk in .
•Never place hands in front of nozzle.
•Direct spray away from se
lf and others.
•Make su re hose a nd fittings are tight-
ened and in good condition. Never
hold onto the hose or fittings during
operation.
•Do not allow the hose to contact muffler.
•Never attach or remove wand or hose
•To relieve system pressure, shut off
engine, turn off water supply and pull
gun trigger until water stops flowing.
•Use only hoses and accessories rated
for pressure higher than your pressure
washer's psi.
A DANGER:
RISK OF INJURY FROM SPRAY
WHAT CAN HAPPEN
• High-velocity fuild spray can
cause objects to br
ea k, propel-
ling particles
at high speed.
• Light or un secured objects can
become hazardous projectile
s.
HOW TO PREVENT IT
.Always wear ANSI-approved Z87 .1
safety glasses. Wear protective clothin
to protect against accidental sp ra y in g.
• Never point wand at or spray people or
animals.
•Always secure trigger lock when wand
is not
in service to prevent accidental
operation.
• Never permanently secure trigger in
pull-back (open) position.
7

A SAFETY INFORMATION
Please read a nd understand this entire manual before attempti ng to assemble, operate or in sta ll
the product. Ifyou have any questions regarding the product, please contact our customer service
department at 1-877-FNA-GAS1 (1-877-362-4271).
A DANGER:
RISK OF UNSAFE OPERATION
WHAT CAN HAPPEN
• Unsafe operation of your press-
ure washer could lead to seri-
ous injury or death to you or
others.
• If proper starting procedure is
not followed, engine can kick-
back
ca using serious ha nd and
arm injury.
•The spraygun/wand is a power-
ful cleani ng tool that could look
like a toy to a
ch ild.
•Reactive force
of spray wi ll
cause gun/wand to kick-back,
and could
ca use the operator to
slip or fall, or misdirect the
spray. Improper control
of gun/
wand can result in injuries to
se lf and others.
HOW TO PREVENT IT
• Do not use chlorine bleach or any other
corrosive compound.
• Become familiar with the operation and
controls of the pressure washer.
• Keep operating area clear of all
persons, pets, and obstacles.
• Do not operate the product when
fatigued or under the influence
of alco-
hol or drugs. Stay alert
at all times.
• Never defeat the safety features of this
product.
• Do not operate machine with missi ng ,
broken, or unauthorized parts.
• Never leave the wand unattended
while the unit is running.
•If engine does not start after two pulls,
squeeze trigger of gun to relieve pump
pressure. Pull started cord slowly until
resistance is fel t. Then pull cord rapidly
to avoid ki ck-back and prevent hand or
arm injury.
• Keep children away from the pressure
washer at all times.
.Do not overreach or stand on an
un stable suppor t.
•Do not use pressure washer while
standing on a ladder.
•Grip gun/wand firmly with both ha
nd s.
Expect the gun to kick-back when
triggered.
8

A SAFETY INFORMATION
Please read and understand t hi s entire manual before attempting to assembl e, operate or install
the product. If you have any questions regarding the product, please contact our customer service
department at 1-877-FNA-GAS1 (1-877-362-4271
).
.A DANGER:
RISK OF INJURY OR PROPERTY DAMAGE WHEN
TRANSPORTING OR STORING
WHAT CAN HAPPEN
•Fue l or oil can leak or spi ll and
could result in fire or breathing
hazard. Serious injury
or death
can result. Fuel
or oil leaks will
damage carpet, paint, or other
surfaces in vehicles or trailers.
HOW TO PREVENT IT
•If pressure washer is equipped with
a fuel shut-off valve, turn the valve
to
the OFF position before transporting to
avoid fuel leaks. If pressure washer
is not equipped with a fuel shut-off
valve, drain the fuel from tank before
transporting. Only transport fuel
in an
OSHA-approved container. Always
place pressure washer on a protective
mat when transporting
to protect
against damage to vehicle from leaks.
Remove pressure washer from vehicle
immediately upon arrival at destination.
.A WARNING:
RISK OF BURSTING
WHAT CAN HAPPEN
•Over inflati on of tires could
result in serious injury and
property damage.
• High Velocity fuid spray directed
at pneumatic sidewalls
(such as found on automobiles,
trailers, and the li
ke) could dam-
age the sidewall resulting in
serious injury.
HOW TO PREVENT IT
•Use a tire pressure gauge to check the
tire pressure before each use and while
inflating tires; see the tire sidewall for the
correct tire pressure.
NOTE:Air tanks, compressors, and
similar equipment used to inflate tires
can fill small tires similar to these very
rapidly. Adjust pressure regulator on air
supply to no more than the rating of the
tire pressure. Add
ai r in small increments
and frequently use the tire gauge
to
prevent over inflation.
• On pressure washer rated above 1600
psi ( 11 0 Bar) usethe widest fan spray
(40° nozzle) and keep the spray a mini-
mum
of 8" (20cm) from the pneumatic
tire sidewa
ll. Do not aim spray directly
at the joint between the tire and rim.
.A WARNING:
RISK OF HOT SURFACES
WHAT CAN HAPPEN
• Contact with hot surfaces, such
as engine exhaust components,
could result in serious burn.
HOW TO PREVENT IT
• During operation, touch only the control
surfaces of the pressure washer.
Keep children away from the pressure
washer at all times. They may not be
able to recognize the hazards of this
produc
t.
9

A SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemb l e, operate or install
the product. If you have any questions regarding t he product, please contact our customer service
department at 1-877-FNA-GAS1 (1-877-362-4271).
A WARNING: RISK OF CHEMICAL BURN
WHAT CAN HAPPEN
• Use ofacids, toxic or corrosive
chemical s, po isons, insecti-
cides, or any kind offlammable
solvent with this product could
result in serious injury or death.
HOW TO PREVENT IT
• Do not use acids, gasoline, kerosene,
or any other flammable materials in this
product. Use only household deter-
gents, cleaners and degreasers recom-
mended for use in pressure washers.
• Wear protective clothing to protect
eyes and sk
in from contact with
sprayed materials.
A WARNING: RISK OF ELECTRICAL SHOCK
WHAT CAN HAPPEN
• Spray directed atelectrical out-
lets or switches, or objects con-
nected to an electrical circui
t,
could result in a fatal electrical
shock.
HOW TO PREVENT IT
• Unplug any electrica
ll y operated prod-
uct before attempting to clean it. Direct
spray away from electric outlets and
sw itches.
AWARNING: RISK OF INJURY FROM LIFTING
WHAT CAN HAPPEN
• Serious injury
ca n result from
attempting to lift too heavy an
object.
HOW TO PREVENT IT
• The pressure washer is too heavy to be
lifted by one person. Obtain assistance
from others before lifting.
RE AD AND SAVE THESE IN STRUC TI ONS
10

A SAFETY INFORMATION
IAI WI
BEFORE OPERATING ENGINE
•
Rea d entire Operating &
Ma intenance In st ructions AND the
instructionsfor the
eq uipment th is enginepowers.
•
Fail ure to follow instructions could res ult in ser ious injury
or death.
THE OPERATING & MAINTENANCE INSTRUCTIONS CONTAIN
SAFETY INFORMATION
TO
• Make
you aware of hazards associated with eng ines
•
Inf orm you of the risk of i njury associated with those hazards, and
• Tell
you how to avoid or reduce the risk of injury .
The safety
alert symbol ( A )is used to ident ify safety i nformation about hazards that can
result in personal ir}jury.
A signal word (WARNING, DANGER. or CAUTION) is used with the alert symbol to i ndicate the
l ikelihood and the potent ial severi ty of ir}jury. In add ition, a hazard symbol may be used to
represent the type of hazard.
A yY~RNING indicates a hazard wh ich, if not avoided, will result in death or serious
- InjUry.
DANGER i nd icates a hazard which , if not avoided, could result in death or serious
injury.
CAUTION ind icates a hazard wh ich, if not avoided, might result in minor or moderate
injury.
When used wi thout the alert symbo l, i nd icates a si tuat i on that cou ld result in damage to
the eng ine.
WARNING A
The engine exhaust from this product contains
chemicals known to the State of Ca li forn ia to cause
cancer,
birth defects, or other re productive harm .
CAUTION:You should carefully read and understand the operating instructions for the
PW2600 Pressure Washer.
THE INTERNATIONAL SYMBOLS USED ON
THE ENGINE OR IN THIS MANUAL IN CLUDE :
11

A SAFETY INFORMATION
H AZARD SYMBOLS AND MEAN IN GS
Ex p losio n Fire
~- ... ~
r* ~
g~- - fp
..,..
T ox ic Fu m es
Moving Par ts K ic kb ac k H ot Su rface Shock
12

A SAFETY INFORMATION
IMPORTANTSAFETY INFORMATION
Most acc idents with engines can be prevented if you follow all instructions in this manual
and on the engine. Some of the most common hazards are discussed below, along with the
best way to protectyourself and others.
Owner Responsibilities
• The engines are designed to give safe and dependable service if operated according to
instructions. Read and understand this owner'smanual before operating the engine. Failure
to do so could result in personal injury or equipment damage.
• Know how to stop the engine quickl y, and understand the operati on of all controls. Never
permit anyone to operate the engine without properinstructions.
• Do not allow children to operate the engine. Keep children and pets away from the area of
operation. A WARNING
Fi r e ExpI os ion
Gasoline and its vapors are extremely flammable and
explosive.
Fire or explosion can cause severe burns or death.
WHEN ADDING FUEL
• Turn engine OFF and l et engine cool at least 2 minutesbefore removing gas cap.
• Fill fueltankoutdoors or in well-ventilated area.
• Do not over II fuel tank. Fill tank to approximately 1-1/2 inches below top of neck to
allowforfuel expansion.
• Keep gasoline away fr om sparks, open ames, pilot lights, heat. and other i gnit ion
sources.
• Check fuel lines, tank, cap, and ttings frequently for cracks or leaks. Replace if
necessary.
WHEN STARTING ENGINE
• Make sure spark plug, mu er, fuel capand air cleaner are in place.
• Do not crank engine with spark plug removed.
• If fuel spills, wait until it evaporates beforestarting engi ne.
• If engine oods, set choke to OPEN position, place ON / OFF switch in
ON position and crank untilenginestarts.
WHEN OPERATING EQUIPMENT
• Do not tip engine or equi pment at angle wh ich causes gasoline to spil l.
• Do not choke carburetor to stop engine.
WHEN TRANSPORTING EQUIPMENT
• Transport with fuel tank EMPTY or with fuel shut-o va lve OFF.
WHEN STORING GASOLINE OR EQUIPMENT WITH FUEL IN TANK
• Store awayfrom furnaces, stoves, water heaters or other appliances that have pi lot
li ght orother i gnit ion source because theycan ignitegasolinevapors.
13

A SAFETY INFORMATION
A WARNING
Starting engine creates sparking.
Fire Exp los ion
Sparking can ignite nearby flammable gases.
Explosion and fire could result.
e lf there is natural or gas leakage in area, do not startengine.
• Do not use pressurized starting uids because vapors are ammable.
Kickback
A WARNING
Rapid retraction of starter cord (kickback) will pull hand and
arm toward engine faster than you can let go.
Broken bones, fractures, bruises or sprains could result.
• When starting engine, pull cord slowly until resistance isfelt, then pull rapidly.
• Remove all external equipment/eng ine loadsbefore starting engine.
• Direct coupled equi pment components such as, but not limited to, blades, impellers,
pulleys, sprockets, etc.,
must be securely attached.
Toxi c Fumes
A WARNING
Engines give off carbon monoxide, an odorless, colorless,
poison gas.
Broken bones, fractures, bruises or sprains could result.
• Startand run engi ne outdoors.
• Do not start or run engine enclosed area, even if doors or windows are open.
Moving Parts
A WARNING
Rotating parts can contact or entangle hands, feet, hair, clothing
or accessories.
Traumatic amputation or severe laceration can result.
• Operate equi pment with guards inplace.
• Keep handsand feet away
from rotating parts.
• Tie up long hairand remove jewelry .
• Do not wear loose- tt i ng clothing, dang ling drawstrings or items that could become
caught.
14

A SAFETY INFORMATION
=-w
,,1Jflllnhhhh
Fire Hot Surface
A WARNING
Running engines produce heat. Engine parts,
especially muffler, become extremely hot.
Severe thermal burns can occur on contact.
Combustible debris, such as leaves, grass, brush,
etc. can catch fire.
• Allow mu er, enginecylinderand ns to cool before touching .
• Remove accumulated combustibles from mu erarea and cylinderarea.
Mov ing Parts Shock
Fire
A WARNING
Unintentional sparking can result in fire or electric
shock.
Unintentional start-up can result in entanglement,
traumatic amputation, or laceration.
BEFORE PERFORMING ADJUSTMENTS OR REPAIRS
• Disconnectspark plug wire and keep it away from spark plug.
• Disconnect battery
at negative termi na l (onlyengineswi th electric start).
WHEN TESTING FOR SPARK
• U se approved spark plug tester.
• Do not check for spark with spark plug removed.
15

CARTON CONTENTS
NOTE: Photograp hs and line drawings used in this ma nual are for reference only
and do no t represent a specific mode l.
• Operation
Manual
Engine Frame
and Wheel Engine I
Assembly Manual
eSprayGun
0
Chemical
Hose
Bagged Parts
' '.
I
" ? ~
Nozzle
Cleaning
Tool
/~ - - - --- -- - - - - ---- -- - --
.
High Pre ss ure
Hose '-· = -
ASSEMBLY INSTRUCTIONS
M ult i-Ad ju stable
Spray Wand
1. Locate and remove all loose
parts from the carton.
2. Cut four cornersof the carton
from top to bottom and lay the
panels fl at.
3. Place handle onto
frame , depress the
snap buttons, and
slide the handle
assembly onto the
frame until snap
buttons snap into
place.
Handle
u
A CAUTION: Risk of personal
injury. Avoid plac-
ing han ds between handle and
frame when assembling to prevent
pinchin
g.
4. Connect wand to gun.Tighten
securel y.
5. Attach high
pressure hose to
gun. Tighten
secur ely.
16

A CAUTION:
Engine shipped without oil. Before starting engine,
fill with oil provided. If you start the engine
without oil, the engine will be damaged beyond
repair and will not be covered under warranty.
NOTE: T he pump on this unit is
maintenance free and requir
es no oil.
If there is a problem with the pu mp
contact an Aut ho rized Service Center.
OPERATING INSTRUCTIONS
Compare the illustrations with your unit to familiarize yourself with the location of
various controls and adjustments. Save this manual for future reference.
Engine
BASIC ELEMENTS OF A
PRESSURE WASHER
High Pressure Pump: Increases the
pressure
of the water sup ply.
Engine: Drives the high pressure
pump.
High Pressure Hose: Carries the pres-
surized water from the pump to the
gun and spray wand.
Hi gh
Pressure
Hose
Multi-Adjustable
Spray Wand
Spray Gun: Connects with spray wand
to control water flow rate, direction,
and pressure.
Multi-Adjustable Spray Wand: Allows
the user to use high or low pressure and
adjusts from a penc
il stream (0 °) to a wide
angle fan spray (40°). See How To Use Wand
instructions in this section.
Chemical Hose (not shown): Feeds
cleani ng agents in to the pump to mi x
with
th e water. See How To Apply
Chemicals/Cleaning Solvents instruc-
ti ons in this section.
17

BASIC ELEMENTS OF AN
ENGINE
STARTER GRIP
FINGER GUARD
MUFFLER
CARBURETOR
FUEL
TANK CAP
OIL FILLERCAP/
DISPTICK
FUEL TANK
AIR CLEANER
1P68FA,1P70F,1P70FA
FINGER GUARD
MUFFLER
1
P61 FA , 1P65FA
18

PRESSURE WASHER
TERMINOLOGY
ps i: Pounds per Square Inch. The unit
of measure for water pressure. Also
used for air pressure, hydraulic pre s-
sur e, etc.
GPM: Ga
ll ons Per Minute. The unit of
measure for the flow rate of water.
CU: Cleaning Unit s. GPM multiplied
by psi. GPM x psi = CU
Byp ass M ode : Allows water to
re -c irculate within pump when the gun
trigger is n
ot pulled.
CAUTION: Allowing the unit to
run for more than
two minutes without the gun trigger
pulled could cause overheating and
damage to the pump.
Th ermal Re li ef Val ve (not shown)
When the temperature insi
de the
pump
ri ses too high the valve will
open and release a gush of water in
an effort to lower the temperature
inside the pump. The valve will then
close.
Ch e mi cal Inj ectio n Sy ste m: Mixes
cleaners or cleaning solvents with
the water to improve cleaning
effectiveness.
W
ater Sup p ly : All pressure washers
must have a
so urce of water. The min-
imum requirements for a water supply
are 20 psi and 5 ga ll ons per minute.
PRESSURE WASHEROPERATING
FEATURES
P ress ure Adju st men ts
The pressure setting is preset at the fac-
tory to achieve optimum pressure and
cleaning. If you need to lower the pres-
sur e, it can be accomp li shed by the se
methods.
1. Back away from the surface to
be cleaned. The further away you
are, the less the pressure will
be on
the surface to be cleaned.
2. Rotate the nozzle at the end of
the multi-adjustable spray wand
to w
id en the fan spr ay.
19
The wider fan sprayw ill minimize
the pressure
on the surface to
be cleaned.

HOW TO USE SPRAY WAND
You r pressure wash er is equipped
with a multi-adjustable spray wand
with both high and low pressure.
setting
s. The high pressure sett1 ng
is for cleaning and rinsing, the low
pressure setting is _for applxi ng
chemicals or clean1ng solut 1ons to
surfaces.
A DANGER
Risk of fluid
injecti
on. Do not
directdischarge stream toward
persons, unprotected ski.n,
exe~ or
any pets or animal
s. Senous I nJ ury
will occur.
For high pressure operation,
pu ll back
the noz
zl e of the multi-adjustable
spray wand as shown.
The nozzle at the end
of the multi-
adjustable spray wand can be rotated
to change the high pressure spray
pattern from a 0° pencil stream
to a
40° fan spray, as shown. Markings
have been placed on the nozzle to
help you select the spray pattern.
1~ -: ~
:~:.-- -- ---
For low pressure operation, extend
the nozzle
of the multi-adjustable
spray wand as shown.
CAUTION= The
powerful
spray from your
pressure washer is capable of
c ausing damage to surfa ces such
as wood, glass, automobile pa.int,
auto striping and trim , and delicate
objects such as flowers and shrubs.
Before spraying , check the item to
be cleaned to assure yourself that it
is strong enough to resist damage
from the force of the spray .
How to Apply Chemicals / Cleaning
Solvents
Applying chemi ca ls or clean i n~ sol-
vents is a low pressure operat1on.
NOTE: Use only soaps and chemicals
designed for pressure washer use. Do
not use bleach.
To Apply chemicals:
1. Press chemical
hose onto
barbed fitting
located near high
pressure hose
connection of
pump as shown.
2. Place other end of chemical hose
with filter on it into container hol
d-
ing chemical/cleaning solution.
NOTE: For every 7 ga ll ons of
water pumped 1 gallon
of chemi-
cal/cleaning sol ut ion will be used.
3. Set multi-adjustable nozzle to
low pressure setting. See How
To Use Wand paragraph in this
secti
on.
4. After use of chemicals, place
chemical hose into container of
clean water and draw clean water
through chemical injection
20
system to rinse system
thoroughly. If chemicals remain
in the pump it could be
damaged. Pumps damaged
due
to chemicals will not be
covered under warranty.
