BCP SKY5306 User manual

SKY5306
Ver. 1
INSTRUCTION
MANUAL
1800-Watt Electric
Pressure Washer

Before spraying on
intended surface, test spray
in an area free of people
and objects.

WOOD/VINYL
DECK
CARS, BOATS,
MOTORCYCLES
GRILLS, EQUIPMENT,
TOOLS
CEMENT PATIO,
STONE, BRICK
• PRESSURE: Dispense soap on low, rinse on high
• DISTANCE: 6-9 inches away
• SPRAY PATTERN: Fan, left to right, top to bottom
• NOTES: Increase distance on softer woods or if using
direct spray
• PRESSURE: Dispense soap on low, rinse on high
• DISTANCE: 3-6 inches away
• SPRAY PATTERN: Fan, sweeping motion
• NOTES: Increase distance if using direct spray
• PRESSURE: Dispense soap on low, rinse on high
• DISTANCE: 8 inches away
• SPRAY PATTERN: Fan, sweeping motion
• NOTES: Increase distance if using direct spray, wipe dry
• PRESSURE: Dispense soap on low, rinse on high
• DISTANCE: 1-3 inches away
• SPRAY PATTERN: Fan
• NOTES: Increase distance if using direct spray
CLEANING TIPS

4|
Please retain these instructions for future reference.
• Machine is not a toy. Keep out of reach of children.
• Do not allow children to operate this item.
• Machine is intended for household use.
• Use machine on a flat and stable surface.
• Do not leave machine unattended while it is running.
• Safety glasses, hearing protection, boots, and gloves should be worn when operating this machine.
• Wear a respirator or mask if there is a risk of inhaling harmful vapors.
• Before plugging machine into wall outlet, make sure the power switch is o. Switch o machine
before unplugging.
• Turn o and unplug machine before assembly, disassembly, or maintenance.
• Ensure that your voltage is consistent with specifications.
• This machine is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the machine by a person responsible for their safety.
• If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made and/or
factory replacement parts are installed.
• Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
NOTICE
• Immediately turn o in the event of an accident or if machine malfunctions.
• Only use your hand to squeeze the trigger; do not jam the trigger in the ON position.
• Do not bend, twist, or fold the high pressure hose.
• Do not operate machine if under the influence of alcohol or drugs.
• Do not use in rain or a damp location.
• Do not direct high pressure jet at other people, animals, electrical equipment, or the machine itself.
• Do not use machine in the vicinity of other people unless they are wearing protective clothing.
• Do not direct high pressure jet at yourself or others to clean clothing/footwear.
• Do not direct water at fire or hot equipment; hot water or steam is dangerous if reflected back.
• Do not use pressure washer to draw water contaminated with solvents (e.g. paint thinners, gasoline,
oil, etc.).
• Do not use pressure washer to draw hot water, non-water, or flammable liquids.
• Do not allow dirt or debris to be drawn into the machine. Make sure to use a clean water source.
• Do not operate machine without water.
• Position machine so exhaust emissions are not in the vicinity of an air intake.
• Do not immerse in water or allow electrical components to touch water.
• Do not handle power cord/plug or touch wall outlet with wet hands.
• Do not unplug the machine by pulling on the power cord. Always grasp the plug firmly and pull straight
out from the outlet.
• Use with an extension cord is not recommended. If using extension cord, make sure plug and cord are
watertight and designed for outdoor use.
• Do not use if the plug or any components are damaged.
• Do not use any accessory or fitting other than original accessories and fittings.
• Keep machine on a flat surface during moving or installation.
• Always use handle to move or transport machine. Do not move machine by pulling on the hose or
power cord.
WARNING

| 5
HARDWARE
1
8 PCS
M4 x 15mm
SCREW
TOOLS REQUIRED
APPROXIMATELY
10 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
PHILLIPS
SCREWDRIVER
SPECIFICATIONS
Rated Pressure
Max Pressure
Max Inlet Pressure
Rated Flow
Max. Flow
Rated Frequency
Rated Power Input
Max Water Temperature
1450 psi
2030 psi
174 psi
6.0 l/min
7.0 l/min
50~60Hz
Rate Voltage 120V
1800 W
Sound Power Level 87 dB
104°F
2
1 PC
PRESSURE
HOSE CLIP

PARTS
1 PC
TOP FRAME/HANDLE
1 PC
HOSE REEL
1 PC
1 PC
SPRAY GUN HOLDER
D
2 PCS
HOSE SUPPORT
AB
F
E
1 PC
HOSE HANGER
HOSE REEL HANDLE
C
1 PC
SPRAY GUN
1 PC
LANCE
1 PC
1 PC
INLET CONNECTOR
J
1 PC
HIGH PRESSURE
HOSE
GH
L
K
2 TYPES
QUICK CONNECTORS
CLEANING PIN
I
6|

| 7
DIAGRAM
LANCE
ADJUSTABLE
NOZZLE
SPRAY GUN
TOGGLE LANCE
ROTATION
WATER PRESSURE
COLLAR
SAFETY BUTTON
SPRAY GUN
HOLDER
TOP FRAME/
HANDLE
HOSE REEL
HOSE
HANGER
POWER CORD
HANGER
HIGH PRESSURE
HOSE
INLET
(WITH CONNECTOR)
OUTLET
SOAP
DISPENSER
ON/OFF
SWITCH
POWER
CORD
ACCESSORY
CLIPS
• TOGGLE LANCE ROTATION: Rotate lance to adjust cleaning angle
• WATER PRESSURE COLLAR: Rotate to adjust water pressure low/high

8|
PRODUCT ASSEMBLY
1
2
Insert two part D hose supports into the part B hose reel.
Insert the part C hose reel handle through the part A top frame and into a hose support. Attach
the hose supports to the top frame with four part 1 screws.
B
Dx2
C
A
1x4

| 9
PRODUCT ASSEMBLY
3
4
Attach the top frame with two part 1 screws.
Attach the part E hose hanger with two part 1 screws.
1x2
1x2
E

10 |
PRODUCT ASSEMBLY
5
6
Slide the part F spray gun holder onto the machine.
Screw the part L inlet connector onto the inlet.
F
L

J
PRODUCT ASSEMBLY
7
8
Insert the part H lance into the part G spray gun and turn it clockwise to lock it in place.
Insert the part J high pressure hose into the spray gun.
G
H
Insert the other end of the high pressure hose into the outlet.
| 11

PRODUCT ASSEMBLY
9
10
Insert the quick connector on the hose into the inlet connector and attach the other side to a
water supply tap.
NOTE: To remove, pull down locking sleeve on the water supply hose and pull from the
inlet connector.
Attach a part K quick connector onto a water supply hose (not included).
NOTE: There are two types of quick connectors (threaded and non-threaded); use the
appropriate connector.
12 |
K
K
THREADED
NON-THREADED

| 13
USAGE TIPS
• Operating area must be clear of all persons.
• Work area should have adequate drainage to reduce the risk of falling due to slippery surfaces.
• Keep sturdy footing and balance at all times; do not overreach or stand on an unstable surface.
• Always hold spray gun and lance with two hands when operating.
• Do not connect machine to a portable water pipe; only connect to a running water supply.
• Machine is not intended to connect to a potable water main.
• Hold nozzle tightly during operation as there may be sudden kickback force.
• Only use specific cleaning agents designed for use with a pressure washer.
• Water that flows through backflow preventers is non-potable.
• Dirt or debris in feed water will damage the machine.
• Use a cold, clean water supply. Do not use with sea water.
• Water supply hose must be at least ¾-inch in diameter.
• Flow rate of water supply must not fall below 6 liters per minute.
• Temperature of water supply must not exceed 104°F.
• Make sure hose connections are tight and secure before operation.
• Do not remove high pressure hose if the machine is still pressurized.
OPERATING INSTRUCTIONS
Before using pressure washer, remove potential hazards and objects that could be tripped over. Ensure all
doors and windows are tightly closed.
1. Plug pressure washer into a wall outlet.
2. Fully open the water supply tap.
3. Release the safety on the spray gun.
4. Lightly press and hold the trigger to expel air and water. Hold trigger until water flows from the gun
(indicating the pump is full).
5. Switch the machine on. Press the trigger to spray water.
NOTE: Be aware of sudden kickback force when spraying water.
ADJUSTING SPRAY PATTERN
• Twist the adjustable nozzle to adjust from a jet spray to a fan spray pattern.
• It is recommended that you begin with a fan spray when cleaning wood decks, siding, vehicles, etc.
• Begin spraying at a 20° spray angle a minimum of 36 inches away to avoid damaging the surface.
• DO NOT adjust nozzle/spray angle while spraying.

SAFETY FEATURES
HOSE REEL
• SAFETY LOCK: Spray gun has a safety lock under the grip. Keep safety lock engaged when machine is
not in use.
• AUTOMATIC ON/OFF: Motor turns on only when the trigger is pressed and the power switch is in the
ON position. If trigger is released, the motor will stop. To completely turn o, turn power switch to OFF.
• OVERLOAD PROTECTION: If pressure is too high, the overload protection function will activate and the
machine will automatically stop operation.
SWITCHING OFF
1. When finished, turn o and unplug the machine.
2. Close the water supply tap.
3. Press trigger to release trapped pressure/water.
4. Remove the water supply hose and high pressure hose.
5. Press trigger to drain residual water. Engage the safety lock on the spray gun.
If machine is not in use, wrap the high pressure hose in the hose reel.
1. Insert one end of the high pressure into the slot in the hose reel.
2. Rotate the hose reel handle until the hose is completely wrapped.
SOAP DISPENSER
1. Lift the plug/straw and remove the soap dispenser
from the machine.
2. Add detergent to the soap dispenser.
- Do not add water; the detergent will mix with
water when spraying at low pressure.
3. Replace the soap dispenser and reinsert the
plug/straw.
4. Turn water pressure collar to low pressure and press
the trigger to spray a mixture of soap and water.
5. Turn water pressure collar to high pressure to spray
water and rinse the soap mixture.
To remove dirt more eectively, add detergent to the soap dispenser. Only use specific cleaning agents
designed for use with a pressure washer.
WARNING: Never use products with bleach or chlorine or any other corrosive materials, including liquids
containing solvents (i.e. gas, oils etc.), tri-sodium phosphate products, ammonia, or acid-based cleaners.
14 |
CLEANING AND MAINTENANCE
• Turn o and unplug the machine before cleaning and maintenance.
• Do the following after every use:
- Wash water hose, high pressure hose, lance, nozzle, and accessories
- Clean connectors of dust and sand
- Rinse soap dispenser
• Dirt in feed water will damage the machine.

TROUBLESHOOTING
REASON
Not plugged in
Inadequate water supply
Defective extension cord
Plug in machine
Make sure water supply meets
requirements, fully open water tap
Pump intaking air, not water
Hose diameter too small
Hose kinked
Inlet blocked Clean inlet
Make sure hoses and connections are tight
Use min. ¾-inch hose
Straighten hose
Try without extension cord
Pump intaking air, not water
Incorrect voltage
Nozzle blocked
Make sure voltage is correct
Clean nozzle
Make sure hoses and connections
are tight
PROBLEM
Machine pulsating
Machine starts but does
not spray water
Machine stops
Fluctuating water pressure
Machine not working
Does not reach adequate
water pressure
SOLUTION
Air in inlet hose
Inadequate water supply
Inlet or nozzle blocked
Spray water until reaches
normal water pressure
Make sure water supply meets
requirements, fully open water tap
Clean inlet or nozzle
Pump/hoses or
accessories frozen
No water supply
Nozzle blocked
Thaw pump/hoses
or accessories
Connect water supply
Clean nozzle
Hose kinked Straighten hose
STORAGE
• Do the following to completely drain machine of water prior to storage:
- Turn o machine and detach water supply hose.
- Turn on machine and press the trigger to expel all remaining water from the machine and spray gun.
Only leave machine on for 2 to 4 seconds.
- Turn o machine and unplug.
• Wind up hoses and cable on the machine. Place spray gun, lance, and accessories in their
designated places.
• Store in a cool, dry place away from direct sunlight and dirt. Do not store in an especially cold or frozen
room (below 32°F).
CLEANING AND MAINTENANCE
• If nozzle clogs, immediately stop machine and clean nozzle.
• If necessary, clean nozzle with provided cleaning pin. Use pin to remove obstructions and flush water
through the nozzle.
• Wipe down exterior of machine. Clear vents of obstructions.
• Regularly grease couplings and collars.
| 15

All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long
as the item is returned in its original product packaging and all accessories from its original shipment are
included. All returned items will receive a full refund back to the original payment method. All returned
items will not be charged a re-stocking fee.
All returned items require an RA (Return Authorization) number, which can only be provided by a Best
Choice Products Customer Service Representative when the return request is submitted. Items received
without an RA may not be accepted or may increase your return processing time. Once an item has been
received by Best Choice Products, refunds or replacements will be processed within 5 business days.
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If
the reason for return is a result of an error by Best Choice Products then Best Choice Products will provide
a pre-paid shipping label via email. Boxes for return shipping will not be provided by Best Choice Products,
and is the customer’s responsibility to either use the original shipping boxes or purchase new boxes.
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items
returned are not considered undamaged until they are received by Best Choice Products and verified as
such. All damages to items are the customer’s responsibility until the item has been received by and
acknowledge by Best Choice Products as undamaged.
PRODUCT WARRANTY INFORMATION
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, or neglect of this product.
HELP CENTER
Product Assembly
Product InquiryChat Support Returns & Refunds
Orders FAQ
WARNING
Question about your product? We're here to help. Visit us at:
help.bestchoiceproducts.com
CHAT
US!
