PQUIP RBR101 User manual
Heavy Duty Small Base Quad Cane
Features
All steel construction
Double height adjustment button to allow for
either left or right handed use
Double plated base for added safety
Secured with locking ring for added safety
Non-slip rubber tips (with metal inserts) ensure a
secure grip
No assembly required
12 months warranty (conditions apply)
Specifications
The Heavy Duty Small Base Quad Cane provides additional stability and support with a four
point cane, and will support a weight capacity of 227kg.
Designed for a heavier person, this cane is made of steel rather than the traditional aluminium.
The cane is height adjustable with a push button (accessible to either a left or right handed
person), and has a locking ring for added safety.
The offset handle is covered by a PVC handgrip and is available in a black powder coated
finish only.
Handle Height: 75cm to 98cm
Base Size: 15cm wide x 20cm deep
Weight Capacity: 227kg
Cane Weight: 1.8kg
Replacement 13mm
Cane Tips.
Product Code
RTIP110BL.
Product Code: RBR101
Double plated base for
added strength
Double button allows the
cane base to be swivelled
around to adapt to a left or
right handed person
Pharmaquip Healthcare - 1/7 Monte Khoury Drive Loganholme Queensland Australia 4129
Heavy Duty Small Base Quad Cane
Pharmaquip Healthcare - 3 Harris Road Underwood Queensland Australia 4129
Cane Height Adjustment
To adjust the cane to the appropriate handle height:
1. Turn the locking ring counter clockwise to loosen the ring.
2. Slide the extension leg to adjust to your required height.
3. Ensure that the snap button is fully protruding through the height adjustment hole. An audible
‘click’ will be heard when the push button has securely locked in the hole.
4. Turn the locking ring in a clockwise motion to secure the cane.
Locking Ring
Snap Button
Care and Maintenance
The following should be checked periodically:
1. Ensure the locking ring is securely tightened.
2. Check the cane tips for wear and tear.
3. Check the handle to ensure it is attached securely.
Measuring a Cane
To find the appropriate handle height:
1. Put on your usual walking shoes.
2. Stand upright with your arms at your side with a normal relaxed bend in your elbow.
3. The cane needs to be adjusted so the top of the handle equals the position of the wrist joint.
This is a general measurement guide. Certain users may have specific conditions that will require them to have the
cane at a different height. Each individual should always consult with their doctor or therapist to determine proper
adjustment and usage.
Using a Cane
Generally, walking sticks are held in the hand opposite to the injured or affected leg, however in some circumstances
it may be appropriate to use the cane on the affected side.
When walking, the cane should be placed forward at the same time as the affected leg is moved forward, the
unaffected leg then following.
Keep the cane away from your feet to avoid tripping.
Going up stairs: Place the unaffected leg forward first, followed by the cane and affected leg.
Going down stairs: The affected leg and cane should be lowered first followed by the unaffected leg on the same step.
