Practivet INFUSION PUMP User manual

!
BASIC OPERATION
1. Press POWER key to turn on the pump
2. Open door & move lever on the left up
3. Install infusion set from left to right & close door
4. Set infusion parameters & press ENTER key to save
5. Press START to start infusion
INFUSION INTERFACE TO SETTINGS
o Press the soft key on the top left of the screen and the STOP button at
the same time
o To get back to the ‘Rate Mode’ interface from the Settings interface, press
the same 2 keys at the same time
SILENCE ALARMS
o Press the SILENCE key on the front of the pump to silence any alarm
o To silence ‘Air in Line’ alarm, you must also open door
o You must manually start pump after the alarm is silenced and occlusion
has been cleared

CALIBRATING PUMP
1. Select ‘Tube’ on menu in settings interface
2. Use the + & - to find the ‘Tube’ you want to calibrate
3. When the tube you want to calibrate appears on the menu press ENTER
4. Press ‘Accu.’
5. Prime your admin set and attach transfer device included to the male end
6. Attach a 10mL syringe to the other end of the transfer device
7. Press START on your pump
8. The pump is going to infuse 10mL according to factory settings (Value will be <7
typically)
9. Once infusion is complete, input actual volume infused into your syringe in the
highlighted portion next to ‘Real’**
10. Press ENTER
o Your pump is now calibrated to the admin set you used
o 10 tube calibrations can be stored
BOLUS RATE
o When you hold the BOLUS key on the front of the pump, the pump will infuse at
default bolus rate 600ml/hr –it is programmable between 300 & 1200 ml/h in the
bolus menu in the setting interface
o To program a bolus to give during infusion
1. Go to settings interface & choose ‘Bolus’
2. Program the bolus rate (ml/h) & VTBI
3. Press ENTER
4. When you would like to give the programmed bolus during infusion, press
BOLUS
OTHER SETTINGS
oKVO – Keep Vein Open
oBolus- Refer to BOLUS
o
Occl. – Occlusion detection sensitivity
oAir L – Air in line detection sensitivity
o
Tube – Type of admin set being used
o
Accu.- Refer to CALIBRATING PUMP
oSound – High or low
oBackL – Backlight
oKey S – Key stroke sound on or off
!
oTime – Time & date
oPress – Tube pressure baseline
oLog- View or upload infusion history
oNo Op- Alarms when no activity
oADone- Alarm before infusion is done
oNight- Dims backlight and low volume
oMaint- Set maintenance reminder
oKLock- Lock keypad
oSettings that are not applicable:
D./ml, WIFI, DedSet, Sensor
!
PLEASE REFER TO FULL DFU FOR DETAILS
