Precision Medical EasyPulse5 User instructions

Setting up your
Troubleshooting
PROBLEM PROBABLE CAUSE REMEDY
Precision Medical, Inc.
300 Held Drive • Northampton, PA 18067
800-272-7285 • 610-262-6090 • fax: [phone] 504345rev3 25M 9/07 Printed in USA
A. No flow 1. Cylinder valve closed 1.Turn on cylinder
2. Conserver in “OFF” 2.Set to prescribed
position setting
3. Cylinder empty 3.Replace cylinder
4. Dial not at setting 4.Set dial so indicator
points to a setting
5. Conserver not sensing 5.Check position of
breath cannula in nose
Do not breathe
through mouth
B. Leaking at Yoke 1. Missing or defective 1.Replace Yoke Seal
Yoke Seal
If problem cannot be corrected, consult your dealer/Homecare equipment provider.
Quick Start Guide only
Refer to EasyPulse5 User Manual for complete operating instructions, warnings and cautions.

When using a Precision Medical Carry Bag, slide the cylinder into
the bag with the gauge facing the mesh. Attach the cannula to the
Conserver’s Cannula Connection.
Slowly open the cylinder valve. Turn Dial to the prescribed setting.
Zip the bag closed.
EasyPulse5 Oxygen Conserving Regulator (Conserver)
Dial
T-Handle
Contents
Gauge
(if equipped)
Cylinder
Index
Pins
Cannula
Connection
Post Valve
Index Pin
Alignment
Holes
4
3
5
6
1
2
P
A
R
T
S
S
T
E
P
S
T
E
P
S
T
E
P
S
T
E
P
S
T
E
P
S
T
E
P
I
D
When finished using:
Turn the cylinder valve to the OFF position. Turn Conserver Dial to “2 LPM Continuous”
position. Wait for Oxygen to stop flowing from Conserver. Remove Conserver from Post
Valve. Store Conserver and Carry Bag in a safe place.
Place cannula in nostrils
and breathe through
nose to begin Oxygen
flow. If using a bag
adjust the straps for
maximum comfort. Typical bag carrying configurations
Cannula prongs in
nostrils
Yoke Seal
View of properly
attached conserver
Inspect Conserver and Post Valve for damage or contaminants.
Do NOT use if any are found. “Crack” cylinder valve by opening the
valve slightly and closing.
Ensure Conserver is in the OFF position and Yoke Seal is in place.
Align Index Pins with Index Pin Alignment Holes in Post Valve.
Hand tighten T-Handle. Do NOT use tools.
Carry
Bag
Cannula
Oxygen
Cylinder
