Precision Microdrives Haptic Feedback Evaluation Kit User manual

[phone]
www.precisionmicrodrives.com
[email protected]
Haptic
Feedback
Evaluation Kit
Quick Start Guide

2
1Introduction
Welcome to the Haptic Feedback Evaluation Kit!
This Quick Start Guide will show you how to get up and running, whilst demonstrating the
dierent modes of operation. There are also some useful references towards the end.
Learn more
Please read the full User Manual for complete information on technical details and advice
for accessing the advanced features of the Haptic Feedback Evaluation Kit.
Additional Resources
Online at precisionmicrodrives.com/haptic-kit you can nd a range of additional resources
available, including:
l Downloadable PDF of this document
l Downloadable PDF of the full User Manual
l A4 printable posters for reference (Eect Table, True Haptics Menu Map, etc.)
l Tutorials on the advanced features
l Arduino code for dierent Modes of Operation and example applications
l Further resources as they are developed!
Further Development
Once you have experienced haptics with this kit, you may want to apply it to your own
projects. We have an extensive range of vibration actuators that can be found on our
website at precisionmicrodrives.com/vibration-motors and are available to purchase in
our online shop. However, if you are unable to nd what you are looking for or you need
some support, our engineers are always happy to answer any questions. Please contact
us using any of the methods shown below.
Contact PrecisionMicrodrives
For questions about the Haptic Feedback Evaluation Kit, ordering and quotes, or technical
queries please do not hesitate to get in touch:
[phone]
www.precisionmicrodrives.com
[email protected]

3
2System Overview
The Haptic Feedback Evaluation Kit is comprised of two main hand-held units, the Haptic
Controller and the Haptic Grip:
Haptic Controller
Together, the Haptic Shield and the Arduino UNO R3 make up the Haptic Controller and act
as the ‘brains’ of the system.
Arduino is an open source development platform for electronics, as a term it is colloquially
use to describe the parent company, the product range, or a speci c board. The UNO
R3 is based on the Atmel ATmega328 microcontroller, its stackable headers enable the
functionality to be extended by connecting customised boards, called ‘shields’, which
mate with the Arduino.
The Precision Microdrives Haptic Shield is specially designed for haptic feedback, with
capacitive touch buttons for input and a Texas Instruments DRV2605L haptic driver and
MOSFET for vibration output.
Haptic Grip
The Haptic Grip houses 4 di erent vibration actuators to enable users to experience
a range of haptic feedback and vibration alerting, including 3 ERMs (304-103, 306-109,
308-102) and the C10-100 LRA.
This makes it easy to compare haptic e ects against each other and feel the e ects
independently of the Haptic Controller. It is designed to have a form factor that can
represent a variety of end applications, such as hand held instruments or joystick
interfaces.
A PDF reference is available at precisionmicrodrives.com/haptic-kit which lists key
parameters of each motor included, with space for notes about other actuators you may
use.
Haptic Feedback Evaluation Kit
Haptic Shield
Haptic Grip
Arduino UNO R3
Haptic Controller

4
3Setup & Installation
The Haptic Feedback Evaluation Kit arrives completely assembled with all hardware
provided in the box. To start, simply connect the kit to one of the power sources outlined
below.
Power
The Arduino allows you to supply power via the USB port or DC connector. You can use
either option. However, please note that old versions of the Haptic Shield must be powered
via USB only. If this Quick Start Guide was supplied with your kit, you have the new version
and may proceed with your preferred choice. If you are reading this online, you should
double check your version of the Haptic Shield by visiting precisionmicrodrives.com/
haptic-kit.
If using a USB port on a computer or laptop to power the unit you may be subject to
current limiting on the USB port. You will need to install the Arduino drivers to correct
this. When the actuators are vibrating the current draw can peak over 100mA. By installing
the drivers the Arduino is able to negotiate up to 500 mA. Not installing the drivers risks
limiting the current to the motors, thereby reducing the performance and in some cases
not allowing the kit to start-up.
(In some computers, particularly laptops, several USB ports can use the same internal
power supply. If possible, remove other USB devices that may be connected to the same
line as the kit.)
Drivers andSoftware
Installing the drivers and software for the Arduino Uno R3 is simple, but they are updated
periodically. Therefore it is best to get the latest version and instructions from the Arduino
website (note URLs are case-sensitive):
l Navigate to arduino.cc/en/Main/Software or search ‘Arduino software’
l Install the Arduino software, includes drivers and IDE (1.8.7 at time of release)
l Refer to the Getting Started page for more help arduino.cc/en/Guide/HomePage
Existing Arduino Users and Kit Owners
If you already have the Arduino IDE installed, we recommend ensuring you upgrade
to the latest version. If you wish to continue using an older version, please visit
precisionmicrodrives.com/haptic-kit for legacy support.
For owners of the Rev1 kit, please ensure you replace the libraries with the Rev2 versions.
For full upgrade instructions, please visit precisionmicrodrives.com/haptic-kit.

5
4Intro Mode
The Intro Mode rmware is loaded onto the Haptic Controller prior to shipping. After
successfully completing the installation process and providing power, the kit will
automatically start and the Precision Microdrives logo will appear on the OLED main
screen.
Intro Mode serves as an introduction to haptic feedback and vibration alerting. This makes
it perfect for those who are unfamiliar with haptics, or for demonstrating to colleagues the
value of the features. Even if you are experienced with haptic feedback, you may wish to
explore the tutorials to discover some of the additional features of the DRV2605L.
There are four tutorials in the Intro Mode,
use the Left and Right buttons to move
between them.
Press the Select button to start:
l Quick-Start Demo
l Haptic Feedback Tutorial
l Vibration Alerting Tutorial
l DRV2605 Overview
Develop Understanding
Each tutorial has several slides for you to read about the concepts demonstrated. They
are easy to follow and you can go back by pressing the Left button, or exit with the Back
button.
Feel Eects
At specic points in each tutorial you will be prompted to press the Play button. Dierent
eects are played on the Haptic Grip or the Haptic Controller, you can repeat them by
pressing the Play button a second time.
Apply
Not only will the tutorials walk you through the concepts of vibration alerting and haptic
feedback, some also include example applications. Start thinking about how you would
use haptics to improve your product, then try out the Engineering Mode.
Right ButtonLeft Button
Select Button
PMD ButtonBack Button
Play Button

6
5 Engineering Mode
The Engineering Mode uses dierent rmware that needs to be loaded into the Arduino,
to perform this you will need to have installed the Arduino Environment (see Section 3)
and have downloaded the code from precisionmicrodrives.com/haptic-kit. It gives access
to a greater range of eects and functionality.
It is also recommended you read the Section 5 of the User Manual to get the most out of
the Engineering Mode. The User Manual is available online at precisionmicrodrives.com/
haptic-kit.
Upload the Code
To enter the engineering mode, you need to compile and upload the code
through the Arduino Environment. Downloaded and extract the code to your
chosen folder, open the EngineeringMode.ino le (.ino les are called ‘sketches’).
Supporting les called ‘libraries’ are included in the zip, ensure the Sketchbook
Location (File -> preferences) points to the folder above the libraries folder. If
everything is correct you can click the 'upload’ button. More detailed instructions
available in the User Manual or at precisionmicrodrives.com/haptic-kit.
Using True Haptics
Here you can experience haptic feedback through the DRV2605 which includes 123
dierent haptic eects and 6 libraries. Navigate clicks, bumps, pulses, and many more
options.
Press the Play button to play the chosen eect and press the PMD button to cycle
actuators. The True Haptics Menu Map and Eect ID Table (Sections 9 and 10) will help you
nd eects quickly.
Using VibrationAlerting
Vibration alerts can be played through the on-board MOSFET and PWM. Build your own
vibration alerting waveform by setting each variable in the Vibration Alerting section,
including vibration power, vibration waveform, on time, and o time. Please note that
LRAs require an AC signal, so cannot be played by the on-board MOSFET.
Keep Developing
Try using the DRV2605 library and example code to start prototyping your own system.
The Arduino can be used to accept inputs, the library lets you easily interface with the
DRV2605, and you can connect to an external actuator using the terminals on the Haptic
Shield.

7
6 Development Mode
Having approached haptics with the Intro Mode and gained a more in depth idea of what
our motors can do through using the Engineering mode, you may be thinking about how
you can develop this into your own project.
The Development Mode has been created to allows designers to implement haptics using
our Haptic feedback kit. You can download the rmware from precisionmicrodrives.com/
haptic-kit.
Modifying and uploading the code
All the software needed to run in our Haptic Kit is available on our website and users
can deal in the Software without restriction, including without limitation, the rights to use,
copy or modify it.
The Development Mode program is used to start writing your own code. It handles
the initialisation of the pins, I2C bus, and the serial port. Advanced users will nd
the DRV2605 Arduino Library Reference useful, but those unfamiliar with Arduino
programming may nd the tutorials and examples more benecial.
To upload the code in the kit, follow the same instructions as in the Engineering
Mode. This will give you complete access to the open source code. The motors
are driven using the driver DRV2605 from Texas Instrument. The Development
Mode will allow you to program the driver and choose the setting that best
suits your application and the PMD motor you are using. You can refer to
Texas Instruments (TI) to understand the features of the driver and map of addresses.
You can connect an external actuator to the kit using the green screw terminal
and program your own patterns, eects and recurrences. It is also worth noting that the
OLED display is disabled in the Development Mode as it is designed to be very simple. This
means that nothing will appear on it and the pins that were required to drive it are now
available. The Pin Mapping in section 8 will help you identify which pins are free.
Tutorials and Examples
You will nd on our website dierent tutorials and examples to follow with the
Development Mode. Here is a few options for the users to continue investigating and
developing new haptics applications.
1: How to connect an external motor to the Haptic Feedback Evaluation Kit
precisionmicrodrives.com/content/connecting-external-actuator-vibration-motor-to-the-
m20-200-haptics-kit/
2: Driving multiple LRA's
precisionmicrodrives.com/content/new-haptic-feedback-evaluation-kit-tutorial-driving-
multiple-lras/
3: Using the Audio-to-Vibe function
precisionmicrodrives.com/content/tutorial-using-haptic-feedback-with-music-or-audio-
signals/

8
7 DRV2605 Library
The DRV2605 and DRV2605L from Texas Instruments are functionally similar, the
DRV2605L is available in a 10VSSOP package and is used in the Haptic Feedback Evaluation
Kit. However, you should be able to use the library with either chip. If you have any issues
in Development Mode, please contact us.

9
8Pin Mapping
I2C SCL
I2C SDA
Grip Connect 3 (S1)
Grip Connect 6 (S2)
Shield ERM Select
SPI (CLK) OLED 8
SPI (DAT) OLED 9
SPI (RES) OLED 4
PWM (IN/TRIG, MOSFET
SPI (DC) OLED 5
DRV2605 - EN 6
Shield LRA Select
SPI (CS) OLED 3
Source select
Grip select
Touch driver - IRQ
12C Addresses
USING 7BITS ADDRESSING
Capacitive Touch Driver MPR121 0x5D
Haptic Driver DRV2605L 0x5A
Key of pin requirements
OLED 3V3, 5V, GND, 5, 8 , 10, 11, 13
Haptic Grip 5V, GND, A0, A1, 3, 4
DRV2605 3V3, 5V, GND, A4, A5, 5, 7, 9
Capacitive Touch 3V3, 5V. GND, A4, A5, 2
MOSFET 5V, GND, 4, 9

10
9True Haptics Menu Map
Looking to nd a specic eect in the True Haptics menu? You can use the reference below
in conjunction with the Eect Table to nd the menu location of each eect available on
the DRV2605L.
Buzzes
Buzzes
Pulses
Pulses
Bumps
Bumps
Hums
Hums
13, 14, 47, 48, 49,
50, 51, 118
52, 53, 54, 55, 56, 57
7, 8, 9
64, 65, 66, 67, 68,
69, 119, 120, 121,
122, 123
Other
Strong
Single
Strong
Double
Medium
Medium
Tick
Tick
Transition
Triple
Triple
1, 2, 3, 17, 18, 19, 20
10, 11, 27, 28, 29,
30, 37, 38, 39, 40
21, 22, 20
31, 32, 33, 41, 42, 43
4, 5, 6, 24, 25, 26
34, 35, 36, 44, 45, 46
58, 59, 60, 61, 62 ,63
12
Clicks
Short
Up
Short
Down
Medium
Medium
Long
Long
86, 110, 87, 111, 92,
116, 93, 117
74, 98, 75, 99, 80,
104, 81, 105
84, 108, 85, 109, 90,
114, 91, 115
72, 96, 73, 97, 78,
102, 79, 103
82, 106, 83, 107, 88,
112, 89, 113
70, 94, 71, 95, 76,
100, 77, 101
Ramps
Alerts
Library
Audio-
2Haptics
Shield
Haptics
Alerts
Library
Audio-
2Haptics
Shield
Haptics
5, 16
1, 2, 3, 4, 5
ERM, LRA
Alerts
Library
Audio2Haptics
Shield Haptics

11
10 Eect Table
ID Waveform Menu
1Strong Click 100% 63Clicks > Single > Strong Transition Click 6 10%
2
Clicks > Single > Transition
Strong Click 60%64Clicks > Single > Strong Transition Hum 1 100%
3
Other > Hums
Strong Click 30%65Clicks > Single > Strong Transition Hum 2 80%
4
Other > Hums
Sharp Click 100% 66Clicks > Single > Tick Transition Hum 3 60%
5
Other > Hums
Sharp Click 60%67Clicks > Single > Tick Transition Hum 4 40%
6
Other > Hums
Sharp Click 30%68Clicks > Single > Tick Transition Hum 5 20%
7
Other > Hums
Soft Bump 100% 69Other > Bumps Transition Hum 6 10%
8
Other > Hums
Soft Bump 60%70Other > Bumps
9
Ramps > Down > LongTransition Ramp Down Long Smooth 1 100-0%
Soft Bump 30%71Other > Bumps
10
Ramps > Down > LongTransition Ramp Down Long Smooth 2 100-0%
Double Click 100% 72Clicks > Double > Strong
11
Transition Ramp Down Medium Smooth 1 100-0% Ramps > Down > Medium
Double Click 60%73Clicks > Double > Strong
12
Transition Ramp Down Medium Smooth 2 100-0% Ramps > Down > Medium
Triple Click 100% 74Clicks > Triple
13
Ramps > Down > StrongTransition Ramp Down Short Smooth 1 100-0%
Soft Fuzz 60%75Other > Buzzes
14
Ramps > Down > StrongTransition Ramp Down Short Smooth 2 100-0%
Strong Buzz 100% 76Other > Buzzes
15
Ramps > Down > LongTransition Ramp Down Long Sharp 1 100-0%
750ms Alert77Other > Alerts
16
Ramps > Down > LongTransition Ramp Down Long Sharp 2 100-0%
1000ms Alert78Other > Alerts
17
Ramps > Down > MediumTransition Ramp Down Medium Sharp 1 100-0%
Strong Click 1 100% 79Clicks > Single > Strong
18
Transition Ramp Down Medium Sharp 2 100-0% Ramps > Down > Medium
Strong Click 2 80%80Clicks > Single > Strong
19
Ramps > Down > StrongTransition Ramp Down Short Sharp 1 100-0%
Strong Click 3 60%81Clicks > Single > Strong
20
Ramps > Down > StrongTransition Ramp Down Short Sharp 2 100-0%
Strong Click 4 30%82Clicks > Single > Strong
21
Ramps > Up > LongTransition Ramp Up Long Smooth 1 0-100%
Medium Click 1 100% 83Clicks > Single > Medium
22
Ramps > Up > LongTransition Ramp Up Long Smooth 2 0-100%
Medium Click 2 80%84Clicks > Single > Medium
23
Ramps > Up > MediumTransition Ramp Up Medium Smooth 1 0-100%
Medium Click 3 60%85Clicks > Single > Medium
24
Ramps > Up > MediumTransition Ramp Up Medium Smooth 2 0-100%
Sharp Tick 1 100% 86Clicks > Single > Tick
25
Ramps > Up > ShortTransition Ramp Up Short Smooth 1 0-100%
Sharp Tick 2 80% 87Clicks > Single > Tick
26
Ramps > Up > ShortTransition Ramp UP Short Smooth 2 0-100%
Sharp Tick 3 60%88Clicks > Single > Tick
27
Ramps > Up > LongTransition Ramp Up Long Sharp 1 0-100%
89Short Double Click Strong 1 100% Clicks > Double > Strong
28
Ramps > Up > LongTransition Ramp Up Long Sharp 2 0-100%
90Short Double Click Strong 2 80%Clicks > Double > Strong
29
Ramps > Up > MediumTransition Ramp Up Medium Sharp 1 0-100%
91Short Double Click Strong 3 60%Clicks > Double > Strong
30
Ramps > Up > MediumTransition Ramp Up Medium Sharp 2 0-100%
92Short Double Click Strong 4 30%Clicks > Double > Strong
31
Ramps > Up > ShortTransition Ramp Up Short Sharp 1 0-100%
93Short Double Click Medium 100% Clicks > Double > Medium
32
Ramps > Up > ShortTransition Ramp Up Short Sharp 2 0-100%
94Short Double Click Medium 2 80%Clicks > Double > Medium
33
Ramps > Down > Long
Transition Ramp Down Long Smooth 1 50-0%
95Short Double Click Medium 3 60%Clicks > Double > Medium
34
Ramps > Down > LongTransition Ramp Down Long Smooth 2 50-0%
96Short Double Sharp Tick 1 100% Clicks > Double > Tick
35
Ramps > Down > MediumTransition Ramp Down Medium Smooth 1 50-0%
97Short Double Sharp Tick 2 80%Clicks > Double > Tick
36
Transition Ramp Down Medium Smooth 2 50-0%Ramps > Down > Medium
98Short Double Sharp Tick 3 60%Clicks > Double > Tick
37
Ramps > Down > StrongTransition Ramp Down Short Smooth 1 50-0%
99Long Double Sharp Click Strong 1 100% Clicks > Double > Strong
38
Ramps > Down > StrongTransition Ramp Down Short Smooth 2 50-0%
100Long Double Sharp Click Strong 2 80%Clicks > Double > Strong
39
Ramps > Down > LongTransition Ramp Down Long Sharp 1 50-0%
101Long Double Sharp Click Strong 3 60%Clicks > Double > Strong
40
Ramps > Down > LongTransition Ramp Down Long Sharp 2 50-0%
102Long Double Sharp Click Strong 4 30%Clicks > Double > Strong
41
Transition Ramp Down Medium Sharp 1 50-0%Ramps > Down > Medium
103Long Double Sharp Click Medium 1 Clicks > Double > Medium
42
Transition Ramp Down Medium Sharp 2 50-0%Ramps > Down > Medium
104Long Double Sharp Click Medium 2 80%Clicks > Double > Medium
43
Ramps > Down > StrongTransition Ramp Down Short Sharp 1 50-0%
105Long Double Sharp Click Medium 3 60%Clicks > Double > Medium
44
Ramps > Down > StrongTransition Ramp Down Short Sharp 2 50-0%
106Long Double Sharp Tick 1 100% Clicks > Double > Tick
45
Ramps > Up > LongTransition Ramp Up Long Smooth 1 0-50%
107Long Double Sharp Tick 2 80%Clicks > Double > Tick
46
Ramps > Up > LongTransition Ramp Up Long Smooth 2 0-50%
108Long Double Sharp Tick 3 60%Clicks > Double > Tick
47
Ramps > Up > MediumTransition Ramp Up Medium Smooth 1 0-50%
Buzz 1 100% 109Other > Buzzes
48
Ramps > Up > MediumTransition Ramp Up Medium Smooth 2 0-50%
Buzz 2 80% 110Other > Buzzes
49
Ramps > Up > ShortTransition Ramp Up Short Smooth 1 0-50%
Buzz 3 60% 111Other > Buzzes
50
Ramps > Up > ShortTransition Ramp Up Short Smooth 2 0-50%
Buzz 4 40% 112Other > Buzzes
51
Ramps > Up > LongTransition Ramp Up Long Sharp 1 0-50%
Buzz 5 20% 113Other > Buzzes
52
Ramps > Up > LongTransition Ramp Up Long Sharp 2 0-50%
Pulsing Strong 1 100% 114Other > Pulses
53
Ramps > Up > MediumTransition Ramp Up Medium Sharp 1 0-50%
Pulsing Strong 2 80%115Other > Pulses
54
Ramps > Up > MediumTransition Ramp Up Medium Sharp 2 0-50%
Pulsing Medium 1 100% 116Other > Pulses
55
Ramps > Up > ShortTransition Ramp Up Short Sharp 1 0-50%
Pulsing Medium 2 60% 117Other > Pulses
56
Ramps > Up > ShortTransition Ramp Up Short Sharp 2 0-50%
Pulsing Sharp 1 100% 118Other > Pulses
57
Long Buzz for Programmatic Topping 100% Other > Buzzes
Pulsing Sharp 2 60% 119Other > Pulses Smooth Hum 50%
58
Other > Hums
Transition Click 1 100% 120Clicks > Single > TransitionSmooth Hum 40%
59
Other > Hums
Transition Click 2 80% 121Clicks > Single > TransitionSmooth Hum 30%
60
Other > Hums
Transition Click 3 60% 122Clicks > Single > TransitionSmooth Hum 20%
61
Other > Hums
Transition Click 4 40% 123Clicks > Single > TransitionSmooth Hum 10%
62
Other > Hums
Transition Click 5 20% Clicks > Single > Transition
ID Waveform Menu

Looking for the perfect design?
We can help.
Precision Microdrives is an ISO 9001:2015
trusted designer and manufacturer of
miniature, cost-eective, and well engineered
motors and mechanisms. We are specialists in,
l Trusted precision motor design
l Flexible motor & mechanism
manufacturing
l Dependable quality control & after-sales
support
l Industry leading motor testing and
validation
Design for application case studies
Email: [email protected]
Call: [phone]
SPEAK TO OUR DESIGN ENGINEERS TODAY
Our UK based motor design engineers, will support you through the complex process
of specifying, developing, validating, and mass manufacturing, a custom motor or
mechanism. The result? A part perfect for your application.
Delivered, 'On-Time & To Spec'.
ENCAPSULATED
VIBRATION MOTOR FOR A
CPR TRAINING DUMMY
lLow volume,
high value
manufacturing
l Custom CNC
machined enclosure
lOptimised haptic
performance
l Custom PCB
including EMI lters
PRECISION SPEED AND
TORQUE CONTROLLED
SERVO WITH INTEGRATED
TUNABLE PID LOOP FOR
SINGLE-USE SCIENTIFIC
INSTRUMENT
l Medium volume,
high value assembly
lAdapted control
software including digital
IO (to customer’s
specication)
CUSTOMISED PRECISION
GEAR MOTOR WITH
ROBUST OPTICAL
ENCODER
lHigh volume production
l Application specic
output shaft
l Rear motor shaft with
noise resistant optical
encoder
lTailored motor
performance curves
