Precision Power PP36PB-12 User manual

USER’S MANUAL FOR
Precision Power
Model Number: PP36PB-12
OVERVIEW
1
2
3
4
5
1
2
3
5
4
PASS THROUGH AC INPUT OUTLET
SCREW FOR MOUNTING TO WALL PLATE
NETWORK INTERFACE RESET BUTTON
3 PIN CONNECTOR AND CABLE GUARD
DC/CONTROL TERMINAL OUTPUT
PB36 INTRODUCTION
PB36 is designed and intended for use as a compact outlet mount
DC power supply device for Indoor and Outdoor 12Vdc Optical
Network Terminals (ONT) as well as wireless local loop
applications. The PB36 is designed to provide constant supply of
12Vdc DC output power during normal operating conditions. The
PB36 is equipped to supply direct DC power to ONT or to inline
Battery Backup Unit. The PB36 also provides customer facing
Network Interface Reset Intelligence to provide integrated ONT
reset technology designed to reduce Provider OPEX.
Network Interface Reset Button- Allows for reset of DC power
output when pushed and held for 2 seconds. This provides reset/
reboot option for Optical Terminal Network without having to
unscrew the PB36 from wall plate mount, unplug and replug at AC
outlet in order to reset DC power output.
INSTALLATION
1. Inspect the PB36 for any visible damage before proceeding to
following steps. If the PB36 shows visible signs of any damage at
time of unpacking, then device should not be installed.
2. Plug 3-Pin Connector with attached cable into DC/ Control
Terminal Output.
3. Using provided cable ties, secure cable to cable guard running
cable through provided holes in cable guard.
4. Remove AC wall plate screw.
5. With wall plate still in place over AC wall outlet, plug the PB36
into AC outlet and use provided PB36 screw to secure the PB36 to
the AC outlet.
Review the following important safety warnings to avoid bodily
injury or damage to equipment during installation or operation of
this device.
Read ALL instructions before attempting to install or operate this
device.
This device is intended for indoor use only. To prevent
the risk of fire or eletrical shock, install in dry location
free from damp or wet environment, or potentially damp
or wet environment.
Adhere to all acceptable operating environment
limitations as listed to prevent the risk of of fire or
electrical shock (see user specifications within User's
Manual)
NO user-replaceable parts within this device. To avoid
bodily injury, risk of fire or electrical shock do not attempt
to remove cover of device.
Device is not designed for use with any alternate
connection to AC power than as stated within user
specifications of this user's manual.
WARNINGS
NOTE: The reference to “PB36” within this User Manual refers
to Precsion Power Model PP36PB-12 and all package
accessories as listed below.
CONTENTS OF NXGM PACKAGE
NOTE: Please verify all standard contents are accounted for
upon receipt of PB36
STANDARD: (1) DC Power Supply;(3) Cable Ties; (1) 3- Pin
Connector; (1) User's Manual

FCC NOTICE
This equipment has been tested and found to comply with the
limit for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with these
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by tuning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures: (1)
Reorient or relocate the receiving antenna. (2) Increase the
separation between the equipment and receiver. (3) Connect
the equipment into an outlet on a circuit different from that to
which the receiver is connected. (4) Consult the dealer or an
experienced radio/TV technician for help.
CAUTION: Any changes or modifications could void the
authority granted by the FCC to operate this equipment.
NOTE: Precision Power reserves the right to change or
correct the contents of this document and does not assume
any responsiblity for ommissions or errors.
Core Telecom Systems
[phone]
[email protected]
www.coretelecom.net
