CommercialTreadmill Owner’s Manual
COMMERCIAL PRODUCTS DIVISION
C954
C956

page 2
COMMERCIAL PRODUCTS DIVISION
Thank you for purchasing the Precor C956 or C954 Commercial Treadmill.
Built to the exacting standards of the health club environment, the treadmill is
intended for commercial use and can withstand the rigors of daily club use with
little maintenance.
BeforeusingPrecorequipment,weurgeyoutofamiliarizeyourselfandstaffwith
the entire Owner’s Manual. Understanding this manual will help you and your
customers use the treadmill safely and successfully.
ABOUT THIS MANUAL
Inside this manual, you will find instructions for assembling and using the tread-
mill.To maximize the use of the unit, please study this manual thoroughly. The
manual uses the following conventions for identifying special information:
“Note:”Containsadditionalinformationthat applies to the preceding text.
“Important:”Indicates information to which you should payspecial attention.
“CAUTION:”Indicatesstepsorinformationnecessarytopreventharmtoyourselfor
damagetotheequipment.
“WARNING:”Providesinstructions toprevent electrical damage totheequipment
and prevent injuries to yourself.
“DANGER:” Indicates steps you must take to prevent electrical shock.
OBTAINING SERVICE
Do not attempt to service the treadmill yourself except for the maintenance tasks
described in this manual.The treadmill does not contain any user-serviceable parts.
For information about product operation or service, visit the Precor Web Site at
www.precor.com or contact an authorized Precor dealer or a Precor Factory
Authorized Service Company.To locate the dealer or service person nearest you,
call1-888-665-4404.
Theserial number on thetreadmillisprinted on alabellocatedonthe base frame.
Tolocate the serialnumber,verifythatthetreadmillisturnedOFF.Then,standat
therearofthetreadmillandface the display console, kneel down and look under
the treadmill on the inboard-side of the running bed at the left, rear corner. For
future reference, write the serial and model number and the date of purchase in
thespaceprovidedbelow.
Model/unit #: _____ Serial #: __________________ Date purchased:_____
Model/unit #: _____ Serial #: __________________ Date purchased: ____
Model/unit #: _____ Serial #: __________________ Date purchased: ____
Model/unit #: _____ Serial #: __________________ Date purchased: ____
If you have questions regarding the treadmill, use the model and serial number when-
ever you contact Precor Customer Service, your Precor dealer, or service person.
BeforeYou Begin

page 3
COMMERCIAL PRODUCTS DIVISION
When using an electrical appliance, basic precautions should always be taken,
including the following:
• Read all instructions before using the treadmill.These instructions are written
to ensure your safety and to protect the unit.
• To ensure the proper use and safety of the treadmill, make sure that all users
read this manual. Please make this manual a part of your training program.
Before beginning any fitness program, users of this equipment should obtain a
complete physical examination from a qualified physician.
Il est conseillé de subir un examen médical complet avant d’entreprendre tout
programme d’exercise. Si vous avez des étourdissements ou des faiblesses, arrêtez
les exercices immédiatement.
DANGER
WARNING
• When it is plugged in, do not leave the treadmill unattended. Unplug the treadmill
from the outlet when it is not in use, and before putting on or taking off parts.
• Do not allow children on or near the treadmill.
• Use the treadmill only for its intended use as described in this manual. Do not
use accessory attachments that are not recommended by the manufacturer—
such attachments might cause injuries.
• Never operate the unit if it has a damaged cord or plug, if it is not working
properly, if it has been dropped or damaged, or dropped in water. Return the
treadmill to a service center for examination and repair.
• Keep the power cord away from heated surfaces. Keep hands away from mov-
ing parts.
• Never block the air openings on the hood while operating the treadmill. Keep
the air openings clean and free of lint, hair, or anything that might impede the
free flow of air. Never drop or insert objects into any opening.
• Do not operate where aerosol (spray) products are being used or where oxygen
is being administered.
• Do not use outdoors.
• Turn the power switch to the OFF (O) position, when the treadmill is not in use
for an extended period of time.Then, remove the power plug from the outlet.
WARNING
IMPORTANT SAFETY INSTRUCTIONS
IMPORIMPOR
IMPORIMPOR
IMPORTT
TT
TANT SAFETY INSTRUCTIONSANT SAFETY INSTRUCTIONS
ANT SAFETY INSTRUCTIONSANT SAFETY INSTRUCTIONS
ANT SAFETY INSTRUCTIONS
To reduce the risk of electrical shock, always unplug the
unit from its power source before cleaning or performing
any maintenance tasks.
To reduce the risk of burns, fire, electric shock, or injury to
persons, take the following precautions:
Connect the treadmill to a properly grounded outlet only.See
Grounding Instructions on page 4.
SAVE THESE INSTRUCTIONS

page 4
COMMERCIAL PRODUCTS DIVISION
GROUNDING INSTRUCTIONS
The C956 or C954 treadmill must be grounded. If it should malfunction or
break down, grounding provides a path of least resistance for electric current
which reduces the risk of electrical shock. The C956 or C954 treadmill is
equipped with a power cord having an equipment-grounding conductor and a
grounding plug. The plug must be inserted into an appropriate outlet that is
properly installed and grounded in accordance with all local codes and ordi-
nances. If you do not follow these Grounding Instructions , you could void the
Precor limited warranty.
DANGER
Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or service person if you
are in doubt as to whether the treadmill is properly grounded. Do not modify
the plug provided with the treadmill—if it doesn’t fit the outlet, get a proper
outlet installed by a qualified technician.
120V Units Designated for U.S. Markets
The C956 or C954 treadmill must be connected to a 20 amp dedicated circuit
having a nominal rating of 120-volts. The treadmill’s grounding plug looks like
the plug illustrated in Diagram A. The power outlet must have the same con-
figuration as the plug. No adapter should be used with this product.
240V Units Designated for U.S. Markets
The C956 or C954 treadmill must be connected to a 20 amp dedicated circuit
having a nominal rating of 240-volts. The treadmill is factory-equipped with a
specific power supply cord to permit connection to a proper electric circuit.
Make sure that the treadmill is connected to an outlet having the same configu-
rations as the plug. See Diagram A. No adapter should be used with this product.
If the treadmill must be reconnected for use on a different type of electrical
circuit, the reconnection must be made by qualified service personnel.
SAFETY APPROVAL
When identified with the ETL-c logo, the treadmill has been tested and con-
forms to the requirements of CAN/CSA-E-335-1/2-94, Safety of Household
and Similar Electrical Appliances.
Diagram A
Correct power
outlet for U.S.
Markets: 20 amp
120-volt and
240-volt plugs.
120-volt grounding plug 240-volt grounding plug

page 5
COMMERCIAL PRODUCTS DIVISION
RFI — RADIO FREQUENCY INTERFERENCE
Federal Communications Commission Part 15
The treadmill has been tested and found to comply with,
• theIECEMCDirective(internationalelectromagneticcompatibilitycertification)
• the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a commercial installation.The treadmill generates, uses, and
can radiate radio frequency energy and, if not installed and used in accor-
dance with the owner’s manual instructions, may cause harmful interference
to radio communications. Operation of the treadmill in a residential area is
likely to cause harmful interference. If this occurs, the user will be required to
correcttheinterferenceathisor her own expense.
CAUTION
Canadian Department of Communications
This digital apparatus does not exceed the Class A limits for radio noise emis-
sions from digital apparatus set out in the Radio Interference Regulations of
the Canadian Department of Communications.
Leprésent appareil numérique n’émet pasdebruitsradioéélectriquesdépassant
leslimitesapplicablesauxappareilsnumériques de la Class A prescrites dans le
Règlementsur le brouillage radioélectriqueédictéparle ministére des Communi-
cationsduCanada.
EUROPEAN APPLICATIONS
This product conforms to the requirements of the European Council Directive 89/336/
EEC, Electromagnetic Compatibility and has been tested to the following standards:
EN55022, Limits & Methods of Measurement of Radio Interference, Informa-
tion Technology Equipment (Class A).
EN50082-1, Generic Immunity Standard for Residential, Commercial and Light
Industrial Products (Class A).
ThisproductadditionallyconformstotherequirementsoftheEuropeanCouncilDirective
73/23/EEC,LowVoltageDirectiveand hasbeentestedtothefollowingstandard:
IEC 335-1, Safety of Household and similar Electrical Appliances.
European Applications −−
−−
−240Volt Units Only
This product has been tested to the requirements of EN55022,“Limits & Methods of
Measurement of Radio Interference, Information Technology Equipment.” Per that
standard, the C956 or C954 treadmills are a Class A product. In a domestic environ-
ment, these products may cause radio interference, in which case the user is re-
sponsible to take adequate measures to alleviate the interference.
Per FCC rules, changes or modifications to the
treadmill not expressly approved by Precor, could
void the user’s authority to operate the equipment.

page 6
COMMERCIAL PRODUCTS DIVISION
PERSONAL SAFETY
When using the treadmill, take the following precautions:
• Do not allow children on or near the treadmill. Do not leave children unsu-
pervised around the treadmill.
• Assemble and operate the treadmill on a solid, surface. Locate the treadmill
a few feet from walls or furniture. Keep the area behind the treadmill clear.
• Turn OFF (O) and unplug the treadmill when adjusting or working near the rear
roller. Do not adjust the running belt when someone is standing on the unit.
• Keep all electrical components, such as the motor, power cord, and I/O switch,
away from liquids to prevent shock.Do not set anything on the handrail, display
console, or hood. Place liquids only in the appropriate receptacles.
• The security clip should be attached at waist level prior to beginning a
workout. A cord connects the security clip to the red STOP button on the
console.Ifauserencountersdifficulties, the running belt can be stopped by
pulling on the cord.To resume operation, press the Speed ▲key.
• Maintain the treadmill in good working condition. (Refer to the Maintenance
section). Run through a check list prior to each use. Make sure that all
fasteners are secure and the belt is cleaned and running smoothly.
• Wear proper exercise clothing and shoes during a workout—no loose cloth-
ing. Tie long hair back. Keep all loose towels away from the running sur-
face. The running belt will not stop immediately if an object becomes
caught in the belt or rollers.
• Use care when getting on or off the treadmill. Use the handrail(s) whenever
possible. Step onto the running belt when the speed is at 1 mph (1.6 kph).
Never step off the treadmill while the running belt is moving.
• Before the running belt begins moving (prior to a workout), and after it
stops (at the end of a workout), straddle the belt by placing your feet
firmly on the right and left side platforms.
• Never turn ON the treadmill when someone is standing on the machine.
• Keep your body and head facing forward.Never attempt to turn around on
the treadmill when the running belt is moving.
• Do not rock the unit.Do not stand on the handrails, display console, or hood.
• Do not attempt to service the treadmill yourself other than the assembly and
maintenance instructions found in this manual. Refer to Obtaining Service .
• Do not overexert yourself or work to exhaustion.If you feel any pain or abnor-
mal symptoms, stop your workout immediately and consult your physician.
PRECOR HEART RATE OPTIONS—SAFETY GUIDELINES
The Precor Heart Rate Options are created and designed exclusively for Precor
products.The equipment is very sensitive—you should use the heart rate options
with this in mind and take time to read the guidelines found in this owner’s manual.
If you purchased the POLAR®chest strap, review the guidelines found in the
Precor Heart Rate Option Owner’s Manual that is supplied with that option.

page 7
COMMERCIAL PRODUCTS DIVISION
BeforeYou Begin ..............................................................2
About this Manual .................................................................. 2
ObtainingService................................................................... 2
Important Safety Instructions................................................. 3
GroundingInstructions ........................................................... 4
SafetyApproval ..................................................................... 4
RFI—RadioFrequency Interference ..................................... 5
EuropeanApplications ........................................................... 5
PersonalSafety...................................................................... 6
Precor Heart Rate Option - Safety Guidelines ........................ 6
Unpacking theTreadmill ..................................................9
StandardEquipment............................................................... 9
OptionalEquipment................................................................ 9
HardwareKit .......................................................................... 10
AcquiretheAppropriateTools ................................................. 10
Setting Up the Treadmill ................................................11
Installation Requirements...................................................... 11
Assembly Instructions .......................................................... 11
Turning the Unit ON and OFF................................................ 18
Checking the Alignment of the Running Belt......................... 19
Club Information ............................................................20
Changing the Club Settings................................................... 20
Selecting the Language ......................................................... 20
Determining the Units of Measure ........................................ 21
DeterminingtheClubSpeedLimit .......................................... 22
Setting a Workout Time Limit ................................................ 22
Setting a Pause Time Limit.................................................... 22
Changing the C956 Custom Courses.................................... 23
Viewing the Odometer, Hours of Use,
Software Version, and Error Log ........................................... 24
Using CSAFEStandard Equipment ........................................ 24
Table of Contents

page 8
COMMERCIAL PRODUCTS DIVISION
Table of Contents
The C956/C954 Display..................................................25
FeaturesontheDisplayConsole............................................ 25
Top Display Windows ............................................................ 25
Center Display Window (C956 only) ..................................... 26
Elongated CenterDisplay (C956 andC954) ............................ 26
Keys on the Display Console ................................................ 28
Keypad Tips........................................................................... 28
Exercising on the Treadmill...........................................32
Using the Security Clip ......................................................... 32
Pause, Cool Down, Summary and Exit Features .................... 32
Quick Steps to Working Out.................................................. 34
Workout Tips ......................................................................... 34
Cooling Down After a Workout .............................................. 35
Courses ...........................................................................36
The Heart Rate Features....................................................... 36
Utilizing the Smart Rate® Feature.......................................... 36
Manual Mode and the Quick Start Key ................................. 37
The Track Course .................................................................. 38
Preprogrammed Courses ...................................................... 38
Interval Course ..................................................................... 38
Custom Courses ................................................................... 39
Random Course .................................................................... 39
Heart Rate Course ................................................................ 40
Weight Loss Course .............................................................. 41
Goal-based Courses ............................................................. 41
Maintenance....................................................................42
Cleaning the Equipment ........................................................ 42
Aligning the Running Belt ...................................................... 42
Storing the POLAR®Chest Strap .......................................... 43
Servicing the Treadmill .......................................................... 43
LongTerm Storage ................................................................ 43
Specifications............................................................back cover

page 9
COMMERCIAL PRODUCTS DIVISION
Thetreadmillis carefully tested and inspected beforeshipmentsoitshouldarrive
in good operating condition. Precor ships the unit in the following pieces:
• base frame assembly
• hood
• front assembly (includes 2 upright supports and display console)
• handrails(oneforeachside)
• owner’smanual and hardwarekit
CAUTION:The treadmill weighs over 350 pounds (157 kilograms).To avoid
injury and ensure the safety of the unit and yourself, we suggest that you
get assistance before removing the unit from the box.
If any items are missing, contact your Precor Commercial Products Service
Representative at 1-888-665-4404.
STANDARD EQUIPMENT
Both the C956 and C954 treadmills incorporate the Precor Smart Rate®and
Heart Rate features into it’s display consoles. Devices, such as FittLinxx that
are CSAFE compatible, can also be attached.
Note: An optional POLAR® chest strap must be worn to transmit a user’s heart
rate to the display console’s receiver. Another option, Precor “touch” heart rate
can be purchased (at point of sale) and provides electrode strips on the center
handrail. When a user places his or her hands over the strips and grasps the
handrail, a heart rate is transmitted to the receiver.
OPTIONAL EQUIPMENT
Optional equipment that you can purchase through your dealer includes:
• POLAR®chest strap
• Touch Heart Rate (separate display console)
• Longhandrails
If you are interested in obtaining Precor option kits for your unit, check with
you dealer. To locate the dealer nearest you, call 1-888-665-4404. For cus-
tomer service, see Obtaining Service on page 2.
Unpacking the Treadmill

page 10
COMMERCIAL PRODUCTS DIVISION
HARDWARE KIT
After unpacking the treadmill, open the hardware kit and make sure that you
have the following items shown in Diagram 1.
Diagram 1 C956/C954Hardware Kit
(A) 20 — 1” long buttonhead screws
(B)14 — washers
(C) 4 — 1/2” long flat head screws
(D) 1/4” hex key — belt adjustment
(E) 3/16” hex key — mount uprights, display and handrails to base frame
(F) 5/32” hex key — install handrails to display and hood to base
D
EF
Note: After assembling the treadmill, be sure to store the hex keys in a secure
place.Thetoolsareused forspecificmaintenanceproceduresthataredescribedin
this manual.
ACQUIRE THE APPROPRIATE TOOLS
Obtainthefollowingtools before assemblingthetreadmill.
Wirecutter
Bubblelevel
Medium weight string [about 1 foot (30 cm)]
Strongadhesivetape
SAE Standard socket set with a ratchet or 8” Crescent wrench
C
A
B

page 11
COMMERCIAL PRODUCTS DIVISION
You do not need any special knowledge or experience to set up the treadmill.
However, you will need assistance. Because of the size and weight of the
treadmill, it is recommended that at least three adult persons assemble it.
INSTALLATION REQUIREMENTS
Follow these installation requirements when installing the treadmill. If you do
not install the treadmill according to the following guidelines, you could void
the Precor limited warranty.
•Set up the treadmill on a solid, flat surface. Unpack and assemble the
treadmill close to where you plan to use it. Make sure that the flat surface
under the unit is smooth and level. A level unit is required for the user’s
safety and proper operation.
•Provide ample space around the unit.Openspacearoundthe unit makes
for a safer mount and dismount.
•Fill out and mail the limited warranty card. Be sure that the treadmill is
turned OFF. To locate the serial number, place yourself at the rear of the
treadmill facing the display console, kneel down and look under the tread-
mill on the inboard-side of the running bed of the left, rear corner. Write
the serial number onto the Precor limited warranty card found on the back
cover of this manual. Refer to Obtaining Service on page 2 and write the
number(s) there as well.
•Use the appropriate voltage,dedicated circuit,and grounding as speci-
fied on the treadmill. The treadmill is available in both 120-volt and 240-
volt models. Refer to the treadmill’s identification label to determine the
voltage that your treadmill requires. Both the 120-volt and 240-volt mod-
els require a dedicated 20 amp circuit.
CAUTION: Do not use a non-grounded outlet or transformer. Do not
remove or otherwise bypass the plug with an adapter. Electrical dam-
age can occur and void the Precor limited warranty if the treadmill is
connected to an improper power source.
ASSEMBLY INSTRUCTIONS
Take the following steps to assemble the treadmill. We recommend at least
three people help with assembling the unit.
Note: The C956 and C954 treadmills have the same assembly instructions.
The differences appear in the display console and course programs.
1. Obtain assistance. Ask for assistance to help assemble the treadmill.
Have the assistant(s) help place the shipping carton close to the location
where you plan to use the treadmill. Breakdown the side walls of the
shipping carton so that they lie flat. Remove the loose contents.
Setting Up the Treadmill

page 12
COMMERCIAL PRODUCTS DIVISION
CAUTION:Toavoidinjuryand ensure your safety,getassistance before
lifting the treadmill off the pallet and rolling it onto the floor. Do not
drop the unit.
2. Remove the treadmill from its shipping pallet. Eight fasteners secure the
treadmill to its pallet. Use a socket and crescent wrench to loosen and remove
the 4 lag bolts that hold the treadmill to the pallet and the 4 screws (2 on each
side)thatthreadthroughthebracketandintotheunit.Discardthefasteners.Once
thefastenershavebeenremoved,obtainseveralassistantstoliftthetreadmilloff
theshippingpallet.
3. Make sure that the power is OFF. Check the ON/OFF power switch on
the front of the base assembly. Place the switch in the O (OFF) position.
Make sure that the treadmill is not plugged into a power source.
4. Loosen the screws that attach the hood to the base.With the supplied hex
key, loosen the 2 screws on the front panel and the 2 screws on the side (1 on
eachside).To detachthehood fromthebase,stand atthesideofthe treadmill.
Liftthehoodupslightlyandslideittowardtherearoftheunit.RefertoDiagram
10.
Diagram 2 Attach the left
upright support to
the base.
5. Remove 10 buttonhead screws (A) and washers (B) from the Hardware
kit. Place the washers on the screws and split the screws into two sets of 5.
Put the sets in easy reach of the column support mounts (5 screws per side).
6. Attach the left side upright support to the base assembly. Diagram 2.
Locate the left upright support. This is the one you want to install first.
Place the upright support into the base assembly and align all 5 mounting
holes (3 on the side, 2 in the front). Insert 5 screws (A) and washers (B).
Thread the screws into the unit, but leave them loose for final adjustments.
Do not securely tightenthe screws until afterthedisplayconsoleand hand-
railshavebeeninstalled.
Note: The left or right side of the treadmill can be determined when you
stand near the rear roller and face the motor.
Base assembly
Upright support
(left side)
Column support

page 13
COMMERCIAL PRODUCTS DIVISION
7. Route the display cable. Diagram 3. Have an assistant hold the other sup-
port upright. See “Note:” below. Position the display console above the up-
right support and route the cable through it.Pull the cable through the hole in
the upright support.Lay the display console and upright support on the floor.
Note:Tying one end of a string to the end of the cable and the other end to
a washer may help in routing the cable.You can drop the washer through
the upright support and pull the cable through. Refer to Diagram 3, #2.
Diagram 3 Route the cable through the upright support.
12
Diagram 4 Attach the display
console.
8. Secure the display console to the upright support. Attachthe console to
the right side support before placing the assembly onto the treadmill.To do
this, take the following steps:
Upright support
Cable
Right side
support
Displayconsole
(bottomside)
Route the cable through the
hole and tape it to the side of
the upright support.

page 14
COMMERCIAL PRODUCTS DIVISION
a. Make sure that the cable is routed through the hole in the upright support.
b. Place a protective base (cardboard or plastic sheeting from the shipping
container) on the floor. Position the display console (display-side down)
onto it.
c. Remove 2 screws (A) and washers (B) from the hardware kit.
d. Align the upright support mounts with the display console’s.Insert 2 screws
and washers.Tighten the screws securely with the hex key provided.
Diagram 5
Connect the
cable and attach
the right side
support to the
base.
9. Attach the display console assembly to the base. Diagram 5.Take the
following steps to install the display console assembly onto the treadmill.
a. Position the display console and right upright support over the column
support mount located on the base.
Important: Do not crimp or pinch the cable! Crimped or pinched cables
are not covered by the Precor limited warranty.
b. Carefully lower the upright support and align the mounting holes.See Dia-
gram 5 #2. Check that the display console is seated properly on the left
upright support. Insert 5 screws (A) with washers (B).Thread the screws
into the unit, but leave them loose for final adjustments. Do not securely
tightenthe screws until after the displayconsoleandhandrailshave been
installed.
c. Plug the connector intoitsreceptacleonthe lower board. A definite“click”
isheardwhen the cable is properly attached. See Diagram 5 #3.Ifyoudo
not hear and feel the connector “snap”into place, reinsert it.
1
Route cable
through hole.
2
3

page 15
COMMERCIAL PRODUCTS DIVISION
10. Secure the display console to the left upright support. Diagram 6. Align
the mounting holes on the console to those on the left upright support.
Insert 2 screws (A) and washers (B). Do not securely tighten the screws
until after the handrails have been attached.
Important: With the handrails attached, the width of the treadmill is 36.75”
(93 cm).It will not fit through a standard 36” doorway.
11. Attach the handrails. Diagrams 7 and 8.For ease of assembly, place the
side rails or rear feet on blocks. Obtain assistance to lift the treadmill. Do
not place blocks beneath the running bed.
To attach the handrails, perform the following steps on one side at a time :
Diagram 6
Attach the
console to the
left upright
support.
Diagram 7
Handrail alignment and installation.
a. Alignment pins on the top of the handrails necessitate sliding the hand-
rails into the console assembly at an approximate 45οangle. Position the
handrail as shown in Diagram 7 and slide it onto the console extension.
When the alignment pins are fully engaged, carefully lower the handrail
toward the base. Insert 2 screws (C) and finger-tighten.
1
3
2
Buttonhead
screws
Console
extension

page 16
COMMERCIAL PRODUCTS DIVISION
Diagram 8
Secure the handrail to the base.
b. Align the handrail bracket with the 3 base mounts and insert 3 screws (A).
See Diagram 8.Tighten the screws securely.
c. Return to the upper handrail screws and securely tighten each one.
d. Perform steps a. through c. on the opposite side.
e. Obtain assistance and remove the blocks from beneath the base.
Diagram 9
Tightenfrontplate
screws first.Then
securely tighten all
fasteners.
12. Tighten all mounting screws with the hex keys provided. Diagram 9.
Start at the front of the treadmill with the 4 screws that attach the upright
supportstothefrontplate.Tightening these screwsfirst helps pull the rest of
the treadmill’s parts into alignment.Then, proceed with securely tightening
the upright supports and console assembly screws.
Tighten these screws
first on both sides of
the front plate.
Handrail bracket

page 17
COMMERCIAL PRODUCTS DIVISION
Diagram 10
Secure the hood.
13. Attach the hood. Diagram 10. Place the hood over the motor and slide it
under theupper4screws(see Diagram 10 #1)and over the2lowerscrews(1
foundon eachside) of both uprightsupports.
Asyoulowerthe hood,slidethe hoodunderthe washersandontothescrews
(2inthe front, 1 on either sideofthe treadmill). See Diagram 10, #2 and#3.
Retightenthescrewsthat you loosened in step 4. Be sure that the hood is
sandwiched between thebaseassemblyand the washers.The washers
must be on the outside of the hood. Tightenthe screwssecurely usingthe
hex key provided.
CAUTION:Donotovertightenthescrewsor youmay inadvertently cause
stress cracks in the plastic hood.
Diagram 11 Level the unit.
14. TheC956andC954unitshaveadjustablerearfeet.Checktomakesurethatthe
runningsurfaceislevel(useabubblelevelasshowninDiagram11).Ifthetread-
millisplacedonaslightly,unevensurface,adjustingtherearfeetcanhelp,butwill
notcompensateforextremelyunevensurfaces.
1 3
2
1
Slide the
hood under
the 2 screws
found on the
inboard side
of both
upright
supports.
2 4

page 18
COMMERCIAL PRODUCTS DIVISION
Diagram 12
Adjust the rear foot.
Important: If you need to make adjustments, adjust one rear foot at a time.
Do not use the rear foot to raise or lower the unit more than 1/4” in height.
Check the level of the unit after each adjustment.
15 Toadjust a rear foot, locate the nutthat secures the rear footto thedeck.See
Diagram12.Loosenthe nut with a crescent wrench or appropriate open-end
wrench until you can easily turn the foot. See inset in Diagram 12.
CAUTION: Ask for assistance to lift the rear of the unit slightly off
the floor. Lift the unit by its side rails.Trying to lift the unit and adjust
the rear foot without assistance may cause injury to yourself or dam-
age to the unit. Do not try to lift the unit using the running belt.
16. To raise the rear deck, turn the foot clockwise and make the proper height
adjustment.Then, retighten (counterclockwise) the nut securely using the
wrench.
TURNING THE UNIT ON AND OFF
Use the ON/OFF (I/O) power switch to turn the unit ON and OFF.This switch is
located on the front of the unit, near the power cord.
The treadmill requires a dedicated circuit. Plug the power cord into a dedicated
20 amp, grounded, power source. Make sure that no other product or machine
uses the same circuit as the treadmill.
CAUTION: Never remove or bypass the 3-prong plug on the unit’s power
cord with an adapter. Do not use a non-grounded outlet. Do not plug the
treadmill into a power transformer in an attempt to adjust the voltage
requirements.
Tocompletethe installation ofthetreadmill, continueto CheckingtheAlignmentof
theRunningBelt.

page 19
COMMERCIAL PRODUCTS DIVISION
CHECKING THE ALIGNMENT OF THE RUNNING BELT
The belt is aligned at the factory before shipment. However, during shipment or
by using the treadmill on an uneven surface, the belt might move off center.
Proper belt alignment is important because it allows the belt to remain centered
and assures smooth operation.
Follow these steps to check the alignment:
CAUTION: Do not walk on the running belt during this procedure.
1. The treadmill has adjustable rear feet. Check to make sure that the run-
ning surface is level (refer to steps 14 - 16 on the previous pages). If the
treadmill is placed on a slightly uneven surface, adjusting the rear feet
can help, but will not compensate for extremely uneven surfaces.
2. Locate the ON/OFF (I/O) switch at the front of the treadmill and turn ON (I)
the unit.
Note:StandbesidethetreadmillandpressQuickStart.Therunningbeltstarts
automatically after the message, “ Belt Starting 3, 2, 1,... ” appears.
3. Continue standing next to the treadmill and hold down the Speed ▲key
until the display shows a speed of 3 miles per hour (5 kph).
4. Walk around to the rear of the treadmill and observe the belt for a few
minutes as it moves.
If the running belt,... Then,...
tracks centered on the running surface the belt is functioning correctly
(evenly distributed between the side rails) and no adjustment is necessary.
runs or drifts off center you need to adjust the belt; see
Aligning the Running Belt, page 42.
Important: If you notice that the belt needs alignment, make the adjustments
at once. Failure to do so might cause the belt to tear or fray which is not
covered by the Precor limited warranty.
5. To stop the running belt, press the red STOP button.
If the belt is functioning correctly, the treadmill is ready to use. Please continue
on to Club Information to learn how to customize the treadmill for your Club.

page 20
COMMERCIAL PRODUCTS DIVISION
12345
INCL
INE
7
6890
SPE
EDC
ONT
RO
L
RES
ET
ENT
ER
Diagram 13 Display console keypad.
Numericalpad disabled whilein
ClubCustommode.
Thesenext fewpagesprovideinformationthat lets you customize the treadmill for
your Club. It is not information that your customer needs or, necessarily, should
see.This section covers the following information about how to:
• determinewhichlanguageappears on the display
• set maximum speed, workout, and pause times
• design custom courses
• display the odometer and other useful information
• connect to CSAFE compatible devices
Note:Ifyourcustomersareinterestedinthelearningmoreabout theC956 orC954
treadmill,youmay wish todirectthem tothemanualavailableonPrecor’s website
(www.precor.com).(Themanualthatappears onthewebsitedoes notcontainthe
information found in this section.)
Club Information
CHANGING THE CLUB SETTINGS
The Club “custom” settings are accessed through specific codes that help elimi-
nate unauthorized access. Refer to Diagram 13 to locate the keys. Information
that you can access and features that can be customized are as follows:
•Language — Choose to display English, German, Spanish or French.
•Units of Measure — Select between U.S.Standard and Metric displays.
•MaximumSpeed —Determinesthemaximum speedthata user canselect.
Selectionsrange between 0.5 to 12 mph (1 - 20 kph).
•MaximumWorkoutTime — Sets a maximum limit on workout time.
Note: Remember that the user will get an additional 5-minute cool down period
appendedtoacompletedcourse.So, adjustthemaximumtime limitaccordingly.
•Maximum Pause Time — Sets the maximum duration in which a person
can“pause”hisorherworkout.
•Custom Course 1 and 2 —Provides 2 courses that can be customized for
a specific user or general club purpose.
•Odometer, Hours of Use, SoftwareVersion,and Error Log —The treadmill
storesthecumulativemilesorkilometers,thenumberofhoursthattheunithas
been in use, the software version and software type (which is valuable when
callingcustomerservice),andanerrorlog(usefulwhentroubleshooting).
Note: The CHANGE key is not shown in this diagram.
Referto Diagram15 forits location.
Gently, press and hold the
▼ or ▲ key to view the
availableselections.
