Premise VP-CS-CF3 Service manual

MOTION SENSOR
SETTINGS GUIDE
For use with:
LED Vapor Proof Fixture:
VP-484-5 |VP-484-5-347 |VP-484-MS-5
Premise LED Inc.
82-86 Carrier Drive
Toronto, ON Canada
M9W 5R1
BEFORE YOU BEGIN
Before beginning the setup of your moon sensor, please familiarize yourself with
the sensor’s layout and dip switches.
DETECTION
AREA
SETTINGS
HOLD
TIME
SETTINGS
TURN OFF
PERIOD
SETTINGS
STAND-BY
DIMMING LEVEL
SETTINGS
NOT
IN
USE
LED Commercial Linear Strip:
CS-484-4 |CS-484-4-347
CS-484-MS-4 |CS-484-MS-4-347
LED Garage Luminaire
CF3-404-MS-1 |CF3-604-MS-1
CS-Series
VP-Series
CF3-Series

65’
32’
10’
3’
1. Use the DETECTION AREA SETTINGS to set your desired detecon area.
The maximum detecon radius is 65 feet (20 m) and 30 feet (10 m) in
any direcon from the midpoint of the luminaire. The dip switch sengs
allow for the following detecon ranges:
2.
3.
•65 feet (20 m)
•30 feet (10 m)
•10 feet (3 m)
•3 feet (1 m)
TO SETUP THE MOTION SENSOR
1. Next, use the HOLD TIME SETTINGS to indicate the amount of me you
want the luminaire to remain at 100% illuminaon aer no moon is
detected. The dip switch sengs allow for the following hold mes:
•5 seconds
•30 seconds
•90 seconds
• 3 minutes
•20 minutes
•Disabled
1. Next, use the STAND-BY DIMMING LEVEL SETTINGS
to indicate the reduced light level that you would like the luminaire to
remain at aer no moon is detected and the hold me has elasped. The
dip switch sengs allow for the following light levels:
2.
3.
•50%
•30%
•20%
•10%
1. Use the TURN-OFF PERIOD SETTINGS to set how long the luminaire
should remain at the low light level unl turning o completely. If you
want the luminaire to stay illuminated at the low light level without ever
turning o completely, congure the switches to DISABLE. The dip switch
sengs allow for the following hold mes:
•0 seconds
•5 seconds
• 5 minutes
• 10 minutes
• 30 minutes
• 1 hour
•Disabled
1
Moon sensor sengs are now complete. Note that whenever the luminaire turns on for the rst me, it will perform a self-check process that lasts 15
seconds. During this process, the xture will dim down to a lower light level. This operaon is normal.
!
STEP 3
Note: If the sensor is set with any seng other than what is illustrated, the
corresponding features will be disabled. Note: If the sensor is set with any seng other than what is illustrated, the
corresponding features will be disabled.
STEP 1
STEP 2STEP 4
