Premium levella PRNS507DX User manual

Model/Modelo: PRNS507DXPRNS757DXPRNS1057DX
ESPRESSO MAKERMQUINA PARA ESPRESSO
VERTICAL REFRIGERATOR DISPLAY YEXHIBIDOR VERTICAL

1
Dear Consumers:
Thank you very much for purchasing our products. In order to ensure your
safety and achieve the best out of this freezer, pls read this instruction carefully.
Details of Product
1. It uses quality, effective and hermetic compressor with broad range of
starting voltage, suitable ambient temperature: not higher than 38℃,
reasonable matching of the showcase system guarantees its powerful
refrigerant ability and energy saving.
2. Goods stored can be displayed clearly through the door made from
luxurious hollow glass.

¥Shelf installation
A. Hook shelf clips onto clip hanger
B. Place shelves on shelf clips making sure all corners are seated properly
C. Hook the plastic frame of price tag on shelves
Remove the glass door racket from the door efore use
2

Attention: To ensure safety, the power plug must be pulled out before
cleaning. All safety precautions must be followed. Dispose of properly in
accordance with Federal or local regulations. Risk of fire or explosion due
to puncture of refrigerant tubing. Follow handling instrucitons carefully.
DANGER: Risk of fire or explosion. Flammable refrigerant R290 used. To
be repaired only by trained service personnel. Do not use mechanical
devices to defrost refrigerator. Do not puncture refrigerant tubing.
ATTENTION: pour assurer la sécurité, la fiche d'alimentation doit être
retirée avant le nettoyage. Toutes les précautions de sécurité doivent être
respectées. Disposer correctement conformément aux réglementations
fédérales ou locales. Risque d'incendie ou d'explosion dû à la perforation
du tube réfrigérant. Suivre la manutention instrucitons soigneusement.
Danger: risque d'incendie ou d'explosion. Réfrigérant inFlammable R290
utilisé. Être réparé uniquement par un technicien qualifié. N'utilisez pas de
dispositifs mécaniques pour dégivrer le réfrigérateur. Ne pas perforer le
tube réfrigérant.
◆This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
◆Children should be supervised to ensure that they do not play with the appliance.
◆Cleaning and user maintenance shall not be made by children without supervision.
◆Do not store explosive substances such as aerosol cans with a flammable propellant
in this appliance.
◆If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
◆Please according to local regulations regarding disposal of the appliance for its
flammable blowing gas. Before you scrap the appliance, please take off the doors to
prevent children trapped.
◆WARNING – Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
◆WARNING – Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer
◆WARNING – Do not damage the refrigerant circuit.
◆WARNING – Do not use electrical appliances inside the food storage compartments
of the appliance, unless they are of the type recommended by the manufacturer.
◆This appliance is intended to be used in household and similar applications such as
- staff kitchen areas in shops, offices and other working environments;
- farm houses and by clients in hotels, motels and other residential type environments;
- Catering and similar non-retail applications.
◆The appliance shall not be installed in public corridors or lobbies.
◆Please according to local regulations regarding disposal of the appliance for its
flammable gas. Before you scrap the appliance, please take off the doors to prevent
children trapped
◆Warning: the appliance shall be installed in accordance with national wiring
regulations
3

4
◆The appliance is to be installed in accordance with the Safety Standard for
Refrigeration Systems, ANSI/ASHRAE 15.
Notice: Any person who is involved with working on or breaking into a
refrigerant circuit should hold a current valid certificate from an
industry-accredited assessment authority, which authorizes their competence to handle
refrigerants safely in accordance with an industry recognized assessment specification.
Notice: Servicing shall only be performed as recommended by the equipment
manufacturer. Maintenance and repair requiring the assistance of other skilled
personnel shall be carried out under the supervision of the person competent in the use
of flammable refrigerants.
Notice: Component parts shall be replaced with like components so as to minimize the
risk of possible ignition due to incorrect parts.
The appliance is to be installed in accordance with the Safety
◆WARNING
Do not use means to accelerate the defrosting process or to clean, other than those
recommended by the manufacturer.
The appliance shall be stored in a room without continuously operating ignition
sources(for example: open flames, an operating gas appliance or an operating electric
heater.
Do not pierce or burn.
Be aware that refrigerants may not contain an odour.
◆Warning: The appliance shall be stored in a well-ventilated area where the
room size corresponds to the room area as specified for operation;
Warning: The appliance shall be stored in a room without continuously
operating open flames (for example an operating gas appliance) and ignition
sources (for example an operating electric heater).
Warning: The appliance shall be stored so as to prevent mechanical damage
from occurring.
Warning: Risk of fire / flammable materials, taking care to avoid causing a fire
by igniting flammable material.
The maximum loading of each type of shelf is 8kg.
The ambient temperature and humidity conditions of the show case climate class
following the tab below
Test room
climate class
Dry bulb
temperature ℃
Relative
humidity %
Dew point ℃Water vapour
mass in dry air
g/kg
0 20 50 9.3 7.3
1 16 80 12.6 9.1
8 23.9 55 14.3 10.2
2 22 65 15.2 10.8
3 25 60 16.7 12.0
4 30 55 20.0 14.8
6 27 70 21.1 15.8
5 40 40 23.9 18.8
7 35 75 30.0 27.3
NOTE the water vapour mass dry air is one of the main points influencing the performance

5
and the energy consumption of the cabinets. Therefore, the order of the climate class in the
table is based on the water vapour mass column. See also Annex B to compare lab and store
conditions.
Maintenance
All maintenance staff and others working in the local area shall be instructed on the
nature of work being carried out. Work in confined spaces shall be avoided.
If any hot work is to be conducted on the refrigerating equipment or any associated
parts, appropriate fire extinguishing equipment shall be available on hand. A dry
chemical or CO2 fire extinguisher should be adjacent to the charging area.
Notice: Any person who is involved with working on or breaking into a
refrigerant circuit should hold a current valid certificate from an
industry-accredited assessment authority, which authorizes their competence to
handle refrigerants safely in accordance with an industry recognized assessment
specification.
Notice: Servicing shall only be performed as recommended by the equipment
manufacturer. Maintenance and repair requiring the assistance of other skilled
personnel shall be carried out under the supervision of the person competent in the
use of flammable refrigerants.
No person carrying out work in rel ation to a REFRIGERATING SYSTEM which
involves exposing any pipe work shall use any sources of ignition in such a manner
that it may lead to the risk of fire or explosion. AIl possible ignition sources, incl
luding cigarette smoking, should be kept sufficiently far away from the site of
installation, repairing, removing and disposal,during which refrigerant can possibly
be rel leased to the surrounding space. Prior to work taking pl ace, the area around
the equipment shall be surveyed to make sure that there are no flammable
hazards or ignition risks.“No Smoking" signs shall be displ layed.
Checking for presence of refrigerant, The area shall be checked with an
appropriate refrigerant detector prior to and during work, to ensure the technician is
aware of potentially toxic or fl lammable atmospheres. Ensure that the leak
detection equipment being used is suitable for use with all applicable refrigerants,
i.e., nonsparking, adequately sealed, or intrinsically safe.
Ensure that the area is in the open or that it is adequately ventilated before
breaking into the system or conducting any hot work. A degree of ventil lation shall
continue during the period that the work is carried out. The ventilation should safely
disperse any rel leased refrigerant and preferably expel it externally into the
atmosphere.
Where electrical components are being changed, they shall be fit for the purpose
and to the correct specification. At all times, the manufacturer's maintenance and
service guidelines shall be followed. If in doubt, consult the manufacturer's
technical department for assistance.
Detection of flammable refrigerants: Under no circumstances shall potential
sources of ignition be used in the searching for or detection of refrigerant leaks. A
halide torch (or any other detector using a naked flame) shall not be used.
Defrosting
Defrost for better freezing efficiency when the frost film in the cabinet is 4-5mm
thick.
When defrosting, turn off the power, take out the frozen foods, open the door for
warming and melting. Use soft cloth to absorb water and clean it up.

6
Do not use sharp metal tools such as steel brush to clean the frost film when
defrosting so as to avoid evaporator damage.
Trouble Shooting
Breakdown Case Removal method
The indicator is not on.
The compressor doses not
start.
The plug isn’t connected to
the
socket really. Replug it.
no power Connect the socket with
power.
The indicator is on ,but the
com- pressor doesn’t work
and buzzes only The power voltage is＜98V. Put a power-regulater more
than
1000W power together.
Th
e compressor s
t
ops a
minute after start, and
restart after a few minutes,
and so re
p
eatedl
y
.
The power voltage is＞
132V.
The compressor works
normally,
but the temperature in the
cabinet
lowers too slowly.
The door is opened too
frequently. Reduce open times.
The food in the cabinet is
too
much, and placed
improperly.
Pl
ace
f
oo
d
s proper
l
y
k
eep
place
between them for
ventilation of
cold air.
The frost film is too thick. Take out foods and defrost.
Th
e sur
f
ace o
f th
e
condenser is
too dirt
y
.
Stop and clean the
condenser.
The door seals badl
y
. Ad
j
ust the door seal.
The noise is too loud
The freezer is placed
unstably. Place it stably.
The fixing of the freezer is
loose. Tighten the fixing.
there’s contact between
pipes. Separate them.
The following are not faults:
When the freezer is working or after stopping for a while, the refrigerant in
the pipes is cycling and gives out＂running water＂sounds.
The surface temperature of the compressor may be up 70℃~80℃when it
is working.
The back side of step cooler gives out heat.
In rainy season, the outer surface of the cabinet may have dew, which
makes no defects on normal use. Just dry it with a piece of cloth.

7
