Installation and Maintenance Manual
Freestanding Gas Stove
MODEL: PGS3006 GPEES30C

--
Warning
����Maintenanceproductsshouldbecarriedoutbyprofessionalandtechnicalpersonnelwithrelevantqualification,as
impropermaintenancemayleadtootherdangers!
����Beforemaintenance,besuretocutoffthepower!
����Ifthepowerlineshavefaulthiddendangers,itisrequiredtoreplacethepowerlineswithrelevanttechnicalparameters
(seethemanualforparameters)!
�Beforemaintenanceofproduct,pleasereadthesafetywarningsinthismanualcarefully!

--
Table
SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS……………………………………………………………………………1
TECHNICALINFORMATION…………………………………………………………….1
INSTALLATIONS INSTALLATIONS INSTALLATIONS INSTALLATIONS……………………………………………………………………………..2
SAFETYPRECAUTIONSFORINSTALLATION…………………………………..2
INSTALLATIONOFOVEN………………………………………………………………..2
SERVICE SERVICE SERVICE SERVICEINFORMATION INFORMATION INFORMATION INFORMATION…………………………………………………………………3
NECESSARYTOOLS…………………………………………………………………...3
DISASSEMBLYANDADJUSTMENT……………………………………………….5
COMPONENTS COMPONENTS COMPONENTS COMPONENTSTEST TEST TEST TESTPROCEDURE PROCEDURE PROCEDURE PROCEDURE…………………………………………………6
TROUBLESHOOTING TROUBLESHOOTING TROUBLESHOOTING TROUBLESHOOTING……………………………………………………………………....7
EXPLODE EXPLODE EXPLODE EXPLODEVIEW VIEW VIEW VIEW………………………………………………………………………………8

- - - 1 -
Specification
Technical Parameters
Product Type
Product Dimensions
(Height / width / depth) (mm) 760*600*940
Maximum temperature 250°C
Function switch (quantity) 9/11
Grill number of layers 4
Nozzle hole diameter (mm) φ0.88/φ0.5/φ0.64/φ0.8
Heating tube power (down) (W) 2800
30inch

- - - 2 -
Installation
Before Maintenance, please read the following instructions carefully!
Installation Warning
1. All the equipment around 50mm of the product should be able to have heat resistance above 75 ° C, otherwise, nearby
apparatus may deform during the use of this product.
2. When removing packing materials, keep metal plates, packaging bags, foam, screws and other materials away from the
reach of children to avoid potential threat. For example, children may swallow small parts or lead to asphyxiation when
play packaging bags.
Oven Installation
1. Please remove packaging first, and then install in reference to the below specified size. (Please dispose packaging
materials properly)
2. If it is necessary to lift or move the oven, please open the oven door, touch the top and square holes on the back. Please
do not directly use oven door handle to lift the oven.
3. The oven should not touch or get close to flammable, explosive, non-temperature items.
4. Floor for placing the oven should be smooth enough to ensure sufficient stability for the product.
5. Product dimensions (Height / width / depth) (mm) 760*600*940

- - - 3 -
Maintenance Information
Relevant Tools
Relevant tools list.
•
•
•
•Drill steel clamp (vise) •
•
•
•Needle-nosed pliers •
•
•
•Phillips screwdriver •
•
•
•Electric iron
•
•
•
•Solder wire •
•
•
•Insulation tape •
•
•
•Sandpaper •
•
•
•DC Voltage Meter
•
•
•
•AC Voltage Meter •
•
•
•Ohm meter
Disassemble and repair
A. The removal of door
1) Open the oven door to the horizontal position.
2) Slide snaps of the left and right hinge to the maximum position. (See below pictures)
3) Close the door to 50 degrees position, grasp the door with both hands, pull together with the hinge. (See below
pictures)
Warning: the door can not be pulled out forcibly to prevent broken glass in the removal process

- - - 4 -
B. The removal of cooktop back guard
1) Remove the screws for fixing the back board. (See below pictures)
C. Remove the right and left bracket of the cooktop
1) Turn off the gas source.
2) Remove the screws on supporting blocks of both sides of the cooktop cover. (See below pictures)
Remove the screws

- - - 5 -
D. Remove of the stove board
1) Turn off the gas supply, disconnect the power, remove the power line.
2) Remove back plate connection board
3) Remove the screws of the end of the cooking plate connection the cup（See below pictures）
4）Push forward 10-20mm from behind of the stove board by hand, then use the appropriate force to squeeze the side of the
stove board, take down the stove board carefully(can’t take down forcibly)
5) According to the maintenance circuit diagram of part of the power failure or gas source inspection and maintenance

- - - 6 -
E．Removal and Replacement of Glass Door
1) Remove the door and lie flat carefully.
2) Remove the screws for fixing supporting blocks at the bottom of door.
3) Remove the screws for fixing handle, remove the handle, seal and window glass outside the door
carefully.
4) Remove the silica in the four corners of inside glass with a blade or other tools.( Glass with care)
5) Replace glass in the same specifications provided by manufactures.(Glass must be high temperature
and toughened)
Relevant Test of Parts
Pneumatic
control part
Push from back
to front 5~10mm

---7-
Parts
T estprogramResults
Stovebody T esttightness
(useairtightinstrumenttest:under15kpa
pressure)
Normal:lessthan0.5ml/min,
Fault:∞ormorethan0.5

---8-
Troubleshooting
Whenyoureceivecustomercomplaints,whatneedstodofirstisanalyzingcomplaintscarefully.Ifsomeofthefollowing
situationissuitable,pleasetellthecustomerhowtousetheovenproperly.Thiswillavoidunnecessarymaintenance.
Attention!
1.Checkgroundingbeforetrouble
2.Notethatsomehigh-voltagecircuit
SituationCheckResults
Causes
Resolve
Ovendoesnot
work
Checkwhetherthe
switchispoweron
Nopower
SwitchfailureReplace
Checkwhetherthe
energizedcableis
poweron
Nopower
Energizedcable
failure
Replace
Ovennot
heating
Checktheupper
heatingtube
components
AbnormalDamageReplace
Abnormal Checktheunder
heatingtube
components
DamageReplace
Abnormal StoveheatingtubeDamageReplace
Connectorpoor
contact
Replace/
service
