Prestige 500 User manual

USER GUIDE

Wlcome a
You have just taken delivery of your PRESTIGE 500 - congratulations!
Designed and built by Jeanneau professionals, your boat will be a source of great happiness.
The entire PRESTIGE team is now at your service.
Close to 300 dealers who share our values and love of boats have been selected from dealerships around the world.
They have been carefully trained in three essential areas: customer counselling, diagnostics and problem solving.
Threy are also equipped with an innovative logistical support service to ensure timely delivery of spare parts.
We are proud to sharing our passion for the sea with you and we will be there to assist you throughout the life of your boat.
To begin, we have developed this technical guide as a resource for you. Please read through it carefully to learn more about optimal
conditions for use of your boat and to ensure your full satisfaction.
As you take the helm of your new PRESTIGE, I wish you fair winds.
JP Chapeleau
GENERAL MANAGER

Preamble
 This instruction guide is a tool that will enable you get to know your boat and apprehend the use of the components that
are necessary for running her. Some of the equipments mentioned in this guide are optional fittings.
 A WAY TO MAKE THE MOST OF THIS INSTRUCTION GUIDE
In order to have an easier apprehension, this guide offers you two complementary reading levels:
. The pages with text on the right hand side of the document develop the different subjects dealt with in the chapters,
. The pages on the left hand side are given to the related photos, layouts or block diagrams.
 The different warnings used throughout this guide are as follows:
 Before you put out to sea, please read the owner’s manual (CE standard manual) delivered with your boat and please follow
the instructions.
RECOMMENDATION
Shows a piece of advice to do the appropriate actions or
manoeuvres adapted to what you are thinking of doing.
Draws your attention on dangerous ways of doing that may
bring about injuries to people or damages to the boat or her
components.
Warns you about the existence of a hazard that may have
serious or fatal consequences if the appropriate precautions
are not taken.

7.1 Engines
7.2 Fuel
7.3 Dash boards
7.4 Steering system
7.5 Demister
7.6 Trim tabs
7.7 Propellers and anodes
7.8 Bow thruster
8.1 Laying up
8.2 Protection
9.1 Preparation
9.2 Crane lifting
10.1 Prevention
10.2 Gas system
10.3 Fire
10.4 Bilge pump system
10.5 Safety equipments
10.6 General remarks
11.1 Maintenance schedule
1.1 I D of your boat
1.2 Technical specifications
1.3 Wheelhouse helm description
1.4 Flying bridge control house description
1.5 24 V - 230 V electrical panel description
2.1 Construction
2.2 Careening
2.3 Deck fitting
2.4 Access to the boat
2.5 Cockpit
2.6 Flying bridge
2.7 Access to the crew cabin
2.8 Retractable sun awning
2.9 Deck wash pump
2.10 Swim ladder
2.11 Deck searchlight
2.12 Underwater spotlights
2.13 Capstan
2.14 Anchoring
2.15 Gangway
2.16 Hydraulic platform
3.1 Saloon table
3.2 Floorboards
3.3 Portholes - Deck hatches
3.4 Windows
3.5 Cabins
3.6 Helm stations
1 Specifications Page 07
5
Contents
2 Hull / deck Page 17
3 Accommodations Page 35
4.1 Slot-in television
4.2 Flying bridge refrigerator
4.3 Flying bridge grill
4.4 Icemaker
4.5 Microwave oven
4.6 Stove unit
4.7 Induction cooktop
4.8 Extractor hood
4.9 Refrigerator / freezer
4.10 Dishwasher
4.11 Washer dryer
4.12 Safe
4.13 Heating
4.14 Air conditionning
5.1 Bilge pump system
5.2 Grey waters
5.3 Black waters
5.4 Fresh water
6.1 24 V circuit
6.2 Inverters
6.3 230 V circuit
6.4 Electronics
5 Water systems Page 55
6 Electricity Page 65
10 Safety
11 Maintenance
8 Winter storage
9 Handling
4 Utility aboard Page 41 7 Propulsion Page 81
Page 93
Page 97
Page 101
Page 115
Code 136497 - Indice C

7
Specifications
1.1 I.D. of your boat
1.2 Technical specifications
1.3 Wheelhouse helm description
1.4 Flying bridge control house description
1.5 24 V - 230 V electrical panel description
1

NAME OF YOUR BOAT: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
VERSION: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DELIVERY DATE: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REGISTRATION NUMBER: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DOOR KEY NUMBER: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HULL NUMBER: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MAKE OF THE ENGINES: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
NUMBERS OF THE ENGINE KEYS: . . . . . . . . . . . . . . . . . . . . . . . .
SERIAL NUMBER OF THE STARBOARD ENGINE: . . . . . . . . . . . . .
SERIAL NUMBER OF THE PORT ENGINE: . . . . . . . . . . . . . . . . . . .
FURTHER INFORMATION: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OWNER’S NAME: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ADDRESS: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
E-MAIL ADDRESS: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LANDLINE PHONE NUMBER: . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MOBILE PHONE NUMBER: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
9
Your boat
BP 529 - 85505 LES HERBIERS CEDEX - FRANCE - TEL [phone] - FAX [phone] - www.prestige-yachts.com

10
Design categories
CATEGORY A
The boat is designed for sailing in winds that may exceed force 8 on the Beau-
fort Scale and in waves of a significant height of 4m and more and the boat is
to a large extent self-sufficient.
Unusual conditions such as hurricanes are excluded.
You may meet with such conditions when you sail long crossings, for instance
across the oceans, or close to the shore when you are not protected from the
wind or waves over several hundreds of nautical miles.
CATEGORY B
The boat is designed for sailing in winds that do not exceed force 8 on the
Beaufort Scale and in the corresponding waves (waves of a significant height
inferior or equal to 4m).
You may meet with such conditions when you sail offshore or close to the
shore when you are not protected from the wind or waves over several dozens
of nautical miles. You may also meet with such conditions in inland seas of a
sufficient size to be able to give the wave height in question.
CATEGORY C
The boat is designed for sailing in winds that do not exceed force 6 on the
Beaufort Scale and in the corresponding waves (waves of a significant height
inferior or equal to 2m).
You may meet with such conditions in exposed inland waters, in estuaries and
in coastal waters with mild weather conditions.
CATEGORY D
The boat is designed for sailing in winds that do not exceed force 4 on the
Beaufort Scale and in the corresponding waves (occasional 0.5m high waves
at a maximum).
You may meet with such conditions in sheltered inland waters and in coastal
waters in fine weather.
NOTE :
The significant height of a wave is the average height of the upper third of the
waves; this corresponds more or less to the height of a wave an experienced
observer can assess.
Some waves will be twice as high as this value.

Length overall (L. O. A.) . . . . . . . . . . . . . . . . . . . . . . . . . . . 15,20 m / 49'10"
Hull Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14,92 m / 48'11"
Beam. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4,50 m / 14'9"
Air draft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5,23 m / 17'1"
Draft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1,05 m / 3'5"
Light displacement . . . . . . . . . . . . . . . . . . . . . . . . . . . 14100 kg / 30080 lbs
Maximum load displacement . . . . . . . . . . . . . . . . . . . . 19862 kg / 43795 lbs
Manufacturer’s maximum recommended load . . . . . . . B/4900 kg - C/4950 kg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B/10805 lbs - C/10915 lbs
Fresh water capacity . . . . . . . . . . . . . . . . . . . . . . . . 2 x 318 l / 2 x 84 US gal
Black water capacity . . . . . . 120 l / 32 US gal + 50 l / 13 US gal / crew cabin
Fuel capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 x 650 l / 2 x 172 US gal
Refrigeration unit capacity 24 V . . . . . . . . . . . 218 l/galley - 80 l/flying bridge
. . . . . . . . . . . . . . . . . . . . . . . . . . 58 US gal/galley - 21 US gal/flying bridge
24 V BATTERY CAPACITY
Domestic system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 x 140 Ah
Engine system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 x 50 Ah
Bow thruster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 x 55 Ah
12 V BATTERY CAPACITY
Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 x 50 Ah
Maximum engine power . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 x 435 HP (IPS)
Design category. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B / C
CE CATEGORY Maximum number of persons
A.................................................................................
B.........................................................................12 persons
C.........................................................................14 persons
D.................................................................................
1
11
Technical specifications
Bottom surface: 52,5 m2 / 565 sq ft

12 2 3 4 51 7
1 1 68 9 10
11
12
13
14
1 - Screen/ repeater for the electronic system
(optional fitting).
2 - Compass.
3 - Port engine rev counter.
4 - Rudder angle indicator.
5 - Starboard engine rev counter.
6 - Adjustable steering wheel.
7 - VHF radio (optional fitting).
8 - Bow thruster control (optional fitting).
9 - Trim tab control.
10 - Engine controls.
11 - Air conditioning control (optional fitting).
12 - Deck searchlight control (optional fitting).
13 - Release pull handle of engine extinguisher.
14 - 24 V switches (for more details about their
functionalities, see p.66).
WHEELHOUSE HELM
WHEELHOUSE HELM

1
13
2 3 4 51 96 7510
1 - Adjustable steering wheel.
2 - VHF radio (optional fitting).
3 - Port engine rev counter.
4 - Rudder angle indicator.
5 - Screen/ repeater for the electronic system
(optional fitting).
6 - Compass.
7 - Engine controls.
8 - Starboard engine rev counter.
9 - VHF loudspeaker (optional fittin).
10 - Engine control screens.
11 - Bow thruster control (optional fitting).
12 - Joystick / engine controls (optional fitting).
13 - Engine start / stop control unit.
14 - Trim tab control.
15 - Deck searchlight control (optional fitting).
8
11
14
12
13
15
FLYING BRIDGE CONTROL HOUSE
FLYING BRIDGE CONTROL HOUSE

14
24 V - 230 V ELECTRICAL PANEL
34
5
2
1
10 11 12 13 14 15
689
18 19
16
7
17

1
15
LEGEND OF THE OPPOSITE PICTURE / 24 V - 230 V ELECTRICAL PANEL
1 - Starboard water tank gauge.
2 - Port water tank gauge.
3 - Ammeter.
4 - Ammeter selector.
5 - General ON/OFF cut out.
6 - Generator control (optional fitting).
7 - 230 V generator - shore supply selector / on board equipment.
8 - Voltmeter.
9 - 230 V generator - shore supply selector / air conditioning (optional fitting).
10 - On board positive cut out.
11 - General negative cut out.
12 - Starboard engine positive cut out.
13 - Port engine positive cut out.
14 - Bow thruster positive cut out (optional fitting).
15 - Bow thruster negative cut out (optional fitting).
16 - 24 V / 230 V inverter control.
17 - Control to start the air conditioning.
18 - Water heater ON / OFF switches.
19 - 230 V selectors ON / OFF switches.

2
17
Hull / deck
2.1 Construction
2.2 Careening
2.3 Deck fitting
2.4 Access to the boat
2.5 Cockpit
2.6 Flying bridge
2.7 Access to the crew cabin
2.8 Retractable sun awning
2.9 Deck wash pump
2.10 Swim ladder
2.11 Deck searchlight
2.12 Underwater spotlights
2.13 Capstan
2.14 Anchoring
2.15 Gangway
2.16 Hydraulic platform

18
