Presto TT Series Setup guide

TT & WT and
ECOA HTT & HUE
Series Tilt Tables
Installation, Operation
and Service Manual
Model Number ___________________
Serial # _________________________
Date Placed in Service _____________
IMPORTANT: READ CAREFULLY
BEFORE INSTALLING OR OPERATING LIFT
Part orders are subject to a $50 minimum charge.
January 2017

Page 2 — OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series
This manual was current at the time of printing. To obtain the latest, most updated version,
please contact Presto/ECOA Lifts Customer Service Department or go to our website:
www.PrestoLifts.com where you will nd a complete list of current owner’s manuals to print.

OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series — Page 3
C O N T E N T S
SECTION 1: Introduction ........................................................................................................................4
Responsibility of Owners and Users .....................................................................................................5
Safety Alert Symbols and Signal Words................................................................................................6
SECTION 2: Safety ................................................................................................................................7
SECTION 3: Installation ..........................................................................................................................8
A. Inspection..........................................................................................................................................8
B. Installing............................................................................................................................................8
C. Hydraulics .........................................................................................................................................8
D. Testing the Tilter with No Load..........................................................................................................9
SECTION 4: Operation ............................................................................................................................9
A. Method of Operation..........................................................................................................................9
B. Operation Procedures.......................................................................................................................9
SECTION 5: Maintenance .....................................................................................................................10
A. Routine Maintenance .....................................................................................................................10
B. Troubleshooting Maintenance.........................................................................................................10
PARTS / QUALITY ISSUES / GENERAL ...............................................................................................16
ORDERING REPLACEMENT PARTS ...................................................................................................17
LIST OF FIGURES:
Figure 1 Hydraulic Schematic.................................................................................................................12
Figure 2 Hydraulic Power Unit Wiring Diagram......................................................................................12
Figure 3 Electrical Schematic Pump Unit Single Phase 115 Volts AC....................................................13
Figure 4 Electrical Schematic Pump Unit 1 Phase 208, 240 Volts AC ...................................................14
Figure 5 Labels and Label Location .......................................................................................................15
Figure 6 WT Series Wide Base Tilt Specications .................................................................................19
Figure 7 Labels and Locations ...............................................................................................................15
LIST OF TABLES:
Table 1 Hydraulic Oil Specications .......................................................................................................14
WARRANTY ............................................................................................................................. Back Page

Page 4 — OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series
S E C T I O N 1
INTRODUCTION
The lifts and tilters are designed for litng, tilting and position a wide variety of loads. These tilters are
capable of being mounted on other Presto-ECOA tables and stands or lagged directly to the oor.
These lifts are designed for in-plant/non-hazardous location use only.
This manual attempts to provide all of the information necessary for the safe and proper installation,
operation and maintenance of these tilters. It is important that this manual be read by all personnel
involved with the installation, maintenance or operation of the tilter. If the manual does not address an
application, call your distributor or Presto-ECOA Lifts for assistance. Additional manuals are available
upon request at www.PrestoLifts.com.
The tilter has a nameplate that provides the load capacity rating, serial number and model identication.
Please refer to these numbers when ordering parts or requesting further information.

OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series — Page 5
Responsibility of Owners and Users
Inspection and Maintenance
The device shall be inspected and maintained in proper working order in accordance with Presto-
ECOA owner’s manual.
Removal from Service
Any device not in safe operating condition such as, but not limited to, excessive leakage, missing
rollers, pins, or fasteners, any bent or cracked structural members, cut or frayed electric, hydraulic,
or pneumatic lines, damaged or malfunctioning controls or safety devices, etc. shall be removed
from service until it is repaired to the original manufacturer’s standards.
Repairs
All repairs shall be made by qualied personnel in conformance with Presto's instructions.
Operators
Only trained personnel and authorized personnel shall be permitted to operate these lifts.
Before Operation
Before using the device, the operator shall have:
• Read and/or had explained, and understood, the manufacturer’s operating instructions and
safety rules.
• Inspected the device for proper operation and condition. Any suspect item shall be carefully
examined and a determination made by a qualied person as to whether it constitutes a hazard.
All items not in conformance with Presto’s specication shall be corrected before further use
of these lifts.
During Operation
The device shall only be used in accordance with this owner’s manual.
• Do not overload.
• Ensure that all safety devices are operational and in place.
Modications or Alterations
Modications or alterations to any Presto-ECOA industrial positioning equipment shall be made only
with written permission from Presto.

Page 6 — OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series
SAFETY ALERT SYMBOLS AND SIGNAL WORDS
The safety of all persons operating, maintaining, repairing, or in the vicinity of this equipment is of paramount concern. This is
a powerful machine with moving parts, and is capable of causing personal injury if proper precautions are not taken. Therefore,
throughout this manual, certain hazards have been identied which may occur in the use of the machine, and there are appropriate
instructions or precautions which should be taken to avoid these hazards. In some cases, there are consequences which
may occur if instructions or precautions are not followed. Below are the symbols and signal words along with their denitions
referenced from ANSI Z535.4 - Product Safety Signs and Labels.
4.11 Safety Alert Symbols: A symbol that indicates a hazard. It is composed of an equilateral triangle surrounding
an exclamation mark. The safety alert symbol is only used on hazard alerting signs. It is not used on safety notice and safety
instructions signs.
4.14 Signal Words: The words used in the signal word panel. The signal words for hazard alerting signs are “DANGER,”
“WARNING,” and “CAUTION.” Safety notice signs use the signal word “NOTICE.” Safety instruction signs use signal words that
are specic to the situation.
DANGER indicates a hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
NOTICE is used to address practices not related to physical injury.
SAFETY INSTRUCTIONS (or equivalent) signs indicate specic safety-
related instructions or procedures.
NOTE: DANGER, WARNING or CAUTION should not be considered for property damage accidents unless personal injury risk
appropriate to these levels is involved.
A): for use with DANGER signal word; (safety white triangle, safety red exclamation mark, safety red background)
B): for use with WARNING signal word; (safety black triangle, safety orange exclamation mark)
C): for use with CAUTION signal word; (safety black triangle, safety yellow exclamation mark)
D) and E): for use with DANGER, WARNING, or CAUTION signal word; (D: is a safety yellow triangle with a
black border and safety black exclamation mark; E: is a safety yellow triangle with a safety black exclamation mark and a
safety yellow border around a safety black band)
NOTE: D and E are provided to allow for consistency with certain ISO standards such as ISO 3864-1 and ISO 3864-2.

OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series — Page 7
WARNING!
• Do not perform any repair work on a lift with a load on the platform or with the table in a raised position.
• All personnel must stand clear of the lift when the lift is in motion.
• Do not put hands or feet under lift table.
• Do not perform any repair or maintenance work with the lift in an open position without securing it
rst with proper maintenance devices.
• Do not stand, sit or climb on the lift at any time.
• Do not use the lift on soft, uneven or unstable surfaces.
• Do not exceed the load capacity rating on the data plate.
• Do not place a load on a moving lift.
• Do not exceed load capacity.
• Place a load in the center of the lift and be sure that the load is secured properly.
S E C T I O N 2
SAFETY
The safety of all persons installing, using, servicing, or working near the unit is of paramount concern to
Presto-ECOA Lifts. The lift is a powerful machine with moving parts, and is capable of causing personal
injury if proper precautions are not taken. Therefore, throughout this manual, Presto-ECOA Lifts have
identied certain hazards, which may occur in the use of the unit, and provided appropriate instructions
or precautions that should be taken to avoid these hazards. In some cases, Presto-ECOA Lifts has also
pointed out the consequences that may occur if Presto-ECOA Lifts instructions or precautions are not
followed. Presto-ECOA Lifts use the following nationally recognized system for identifying the severity
of the hazards associated with its products:
DANGER – Immediate hazard that will result in severe personal injury or death.
WARNING – Hazard or unsafe practice, that could result in severe personal injury or death.
CAUTION – Hazard or unsafe practice, that could result in minor personal injury or property
damage.
In the interest of safety, please read the entire manual carefully. You must understand the material
in this manual before you install, use, or service the unit. If you have any question about any of
the instructions in this manual, please contact Presto-ECOA Lifts at 1-800-343-9322.

Page 8 — OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series
WARNING!
Do not perform any repair work on a lift in a fully
extended position. Unload lift prior to working
under or around.
All personnel must stand clear of the lift when the
lift is in motion.
Do not put hands or feet under lift.
Do not work under lift without securing it rst with
proper maintenance devices.
Do not stand, sit or climb on the lift at any time.
Do not use the lift on soft, uneven or unstable
surfaces.
Do not exceed the load capacity rating on the data
plate.
Do not place a load on a moving lift.
Place a load in the center of the lift and be sure
that the load is secured properly.
S E C T I O N 3
INSTALLATION
A. INSPECTION
Upon receipt of the tilters, inspect the equipment completely
to determine if there is any shipment damage and that the
tilter is complete. Do not use the tilter if there appears to be
any damage. With the tilter in a collapsed position, check
the following:
1. Check for signs of damage, especially to the electricals
and hydraulics.
2. Check all connections for tightness. Also check for vis-
ible hydraulic liquid around the connections.
3. Check for any physical damage to the frame.
4. Inspect the platform for damage, either twisted or bent.
B. INSTALLING
Read all of the instructions prior to starting or connecting
the tilter.
1. Working Area
a) Make sure that the oor and the operation area
is at, stable, relatively smooth and free from dirt,
obstacles and surface defects.
b) Place the empty tilter in the exact operating area
to be sure that there are no encumbrances due to
components or equipment in the general area.
c) Make sure that the complete base of the tilter is in
contact with the oor. In order to complete contact
with the oor, the base may be shimmed or grouted.
d) The tilters are provided with anchoring holes on the
base. Place the tilter in the exact operating position
before spotting and drilling holes for the bolts. Bolt
the lift securely using oor lag bolts with a minimum
of 2000# pull out strength per bolt.
WARNING!
Install the tilter on a solid and stable surface.
CAUTION!
All wiring must conform to local code and must
be performed by licensed electricians. The stan-
dard AC single phase motor requires a 120 volt
20 amp fused outlet, do not remove or replace
the plug or cord set provided. Do not use an
extension cord.
WARNING!
Do not tamper with or remove the cover of
the electrical junction box. Only authorized,
qualied personnel should service the electrical
system. Motor direction is critical. This motor
has been wired according to its nameplate and
should not be tampered with as it may lead to
pump or motor failure.
C. HYDRAULICS
1. Before using the tilter, check the hydraulic oil level by
removing the solid plug from the reservoir. Remove the
plug, check for oil and add oil if necessary. See the chart
below for correct oil level. Replace the plug with the
vented plug provided; if the vented plug is not installed
you may damage the pump. Note: if a vented plug is
not available, the solid plug may be modied by drilling
a 1/8 diameter hole through the center of the plug and
reinstall.
WARNING!
Do not use automotive hydraulic brake or trans-
mission uids, they will damage seals and pose
a serious re hazard.

OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series — Page 9
D. TESTING THE TILTER WITH NO LOAD
Before operating the tilter, read and understand this section.
1. Before testing the tilter, clear the area of any loose mate-
rial. Be sure the tilter has no obstruction above it or on
any side. Using the controls provided, briey operate
the tilter (5-10 seconds). If the tilter begins to rise with
a humming sound and functions properly, continue to
the full upright position.
CAUTION!
If the tilter does not rise immediately, or there is
any operational problem, stop it immediately. Be-
fore continuing, check the rotation of the pump
and motor and the voltage at motor terminals,
again briey operate the tilter. If the tilter does
not move smoothly with the humming sound,
stop and review the procedures in the section
on troubleshooting (Section 5B).
2. After raising the tilter completely, lower the tilter com-
pletely. It should move slowly and smoothly without a
humming sound. If the tilter operates properly, raise
and lower the tilter and stop at different levels in order
to familiarize yourself with the tilter’s operations and
movements.
WARNING!
As the tilter platform and forks move up and
down, pinch points are created at locations near
the base of the frame. While operating the tilter
the operator should be standing clear of the tilter
and container while in use. In that way, the op-
erator’s arms, legs or clothing will not be caught
in the moving parts. During operations the op-
erator should avoid the pinch point areas which
are located on either side of the tilter. See the
diagram pointing out the particular pinch points.
S E C T I O N 4
OPERATION
A. METHOD OF OPERATION
All tilters are provided with a special hydraulic relief valve,
which is factory preset to the maximum safe capacity of the
container tilter (see the nameplate attached to the tilter.)
Activating and holding the up switch will energize the motor.
The motor is attached to a positive displacement pump which
draws hydraulic uid from the reservoir and transfers it under
pressure to the cylinder. This forces the piston forward and
the raise to rise in a thirty (30º) to ninety degree (90º) arc.
Releasing the up button will stop the tilter. A check valve
between the pump and piston holds the platform in position.
Depressing and holding the down button of the switch will
energize a solenoid, which allows the oil from the cylinder
to return to the reservoir through a preset ow control. This
allows the tilter to lower smoothly and at a controlled speed.
CAUTION!
Do not maintain the up button on the switch en-
ergized if the tilter does not move or has reached
its upper limit. This may cause damage to the
motor, pump and controls.
B. OPERATION PROCEDURES
In order to operate the tilter, follow these operating proce-
dures:
1. Read and understand all the instructions before op-
erating. If the tilter has modications or accessories,
read and understand their functions.
2. Load the tilter correctly. Refer to the attached name-
plate for load capacity information.
a) Load the tilter while it is in the lowered position.
b) Do not exceed the maximum rated load (note
that load capacity is on the nameplate of the
tilter).
c) Place the load in the center and at the very back
of the platform (pivot end).
d) If the load is unstable or may become unstable,
fasten it into position.
e) Use additional precautions when tilting a load
of loose parts. Excessive (what?) can cause
parts to fall out of the container.
3. Operate the tilter.
a) To raise the tilter, press and hold the up button
on the switch.
b) To lower the tilter, press the down button on the
switch.
c) Release the button to stop the tilter in either
direction.
4. Wait until the tilter has come to a complete stop
before loading or unloading.
5. Stand clear of the tilter when operating in order to
avoid injury.

Page 10 — OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series
WARNING!
• Do not stand, sit or climb onto the tilter.
• Do not load or unload a moving tilter.
• If the tilter fails to move or exhibits strange movements
or sounds, stop immediately. Do not operate the tilter
until it has been checked and repaired.
• Obey all warning labels.
• Load the lift only in the lowered position.
• Do not stand near the tilting side when tilting containers
of loose parts. Parts may fall out of the container and
could harm the operator.
6. All people and unrelated objects must stand clear of
the lift when operating in order to avoid personal injury or
property damage.
S E C T I O N 5
MAINTENANCE
Generally, the tilter lifts will require little maintenance. How-
ever, routine inspection and maintenance will minimize costly
repairs or hazardous conditions.
WARNING!
Before servicing the unit, read and understand
this entire section and the section entitled Op-
erating Instructions. Never go under or service
a tilter with a load on the platform or with the
platform in a raised position. Always service the
tilter in a down or chocked position.
A. ROUTINE MAINTENANCE
All routine inspection and maintenance should be performed
monthly. When servicing the tilter in a partially or fully raised
position, chocks or safety pins must be in place to secure the
platform during maintenance. Follow the chocking procedure
in Section 5B if chocks or safety pins are not available. Con-
tact Presto-ECOA for the recommended parts.
1. Safety steps
a) The unit using a power supply of 115 Volt AC must
be disconnected from its power source. Do not work
on electrical parts unless you are a qualied electrician.
b) AC 3 phase or high voltage units must have the power
disconnected via standard lock out, tag out procedures
prior to servicing. Do not move the unit in an up or down
motion while performing maintenance.
c) For performing any maintenance the unit must be
fully secured according to Section 5B. Do not remove
hydraulic lines unless the tilter has been lowered to its
fully secured position. This should be veried several
times by pushing the down button on the switch.
d) When removing hydraulic hoses, crack the ttings
slowly to be sure that any hydraulic pressure that my
be residual is released.
2. Inspect the following:
a) Check the oil level and add oil if necessary according
to the instructions on the hydraulic chart and schematic.
b) Check the bolts on the pivot bar that holds the tilt
platform in place, if loose tighten.
c) Check hydraulic lines for damage or leaking. Replace
if damaged.
d) Check for oil spots or leaks around tting and tighten.
e) Check wiring for damage. Replace immediately if
any signs of wear are evident.
f) Bearings on all lifts are permanently lubricated. (Do
not lubricate bearings.) Replace if worn.
B. TROUBLESHOOTING MAINTENANCE
All servicing should be done by qualied personnel who
should have read and understood all of the information pro-
vided in the Operating, Installation and Maintenance sections
in this manual.
1. Tilt will not move.
a) For the 115 volt and 3 phase AC units:
• Check the power switch, fuses and overload as-
sociated with its electrical circuits.
• Check voltage at motor; motor may have failed.
2. Operational noises (tilter is very noisy)
a) Tilter may be overloaded or jammed. Check
load weights and obstructions.
b) For 115 volt AC motor, check voltage at terminal.
May have low voltage.
c) Oil shortage, reservoir low or oil line failure.
Repair or replace.
d) Down valve open, check wiring. Replace if
necessary.
3. Motor overheats:
a) Excessive cycling (15 cycles per hour maximum).
Check actual time in use.
b) Low voltage-check voltage of 120 volt motors.

OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series — Page 11
c) Oil starvation-check lter on the pump by removing
the coil stem from the pump. Note: do not overtighten
the stem when reinstalling.
4. Tilter operating slowly:
a) Up cycle:
• Oil starvation—check lter in reservoir.
Oil viscosity—oil is too heavy or too thin.
Air in cylinder—cycle tilter with no load 2 or 3 times
and hold down the up button for 10 seconds after
bottoming out on each cycle.
b) Down cycle:
• Down valve dirty—remove and clean. Check oil
condition; replace if dirty. Note: do not overtighten
the stem when reinstalling.
• Pinched hydraulic lines.
• Oil viscosity is too heavy.
5. Tilter raises, then fully lowers without power:
a) Down valve lter is dirty. Remove and clean. Note:
do not over torque when reinstalling down valve.
b) Leaking hydraulic lines or ttings (check for telltale
oil spots).
c) Check valve in pump, may not be seating properly.
Pump must be replaced.
6. Tilter will not lower when energized:
a) Down solenoid faulty. Check voltage of coil. Check
continuity of coil (could be burnt out).
b) Raise the lift to its maximum height.
c) Using only the chock assembly provided, place the
square tubing in the wheel tray sideways and adjacent
to the welded long lifting eye nut.
d) nsert the pin which is secured to the lift through the
holes provided in the wheel tray. Be sure the pin enters
both holes and through the center of the tubing.
e) Lower the lift until the wheels come in contact with
the chock and hold the “down” button for another 2
seconds.
f) Raise lift, remove and replace chock to its straight
position.

Page 12 — OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series
Figure 1: Hydraulic Schematic
Figure 2: Hydraulic Power Unit Wiring Diagram

OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series — Page 13
Figure 3: Electrical Schematic Pump Unit Single Phase 115 Volts AC

Page 14 — OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series
Figure 4: Electrical Schematic Pump Unit 1 Phase 208, 240 Volts AC
Table 1 – Hydraulic Oil Specications
If the lift will be used at normal ambient temperatures, Presto-ECOA Lifts supplies the unit with Conoco Super
Hydraulic 32 oil. This may be replaced by any other good quality oil with 150 SSU at 100° F and rust and
oxidation inhibitors and anti-wear properties.
If the lift will be used at ambient temperatures below 0°F, use aircraft hydraulic oil. Use Type 15 aircraft hydraulic
oil.
The following are equivalent to Conoco Super Hydraulic 32:
TYPE MANUFACTURER
AW32 ................................. CITGO
DTE 24 ............................. EXXON/MOBIL
NUTO H32 ........................ EXXON/MOBIL
AMOCO AW32 .................. CHEVRON (AMOCO CO.)
CAUTION!
It is very important to keep the hydraulic oil free of dirt,
dust, metal chips, water, and other contamination.
Most of the problems with hydraulic systems are caused by contamination in the oil.

OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series — Page 15
Figure 5: Labels and Locations

Page 16 — OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series
PARTS
Standard parts may be returned with a 20% restocking fee or $35.00 net, whichever
is greater. Modied or custom-engineered parts are not returnable. Unfortunately,
due to potentially concealed damage, all sales of electrical assemblies are nal.
QUALITY ISSUES
Should you feel there is a quality problem, please contact the seller to ask ques-
tions and gather information on how to rectify the issue. Presto-ECOA Lift reserves
the right to determine potential credits, as a result of factory defects, based on its
inspection of the merchandise.
GENERAL
All products shipped from our factory have passed Quality Assurance inspection and
testing. The carrier of choice has signed for, and accepted the product in new work-
ing condition. The customer should inspect to ensure it is not received damaged,
has no concealed damage or is not incomplete. Parts orders are determined to be
complete based upon Presto-ECOA inspection sheets and carrier shipping weights.

OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series — Page 17
Ordering Replacement Parts
Presto-ECOA Lifts has carefully chosen the components in your unit to be the best available for
the purpose. Replacement parts should be identical to the original equipment. Presto-ECOA
Lifts will not be responsible for equipment failures resulting from the use of incorrect replacement
parts or from unauthorized modications to the unit.
Presto-ECOA Lifts can supply all replacement parts for your lift. With your order, please include
the model number and the serial number of the unit. You can nd these numbers on the name
plate. This plate is located within the scissors mechanism.
To order replacement parts, please call the Presto-ECOA Parts Department. Parts are shipped
subject to the following terms:
• FOB factory
• Returns only with the approval of our parts department.
• Credit cards preferred (except parts covered by warranty).
• Freight collect for truck (except parts covered by warranty).
• Freight – prepaid and invoice for small parcel shipments (except parts covered
by warranty).
• The warranty for repair parts is 30 days from date of shipment.
Parts replaced under warranty are on a “charge-credit” basis. We will invoice you when we
ship the replacement part, then credit you when you return the worn or damaged part, and we
verify that it is covered by our warranty. Labor is not covered under warranty for Parts orders.
Presto-ECOA Parts Department
50 Commerce Way, Norton, MA 02766
Telephone: [phone]
FAX: [phone]
Email: [email protected]
www.PrestoLifts.com
www.ECOALifts.com

Page 18 — OWNER’S MANUAL: TT & WT and ECOA HTT & HUE Series
Presto-ECOA Lifts
Limited Warranty Policy
Presto-ECOA Lifts warrants all of its products against defects in the welded structural frame
and, if applicable, scissor legs from faulty material and workmanship for a period of ve years
from the date of invoice.
All other components have a limited warranty against defects in faulty material and workmanship
for a two year period from the date of invoice date of invoice and 30 day limited warranty on labor.
Please note that prior authorization from Presto-ECOA Lifts is required on all warranty work.
There are no implied warranties of any kind, more specically, there are no warranties of mer-
chantability or tness for any particular purpose. Presto-ECOA Lifts' sole warranty shall be as
set forth in this limited warranty.
Presto-ECOA Lifts will elect to repair or replace a defective component without charge, if any
components should become defective within the limited warranty period. Proof of purchase is
required for warranty. The charge for shipping the defective component is the responsibility of
the buyer and must be accompanied with an RMA number. The shipping charge to return the
component to the buyer is the responsibility of Presto-ECOA Lifts.
This limited warranty does not cover labor expense for removal or reinstallation of components
after thirty days. This limited warranty shall not cover, among other things: damages result-
ing from foreign matter or water, failure to provide reasonable and necessary maintenance,
and if applicable, use of product while charger is plugged into an AC outlet, or failure to follow
operating instructions. The limited warranty is not valid for damage resulting from negligence,
accident, unreasonable use, abuse or misuse, exceeding data plate capacities or altering the
product without Presto-ECOA Lifts authorization.
Presto-ECOA Lifts expressly disclaims and excludes any liability for consequential, incidental,
indirect or punitive damages or nancial loss to people or property resulting from any breach
of warranty or the operation or failure of this product.
Presto-ECOA Lifts makes no representation that this product complies with local, state, or fed-
eral safety/product standards codes. Should this product fail to comply in any way with those
codes, it shall not be considered a defect of materials or workmanship. Presto-ECOA Lifts shall
not be held liable for any damages resulting from noncompliance. It is the dealer's responsibil-
ity to exercise this limited warranty. This limited warranty is provided to the original purchaser
(dened as the original end user) and is nontransferable. This constitutes the complete and
nal agreement involving Presto-ECOA Lifts limited warranty obligations for products.
