PREVOST H3-45 User manual

FOREWORD
The PRÉVOST Motorcoach Owner's Manual has
been prepared to thoroughly acquaint you, the
owner, with vehicle equipment and features in
order to fully appreciate and safely enjoy your
vehicle. Of course, you are anxious to drive your
new private motorcoach and test its features, but
first please read this publication carefully to help
ensure enjoyable and trouble free operation.
This book should be kept inside the vehicle at all
times for convenient reference. It is also
suggested that it remains with the vehicle at the
time of resale. Please notify PRÉVOST CAR
INC. when the vehicle's ownership is transferred
so that our records can be kept up to date. Do
this by filling out the appropriate form at the end
of this manual.
The specifications, descriptions and figures
given are based on the latest information
available at printing time. And because at
PRÉVOST we are constantly striving to improve
our products, we reserve the right to make
changes at any time without notice and/or
obligation on our part.
Please note that this publication applies to
factory-prepared, conversion-ready luxury
motorcoaches, manufactured by PRÉVOST
CAR INC. It describes and explains the
equipment and options available for installation
in our factory. Therefore, there may be
equipment described herein that is not installed
on your vehicle. This publication also does not
cover equipment installed by your interior
designer or system manufacturer.
This manual, or portions thereof, cannot be
reproduced in any form whatsoever, in whole or
in part, without the written consent of PRÉVOST
CAR INC.
The following words are used to emphasize
particularly important information:
Warning : Identifies instructions which, if not
followed, could result in serious personal injury
or loss of life.
Caution :Denotes instructions which, if not
followed, could cause serious damage to vehicle
components.
Note : Indicates supplementary information
needed to fully understand and complete an
instruction.
For your own safety and to ensure prolonged
service life of your private motorcoach, heed our
cautions, warnings and notes. Ignoring them
could result in extensive damage and/or serious
personal injury.
Caution : Prior to working on a system
inside vehicle, make sure to cut electrical power
and air supply. A component could be supplied
with electricity even if battery master switch is
set to the OFF position and/or a component
could be pressurized even if air tanks are
emptied. Always refer to the appropriate wiring
and pneumatic diagrams prior to working on
electrical and/or pneumatic systems.
Prior to welding or soldering on the vehicle,
disconnect all electronic modules. If these
modules (ECM, ECU, ABS) are not
disconnected, electronic components (EPROM,
CHIPS) could be permanently damaged.
Refer to your maintenance manual for all related
procedures.
iv

TABLE OF CONTENTS
FOREWORD........................................................iii
SAFETY PRECAUTIONS....................................iv
MOTORCOACH EXTERIOR............................ 1-1
ENGINE COMPARTMENT COMPONENTS ...1-2
ENGINE COMPARTMENT R.H. SIDE DOOR.1-3
MAIN POWER COMPARTMENT.....................1-3
BAGGAGE COMPARTMENT........................... 1-4
FUEL FILLER DOOR......................................1-4
A/C CONDENSER DOOR................................1-4
ENTRANCE DOOR........................................... 1-4
EXTERIOR REAR VIEW MIRRORS................ 1-6
RETRACTABLE BACK-UP CAMERA..............1-7
ENGINE COMPARTMENT REAR DOOR .......1-7
110-120 VOLT CONNECTOR..........................1-8
RECLINING BUMPER COMPARTMENT........ 1-8
FRONT ELECTRIC & SERVICE
COMPARTMENT.............................................. 1-8
HVAC COMPARTMENT...................................1-8
REAR ELECTRIC COMPARTMENT................ 1-8
ENGINE RADIATOR DOOR.............................1-9
TRAILER HITCH............................................... 1-9
MOTORCOACH INTERIOR............................. 2-1
SEATS...............................................................2-1
Driver’s seat - “Delivery”.................................... 2-1
Driver’s and co-pilot’s seats – ISRI (optional)... 2-1
Electric ISRI seats .............................................2-2
Safety belts........................................................ 2-2
Sunshades (Blinds) ........................................... 2-3
Inside mirrors.....................................................2-3
Adjustable HVAC registers................................ 2-3
Driver’s power window....................................... 2-3
CONTROLS & INSTRUMENTS....................... 3-1
GENERAL INFORMATION............................... 3-2
Keys................................................................... 3-2
Battery master switch........................................ 3-2
Fuel tank filling................................................... 3-2
L.H. CONTROL PANEL....................................3-3
Transmission display.........................................3-3
Cruise control..................................................... 3-3
Driver’s power window switch ...........................3-4
Mirror controls (optional)....................................3-4
Level low system................................................3-4
Parking brakes control valve..............................3-5
Tag axle control valve........................................3-5
Colant heater timer.............................................3-5
Utility compartment ............................................3-6
Cigarette lighter..................................................3-6
Ashtray ...............................................................3-6
Diagnostic data reader (DDR) receptable.........3-6
DASHBOARD ....................................................3-6
L.H.DASHBOARD PANEL........................................3-6
Control switches.................................................3-6
Ignition switch...................................................3-10
Air register........................................................3-10
CENTER DASHBOARD PANEL ...............................3-10
Message center display (MCD) .......................3-10
Telltale panel....................................................3-11
Gauges.............................................................3-14
Vehicle clearance information..........................3-15
R.H.DASHBOARD PANEL .....................................3-15
Control switches...............................................3-15
HVAC control unit.............................................3-16
Air registers ......................................................3-17
Dashboard compartments...............................3-17
STEERING COLUMN CONTROLS................3-17
Multi-function lever...........................................3-17
Transmission output retarder...........................3-18
Horns................................................................3-19
FOOT-OPERATED CONTROLS....................3-19
Service brakes .................................................3-19
Accelerator pedal.............................................3-19
Steering wheel adjustment unlock air valve....3-20
AUTOMATIC TRANSMISSION.......................3-20
Range selection – push button shifter .............3-20
Oil level display mode (optional)......................3-21
Operation..........................................................3-21
OTHER FEATURES..........................................4-1
DETROIT DIESEL ELECTRONIC CONTROL
(DDEC) SYSTEM..............................................4-1
DDEC IV ELECTRONIC CONTROL MODULE
(ECM).................................................................4-2
MESSAGE CENTER DISPLAY (MCD)............4-2
GAUGE MODE...................................................4-3
FUEL ECONOMY MODE......................................4-3
CLOCK /DIST MODE..........................................4-4
SETTING THE DIGITAL CLOCK ............................4-4
REMINDER ALARM.............................................4-4
i

TABLE OF CONTENTS
TRIP ODOMETERS .............................................4-4
AVERAGE SPEED...............................................4-4
FAULT MESSAGES.............................................4-5
SET-UP MODE ..................................................4-5
Language Selection..........................................4-5
Metric or Standard Units....................................4-5
Clock Format..................................................... 4-5
Setting Contrast.................................................4-5
Setting Backlight................................................4-6
Setting Night Display .........................................4-6
Setting Default Language.................................. 4-6
Setting Fleet Fuel Target................................... 4-6
Setting the Odometer.......................................4-7
DIAGNOSTIC MODE......................................4-7
ECU Diagnostic................................................. 4-7
Cluster Self Test................................................ 4-7
ECU Data........................................................... 4-8
ECU Status Test..............................................4-8
DATA LOG MODE..........................................4-9
PASSWORDS.................................................4-9
Password Input .................................................4-9
Changing passwords......................................4-10
PRODRIVER™ .............................................4-10
WORLD TRANSMISSION ELECTRONIC
CONTROL UNIT (ECU)................................4-10
TRANSMISSION RETARDER......................4-11
JACOBS ENGINE BRAKE ...........................4-11
ANTI-LOCK BRAKING SYSTEM .................4-11
RETRACTABLE TAG AXLE.........................4-12
TAG LOAD RELEASE SYSTEM (TLR)........4-12
COOLANT HEATER.....................................4-12
SWITCHING THE HEATER ON...........................4-12
SWITCHING THE HEATER OFF..........................4-13
COOLANT HEATER TIMER ................................4-13
Timer Operating Instructions (Espar)............4-13
Timer Operating Instructions (Webasto).........4-15
Timer operating instructions (Webasto).......... 4-16
Viewing the Time (Ignition ON) .......................4-16
Troubleshooting and Maintenance..................4-17
110-120 VOLT CONNECTOR......................4-17
KEYLESS ENTRY SYSTEM.........................4-18
KEYLESS OPERATING INSTRUCTIONS ...............4-18
PROGRAMMING APERSONAL CODE .................4-18
REMOTE ENTRY TRANSMITTER ........................4-19
Programming Transmitters ...........................4-19
STARTING AND STOPPING PROCEDURES 5-1
STARTING ENGINEFROM DRIVER’S
COMPARTMENT ............................................. 5-1
Starting engine................................................... 5-1
Stopping engine.................................................5-1
STARTING FROM THE ENGINE
COMPARTMENT.............................................. 5-1
Starting engine................................................... 5-2
Stopping engine.................................................5-2
COLD WEATHERSTARTING..........................5-2
Cold starting aid (ether)......................................5-2
Engine block heater ...........................................5-2
Engine warm-up.................................................5-3
World Transmission (WT) warm-up..................5-3
JUMP STARTING..............................................5-3
EMERGENCY FEATURES AND
SAFETY EQUIPMENT......................................6-1
EMERGENCYFEATURES ...............................6-1
Sliding type window............................................6-1
Hinged type window...........................................6-1
Emergency roof escape.....................................6-1
Emergency air-fill valves....................................6-2
Emergency and parking brakes.........................6-3
SAFETYEQUIPMENT.......................................6-3
Fire extinguishers...............................................6-3
First aid kit..........................................................6-3
Emergency warning reflectors ...........................6-3
Jack/Tools..........................................................6-3
Daytime running lights........................................6-3
Fog lights............................................................6-4
Cornering lights..................................................6-4
Compartment lighting.........................................6-4
Mud flaps and splash guards.............................6-4
Back-up camera.................................................6-4
Back-up alarm....................................................6-4
Back-up alarm override......................................6-4
Alarm system .....................................................6-5
Spare parts kit....................................................6-5
CARE AND MAINTENANCE ............................7-1
CLEANING.........................................................7-1
Interior cleaning..................................................7-1
Exterior cleaning.................................................7-2
OIL LEVEL VERIFICATION...............................7-3
Engine oil level ...................................................7-3
Automatic transmission oil level.........................7-4
Power steering fluid level...................................7-5
Radiator fan gearbox oil level ............................7-5
Wheel bearing oil level.......................................7-6
OTHER VERIFICATIONS..................................7-6
Coolant level check............................................7-6
Air tank purge.....................................................7-6
Fire extinguishers...............................................7-7
Water separator.................................................7-7
Belt tension adjustment......................................7-7
Back-up camera.................................................7-8
Air filter restriction indicator................................7-8
A/C and heating system air filters......................7-9
Driver’s area filters .............................................7-9
Cabin system air filter.........................................7-9
Flexible hose inspection.....................................7-9
ii

TABLE OF CONTENTS
Windshield washer tank ....................................7-9
Lubrication .......................................................7-10
PRE-STARTING INSPECTION......................7-10
With engine stopped........................................ 7-10
With engine running ........................................7-13
FIRST SERVICE ON NEW MOTORCOACH.7-14
GENERAL RECOMMENDATIONS................7-14
WALK-AROUND INSPECTION
(BEFORE EVERYTRIP).................................7-16
LUBRICATION AND SERVICING
SCHEDULE.....................................................7-17
LUBRICANT SPECIFICATIONS..................... 7-20
PART NUMBER SPECIFICATIONS...............7-21
TECHNICAL INFORMATION........................... 8-1
DIMENSIONS....................................................8-1
WEIGHT............................................................ 8-1
CAPACITIES.....................................................8-1
FUEL TYPE....................................................... 8-1
WHEELS AND TIRES.......................................8-1
BELTS................................................................ 8-2
ENGINE.............................................................8-2
TRANSMISSION............................................... 8-2
DRIVE AXLE......................................................8-2
BRAKES............................................................ 8-2
ANTI-LOCK BRAKING SYSTEM (ABS)........... 8-2
STEERING ........................................................ 8-3
ELECTRICAL SYSTEM ....................................8-3
SUSPENSION................................................... 8-3
ALIGNMENT...................................................... 8-3
HEATING AND AIR CONDITIONING ..............8-3
Driver’s system..................................................8-3
Central system................................................... 8-3
Compressor....................................................... 8-3
OIL SPECIFICATIONS ..................................... 8-4
Engine................................................................ 8-4
Automatic transmission.....................................8-4
Differential..........................................................8-4
Fan gearbox....................................................... 8-4
Power steering reservoir....................................8-4
Wheel bearings..................................................8-4
PRE-HEATING SYSTEM (OPTIONAL)............ 8-4
Webasto ............................................................8-4
DDEC IV DIAGNOSTIC CODES.......................8-4
Reading codes...................................................8-4
WORLD TRANSMISSION (WT) DIAGNOSTIC
CODES...............................................................8-7
Diagnostic code memory list (WT) ....................8-7
Clearing the active indicator and code records
from the code list in memory..............................8-8
Code reading and code clearing procedures ....8-8
Diagnostic code response .................................8-9
Diagnostic code list and description ................8-10
Oil level sensor (OLS) codes...........................8-17
Exiting the oil level display mode.....................8-17
LIGHT BULB DATA .........................................8-18
PLATES AND CERTIFICATION .....................8-18
Data plates.......................................................8-19
Vehicle identification number (VIN) .................8-19
Safety certification............................................8-20
COACH FINAL RECORD..................................8-4
APPENDIX
SERVICE LITERATURE.......................................1
NOTICE.................................................................2
INDEX ...................................................................3
iii

SAFETY PRECAUTIONS
To ensure safe and reliable operation, take note
of the safety precautions as follows:
a) Operation and maintenance of the
motorcoach must be performed only by
qualified personnel.
b) Before driving, conduct a walkaround
inspection to check for security of all
baggage compartment doors and equipment
access doors.
c) Make sure good visibility is maintained at all
times. Keep windshields clean and free of
obstructions.
d) Adjust the driver's seat so that all controls
can be reached easily.
e) Always wear the safety belt when driving.
f) Check the instrument panel frequently. Do
not operate the motorcoach when dials or
indicators are not in the normal operating
condition.
g) Always pay attention to pedestrians passing
in front and behind the vehicle. Always yield
to pedestrians at pedestrian walkways.
h) Do not drive over obstacles on the road.
Empty cartons, piles of leaves, and
snowdrifts could conceal hidden dangers
that could damage the motorcoach
suspension and underbody.
i) When turning or changing lanes, signal your
intention well in advance.
j) When approaching to make a right turn,
reduce the space between the motorcoach
and the curb to make sure another vehicle
cannot pass on the right. Since the
motorcoach makes wide turns, allow enough
space to make safe turns.
k) Switch from high beams to low beams when
meeting or following other vehicles within
500 feet (150 meters).
l) Never leave the motorcoach unattended
with the engine running, or with the key in
the ignition. Turn off the engine, remove
keys and apply the parking brake before
leaving the vehicle.
m) Shut-off the engine before refueling, adding
oil or performing maintenance or servicing
tasks, unless stated otherwise.
n) Fuel is highly flammable and explosive. Do
not smoke when refueling. Keep away from
open flames or sparks.
o) Do not run the engine or HVAC system with
access doors left open. Close compartment
doors before operating any equipment.
p) Do not remove the surge tank filler cap or
the cooling system pressure cap when the
engine is hot. Let the engine cool down
before removing filler caps.
q) Do not attempt to push or pull-start a
motorcoach equipped with an automatic
transmission.
r) The service life of the motorcoach depends
on the kind of maintenance it receives.
Always record any problems and report
them immediately to maintenance
personnel.
s) Do not use the trailer hitch before reading
the safety, technical and operational
requirements on page 1-9 of this manual.
t) For additional information about safe driving
practices, contact the local department of
motor vehicles authority.
Defensive driving
a) For city driving, allow a four to six second
travel interval between the motorcoach and
the vehicle ahead. Increase this travel
interval to six to eight seconds for highway
driving. Use increased travel interval for
night driving and in bad weather.
b) Be prepared to stop when approaching an
intersection. The stopping distance of the
motorcoach increases with the weight and
speed of the vehicle.
c) Establish eye-to-eye contact with other
drivers and with pedestrians. Use
headlights, high beams and low beams, turn
signals and horn as needed.
v

SAFETY PRECAUTIONS
d) On highway, don't stare at the road ahead.
Keep your eyes moving. Check all mirrors
and dashboard instruments frequently.
e) To keep the motorcoach from drifting across
lanes during highway driving, always look
over the horizon on the road ahead.
f) Adjust your speed according to the road
conditions, traffic and visibility. Never
exceed the posted speed limits.
g) Reduce your speed if another vehicle is
following too close behind to let the vehicle
pass.
h) For additional information about defensive
driving practices, contact the local
department of motor vehicles authority.
vi

CHAPTER 1 : MOTORCOACH EXTERIOR
H3-45 MOTORCOACH
H3-45 MOTORCOACH EXTERIOR VIEW
1-1

MOTORCOACH EXTERIOR
ENGINE COMPARTMENT COMPONENTS
01039
1. Coolant surge tank
10. Radiator fan gearbox
2. Air cleaner restriction indicator
11. Engine coolant filter/conditioner
3. Transmission oil dipstick
12. Engine oil filters
4. Engine oil dipstick
13. Steering pump
5. Starter selector switch
14. Primary and secondary fuel filters
6. Belt tensioner control valve
7. Rear start push-button switch
15. Alternators
16. A/C compressor
8. Engine oil reserve tank
17. Prime pump switch
9. Radiator
18. Back-up alarm
1-2

MOTORCOACH EXTERIOR
ENGINE COMPARTMENT R.H.
SIDE DOOR
The engine compartment R.H. side door
provides access to the following:
•Engine compartment rear door release lever;
•Fuel filter/water separator (if applicable);
•Power steering fluid reservoir;
•Wet (main) air tank drain valve;
•External air supply fill valve;
•Cold weather starting fluid bottle;
•A/C Compressor.
This door can be locked/unlocked using the
exterior compartment key. Lift up protector cover
to gain access to the lock. Pull up the door
handle to release the latch, then pull the door
open. To keep the door open, engage the safety
catch on top of the door. Release the safety
catch before closing the door.
18184
The lighting in the engine compartment turns ON
automatically when the door is opened. If the
compartment door is open, a telltale light will
illuminate on the central dashboard.
Warning: Do not run the engine when the
engine R.H. side compartment door is open.
Close engine R.H. side compartment door
before starting engine.
MAIN POWER COMPARTMENT
The main power compartment provides access
to the following:
•Battery voltage equalizer;
•Battery voltage equalizer monitor;
•Four (4) 12 volts batteries;
•Main breakers for the 12 volt and 24 volt
electrical systems;
•Main power cut-off relay;
•Booster posts.
MAIN POWER COMPARTMENT
The compartment door can be locked/unlocked
using the exterior compartment key. Turn the key
in the lock to remove.
The lighting in the compartment turns ON
automatically when the door is opened. If the
main power compartment door is open, a telltale
light will illuminate on the central dashboard.
1-3

MOTORCOACH EXTERIOR
BAGGAGE COMPARTMENT
The baggage compartment doors can be locked/
unlocked using the exterior compartment key.
Lift up the cover to gain access to the lock. Pull
up door handle to release the latch, then pull the
door open. Refer to the illustration under
"Engine Compartment R.H. Side Door" in this
chapter. Pressurized cylinders assist the
opening and closing of the baggage
compartment doors and hold the doors open.
The lighting in the baggage compartment turns
ON automatically when the door is opened. If
the baggage compartment door is open, an
indicator light will illuminate on the central
dashboard.
Warning : To avoid injury, keep hands
clear of baggage compartment door edge and
door frame when closing.
Note : To prevent theft and vandalism,
always lock the baggage compartment doors
before leaving the motorcoach unattended.
Note : The baggage compartment doors
can be locked/unlocked from the driver's position
by an optional central locking system on the L.H.
control panel. Refer to "Controls & Instruments"
chapter.
FUEL FILLER DOOR
Both fuel filler doors can be locked/unlocked
using the exterior compartment key. Turn the key
in the lock to remove.
Note : The L.H. fuel filler door lock must be
in the unlocked position before closing.
A/C CONDENSER DOOR
Pull the A/C condenser door release latch located
inside the adjacent baggage compartment to
partly open the condenser door. Push on the
safety hook, accessible through the opening, to
open the door.
CONDENSER DOOR
ENTRANCE DOOR
Inside Operation
There are two ways of unlocking the entrance
door from the inside. The first consists in
actuating the rocker switch on the lower R.H.
control panel. This operation will also unlock the
baggage compartment. Also, you can unlock the
entrance door by sliding its lock lever to the left.
If the orange tab on the door lock lever is visible,
the door is unlocked.
18187
Outside Operation
The first way of locking/unlocking the entrance
door from the outside is the front entrance door
lock key provided with the vehicle. Turn key to
the left to lock or to the right to unlock the
entrance door.
1-4
